Thank you for purchasing our product.
MODEL RTA-4833D
ASSEMBLY INSTRUCTIONS
REV.072021-0

•Please read carefully the assembly instructions
before the installation.
•Do not discard this manual or any of the packaging
material until the unit has been completely
assembled.
•Might require two people.
P. 1 RTA-4833D P. 1

P. 2 RTA-4833D P. 2
1
x1
3
x1
Left structure Main structure
MAIN PARTS LIST
4
x1
5
x1
Upper back structure Lower back structure
6
x1
Left panel 8
x1
Upper shelf panel
9
x1
Upper back panel 10
x1
Lower shelf panel
11
x1
14
x4
Main glass panel
Glide studs
12
x1
13
x1
Left support Right support
2
x1
Right structure
7
x1
Right panel
Upper back structure
Left panel
Right panel
x1
x1
Right support

P. 3 RTA-4833D P. 3
LIST OF HARDWARE, SCREWS AND FITTINGS
PART QTY ITEM
A13 M6x40 (bolt)
B8M6x15
C10 M6x30
D6M6x50
E2ST5x45
1Allen
Wrench
1Screwdriver
MAIN PARTS LAYOUT (FOR REFERENCE):

P. 4 RTA-4833D P. 4
☛
☛
This unit uses cam bolts and locks. The following explains how to use them.
☛
☛
This unit uses cam bolts and locks. The following explains how to use them.
This unit uses cam bolts and locks. The following explains how to use them.
This is not an assembly step; it is a guide for when you are actually doing the
This is not an assembly step; it is a guide for when you are actually doing t
assembly using this kind of hardware.
Cam Bolt Cam Lock
1. Screw the bolt into the
corresponding panel.
2. Place the other panel over the
panel with the bolt, then insert the
cam lock to join the bolt’s head.
If the cam lock does not want to
enter, check its proper alignment.
There might be a very small gap
between the panels which is normal.
3. Turn the cam lock clockwise. This
will lock the parts together and will
close any gaps.
Alignment: The cross
points towards the panel
with the bolt.

BEFORE YOU START THE ASSEMBLY, PLEASE READ THE FOLLOWING TIPS AND WARNINGS.
❶Do aquick inventory
to make sure the package
contains all the parts and
hardware listed in the
assembly instructions.
❷Missing, damaged
and defective parts can
be replaced at no cost
to you. Please refer to
the last pages on this
manual.
❹If during assembly
you find an issue or
need clarification, please
contact our Customer
Service for assistance.
Please refer to the last
pages on this manual.
❺On each step read the
instructions and analyze
the illustrations thoroughly
before proceeding to do the
assembly.
❽Do not overtighten
or force the screws as
they might break, strip,
damage the threads of
the holes or get stuck
inside the part.
❻Make sure you
understand which
hardware will be used on
each step.Using the
wrong size of screw, bolt
or pin might strip the
threads or cause damage
to the part in which it is
being used.
❼To avoid
misalignments, always
leave the screws loose
and tighten them until
all pieces are
positioned correctly.
❾Sometimes the laminate might cover
partially or entirely the hole on apanel.If there
is no visible hole for the screw, pass and press
the tip of your finger over the area where the
hole should be located to feel the indentation,
and once found, carefully pierce the laminate to
reveal the hole underneath.
❿If the hole seems too small for the screw,
first make sure you are using the correct size of
screw and that it’s been installed in the correct
hole.If the hole still appears to be too small,
carefully pierce the laminate to reveal the
hole’s actual size.
P. 5 RTA-4833D P. 5
❸The replacement parts
service is limited to the
48 contiguous United States.
If you reside in Alaska,
Hawaii, Puerto Rico,
U.S. territories or other
countries, please contact the
supplier from where the unit
was purchased.

ASSEMBLY STEPS
Insert the glide studs 14 into the bottom threaded holes of the right and
left structures 1and 2.
STEP 1
Hardware:
14 4
Pcs
P. 6 RTA-4833D P. 6
With the help of another person, and using screws C, assemble between
the structures 1and 2:
•The lower back structure 5.The screws go from the inside, through 5
and into 1, 2.
•The Main structure 3,but make sure the big holes go at the back and
facing UP. The screws go from the inside, through 3and into 1, 2.
2
1
STEP 2
Hardware:
C
M6x30
8
Pcs
2
1
1
2
5
3
The big holes must face UP
(Back)

P. 7 RTA-4833D P. 7
•Assemble the left support 12 to the structures 1and 3 with screws B.
•Assemble the right support 13 to the structures 2and 3 with screws B.
•Please note that the supports are not interchangeable.
With the help of another person, assemble the Upper back structure 4to
the main structure 3with screws C.
STEP 3
Hardware:
B
M6x15
4
Pcs
STEP 4
Hardware:
C
M6x30
2
Pcs
3
1
2
12
13
(Back)
3
4
Install the bolts Ainto the indicated holes on panels 6and 7as shown.
STEP 5
Hardware:
AM6x40
(bolt)
6
Pcs
67
LEFT
RIGHT

P. 8 RTA-4833D P. 8
With the help of another person, place the frame on the floor laying down
on its back, and assemble the Right panel 7to the left structure 2and
the Upper back structure 4with screws D. The screws go from inside
through the structure and into the panel.
Join the Upper back panel 9to the top bolt on panel 7and turn the cam
lock to lock the pieces as shown and as explained in page 4. Please pay
attention that the set of 3 holes on the profile of the panel must face
towards the TOP.
STEP 6
Hardware:
D
M6x50
3
Pcs
STEP 7
Hardware:
(Top)
(Bottom)
The 3 holes
coming from the
cam locks face UP
7
9
7
2
4

P. 9 RTA-4833D P. 9
Attach the Lower shelf panel 10 to the 2 bottom bolts on the Right panel
7making sure the cam locks face towards the BOTTOM and the 2 small
holes on the long profile align with the holes on the frame, as those
holes are intended for the screws on step 10. Then turn the cam locks to
lock the pieces as explained in page 4.
•Join the Left panel 6to panels 9and 10 and lock the pieces by turning
the cam locks as explained in page 4.
•Secure the panel 6to the structure 1with screws D.
STEP 8
Hardware:
STEP 9
Hardware:
D
M6x50
3
Pcs
(Top)
The back of panel 10
has 2 holes for
screws in step 10.
7
10
9
10
1
6
