Ruijie RG-ES100 Series Installation and operating manual

Ruijie RG-ES100 Series Switches
Hardware Installation and Reference Guide V1.0

Copyright Statement
Ruijie Networks©2019
Ruijie Networks reserves all copyrights of this document. Any reproduction, excerption, backup,
modification, transmission, translation or commercial use of this document or any portion of this document,
in any form or by any means, without the prior written consent of Ruijie Networks is prohibited.
Exemption Statement
This document is provided “as is”. The contents of this document are subject to change without any notice.
Please obtain the latest information through the Ruijie Networks website. Ruijie Networks endeavors to
ensure content accuracy and will not shoulder any responsibility for losses and damages caused due to
content omissions, inaccuracies or errors.

Preface
Thank you for using our products. This manual will guide you through the installation of the device.
This manual describes the functional and physical features and provides the device installation steps,
hardware troubleshooting, module technical specifications, and specifications and usage guidelines for
cables and connectors.
Audience
It is intended for the users who have some experience in installing and maintaining network hardware. At
the same time, it is assumed that the users are already familiar with the related terms and concepts.
Obtaining Technical Assistance
Ruijie Networks Website: https://www.ruijienetworks.com/
Technical Support Website: https://ruijienetworks.com/support
Case Portal: https://caseportal.ruijienetworks.com
Community: https://community.ruijienetworks.com
Technical Support Email: [email protected]
Skype: [email protected]
Related Documents
Documents
Description
Configuration Guide
Describes network protocols and related mechanisms that
supported by the product, with configuration examples.
Command Reference
Describes the related configuration commands, including
command modes, parameter descriptions, usage guides, and
related examples.
Symbol Conventions
The symbols used in this document are described as below:
This symbol brings your attention to some helpful suggestions and references.
This symbol means that you must be extremely careful not to do some things that may damage the
device or cause data loss

Ruijie RG-ES100 Series Switches Hardware Installation and Reference Guide Product Overview
1 Product Overview
The RG-ES100 series switches include the following models:
Table 1-1 RG-ES100 Series Switches
Model
10/100/1000 Base-T
Auto-sensing Ethernet Port
1000Base-X SFP Port
Console Port
RG-ES109G-LP-L
9 (Ports 1-8 support
PoE+/PoE）
N/A
N/A
RG-ES126G-P-L
24 (1-24 ports support
PoE+/PoE）
2
N/A
RG-ES126G-LP-L
24 (1-24 ports support
PoE+/PoE）
2
N/A
The SPF ports cannot be downward compatible with 100Base-FX.
1000Base-T is compatible with 100Base-TX and 10Base-T in the downlink direction.
1.1 RG-ES109G-LP-L
Technical Specifications
Model
RG-ES109G-LP-L
Power Supply
AC input
Rated voltage range: 100V to 240V
Maximum voltage range: 90V to 264V
Frequency: 50/60 Hz
Rated current: 1.5A
Power cord requirement: 10A
Adapter output
Rated voltage range: 54V DC
Rated current range: 1.11A
EEE
Not supported
PoE
Supports PoE and PoE+.
Ports 1-8 are PoE/PoE+-capable with the maximum power output of 30W per port. Port 9 does
not support PoE or PoE+.
The overall maximum output power of PoE/PoE+ is 54W.
PoE Mode
Mode A (data pairs 1-2 and 3-6)
Power
Consumption
Less than 7W with no PoE load
Less than 64W with PoE full load
Port Mode LED
When the button is turned to the left position (Mode 1), the LED indicates the switching status

Ruijie RG-ES100 Series Switches Hardware Installation and Reference Guide Product Overview
Switchover Button
of the port: when the LED is solid green, it indicates that the link is up; when the LED blinks
green, data is being transmitted or received.
When the button is turned to the right position (Mode 2), the LED indicates the PoE status of
ports; when the LED is solid green, it indicates that the PoE-supported ports are supplying
power; when the LED blinks green, the power of the ports is overloaded.
Working Mode
Switchover Button
When the button is turned to the left position (flow control is enabled), all ports’ communication
is available and the flow control function is enabled on all ports.
When the button is turned to the middle position (VLAN isolation), ports 1-8 cannot
communicate with each other but can communicate only with port 9; the flow control is disabled
on port 9 but enabled on ports 1-8.
When the button is turned to the right position (flow control is disabled), all ports’
communication is available and the flow control function is disabled on all ports.
Operating
Temperature
0℃to 40℃(32°F to 104°F)
Storage
Temperature
-40℃to 70℃(-40°F to 158°F)
Operating Humidity
10% to 90% RH
Storage Humidity
5% to 95% RH
Fan
Not supported
Temperature
Warning
Not supported
Accessing Optical
Module Information
Not supported
EMC Standards
GB9254-2008
Security Standards
GB4943-2011
Earth Leakage
Current
≤1.5mA
Dimensions
(W x D x H)
206.5 mm x 108.5 mm x 28 mm
Weight
1.1 kg (with package)
The RG-ES109G-LP-L switch is a class A product. In a domestic environment, this product may cause radio
interference in which case the user may be required to take adequate measures.
Product Appearance
On the front panel, the RG-ES109G-LP-L Ethernet switch provides nine 10/100/1000Base-T Ethernet ports. On the back
panel, it provides an AC power port.
Figure 1-1 Appearance of RG-ES109G-LP-L

Ruijie RG-ES100 Series Switches Hardware Installation and Reference Guide Product Overview
Front Panel
Figure 1-2 Front Panel of RG-ES109G-LP-L
Note:
1. System status LED
2. Port Mode LED Switch-Over Button
3. Copper port status LED
4. 10/100/1000Base-T auto-sensing Ethernet port
5. Copper port status LED
6. 10/100/1000Base-T auto-sensing Ethernet port
Back Panel
Figure 1-3 Back Panel of RG-ES109G-LP-L
Note:
1. Grounding pole
2. Working Mode Switch-Over Button
3. Power port
4. Hole for anti-theft lock
Heat Dissipation
The RG-ES109G-LP-L adopts natural heat dissipation, thereby ensuring normal function of the device in the specified
environment. 10 cm distance space should be reserved at both sides and the back plane of the cabinet to allow air
circulation. It is recommended to clean the device once every 3 months to avoid dust from blocking vents.
LEDs
LED
Panel Identification
State
Meaning
System status LED
Status
Off
The switch is not receiving power.

Ruijie RG-ES100 Series Switches Hardware Installation and Reference Guide Product Overview
Blinking green
The PoE power exceeds the power of the entire
device (54 W). The new connected PD cannot be
powered up due to insufficient power. The
switching function is operational.
Solid green
The switch is operational.
RJ45 port PoE status
LED
1-8
Off
PoE is not enabled.
Solid green
PoE is enabled. The port is operational.
Blinking green
Indicates PoE overload.
1000Mbps RJ-45 port
status LED
1-9
Off
The port is not connected.
Solid green
The port is connected at 10/100/1000 Mbps.
Blinking green
The port is receiving or transmitting traffic at
10/100/1000 Mbps.
1.2 RG-ES126G-P-L
Technical Specifications
Model
RG-ES126G-P-L
Optical Module
For details, see Appendix B.
The supported module type may change at any time. Consult us for the latest information.
SFP Port
Supports 1000Base-X modules.
Power Supply
AC input
Rated voltage range: 100V to 240V
Maximum voltage range: 90V to 264V
Frequency: 50/60 Hz
Rated current: 6A
Power cord requirement: 10A
EEE
Not supported
PoE
Supports PoE and PoE+.
Ports 1-24 are PoE/PoE+-capable with the maximum power output of 30W per port.
Ports 25 and 26 do not support PoE or PoE+.
The overall maximum output power of PoE/PoE+ is 370W.
PoE Mode
Mode A (data pairs 1-2 and 3-6)
Power
Less than 25W with no PoE load

Ruijie RG-ES100 Series Switches Hardware Installation and Reference Guide Product Overview
Consumption
Less than 430W with PoE full load
Port Mode LED
Switchover Button
When the button is turned to the left position (Mode 1), the LED indicates the switching status
of the port: when the LED is solid green, it indicates that the link is up; when the LED blinks
green, data is being transmitted or received.
When the button is turned to the right position (Mode 2), the LED indicates the PoE status of
ports; when the LED is solid green, it indicates that the PoE-supported ports are supplying
power; when the LED blinks green, the power of the ports is overloaded.
Working Mode
Switchover Button
When the button is turned to the left position (flow control is enabled), all ports’ communication
is available and the flow control function is enabled on all ports.
When the button is turned to the middle position (VLAN isolation), ports 1-22 cannot
communicate with each other but ports 23-26 can communicate with each other; the flow
control is disabled on ports 23-26 but enabled on ports 1-22.
When the button is turned to the right position (flow control is disabled), all ports’
communication is available and the flow control function is disabled on all ports.
Operating
Temperature
0℃to 40℃(32°F to 104°F)
Storage
Temperature
-40℃to 70℃(-40°F to 158°F)
Operating Humidity
10% to 90% RH
Storage Humidity
5% to 95% RH
Fan
Supports adaptive speed adjustment. The fan stops running when the ambient temperature is
lower than 25°C and the PoE power is smaller than 185 W.
Temperature
Warning
Not supported
Accessing Optical
Module Information
Not supported
EMC Standards
GB9254-2008
Security Standards
GB4943-2011
Earth Leakage
Current
≤1.5mA
Dimensions
(W x D x H)
440 mm x 292 mm x 43.6 mm
Weight
4.2 kg (with package)
The RG-ES126G-P-L switch is a class A product. In a domestic environment, this product may cause radio
interference in which case the user may be required to take adequate measures.
Product Appearance
On the front panel, the RG-ES126G-P-L Ethernet switch provides twenty-four 10/100/1000Base-T Ethernet ports, and two
1000M SFP ports. On the back panel, it provides an AC power port.
Figure 1-4 Appearance of RG-ES126G-P-L

Ruijie RG-ES100 Series Switches Hardware Installation and Reference Guide Product Overview
Front Panel
Figure 1-5 Front Panel of RG-ES126G-P-L
Note:
1. System status LED
2. Port Mode LED Switch-Over Button
3. Working Mode Switch-Over Button
4. Copper port status LED
5. Copper port status LED
6. 10/100/1000Base-T auto-sensing Ethernet port
7. 1000Base-X SFP port
8. SFP port status LED
Back Panel
Figure 1-6 Back Panel of RG-ES126G-P-L
Note:
1. Vent
2. AC power port
3. Grounding pole
Heat Dissipation
The RG-ES126G-P-L adopts turbine fans for heat dissipation, thereby ensuring normal function of the device in the
specified environment. 10 cm distance space should be reserved at both sides and the back plane of the cabinet to allow
air circulation. It is recommended to clean the device once every 3 months to avoid dust from blocking vents. Figure 1-7
shows the flow scheme of heat dissipation.
Figure 1-7 Flow Scheme of Heat Dissipation

Ruijie RG-ES100 Series Switches Hardware Installation and Reference Guide Product Overview
LEDs
LED
Panel Identification
State
Meaning
System status LED
Status
Off
The switch is not receiving power.
Blinking green
The PoE power exceeds the power of the entire
device (370 W). The new connected PD cannot
be powered up due to insufficient power. The
switching function is operational.
Solid green
The switch is operational.
RJ45 port PoE status
LED
1-24
Off
PoE is not enabled.
Solid green
PoE is enabled. The port is operational.
Blinking green
Indicates PoE overload.
1000Mbps RJ-45 port
status LED
1-24
Off
The port is not connected.
Solid green
The port is connected at 10/100/1000 Mbps.
Blinking green
The port is receiving or transmitting traffic at
10/100/1000 Mbps.
1000Mbps SFP port
status LED
25F-26F
Off
The port is not connected.
Solid green
The port is connected at 1000 Mbps.
Blinking green
The port is receiving or transmitting traffic at 1000
Mbps.

Ruijie RG-ES100 Series Switches Hardware Installation and Reference Guide Product Overview
1.3 RG-ES126G-LP-L
Technical Specifications
Model
RG-ES126G-LP-L
Port
Supports 24 10/100/1000 Base-T auto-sensing Ethernet ports;
Supports 2 1000Mbps SFP ports.
Optical Module
Mini-GBIC-SX
Mini-GBIC-LX
Mini-GBIC-LH40
Mini-GBIC-ZX50
Mini-GBIC-ZX80
Mini-GBIC-ZX100
Mini-GBIC-GT
The supported module type may change at any time. Consult us for the latest information.
SFP Port
Supports 1000Base-X modules.
Power Supply
AC input
Rated voltage range: 100V to 240V
Maximum voltage range: 90V to 264V
Frequency: 50/60 Hz
Rated current: 3A
Power cord requirement: 10A
PoE
Supports PoE and PoE+.
Ports 1-24 are PoE/PoE+-capable with the maximum power output of 30W per port.
The overall maximum output power of PoE/PoE+ is 180W.
The output voltage of the PoE port is 53.5V.
Power
Consumption
180W (Max.)
Operating
Temperature
0℃to 50℃(32°F to 122°F)
Storage
Temperature
-40℃to 70℃(-40°F to 158°F)
Operating Humidity
10% to 90% RH
Storage Humidity
5% to 95% RH
Fan
Supported
EMC Standards
GB9254-2008 Class A
Dimensions
(W x D x H)
440 mm x 205 mm x 44 mm (mounting brackets included)
Backplane
Bandwidth
52Gbps
Hardware Version
V2.00

Ruijie RG-ES100 Series Switches Hardware Installation and Reference Guide Product Overview
Product Appearance
On the front panel, the RG-ES126G-LP-L Ethernet switch provides twenty-four 10/100/1000Base-T Ethernet ports, and
two 1000M SFP ports. On the back panel, it provides an AC power port.
Figure 1-8 Appearance of RG-ES126G-LP-L
Front Panel
Figure 1-9 Front Panel of RG-ES126G-LP-L
Note:
1. Power status LED
2. 10/100/1000Base-T Link/ACT LED
3. PoE status LED
4. 10/100/1000Base-T auto-sensing Ethernet port
5. 1000Base-X SFP port
6. Flow control switch
7. SFP port status LED
Back Panel
Figure 1-10 Back Panel of RG-ES126G-P-L
Note:
1. Grounding pole
2. AC power port
Heat Dissipation

Ruijie RG-ES100 Series Switches Hardware Installation and Reference Guide Product Overview
The RG-ES126G-LP-L adopts turbine fans for heat dissipation, thereby ensuring normal function of the device in the
specified environment. 10 cm distance space should be reserved at both sides and the back plane of the cabinet to allow
air circulation. It is recommended to clean the device once every 3 months to avoid dust from blocking vents.
PoE Power Supply
The RG-ES126G-LP-L supports IEEE802.3af and IEEE802.3at PoE. It adopts the Alternative A mode for transmitting
power over Ethernet cabling, that is, power is transmitted through cable pairs 1&2 and 3&6.
LEDs
LED
Panel Identification
State
Meaning
Power status LED
PWR
Off
The switch is not receiving power.
Solid on
The switch is powered on.
Ethernet port status
LED
1-24
Off
The port is not connected.
Solid orange
The port is connected at 10/100 Mbps.
Blinking orange
The port is receiving or transmitting traffic at
10/100 Mbps.
Solid green
The port is connected at 1000 Mbps.
Blinking green
The port is receiving or transmitting traffic at 1000
Mbps.
SFP port status LED
SFP1, SFP2
Off
The port is not connected.
Solid orange
The port is connected at 100 Mbps.
Blinking orange
The port is receiving or transmitting traffic at 100
Mbps.
Solid green
The port is connected at 1000 Mbps.
Blinking green
The port is receiving or transmitting traffic at 1000
Mbps.
Port PoE status LED
1-24
Off
PoE is not enabled.
Solid on
PoE is enabled. The port is operational.

Ruijie RG-ES100 Series Switches Hardware Installation and Reference Guide Product Overview
Blinking
Indicates PoE overload.

Ruijie RG-ES100 Series Switches Hardware Installation and Reference Guide Preparation before Installation
2 Preparation before Installation
2.1 Safety Suggestions
To avoid personal injury and equipment damage, please carefully read the safety suggestions before you install the
RG-ES100 series switch.
The following safety suggestions do not cover all possible dangers.
2.1.1 Installation
Keep the chassis clean and free from any dust.
Do not place the equipment in a walking area.
Do not wear loose clothes or accessories that may be hooked or caught by the device during installation and
maintenance.
Turn off all power supplies and remove the power sockets and cables before installing or uninstalling the device.
2.1.2 Movement
Do not frequently move the device.
When moving the device, note the balance and avoid hurting legs and feet or straining the back.
Before moving the device, turn off all power supplies and dismantle all power modules.
2.1.3 Electricity
Observe local regulations and specifications when performing electric operations. Relevant operators must be
qualified.
Before installing the device, carefully check any potential danger in the surroundings, such as ungrounded power
supply, and damp/wet ground or floor.
Before installing the device, find out the location of the emergency power supply switch in the room. First cut off the
power supply in the case of an accident.
Try to avoid maintaining the switch that is powered-on alone.
Be sure to make a careful check before you shut down the power supply.
Do not place the equipment in a damp location. Do not let any liquid enter the chassis.
Any nonstandard and inaccurate electric operation may cause an accident such as fire or electrical shock, thus
causing severe even fatal damages to human bodies and equipment.
Direct or indirect touch through a wet object on high-voltage and mains supply may bring a fatal danger.
If a power supply system is equipped with a leakage protector (also referred to as "leakage current switch" or
"leakage current breaker"), the rated leakage action current of each leakage protector is greater than twice of the
theoretical maximum leakage current of all the power supplies in the system. For example, if a system is equipped
with twenty identical power supplies, the leakage current of each power supply is equal to or less than 1.5mA, and

Ruijie RG-ES100 Series Switches Hardware Installation and Reference Guide Preparation before Installation
the leakage current of the system totals 30mA. A leakage protector with 30mA rated action current supports less
than ten power supplies (that is, Action current of the leakage protector/2/Maximum leakage current of each power
supply =30/2/1.5=10). In other words, the leakage protector with 30mA rated action current supports no more than
ten power supplies. In this case, the twenty power supplies in the system require at least two leakage protectors with
30mA rated action current and each leakage protector supports ten power supplies. If power supplies in a system
differ in models, the rated leakage action current of each leakage protector divided by two is greater than the sum of
maximum leakage current of all the power supplies. The rated leakage non-action current of a leakage protector
shall be 50% of the leakage action current. Take a leakage protector with 30mA rated leakage action current as an
example. The rated leakage non-action current shall be 15mA. When the leakage current is below 15mA, the
protector shall not act. Otherwise, misoperation may easily occur due to high sensitivity and thus the leakage
protector trips, devices are powered off, and services are interrupted.
To guarantee personal safety, the rated leakage action current of each leakage protector in the system must be
equal to or less than 30mA (human body safety current is 30mA). When twice of the total leakage current of the
system is greater than 30mA, the system must be equipped with two or more leakage protectors.
For the leakage current value of each power supply model, see the power supply model parameter table in Chapter
1.
2.1.4 Static Discharge Damage Prevention
To prevent damage from static electricity, pay attention to the following:
Proper grounding of grounding screws on the back panel of the device. Use of a three-wire single-phase socket with
protective earth wire (PE) as the AC power socket.
Indoor dust prevention
Proper humidity conditions
2.1.5 Laser
The RG-ES126G-P-L series switch supports varying models of optical modules sold on the market which are Class I laser
products. Improper use of optical modules may cause damage. Therefore, pay attention to the following when you use
them:
When a fiber transceiver works, ensure that the port has been connected with an optical fiber or is covered with a
dust cap, to keep out dust and avoid burning your eyes.
When the optical module is working, do not pull out the fiber cable and stare into the transceiver interface or you may
hurt your eyes.
Do not stare into any optical port under any circumstances, as this may cause permanent damage to your eyes.
2.2 Installation Site Requirements
To ensure the normal working and a prolonged durable life of the equipment, the installation site must meet the following
requirements.

Ruijie RG-ES100 Series Switches Hardware Installation and Reference Guide Preparation before Installation
2.2.1 Ventilation
For the RG-ES100, a sufficient space (at least 10 cm distances from both sides and the back plane of the cabinet) should
be reserved at the ventilation openings to ensure the normal ventilation. After various cables have been connected, they
should be arranged into bundles or placed on the cabling rack to avoid blocking the air inlets. It is recommended to clean
the switch at regular intervals (like once every 3 months). Especially, avoid dust from blocking the screen mesh on the
back of the cabinet.
2.2.2 Temperature and Humidity
To ensure the normal operation and prolong the service life of RG-ES100 series switch, you should keep proper
temperature and humidity in the equipment room.
If the equipment room has temperature and humidity that do not meet the requirements for a long time, the equipment
may be damaged.
In an environment with high relative humidity, the insulating material may have bad insulation or even leak electricity.
Sometimes the materials may suffer from mechanical performance change and metallic parts may get rusted.
In an environment with low relative humidity, however, the insulating strip may dry and shrink. Static electricity may
occur easily and endanger the circuit on the equipment.
In an environment with high temperature, the equipment is subject to even greater harm, as its performance may
degrade significantly and various hardware faults may occur.
Therefore, the ambient temperature and humidity of the RG-ES100 series must meet the requirements listed in Table 2-1:
Table 2-1 Temperature and Humidity Requirements of the RG-ES100 Series Switch
Temperature
Relative Humidity
0℃to 40℃(32°F to 104°F)
10% to 90%
The requirements for the sampling site of the temperature and humidity in the operating environment of the device
are as follows:
There is no protective plate at the front or back of the equipment rack.
The vertical height is 1.5 m above the floor.
The distance from the front panel of the equipment is 0.4 m.
2.2.3 Cleanness
Dust poses a severe threat to the running of the equipment. The indoor dust falling on the equipment may be adhered by
the static electricity, causing bad contact of the metallic joint. Such electrostatic adherence may occur more easily when
the relative humidity is low, not only affecting the useful life of the equipment, but also causing communication faults.
Table 2-2 shows the requirements for the dust content and granularity in the equipment room.
Table 2-2 Requirements for the Dust Content and Granularity in the Equipment Room
Dust
Unit
Density
Diameter≥0.5μm
Particles/m3
≤3.5×106
Diameter≥5μm
Particles/m3
≤3×104

Ruijie RG-ES100 Series Switches Hardware Installation and Reference Guide Preparation before Installation
Apart from dust, the salt, acid and sulfide in the air in the equipment room must also meet strict requirements, as such
poisonous substances may accelerate the corrosion of the metal and the aging of some parts. The equipment room
should be protected from the intrusion of harmful gases such as sulfur dioxide, sulfured hydrogen, nitrogen dioxide, and
chlorine), whose requirements are listed in Table 2-3.
Table 2-3 Requirements for Harmful Gases in the Equipment Room
Gas
Average (mg/m3)
Maximum (mg/m3)
SO2
0.3
1.0
H2S
0.1
0.5
NO2
0.5
1.0
Cl2
0.1
0.3
Both average and maximum value are measured for a week. The switch cannot be placed in the environment with
the maximum density for over 30 minutes every day. ..
2.2.4 EMI
The switch is vulnerable to external interface caused by capacity coupling, inductance coupling, electromagnetic wave
radiation, common impedance (including grounding system) coupling and conducting wires (including power cords, signal
and output wires). Therefore, the following points should be noted:
The AC power supplying system is the TN system. The single-phase three-wire socket with protecting grounding
must be used as the socket for the power supply to enable the device’s upper filter circuit to effective filter the power
interface.
The switch should be far from high-power radio transmitting stations, radar stations and high-frequency and
large-current devices.
Electromagnetic shielding methods should be applied when necessary, such as using the shielded cable as the
interface cable.
Cables must be connected to interfaces inside the room to prevent damage to the device’s signal ports caused by
over-voltage and over-current generated by thunder and lightning.
2.2.5 Grounding
A good grounding system is the basis for the stable and reliable operation of the RG-ES100 series switch. It is the chief
condition to prevent lightning stroke and resist interference. Please carefully check the grounding conditions on the
installation site according to the grounding requirements, and perform grounding operations properly as required.
Effective grounding of the switch is an important guarantee for lightning protection and interference resistance.
Therefore, connect the grounding line of the switch properly.
The grounding cable is customer supplied.
Safety Grounding
The equipment using AC power supply must be grounded by using the yellow/green safety grounding cable. Otherwise,
when the insulating resistance decreases the power supply and the enclosure in the equipment, electric shock may occur.
The building must provide protective grounding connection to ensure that the device is connected to the protection
location.

Ruijie RG-ES100 Series Switches Hardware Installation and Reference Guide Preparation before Installation
The installation and maintenance personnel must check whether the A.C. socket is well connected to the protection
location of the building, if not, they should use a protective grounding wire to connect the grounding end of the A.C.
socket to the building's protection location.
The power supply socket must be installed in a place that is near to the device and where users can operate the
device easily.
Before the installation of the device, make sure that ground connection is connected at first and disconnected finally.
The sectional area of the protective grounding wire should be at least 0.75 mm2(18 AWG).
Use the 3-core power supply line. The sectional area of each pin should be at least 0.75 mm2or 18 AWG.
Lightning Grounding
The lightning protection system of a facility is an independent system that consists of the lightning rod, download
conductor and the connector to the grounding system, which usually shares the power reference ground and yellow/green
safety cable ground. The lightning discharge ground is for the facility only, irrelevant to the equipment.
EMC Grounding
The grounding required for EMC design includes shielding ground, filter ground, noise and interference suppression, and
level reference. All the above constitute the comprehensive grounding requirements. The resistance of earth wires should
be less than 1 ohm. The RG-ES100 series switch back plane is reserved with one grounding pole, as shown in Figure 2-1.
Figure 2-1 Grounding of RG-ES100
2.2.6 Lightning Resistance
When the AC power cable is imported outdoors and directly connected to the power port of the RG-ES100 series switch,
lightning line bank should be adopted to prevent the switch from being hit by lightning shocks. Usage of the lightning line
bank: Connect the mains supply AC cable to the lightning line bank. Then, connect the switch to the lightning line bank.
This can help to prevent the current of high-voltage lightning from passing the switch directly through the mains supply
cable to a certain extent.
The lightning line banks are not provided and should be purchased by users as required.
For the usage of lightning line banks, refer to their related manuals.

Ruijie RG-ES100 Series Switches Hardware Installation and Reference Guide Preparation before Installation
2.2.7 EMI
Electro-Magnetic Interference (EMI), from either outside or inside the equipment or application system, affects the system
in the conductive ways such as capacitive coupling, inductive coupling, and electromagnetic radiation.
There are two types of electromagnetic interference: radiated interference and conducted interference, depending on the
type of the transmission path.
When the energy, often RF energy, from a component arrives at a sensitive component via the space, the energy is
known as radiated interference. The interference source can be either a part of the interfered system or a completely
electrically isolated unit. Conducted interference results from the electromagnetic wire or signal cable connection between
the source and the sensitive component, along which cable the interference conducts from one unit to another. Conducted
interference often affects the power supply of the equipment, but can be controlled by a filter. Radiated interference may
affect any signal path in the equipment and is difficult to shield.
For the AC power supply system TN, single-phase three-core power socket with protective earthing conductors (PE)
should be adopted to effectively filter out interference from the power grid through the filtering circuit.
The grounding device of the switch must not be used as the grounding device of the electrical equipment or
anti-lightning grounding device. In addition, the grounding device of the switch must be deployed far away from the
grounding device of the electrical equipment and anti-lightning grounding device.
Keep the equipment away from high-power radio transmitter, radar transmitting station, and high-frequency
large-current device.
Measures must be taken to shield static electricity.
Interface cables should be laid inside the equipment room. Outdoor cabling is prohibited, avoiding damages to
device signal interfaces caused by over-voltage or over-current of lightning.
2.3 Requirements of Installation Tools
Table 2-4 List of Installation Tools
Common Tools
Phillips screwdriver, flathead screwdriver, related electric cables and optical cables, bolts, diagonal
pliers, straps
Special Tools
Anti-static tools
Meters
Multimeter
The tool kit is customer-supplied.
