Ruijie RG-AP730-L Series Installation and operating manual

Ruijie RG-AP730-L Series Access Points
Hardware Installation and Reference Guide V1.01

·
Copyright statement
Ruijie Networks©2020
Ruijie Networks reserves all copyrights of this document. Any reproduction, excerption, backup,
modification, transmission, translation or commercial use of this document or any portion of this document,
in any form or by any means, without the prior written consent of Ruijie Networks is prohibited.
Exemption statement
This document is provided “as is”. The contents of this document are subject to change without any notice.
Please obtain the latest information through the Ruijie Networks website. Ruijie Networks endeavors to
ensure content accuracy and will not shoulder any responsibility for losses and damages caused due to
content omissions, inaccuracies or errors.

·
Preface
Thank you for using our products. This manual will guide you through the installation of the access point.
Scope
It is intended for the users who have some experience in installing and maintaining network hardware. At the same time, it
is assumed that the users are already familiar with the related terms and concepts.
Obtaining Technical Assistance
Ruijie Networks Website: https://www.ruijienetworks.com/
Technical Support Website: https://ruijienetworks.com/support
Case Portal: https://caseportal.ruijienetworks.com
Community: https://community.ruijienetworks.com
Technical Support Email: se[email protected]
Skype: [email protected]
Related Documents
Documents
Description
Configuration Guide
Describes network protocols and related mechanisms that supported by the
product, with configuration examples.
Command Reference
Describes the related configuration commands, including command modes,
parameter descriptions, usage guides, and related examples.
Documentation Conventions
The symbols used in this document are described as below:
This symbol brings your attention to some helpful suggestions and references.
This symbol means that you must be extremely careful not to do some things that may damage the device or cause
data loss.

·
1 Product Overview
Featuring leading 802.11ac Wave2, Ruijie RG-AP730-L supports 2.4G+5G+5G working mode and concurrently 802.11ac
Wave 2, 802.11ac Wave 1 and 802.11n. It delivers up to 400[email protected] (802.11b/g/n) and 1.73Gbps@5G
(802.11a/n/ac). The overall tri-radio, dual-band performance speeds up to 2.13Gbps per device, totally eliminating Gigabit
wireless bottlenecks. The AP can be mounted on a ceiling or wall. And it supports local power supply and PoE to meet
challenges in a wide variety of deployment scenarios, including large-scaled campuses, enterprises, hospitals and WiFi
hotspots.
1.1 Technical Specifications
Table 1-1 Technical Specifications of RG-AP730-L
Hardware Specifications
Radio
RF
2.4GHz: 2 x 2MIMO
5GHz: 2 x 2MU-MIMO
Transmission
Protocol
Support concurrent 802.11ac and 802.11 a/b/g/n.
Supports 2.4G + 5G +5G
Operating Bands
802.11b/g/n: 2.4 GHz to 2.4835 GHz
802.11a/n/ac: 5.15 GHz to 5.35 GHz, 5.47 GHz to 5.725 GHz, 5.725 GHz to 5.85GHz
(Depending on which country the AP is installed)
Antenna
Built-in smart antenna
Spatial Streams
2 streams per radio card
Up to 6 streams per device
Access Rates
2.4GHz: up to 400Mbps
5GHz: up to 1.73Gbps
Total: up to 2.13Gbps
Modulation
OFDM: BPSK@6/9Mbps, QPSK@12/18Mbps, 16-QAM@24Mbps, 64-QAM@48/54Mbps
DSSS: DBPSK@1Mbps, DQPSK@2Mbps, and [email protected]/11Mbps
MIMO-OFDM: BPSK, QPSK, 16QAM , 64QAM and 256QAM
Receive Sensitivity
11b: -96dBm(1Mbps), -93dBm(5Mbps), -89dBm(11Mbps)
11a/g: -91dBm (6Mbps), -85dBm (24Mbps), -80dBm (36Mbps), -74dBm (54Mbps)
11n: -90dBm@MCS0, -70dBm@MCS7, -89dBm@MCS8, -68dBm@MCS15
11ac HT20: -88dBm (MCS0), -63dBm (MCS9)
11ac HT40: -85dBm (MCS0), -60dBm (MCS9)
11ac HT80: -82dBm (MCS0), -57dBm (MCS9)
Maximum Transmit
Power
≤100mw (20dBm)
(Depending on the country of use, laws and regulations.)
Transmit Power
Adjustment
1 dBm
Physical
Dimensions
230 mm x 230 mm x 47 mm (Only host, excluding the bracket)

·
(W x D x H)
(9.06in x 9.06in x 1.85in)
Weight
1.3 kg (Host and bracket)
Service Ports
One 10/100/1000BASE-T Ethernet port (PoE-capable)
Management Ports
One Console port
Button
One Reset button
Anti-theft Locks
Support
LED
1 LED (red, green, blue, orange, and blinking modes, blinking mode for smart device access,
and the indicator can be switched off to silent mode)
Power Supply
Adapter: DC 48V/0.6A (optional)
PoE+: IEEE 802.3at
Power Consumption
Maximum: 25.5W
Temperature
Operating: -10°C to 50°C (14°F to 122°F)
Storage: -40°C to 70°C (-40°F to 158°F)
Humidity
Operating: 5% to 95% RH (non-condensing)
Storage: 5% to 95% RH (non-condensing)
Installation
Ceiling/wall mount
IP Rating
IP41
Safety Standards
GB4943
IEC 60950-1
EMC Standards
GB9254
EN301 489
EN 50155
EN 50121
EN 55032
EN 61000
EN 55035
Vibration Standards
IEC61373
Radio
China Radio Transmission Equipment Type Approval Certificate
EN300 328
EN301 893
MTBF
>400,000H
The weight refers to the weight of host and bracket.
1.2 Product Image
The AP provides one Ethernet port (PoE+-capable), one Console port, one power port for external power supply and one
reset button.
Figure 1-1 Top Panel of RG-AP730-L

·
Note
1. LED indicator
2. Laptop lock
3. Reset button
4. Console port
5. LAN1/PoE port
6. 48V DC power supply input port
1.3 LED Indicators
Fit AP
State
Frequency
Meaning
Off
N/A
The AP is NOT receiving power. Or the AP is in Do Not Disturb mode, which
can be disabled by software.
Blinking green
3Hz
uBoot program initialization in progress
Solid green
N/A
Main program initialization in progress
Blinking red
3Hz
Initialization is complete, but no Ethernet activity.
Solid orange
N/A
Initialization is complete, and the AP is establishing a CAPWAP connection
with an AC.
Blinking orange
3Hz
Firmware upgrade in progress. Do not power off.
Solid blue
N/A
Normal operation, but no wireless clients are associated with the AP.
Blinking blue
3Hz
Normal operation, at least one wireless client is associated with the AP.
Double blinking
red
3Hz for 2 cycles and
off for 2 cycles
Locate the AP.
Reset button
Pressed for less
than 2s
Restart the device.
Pressed for more
than 3s
Restore default settings.
Fat AP

·
State
Frequency
Meaning
Off
N/A
The AP is NOT receiving power. Or the AP is in Do Not Disturb mode, which
can be disabled by software.
Blinking green
3Hz
uBoot program initialization in progress
Solid green
N/A
Main program initialization in progress
Blinking red
3Hz
Initialization is complete, but no Ethernet activity.
Solid blue
N/A
Normal operation, but no wireless clients are associated with the AP.
Blinking blue
3Hz
Normal operation, at least one wireless client is associated with the AP.
Reset button
Pressed for less
than 2s
Restart the device.
Pressed for more
than 3s
Restore default settings.
1.4 Power Sources
The AP can be powered either with a DC power adapter or through Power over Ethernet (PoE+).
The AP requires Ruijie power adapters (If needed, you can buy them from Ruijie).
To use a PoE+ device, make sure it supports the IEEE 802.3at PoE standard.
1.5 Cooling Solution
The AP adopts fanless design.
Leave sufficient space at the surrounding of the AP when place the AP to permit airflow for proper ventilation.

·
2 Preparing for Installation
To prevent device damage and bodily injury, please read carefully the safety recommendations described in this
chapter.
The recommendations do not cover all possible hazardous situations.
2.1 Installation
The AP must be installed indoors. To ensure its normal operation, the installation site must meet the following
requirements.
Install the AP in a well-ventilated environment. If it is installed in a closed room, make sure there is a good cooling
system.
Make sure the site is sturdy enough to support the AP and its accessories.
Make sure the site has enough space for installing the AP and leave sufficient room around the AP for ventilation.
Also, to avoid mutual interference, ensure the site is at least 2 meters away from a base station antenna.
Do not expose the AP to high temperature, dusts, or harmful gases.
Do not install the AP in an inflammable or explosive environment.
Keep the AP away from EMI sources such as large radar stations, radio stations, and substations.
Do not subject the AP to unstable voltage, vibration, and noises.
Keep the AP at least 500 meters away from the seaside and do not face it toward the wind from the sea.
The installation site should be free from water flooding, seepage, dripping, or condensation.
The installation site shall be selected according to network planning and features of communications equipment, and
considerations such as climate, hydrology, geology, earthquake, electric power, and transportation.
Please follow the correct method described in the installation guide to install and remove the device.
2.2 Movement
Avoid moving the device frequently.
Turn off all power supplies and unplug all power cables before you remove the device.
2.3 EMI
Please observe local regulations and specifications when performing electrical operations. Relevant operators must
be qualified.
Please carefully check for any potential danger in the working area, for example, damp/wet ground or floor.
Find out the location of the emergency power supply switch in the room before installation. First cut off the power
supply in case of an accident.

·
Be sure to make a careful check before you shut down the power supply.
Do not place the device in a damp/wet location. Do not let any liquid enter the chassis
Keep the AP far away from the grounding or lightning protection devices of power equipment.
Keep the AP away from radio stations, radar stations, high-frequency high-current devices, and microwave ovens.
Any nonstandard and inaccurate electrical operation can cause an accident such as fire or electric shock, thus
causing severe even fatal damages to human bodies and device.
Direct or indirect touch through a wet object on high voltage and power line can bring a fatal danger.
2.4 Ventilation
For proper ventilation, leave sufficient space around the AP.
2.5 Temperature and Humidity
To ensure normal operation and service life of the device, maintain appropriate temperature and humidity levels in your
equipment room. See Table 2-1. Improper room temperature and humidity can cause damages to the device.
High relative humidity may affect insulation materials, resulting in poor insulation and even electrical leakage, and
sometimes may lead to change of mechanical properties of materials and corrosion of metal parts.
Low relative humidity may dry and shrink insulation sheets and cause static electricity that can damage the circuitry
inside the device.
High temperature greatly reduces reliability of the device and shortens its service life.
Table 2-1 Required Temperature and Humidity for the RG-AP730-L
Temperature
Relative Humidity
-10°C to 50°C (14°F to 122°F)
5% to 95%
2.6 Cleanness
Dust poses a serious threat to device operation. Dust that falls onto the surface of the device can be absorbed onto metal
contact points by static electricity, resulting in poor contact. Electrostatic absorption of dust occurs more easily when the
relative humidity is low, which may shorten the service life of the device and cause communication failures. Table 2-2
shows the maximum concentration and diameter of dust allowed in the equipment room.
Table 2-2
Maximum diameter (μm)
0.5
1
3
5
Maximum concentration
(Particles/m3)
1.4×107
7×105
2.4×105
1.3×105
Besides, the contents of salts, acids and sulfides in the air are also strictly limited for the equipment room. These
substances can accelerate metal corrosion and the aging of some parts. Table 2-3 describes the limit of some hazardous
gases such as SO2, H2S, NO2and Cl2 in the equipment room.

·
Table 2-3
Gas
Average (mg/m3)
Maximum (mg/m3)
SO2
0.2
1.5
H2S
0.006
0.03
NO2
0.04
0.15
NH3
0.05
0.15
Cl2
0.01
0.3
2.7 Power Supply
DC power adapter: 48V/0.6A
Specifications of Connector
Internal Diameter
External Diameter
Depth
Polarity
1.35mm
3.5mm
6.4mm
Internal: positive External: negative
PoE injector: IEEE 802.3at compliant
The DC input power should be greater than the power actually consumed by the system. The input power for the
RG-AP730-L should be greater than 25.5 W.
Please use Ruijie recommended power adapters.
Please use Ruijie certified PoE injectors.
2.8 Installation Tools
Common Tools
Phillips screwdriver, related copper and fiber cables, bolts, diagonal pliers, cable ties
Special Tools
Wire stripper, crimping pliers, RJ-45 crimping pliers, punch down tool
Meter
Multimeter, bit error rate tester (BERT)
The listed tools are customer supplied.

·
2.9 Unpacking the Access Point
Package Contents
Items
Verify that all parts are installed and debugged.
Screws
Mounting brackets
Product quick installation guide
Packing list
The above listed items are for general situations, which may vary in the actual shipment. The purchase order shall
prevail in any case. Please check each item carefully according to the packing list or purchase order. If any item is
damaged or missing, notify the sales person.

·
3 Installing the Access Point
The RG-AP730-L series must be fixed and installed indoors.
Before installing the AP, make sure you have carefully read the requirements described in Chapter 2.
3.1 Installation Flowchart
3.2 Before You Begin
Before you install the AP, verify that:
The installation site provides sufficient ventilation for the AP.
The installation site meets temperature and humidity requirements.
The installation site is equipped with proper power supply.
Network cables are in place.
The installation site meets all described requirements.
The custom AP meets the customers’requirements.
3.3 Precautions
To avoid damages to the AP, observe the following safety precautions:
Do not power the device during installation.
Install the device in a well-ventilated location.
Do not subject the device to high temperatures.
Keep away from high voltage cables.
Install the device indoors.
Do not expose the device in a thunderstorm or strong electric field.
Keep the device clean and dust-free.

·
Disconnect the device before cleaning it.
Do not wipe the device with a damp cloth.
Do not wash the device with liquid.
Do not open the enclosure when the AP is working.
Fasten the device tightly.
3.4 Installing the Access Point
Ceiling Mount
1. Drill four 6 mm diameter holes (53 mm apart) on the ceiling. Tap wall anchors into the holes, and drive screws
through the mounting bracket into the anchors to fix the bracket. See Figure 3-1.
Figure 3-1 Attaching the Mounting Bracket on the Ceiling
2. Align the square feet on the rear of the AP over the mounting holes on the bracket. See Figure 3-2.
Figure 3-2 Aligning the Square Feet with the Mounting Holes
Before mounting the AP on the bracket, you must first install the Ethernet cables.

·
3. Slide the AP onto the bracket in the reverse direction against the arrow on the mounting bracket until it clicks into
place. See Figure 3-3.
Figure 3-3 Mounting the AP on the Bracket
The AP can be installed in any of four directions on the mounting bracket depending on how you route your Ethernet
cable.
The square feet should fit easily into the mounting slots. Do not forcibly push the AP into the slots.
After installation, verify that the AP is securely fastened.
Wall Mount
1. Drill four 6 mm diameter holes (53 mm apart) on the wall with the arrow on the mounting bracket facing up. Tap wall
anchors into the holes, and drive screws through the mounting bracket into the anchors to fix the bracket. See Figure
3-4.
Figure 3-4 Attaching the Mounting Bracket on the Wall
2. Align the square feet on the rear of the AP over the mounting holes on the bracket. See Figure 3-5.

·
Figure 3-5 Aligning the Square Feet with the Mounting Holes
Before mounting the AP on the bracket, you must first install the Ethernet cables.
3. Slide the AP into the holes in the reverse direction against the arrow on the mounting bracket until it clicks into place.
See Figure 3-6.
Figure 3-6 Mounting the AP on the Bracket
For mounting on wall, make sure the “Ruijie” logo is in the upper right corner.
The square feet should fit easily into the mounting slots. Do not forcibly push the AP into the slots.
After installation, verify that the AP is securely fastened.
3.5 (Optional) Securing the Access Point
1. Loosen the screw on the mounting bracket and enable the hidden lock.
Figure 3-7 Enabling the Hidden Lock

·
2. Align the square feet on the rear of the AP over the mounting holes on the bracket, slide the AP in the reverse
direction against the arrow on the mounting bracket until it clicks into place.
Figure 3-8 Mounting the AP on the Bracket
Before mounting the AP on the bracket, you must first install the Ethernet cables.
3.6 Removing the Access Point
1. If the hidden lock is enabled, attach the front part of the key to the edge of the mounting bracket (keep the Ruijie logo
of the key toward the top panel of the AP). Slide the key along with the four edges of the mounting bracket, and
attempt to insert the key to the keyhole (only one marked keyhole can be inserted).
Figure 3-9 Inserting the Key for Unlocking

·
2. If the AP is installed on the wall, hold the AP in your hands and push it upward and away from the bracket in the LAN
port direction.
Figure 3-10 Removing the Wall-Mount AP
3. If the AP is installed on the ceiling, hold the AP in your hands and push it sideward. And attempt to push it along the
direction of the LAN port.
Figure 3-11 Removing the Ceiling-Mount AP

·
3.7 Connecting Cables
Connect UTP/STP to the LAN1/PoE port on the AP. See Appendix A for supported wiring of twisted pairs.
By default, baud rate is set to 9600, data bit 8, parity none, stop bits 1 and flow control none on the console port of
the AP. The console port is used only when you want to configure the AP manually.
Ruijie recommends that you do not use Ethernet cables with protective sleeves as they could make installation of
Ethernet cables difficult.
3.8 Bundling Cables
Precautions
Make sure the cable bundles are neat and orderly.
Bend twisted pairs naturally or to a large radius close to the connector.
Do not over tighten cable bundle as it may reduce the cable life and performance.
Bundling Steps
1. Bundle the drop UTP/STP cables and route them to the LAN1/PoE port.
Attach the cables in the cable tray of the rack.
Extend the cables under the AP and run in straight line.
3.9 Checking after Installation
Checking the Cabinet
Make sure the external power supply matches the specifications of the patch panel in the cabinet.
After installation, make sure you can close the front and rear cabinet doors.
Make sure the cabinet is stable and level.
Make sure the device and all cables are securely fastened in the rack.
Checking Cable Connection
Make sure the UTP/STP cable matches the interface type.
Make sure cables are properly bundled.
Checking the Power Supply
Make sure all power cables are properly connected and safe.
Make sure the AP is operational after power-on.

·
4 System Debugging
4.1 Setting up a Debugging Environment
Use a power adapter or PoE to power the AP.
Setting up the Environment
Verify that the AP is properly connected to the power source.
Connect the AP to an AC through a twisted pair cable.
When the AP is connected to a PC for debugging, verify that the PC and PoE switch are properly grounded.
4.2 Powering up the AP
4.2.1 Checking before power-up
Verify that the power supply is properly connected.
Verify that the input voltage matches the specification of the AP.
4.2.2 Checking after power-up (recommended)
After powering up, it is recommended that you check the following to ensure normal operation of the AP.
Check if any message is printed on the Web-based configuration interface of the AC.
Check if the LED works normally.
4.3 Resetting the System
Insert into the hole, where the reset button is placed, an iron stick with a diameter less than 1mm. After the button clicks,
keep the stick in the same position for five more seconds before releasing it, and factory default settings are restored.

·
5 Monitoring and Maintenance
5.1 Monitoring
LED
You can observe the LED to monitor the AP in operation.
CLI Commands
You can run related commands on the command line interface (CLI) on the AC to remotely monitor the configurations and
status of the AP.
You can login in to the AP via Telnet and use monitoring related commands to maintain the AP.
5.1.1 Remote Maintenance
If the AP operates as a Fat AP, you can login in to the AP remotely for maintenance.
If the AP operates as a Fit AP, you can use AC to centrally manage and maintain the AP.
5.1.2 Hardware Maintenance
If the hardware is faulty, please contact our Technical Assistance Center (TAC) for help.
