Samsara AG24 User manual

Asset Gateway
REEFER INSTALL GUIDE
Questions? samsara.com/support
1× Asset Gateway
What’s included:
1× Mounting Plate
Ring Terminals
1x Reefer Y-Cable
4x Self-Tapping Screws
Zip Ties
1x Thermo King Pigtail
4x Flat-End Screws
Cleaning Wipes
1x Carrier Pigtail
Bullet Connectors

Questions? samsara.com/support AG24 Installation Guide 2
5a 6a
Connect Thermo King 8-pin connector to CAN1 (J12),
CAN2 (J13) or CAN3 (J14).
Note: If all ports are occupied, the pigtail includes
an optional pass-through extension that provides an
additional CAN port.
Connect Thermo King 4-pin connector to J10.
Note: J10 may be located in upper right of control
board depending on model. If J10 is occupied, the
pigtail includes an optional pass-through extension
that provides an additional CAN port.
Proceed to step 8.
NOTICE: Damage to Customer’s transportation refrigeration unit resulting from the use of this product may not be covered by unit manufacturer’s
warranty. Please see Samsara Warranty Policy at samsara.com/support for information on Samsara’s refrigeration unit defect repair coverage.
Attach Thermo King pigtail to Y-cable.Open Thermo King cabinet and electronics control
box (may require unbolting). Route reefer end of
Y-cable into control box via rear grommet.
4a3a
2
Determine desired location of AG24, as high on
trailer as possible.
Some options are: on top of reefer (avoiding airflow
of the cooling fan), inside reefer cabinet, or on the
outside of trailer.
Turn all power OFF.
For Thermo King, follow steps 3a-6a.
For Carrier, follow steps 3b-7b.
1
THERMO KING steps 3a-6a
J12 J13
J10
Reefer cable Thermo King pigtail

Questions? samsara.com/support AG24 Installation Guide 3
4b3b
6b5b
7b 8
Thoroughly clean mounting location with cleaning wipe.Plug Samsara Carrier pigtail into the DM circuit.
Proceed to step 8.
If Display Module (DM) circuit is in use, unplug the
engine harness.
If engine harness was unplugged, re-plug it into
Samsara’s extra adaptor (located on the Carrier pigtail).
Attach Carrier pigtail to Y-cable.Open Carrier unit so that the back of the Display
Module (DM) is accessible.
CARRIER steps 3b-7b
Carrier pigtail
Cleaning
wipe

Questions? samsara.com/support AG24 Installation Guide 4
109
11 12
1413
Turn ON power switches to complete install.Connect 7-way cable to 7-way trailer connector.
See connection pin diagram illustrated above (some
trailers may vary). Connect BLUE (POS+) lead to Aux
power (BLU), BROWN (POS+) lead to tail lights (BRN),
and WHITE (NEG-) lead to ground (WHT). If backup
power is not desired, BROWN (POS+) lead can be left
floating.
Plug AG24 end of Y-cable into AG24 and twist to
secure. AG light turns on for 30 seconds when
correct.
Run 7-way cable along frame to trailer connector.
Fasten to trailer with zip ties and self-tapping
screws.
Mount AG24 onto mounting plate with 4 flat-end
screws (bag 2).
Attach mounting plate with adhesive. Secure with 4
self-tapping screws (bag 1) if desired.
