Samsara AG24 User manual

Asset Gateway - AG24
DRY TRAILER INSTALL GUIDE
Questions? samsara.com/support
What’s included:
Bullet Connectors Ring Terminals Cleaning Wipes
4x Flat-End Screws
4x Self-Tapping Screws
1× Asset Gateway
1× Mounting Plate
Zip Ties
1x 7-Way Cable

34
1
Select desired mounting location and clean
thoroughly with cleaning wipe.
Mount AG onto mounting plate with 4 flat-end
screws (Bag 2).
Plug cable into AG.
2
Attach mounting plate with adhesive. Secure with
4 self-tapping screws (Bag 1) if desired.
Mount with sun exposure for best solar charging.
5 6
Connect cable to 7-way. AG light turns on for 30
seconds if correct.
AG will operate in real time when power is supplied to
the 7-way. When power is not available via the 7-way,
AG will run off of internal battery in power-save mode
(periodic check-ins, not real time).
Run cable to 7-way. Fasten to trailer with zip ties.
WHT
BRN
BLU
White (NEG-)
Brown (POS+)
Blue (POS+)
