Ruckus Wireless ZoneFlex 7982 User manual

Ruckus Wireless™ZoneFlex™
Indoor Access Point
Release 9.5 User Guide
For the following indoor ZoneFlex AP models:
■ZoneFlex 7982 Dual Band 802.11n Smart Wi-Fi Access Point
■ZoneFlex 7962 Dual Band 802.11n Smart Wi-Fi Access Point
■ZoneFlex 7363 Dual Band 802.11n Smart Wi-Fi Access Point
■ZoneFlex 7343 802.11n Smart Wi-Fi Access Point
■ZoneFlex 7341 802.11n Smart Wi-Fi Access Point
■ZoneFlex 7321 2.4/5GHz 802.11n Smart Wi-Fi Access Point
■ZoneFlex 2942 802.11g Smart Wi-Fi Access Point
■ZoneFlex 7025 802.11n Wired/Wireless Wi-Fi Wall Switch
Part Number 800-70413-001
Published October 2012
www.ruckuswireless.com

i
About This Guide
Document Conventions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . i
Related Documentation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .ii
Documentation Feedback . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .ii
1 Introducing the ZoneFlex Access Point
Overview of the ZoneFlex Access Point. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
Unpacking the ZoneFlex Access Point . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
Package Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Getting to Know the Access Point Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
ZoneFlex 7982 Access Point . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
ZoneFlex 7962 Access Point . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
ZoneFlex 7363 Access Point . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
ZoneFlex 7343 Access Point . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
ZoneFlex 7341 Access Point . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
ZoneFlex 7321 Access Point . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
ZoneFlex 2942 Access Point . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
ZoneFlex 7025 Wired/Wireless Wall Switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
2 Installing the Access Point
Before You Begin . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .35
Prepare the Required Hardware and Tools . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Perform a Site Survey . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Determine the Optimal Mounting Location and Orientation . . . . . . . . . . . . . . . 37
Step 1: Preconfigure the Access Point . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .42
Configuring for Management by ZoneDirector . . . . . . . . . . . . . . . . . . . . . . . . . . 42
Configuring for Standalone Operation or for Management by FlexMaster . . . . 42
Step 2: Verify Access Point Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .50
Connect the Access Point to the Network . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
Associate a Wireless Client with the Access Point . . . . . . . . . . . . . . . . . . . . . . . . 50
Check the LEDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
Contents

ii
Check the TR069 Status (FlexMaster Management Only) . . . . . . . . . . . . . . . . . . 51
Disconnect the Access Point from the Network . . . . . . . . . . . . . . . . . . . . . . . . . . 52
Step 3: Deploy the Access Point. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .52
1. Choose a Location for the Access Point . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
2. Connect the Access Point to a Power Source and the Network . . . . . . . . . . . 53
Troubleshooting Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .53
ZoneFlex 7025 Physical Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .54
Using the 110 Punch down Block . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
3 Navigating the Web Interface
Logging Into the ZoneFlex Web Interface. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .57
Navigating the Web Interface. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .58
If You Are Using a Dual Band ZoneFlex Access Point. . . . . . . . . . . . . . . . . . . . . . . . .59
4 Configuring the Access Point
Configuring Device Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .62
Configuring Internet Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .64
VLAN Settings Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64
Configuring NTP Server and Management VLAN . . . . . . . . . . . . . . . . . . . . . . . . 65
Default IP Addressing Behavior . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65
Obtaining and Assigning an IP Address . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66
Configuring L2TP Connection Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68
Configuring Local Subnets . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .70
Configuring Wireless Settings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .71
Configuring Common Wireless Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71
Configuring Wireless # Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 78
Configuring Ethernet Ports . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .92
Setting Ethernet Port Type . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 95
Working with Port-Based VLANs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 96
Working with 802.1X on Wired Ethernet Ports . . . . . . . . . . . . . . . . . . . . . . . . . . . 96
Configuring Hotspot Service. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .97
Customizing Hotspot Optional Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 99
Creating a Hotspot Walled Garden . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 101
Allowing Unrestricted Access by MAC Address . . . . . . . . . . . . . . . . . . . . . . . . . 102

iii
5 Managing the Access Point
Viewing Current Device Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .106
Viewing Current Internet Connection Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . .107
Viewing Current Local Subnet Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .108
Viewing Current Wireless Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .109
Viewing Associated Wireless Clients . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .110
Changing the Administrative Login Settings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .111
Enabling Other Management Access Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . .112
Viewing FlexMaster Management Status . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 116
Pointing the AP to FlexMaster . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 117
Working with Event Logs and Syslog Servers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .118
Enabling Logging and Sending Event Logs to a Syslog Server . . . . . . . . . . . . . 118
Sending a Copy of the Log File to Ruckus Wireless Support . . . . . . . . . . . . . . . 119
Saving a Copy of the Current Log to Your Computer . . . . . . . . . . . . . . . . . . . . 119
Upgrading the Firmware . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .120
Upgrading Manually via FTP or TFTP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 120
Upgrading Manually via the Web . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 121
Upgrading Manually via Local File . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 121
Scheduling Automatic Upgrades . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 121
Rebooting the Access Point . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .122
Resetting the Access Point to Factory Defaults. . . . . . . . . . . . . . . . . . . . . . . . . . . . .123
Running Diagnostics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .124
Where to Find More Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .126
Index

iv

i
About This Guide
About This Guide
This guide describes how to install, configure, and manage the Ruckus Wireless™
ZoneFlex™Access Point. This guide is written for those responsible for installing and
managing network equipment. Consequently, it assumes that the reader has basic
working knowledge of local area networking, wireless networking, and wireless
devices.
NOTE: If release notes are shipped with your product and the information there
differs from the information in this guide, follow the instructions in the release notes.
Most user guides and release notes are available in Adobe Acrobat Reader Portable
Document Format (PDF) or HTML on the Ruckus Wireless Support Web site at:
http://support.ruckuswireless.com/
Document Conventions
Tabl e 1 and Tab le 2 list the text and notice conventions that are used throughout this
guide.
Tabl e 1. Text C onve n tions
Convention Description Example
monospace Represents information as it
appears on screen
[Device name]>
monospace bold Representsinformation that
you enter
[Device name]> set
ipaddr 10.0.0.12
default font bold Keyboard keys, software
buttons, and field names
On the Start menu, click All
Programs.
italics
Screen or page names Click Advanced Settings.
The Advanced Settings page
appears.

ii
About This Guide
Related Documentation
In addition to this User Guide, each ZoneFlex Access Point documentation set
includes the following:
■Quick Start Guide: Provides essential installation and configuration information to
help you get the AP up and running within minutes.
■Online Help: Provides instructions for performing tasks using the Access Point’s
Web interface. The online help is accessible from within the Web interface.
■Release Notes: Provide information about the current software release, including
new features, enhancements, and known issues.
NOTE: If you will be managing your ZoneFlex Access Points using ZoneDirector, refer
to the ZoneDirector User Guide (available from the Ruckus Wireless website).
Documentation Feedback
Ruckus Wireless is interested in improving its documentation and welcomes your
comments and suggestions. You can email your comments to Ruckus Wireless at:
[email protected]
When contacting us, please include the following information:
■Document title
■Document part number (on the cover page)
■Page number (if appropriate)
For example:
■Ruckus Wireless ZoneFlex Indoor Access Point Release 9.5 User Guide
■Part number: 800-70413-001
■Page 88
Table 2. Notice Conventions
Icon Notice Type Description
Information Information that describes
important features or
instructions
Caution Information that alerts you to
potential loss of data or
potential damage to an
application, system, or device
Warning Information that alerts you to
potential personal injury

1
1
Introducing the ZoneFlex Access
Point
Overview of the ZoneFlex Access Point
Congratulations on your purchase of the Ruckus Wireless ZoneFlex Access Point!
ZoneFlex Access Points are the industry’s most easy to use, yet robust and feature-
rich Wi-Fi Access Points designed to bring power and simplicity together for large-
scale indoor deployments.
Your ZoneFlex Access Point uses BeamFlex™, a patented antenna technology from
Ruckus Wireless that allows wireless signals to navigate around interference, extend
wireless signal range, and increase speeds and capacity for wireless networks. The
BeamFlex™ antenna system consists of an array of high-gain directional antenna
elements that allow ZoneFlex Access Points to find quality signal paths in a changing
environment, and sustain the baseline performance required for supporting data,
audio and video applications.
Your ZoneFlex Access Point can be deployed in standalone mode or as part of the
ZoneFlex Smart WLAN system, in which it can be managed by either FlexMaster or
ZoneDirector WLAN controller.
NOTE: For more information on the ZoneFlex system (including FlexMaster and
ZoneDirector), BeamFlex, and other Ruckus Wireless technologies, visit
www.ruckuswireless.com.
In This Chapter
Overview of the ZoneFlex Access Point . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
Unpacking the ZoneFlex Access Point . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
Getting to Know the Access Point Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2

2
Introducing the ZoneFlex Access Point
Unpacking the ZoneFlex Access Point
Unpacking the ZoneFlex Access Point
1. Open the Access Point package, and then carefully remove the contents.
2. Return all packing materials to the shipping box, and put the box away in a dry
location.
3. Verify that all items listed in Package Contents below are included in the package.
Check each item for damage. If any item is damaged or missing, notify your
authorized Ruckus Wireless sales representative.
Package Contents
A complete Access Point package contains all of the items listed below:
■ZoneFlex Access Point
■Software License Agreement/Product Warranty Statement
■Quick Setup Guide
■(Ethernet cables, power adapters and mounting kits are optional accessories that
may or may not be included depending on the SKU purchased)
Getting to Know the Access Point Features
This section identifies the physical features of each ZoneFlex Access Point model that
is discussed in this guide. Before you begin the installation process, Ruckus Wireless
recommends that you become familiar with these features.
■ZoneFlex 7982 Access Point
■ZoneFlex 7962 Access Point
■ZoneFlex 7363 Access Point
■ZoneFlex 7343 Access Point
■ZoneFlex 7341 Access Point
■ZoneFlex 7321 Access Point
■ZoneFlex 2942 Access Point
■ZoneFlex 7025 Wired/Wireless Wall Switch
NOTE: This User Guide does not include information on ZoneFlex Outdoor Access
Points or the ZoneFlex 7731 Wireless Bridge. For information on those ZoneFlex
models (along with Ruckus Wireless MediaFlex and MetroFlex product lines), refer to
their respective documentation available from support.ruckuswireless.com.

3
Introducing the ZoneFlex Access Point
Getting to Know the Access Point Features
ZoneFlex 7982 Access Point
ZoneFlex 7982 features five LEDs on its front panel and buttons and connectors on
its rear panel.
Front Panel
Figure 1 shows the top view of the ZoneFlex 7982. For a description of each front
panel part, refer to Table 3.
Figure 1. ZoneFlex 7982 top view
Table 3. ZoneFlex 7982 front panel elements
LED Description
Power LED • Off: Off.
•Red: Boot up in process.
•Green: On.
DIR LED • Off: The AP is not being managed by
ZoneDirector (standalone mode).
•Green: The AP is being managed by
ZoneDirector.
•Slow flashing green (one flash every two
seconds): The AP is being managed by
ZoneDirector, but is currently unable to
communicate with ZoneDirector.
•Fast flashing green (two flashes every second):
The AP is being managed by ZoneDirector and
is currently receiving configuration settings
(provisioning) or a firmware update.

4
Introducing the ZoneFlex Access Point
Getting to Know the Access Point Features
AIR LED • Off: The Access Point is operating as a
Standalone or RootAP.
•Green: The AP is functioning as a Mesh AP
(MAP), and the wireless signal to its uplink AP
is good.
•Fast flashing green (two flashes every second):
The AP is functioning as a Mesh AP (MAP), and
the wireless signal to its uplink AP is fair.
•Slow flashing green (one flash every two
seconds): Mesh networking is enabled, but the
AP is still searching for a mesh uplink.
2.4GHz LED • Off: The WLAN service is down.
•Green: The WLAN is up and at least one client
is associated.
•Amber: The WLAN is up. No clients are
associated.
5GHz LED • Off: The WLAN service is down.
•Amber: The WLAN is up, but no clients or
downlink MAPs are associated/connected.
•Green: The WLAN is up and at least one client
is associated. No downlink MAPs are
connected.
•Slow flashing green (one flash every two
seconds): The WLAN is up and at least one
downlink MAP is connected. No clients are
associated.
•Fast flashing green (two flashes every second):
The WLAN is up, at least one downlink MAP is
connected, and at least one client is
associated.
Table 3. ZoneFlex 7982 front panel elements
LED Description

5
Introducing the ZoneFlex Access Point
Getting to Know the Access Point Features
Rear Panel
Figure 2 shows the rear panel of the ZoneFlex 7982. For a description of each rear
panel part, refer to Table 4.
Figure 2. ZoneFlex 7982 rear panel
Table 4. ZoneFlex 7982 rear panel elements
Number Item Name Description
1 10/100/1000 Port One RJ-45 port for a 10/100/1000 connection
2 10/100/1000 PoE
Port
One RJ-45 port for a 10/100/1000 PoE (Power over
Ethernet, 802.3af) connection
3 Power Connect the power adapter (12 VDC/1.25A) to this
socket. Power can also be supplied via the 10/100/
1000 PoE port.
4 RESET Button Pressing, and then quickly releasing this internal
button reboots the AP. Pressing and holding it for
six seconds resets the AP to factory default settings.
CAUTION! Resetting the AP to factory default
settings will erase all settings that you configured
previously.
234
1

6
Introducing the ZoneFlex Access Point
Getting to Know the Access Point Features
WARNING: For units with Power over Ethernet (PoE). These products and all inter-
connected equipment must be installed indoors within the same building, including
the associated LAN connections, as defined by Environment A of the IEEE 802.3af
Standard.
Table 5. Behavior of Ethernet port LEDs on ZoneFlex 7982
LEDs Description
Off Not connected
Amber + Green Connected to 10Mbps device
Amber Connected to 100Mbps device
Green Connected to 1000Mbps device

7
Introducing the ZoneFlex Access Point
Getting to Know the Access Point Features
ZoneFlex 7962 Access Point
The side panel of ZoneFlex 7962 features four LED indicators that can be used to
assess both device and network status. The rear view displays the connector panel,
which includes the LAN ports and power adapter connector. Refer to the following
illustrations and tables to learn more.
Side Panel Features
The ZoneFlex 7962 chassis includes a Kensington lock (on the side of the unit opposite
the OPT and DIR LEDs) and a lockable “sliding door” (shown in Figure 3) that hides
and protects the rear connector I/O panel and status LEDs. As your AP may be placed
in a public location, the lock and door mechanisms can help prevent tampering or
theft. Figure 3 illustrates the side panel features of the ZoneFlex 7962. For a descrip-
tion of each side panel part, refer to Table 6.
Figure 3. ZoneFlex 7962 side panel
Table 6. ZoneFlex 7962 side panel elements
Number LED/Button Name Description
1 OPT LED Not used in this model
1
23
4
5
6
7
8

8
Introducing the ZoneFlex Access Point
Getting to Know the Access Point Features
2 DIR LED • Off: The Access Point is not being managed by
ZoneDirector (standalone mode).
•Green: The Access Point is being managed by
ZoneDirector.
• Slow flashing green (one flash every two seconds):
The Access Point is being managed by
ZoneDirector, but is currently unable to
communicate with ZoneDirector.
•Fast flashing green (two flashes every second):
The Access Point is being managed by
ZoneDirector and is currently receiving
configuration settings (provisioning) or a firmware
update.
3 2.4G LED (WLAN) • Off: The WLAN service is down.
•Green: The WLAN service is up, at least one client
is associated, and signal quality is good (RSSI >=
15).
•Flashing green (two flashes every second): The
WLAN service is up but no clients are associated.
•Amber: The WLAN service is up, at least one client
is associated, but signal quality is poor (RSSI < 15).
4 5G LED (WLAN) •Off: The WLAN service is down.
•Green: The WLAN service is up, at least one client
is associated (standalone), or at least one
downlink MAP is connected (RAP), or uplink RAP
is connected (MAP), and signal quality is good
(RSSI >= 15).
•Fast flashing green (two flashes every second):
The WLAN service is up but no clients are
associated (standalone), no downlink MAPs are
connected (RAP), or no uplink RAP is connected
(MAP).
•Amber: The WLAN service is up, at least one
wireless client is associated (standalone), or at
least one downlink MAP is connected (RAP), or
uplink RAP is connected (MAP), but signal quality
is poor (RSSI < 15).
Table 6. ZoneFlex 7962 side panel elements
Number LED/Button Name Description

9
Introducing the ZoneFlex Access Point
Getting to Know the Access Point Features
5 HARD RESET
Button
Pushing and quickly releasing this internal button
reboots the AP. Pushing and holding it for six
seconds resets the AP to factory default settings.
CAUTION! Resetting the AP to factory default
settings will erase all settings that you configured
previously.
6 Sliding Door Protects the ports, buttons, and connector on the
rear panel
7 Kensington Lock The Kensington lock feature, located on the
opposite side of the unit from the pictured LEDs, is
designed to prevent the sliding door from opening,
thus locking the unit. The Kensington lock works with
a Kensington MicroSaver lock.
8 Power LED (front) • Off: Off.
•Amber: Boot up in process.
•Green: On.
Table 6. ZoneFlex 7962 side panel elements
Number LED/Button Name Description

10
Introducing the ZoneFlex Access Point
Getting to Know the Access Point Features
Rear Panel Features
Figure 4 shows the rear panel of the ZoneFlex 7962. For a description of each rear
panel part, refer to Table 7.
Figure 4. ZoneFlex 7962 rear panel features
Table 7. ZoneFlex 7962 rear panel elements
Number Item Name Description
1 Power Connect the power adapter to this socket. (Input
110-240V AC, Output 12V 1.0A DC). Power can also
be supplied via the 10/100/1000 PoE port.
2 Lock Hasp The lock hasp works with a cable or Ruckus Wireless
mounts. The recommended lock type is Masterlock
120 series (D, T, Q, KAD types).
3 LAN Ports Two RJ-45 ports, one for a 10/100/1000 PoE (Power
over Ethernet) connection and another for a 10/100/
1000Mbps connection.
Each Ethernet port has two LEDs. Refer to Tab l e 8 for
LED descriptions.
4 OPTIONAL Button Not active in this model at this time.
5 SOFT RESET
Button
Use to reset AP. This is a normal reset and does not
set AP back to factory defaults.
12 3 4
5

11
Introducing the ZoneFlex Access Point
Getting to Know the Access Point Features
Table 8. Behavior of Ethernet port LEDs on ZoneFlex 7962
LEDs Description
Off Not connected
Amber + Green Connected to 10Mbps device
Amber Connected to 100Mbps device
Green Connected to 1000Mbps device
P

12
Introducing the ZoneFlex Access Point
Getting to Know the Access Point Features
ZoneFlex 7363 Access Point
ZoneFlex 7363 features five LEDs on its front panel, and buttons and connectors on
its rear panel.
Front Panel
Figure 5 shows the front panel of the ZoneFlex 7363. For a description of each front
panel part, refer to Table 9.
Figure 5. ZoneFlex 7363 front panel
Table 9. ZoneFlex 7363 front panel elements
LED Description
PWR LED • Off: Off.
•Amber: Boot up in process.
•Green: On.
OPT LED Not used in this model
DIR LED • Off: The AP is not being managed by
ZoneDirector (standalone mode).
•Green: The AP is being managed by
ZoneDirector.
•Slow flashing green (one flash every two
seconds): The AP is being managed by
ZoneDirector, but is currently unable to
communicate with ZoneDirector.
•Fast flashing green (two flashes every second):
The AP is being managed by ZoneDirector and
is currently receiving configuration settings
(provisioning) or a firmware update.
