Sauder Camarin Series User manual

NOTE: THIS INSTRUCTION
BOOKLET CONTAINS IMPORTANT
SAFETY INFORMATION.
PLEASE READ AND KEEP FOR
FUTURE REFERENCE.
English pg 1-26
Français pg 27-29
Español pg 30-32
Lot # 362230 05/16/14
Purchased: __________________
Be sure to give us a ring before
making any returns. 1-800-523-3987
Desk
Camarin Collection | 414468
Need help? Visit Sauder.com to view video assembly tips or chat with a live rep.
Prefer the phone? Call 1-800-523-3987.
Share your journey!
sauder.com
Sit and surf.

Table of Contents Assembly Tools Required
2-3
4-5
6-26
27-29
30-32
33-34
35
Part Identification
Hardware Identification
Assembly Steps
Français
Español
Safety
Warranty
Hammer
Not actual size
No. 2 Phillips Screwdriver
Tip Shown Actual Size
A RIGHT END (1)
B LEFT END (1)
C UPRIGHT (1)
D TOP (1)
E BOTTOM (1)
F MODESTY PANEL (1)
G SHELF (1)
H BACK (1)
I BRACE (1)
J SMALL DRAWER FRONT (1)
K LARGE DRAWER FRONT (1)
L FRONT/BACK SKIRT (2)
M SIDE SKIRT (2)
N PENCIL DRAWER FRONT (1)
O PENCIL DRAWER BACK (1)
P PENCIL DRAWER SIDE (2)
Q PENCIL DRAWER BOTTOM (1)
RLEFT FRONT/RIGHT
REAR FOOT (2)
SRIGHT FRONT/LEFT
REAR FOOT (2)
T FRONT LEG (1)
U REAR LEG (1)
D14 LARGE DRAWER
RIGHT SIDE (1)
D15 LARGE DRAWER
LEFT SIDE (1)
D20 SMALL DRAWER
RIGHT SIDE (1)
D21 SMALL DRAWER
LEFT SIDE (1)
D74 SMALL DRAWER BACK (1)
D78 LARGE DRAWER BACK (1)
D716 DRAWER BOTTOM (2)
414468 www.sauder.com/servicesPage 2
Part Identification
åWhile not all parts are labeled, some of the parts will have a label or an inked letter on the edge
to help distinguish similar parts from each other. Use this part identification to help identify similar parts.

Part Identification
A
B
C
D
E
F
G
H
I
J
K
L
L
M
M
N
OP
P
Q
R
R
S
S
T
U
D14
D15
D21
D20
D74
D716
D716
D78
414468www.sauder.com/services Page 3

åScrews are shown actual size. You may receive extra hardware with your unit.
Hardware Identification
GROMMET - 1
10P
CAM COVER - 4
12P
HIDDEN CAM - 21
1F CAM SCREW - 6 8F
CAM DOWEL - 15
2F
METAL
BRACKET - 6
4G HINGE - 2 12H
METAL PIN - 7
1R
NAIL - 22
1N
GROMMET CAP - 1
1P
FILE GLIDE - 2
4B
RIGHT CABINET RAIL - 1
VLEFT CABINET RAIL - 1 WRIGHT DRAWER SLIDE - 1 XLEFT DRAWER SLIDE - 1 Y
10A SLIDE CAM - 4
31G CORNER
BRACKET - 4 KNOB - 3
48K
414468 www.sauder.com/servicesPage 4
40CA CABINET RIGHT - 2 40CB CABINET LEFT - 2 40CC DRAWER RIGHT - 2 40CD DRAWER LEFT - 2

Hardware Identification
åScrews are shown actual size. You may receive extra hardware with your unit.
BLACK 1-7/8" FLAT HEAD SCREW - 12
2S
BLACK 1-1/4" FLAT HEAD SCREW - 2
2S74S
BLACK 9/16" LARGE HEAD SCREW - 36
1S
18S BROWN 1" FLAT HEAD SCREW - 4 3S GOLD 5/16" FLAT HEAD SCREW - 20
SILVER 5/8" FLAT HEAD SCREW - 4
23S
SILVER 9/16" LARGE HEAD SCREW - 2
54S
BLACK 1-1/8" MACHINE SCREW - 3
21S
30S BLACK 1-9/16" FLAT HEAD SCREW - 8
414468www.sauder.com/services Page 5

Step 1 Look for this icon. It means a
video assembly tip is available at
www.sauder.com/services/tips
å Assemble your unit on a carpeted floor or on the empty
carton to avoid scratching your unit or the floor.
å Push twenty-one HIDDEN CAMS (1F) into the ENDS (A
and B), UPRIGHT (C), MODESTY PANEL (F), SHELF (G),
and BRACE (I). Then, insert the metal end of a CAM
DOWEL (2F) into each HIDDEN CAM, except in the long
edges of the LEFT END (B).
414468 www.sauder.com/servicesPage 6
B
C
A
F
G
I
Arrow
1F
2F
Arrow
1F
(21 used)
(15 used)
Arrow
1F
2F
Insert the metal end of the CAM
DOWEL into the HIDDEN CAM.
Arrow
Do not tighten the HIDDEN CAMS in this step.
Do not insert
CAM DOWELS
into these edges.
Arrow
The arrow in the HIDDEN
CAM must point toward the
hole in the edge of the board.
Hole
Scan this QR code or go to this address:
http://qr.sauder.com/?ID=803
to watch a video on how to assemble your unit.

å Turn six CAM SCREWS (8F) into the LEGS (T and U).
å Fasten the LEGS (T and U) to the LEFT END (B). Tighten
six HIDDEN CAMS.
Step 2
414468www.sauder.com/services Page 7
8F
B
T
T
U
U
(6 used)
1
2
Remember:
Righty tighty.
Lefty loosey.
Surface with
HIDDEN CAMS
Edge with HIDDEN CAMS
Angled edge
Angled edge

Step 3
å Fasten the CABINET RAILS (V and W) to the LEFT
END (B) and UPRIGHT (C). Use four GOLD 5/16" FLAT
HEAD SCREWS (3S).
å NOTE: The CABINET RAILS are marked "CABINET
RIGHT" and "CABINET LEFT" for easy identification.
414468 www.sauder.com/servicesPage 8
W
V
Surface with
HIDDEN CAMS
B
C
Roller end
Rounded edge
Edge with CAM DOWELS
Roller end
Surface without
HIDDEN CAMS
GOLD 5/16" FLAT HEAD SCREW
(4 used in this step)
3S

å Flip the UPRIGHT (C) over onto its opposite surface.
å Fasten the CABINET RIGHTS (40CA) to the RIGHT END (A)
and the CABINET LEFTS (40CB) to the UPRIGHT (C). Use
eight GOLD 5/16" FLAT HEAD SCREWS (3S) through
holes #1 and #4.
Step 4
414468www.sauder.com/services Page 9
1
2
34
C
A
Rounded edge
Edge with CAM DOWELS Roller end
Rounded edge
Roller end
1
2
3
4
Roller end
Surface with
HIDDEN CAMS
Surface with
HIDDEN CAMS
Roller end
GOLD 5/16" FLAT HEAD SCREW
(8 used in this step)
3S
1
2
34
1
2
3
4

Step 5
å Insert a METAL PIN (1R) into the hole in the TOP (D).
å Fasten the LEFT END (B) to the TOP (D). Tighten two
HIDDEN CAMS.
å NOTE: Be sure the PIN in the TOP inserts into the hole in
the END.
414468 www.sauder.com/servicesPage 10
1R
D
Surface with
more holes
B
Start Tighten
Arrow
Minimum
190 degrees
Caution
Risk of damage or
injury. HIDDEN CAMS
must be completely
tightened. HIDDEN
CAMS that are not
completely tightened
may loosen, and parts
may separate. To
completely tighten:
Arrow
Maximum
210 degrees
Rounded edge
Surface with
HIDDEN CAMS
Do not stand the unit upright without the
BACK fastened. The unit may collapse.
Caution

å Fasten the MODESTY PANEL (F) to the LEFT END (B).
Tighten three HIDDEN CAMS.
Step 6
414468www.sauder.com/services Page 11
Surface without
HIDDEN CAMS
B
F
Arrow
Minimum
190 degrees
Maximum
210 degrees

Step 7
å Fasten the UPRIGHT (C) to the TOP (D). Tighten two
HIDDEN CAMS.
å Fasten the UPRIGHT (C) to the MODESTY PANEL (F). Use
two BLACK 1-7/8" FLAT HEAD SCREWS (2S).
å Insert a METAL PIN (1R) into the hole in the UPRIGHT (C).
å Fasten the BRACE (I) to the UPRIGHT (C). Tighten the
HIDDEN CAM.
å NOTE: Be sure the PIN in the UPRIGHT inserts into the
hole in the BRACE.
414468 www.sauder.com/servicesPage 12
F
C
D
1R
I
Arrow
Minimum
190 degrees
Maximum
210 degrees
Rounded edge
Surface with
HIDDEN CAMS
BLACK 1-7/8" FLAT HEAD SCREW
(2 used in this step)
2S

å Fasten the SHELF (G) to the UPRIGHT (C). Tighten two
HIDDEN CAMS.
Step 8
414468www.sauder.com/services Page 13
Surface with
HIDDEN CAMS
C
G
Arrow
Minimum
190 degrees
Maximum
210 degrees
Rounded edge

Step 9
å Insert a METAL PIN (1R) into the hole in the BRACE (I).
å Fasten the RIGHT END (A) to the TOP (D), SHELF (G) and
BRACE (I). Tighten five HIDDEN CAMS.
å NOTE: Be sure the PIN in the BRACE inserts into the hole
in the END.
414468 www.sauder.com/servicesPage 14
G
I
A
1R
D
Surface without
HIDDEN CAMS.
Arrow
Minimum
190 degrees
Maximum
210 degrees
Edge with CAM DOWELS

å Fasten the BOTTOM (E) to the RIGHT END (A) and
UPRIGHT (C). Use four BLACK 1-7/8" FLAT
HEAD SCREWS (2S).
Step 10
414468www.sauder.com/services Page 15
E
C
A
Surface with
more holes
BLACK 1-7/8" FLAT HEAD SCREW
(4 used in this step)
2S
Rounded edge

Step 11
å Fasten six METAL BRACKETS (4G) to the SKIRTS (L and M ).
Use six BLACK 9/16" LARGE HEAD SCREWS (1S).
å NOTE: Be sure the BRACKETS are even with the edges of
the SKIRTS.
å Fasten the FRONT/BACK SKIRTS (L) to the BOTTOM (E).
Use two BLACK 9/16" LARGE HEAD SCREWS (1S)
å Insert a METAL PIN (1R) into the holes in the FEET (R and S).
å Push the PINS in the FEET into the holes in the SKIRTS.
414468 www.sauder.com/servicesPage 16
4G
1R
L
L
L
L
M
M
1R
E
S
S
R
R
(6 used)
BLACK 9/16" LARGE HEAD SCREW
(8 used for the METAL BRACKETS)
1S

å Fasten the SIDE SKIRTS (M) to the BOTTOM (E). Use four
BLACK 9/16" LARGE HEAD SCREWS (1S).
å Fasten the CORNER BRACKETS (31G) to the BOTTOM (E),
SIDE SKIRTS (M), and FEET (R and S). Use twenty-four BLACK
9/16" LARGE HEAD SCREWS (1S).
Step 12
414468www.sauder.com/services Page 17
31G
31G
31G
31G
E
M
M
R
R
S
S
BLACK 9/16" LARGE HEAD SCREW
(28 used for the METAL BRACKETS)
1S

Step 13
å Carefully turn your unit over onto its front edges. Lay the
BACK (H) over your unit.
å Make equal margins along all four edges of the BACK (H).
Push on opposite corners of your unit if needed to make
it "square".
å Fasten the BACK (H) to your unit using the NAILS (1N).
414468 www.sauder.com/servicesPage 18
H
Do not stand the unit upright without the
BACK fastened. The unit may collapse.
Caution
Unfinished surface
NAIL
(22 used in this step)
1N

å Fasten the PENCIL DRAWER SIDES (P) to the PENCIL DRAWER
BOTTOM (Q). Use four BLACK 1-7/8" FLAT HEAD SCREWS (2S).
å Fasten the PENCIL DRAWER BACK (O) to the PENCIL DRAWER
SIDES (P). Use two BLACK 1-7/8" FLAT HEAD SCREWS (2S).
å Fasten the PENCIL DRAWER BACK (O) to the PENCIL DRAWER
BOTTOM (Q). Use two BLACK 1-1/4" FLAT HEAD SCREWS (74S).
å NOTE: There are no pre-drilled holes in the bottom edge of the
PENCIL DRAWER BACK (O).
Step 14
414468www.sauder.com/services Page 19
Finished surface
Short finished edge
Short finished edge
These holes must
be facing up.
P
P
O
Q
BLACK 1-1/4" FLAT HEAD SCREW
(2 used in this step)
74S
BLACK 1-7/8" FLAT HEAD SCREW
(6 used in this step)
2S

Step 15
å Fasten the HINGES (12H) to the PENCIL DRAWER
FRONT (N). Use four SILVER 5/8" FLAT
HEAD SCREWS (23S).
å Fasten the HINGES (12H) to the PENCIL DRAWER
BOTTOM (Q). Use two SILVER 9/16" LARGE
HEAD SCREWS (54S).
414468 www.sauder.com/servicesPage 20
12H
Q
N
SILVER 5/8" FLAT HEAD SCREW
(4 used in this step)
23S
SILVER 9/16" LARGE HEAD SCREW
(2 used in this step)
54S
