NOTE: THIS INSTRUCTION
BOOKLET CONTAINS IMPORTANT
SAFETY INFORMATION.
PLEASE READ AND KEEP FOR
FUTURE REFERENCE.
sauder.com
CONTACT US FIRST
BEFORE MAKING ANY RETURNS TO THE STORE.
sauder.com
CONTACT US FIRST
BEFORE MAKING ANY RETURNS TO THE RETAILER.
Visit sauder.com/service to order replacement parts, view video assembly tips, or chat with a live rep.
Prefer the phone? Give us a ring at 1-800-445-1527.
Customer Service is available Monday-Friday - 9 a.m. to 5:30 p.m. EST (except holidays)
Sauder.com
Share your journey!
Enlish p 1-45
Français p 46-50
Español p 51-55
Lot # 570165 08/05/21
Purchased: __________________
L-Shaped Desk
Cannery Bride Collection | Model 429556
Sit and surf.

Part Identification
Hardware Identification
Hardware Usage Guide
Assembly Steps
Français
Español
Safety
Warranty
No. 2 Phillips Screwdriver
Tip Shown Actual Size
Table of Contents Assembly Tools Required
3
4-5
6
7-45
46-50
51-55
56-58
59
Pae 2 www.sauder.com/service 429556

Part Identification
åWhile not all parts are labeled, some of the parts will have a label or an inked letter on the edge
to help distinguish similar parts from each other. Use this part identification to help identify similar parts.
Now you know
our ABCs.
A LEFT END (1)
B RIGHT END (1)
C LEFT UPRIGHT (1)
D RIGHT UPRIGHT (1)
E TOP (1)
F LEFT BOTTOM (1)
G LEFT MODESTY PANEL (1)
H BACK (2)
J MODESTY PANEL MOLDING (2)
K SKIRT (2)
L SMALL DRAWER FRONT (4)
M SMALL LEFT DRAWER SIDE (4)
N SMALL RIGHT DRAWER SIDE (4)
O SMALL DRAWER BACK (4)
P SMALL DRAWER BOTTOM (4)
Q LARGE DRAWER FRONT (2)
R LARGE LEFT DRAWER SIDE (2)
S LARGE RIGHT DRAWER SIDE (2)
T LARGE DRAWER BACK (2)
U LARGE DRAWER BOTTOM (2)
V BACK SKIRT (2)
W LEG (1)
X SMALL TOP (1)
Y RIGHT BOTTOM (1)
Z RIGHT MODESTY PANEL (1)
AB
CD
E
F
G
H J JH
K
L
M N
O
P
Q
R
S
T
U
W
X
Y
Z
K
Q
U
P
P
P
L
L
L
R
S
T
N
N
M
M
O
NM
V
V
O
O
Pae 3www.sauder.com/service429556

Hardware Identification
åScrews are shown actual size. You may receive extra hardware with your unit.
(EXTENSION SET SHOWN SEPARATED)
1SHORT EXTENSION
RAIL - 8 2SHORT EXTENSION SLIDE - 8
(EXTENSION SET SHOWN SEPARATED)
4LONG EXTENSION
SLIDE - 4
3LONG EXTENSION
RAIL - 4
5FILE GLIDE - 4 6FILE
HANGER  4
LARGE HIDDEN
CAM - 70
7SMALL HIDDEN
CAM - 16
8
CAM SCREW - 86
9LARGE WOOD
DOWEL - 62
10 METAL BRACKET - 8 12
PULL - 6
13
SMALL WOOD
DOWEL - 48
11
GROMMET
WITH CAP- 3
14 15 CORNER
BRACKET - 3
Pae 4 www.sauder.com/service 429556

Hardware Identification
åScrews are shown actual size. You may receive extra hardware with your unit.
APPLIQUE CARD - 2
17
3/8" FLAT HEAD SCREW - 76
22
1/2" PAN HEAD SCREW - 28
21
1-1/2" FLAT HEAD SCREW - 16
18 19 78" MACHINE SCREW  6
3/4" PAN HEAD SCREW - 4
20
16 CONNECTOR PLATE - 1
Pae 5www.sauder.com/service429556

Hardware Usage Guide
HOW TO USE A HIDDEN CAM & CAM SCREW OR CAM DOWEL
NOTE: Various CAM SCREWS or a CAM DOWEL may be used.
Cam Screws Cam Dowel
Turn the CAM SCREW or
gently tap the CAM DOWEL
until the shoulder is against
the surface of the part.
1.
Hidden Cam
Arrow
Push a HIDDEN CAM into
the part. The arrow in the
HIDDEN CAM must point
toward the hole in the
edge of the board.
Hole
2.
3.
1
2
Insert the CAM SCREW or CAM DOWEL into the
HIDDEN CAM. Tighten the HIDDEN CAM.
Pae 6 www.sauder.com/service 429556

Step 1 Look for this icon. It means a video assembly tip is
available at www.sauder.com/service/tips
Find the numbered video or scan the QR code.
å Assemble your unit on a carpeted floor or on the empty
carton to avoid scratchin your unit or the floor.
å Push fourteen HIDDEN CAMS (7) into the LEFT
BOTTOM (F), a BACK (H), and a SKIRT (K).
å Then, turn two CAM SCREWS (9) into the exact holes
shown in the SKIRT (K).
Some assembly
(and snacks) required.
1
9
(14 used)
H
K
F
7
Arrow
7
Arrow
Arrow
7
7
Arrow
Arrow
7
Pae 7www.sauder.com/service429556

å Insert two LARGE WOOD DOWELS (10) into the SKIRT (K).
å Fasten the SKIRT (K) to the LEFT BOTTOM (F). Tihten two
HIDDEN CAMS.
å NOTE: Be sure the LARGE WOOD DOWELS in the SKIRT
insert into the LEFT BOTTOM.
å Insert two LARGE WOOD DOWELS (10) into the BACK (H).
å Push the LEFT BOTTOM (F) onto the LARGE WOOD
DOWELS (10) in the BACK (H).
Step 2
K
F
H
F
10
Surface with
HIDDEN CAMS
These small holes
should be here.
10
Surface with
HIDDEN CAMS
K
Surface with
HIDDEN CAMS
1
Pae 8 www.sauder.com/service 429556

Step 3
A
1
å Turn six CAM SCREWS (9) into the LEFT END (A).
å Push three HIDDEN CAMS (7) into the LEFT END (A).
9
7
Arrow
Pae 9www.sauder.com/service429556
9

Step 4
A
å Separate the SHORT EXTENSION SLIDES (2) from the SHORT EXTENSION RAILS (1) as shown in the upper diaram
below. Be prepared, the parts are reasy.
å Fasten two SHORT EXTENSION RAILS (1) to the LEFT END (A). Use six 3/8" FLAT HEAD SCREWS (22).
å NOTE: For each EXTENSION RAIL, turn a SCREW into the hole shown in the enlared diaram. Then, slide the inner
cartride of the EXTENSION RAIL in to find the other holes that lines up with the holes in the LEFT END. Turn a
SCREW into these holes.
å NOTE: The SHORT EXTENSION SLIDES will be used later for the SMALL DRAWERS.
3/8" FLAT HEAD SCREW
(6 used in this step)
22
Push the black lever and pull the SLIDE from the RAIL.
1
2
1
1
Open end
7
Pae 10 www.sauder.com/service 429556

Step 5
A
å Separate the LONG EXTENSION SLIDES (4) from the LONG EXTENSION RAILS (3) as shown in the upper diaram
below. Be prepared, the parts are reasy.
å Fasten a LONG EXTENSION RAIL (3) to the LEFT END (A). Use four 3/8" FLAT HEAD SCREWS (22).
å NOTE: For each EXTENSION RAIL, turn a SCREW into the hole shown in the enlared diaram. Then, slide the inner
cartride of the EXTENSION RAIL in to find the other holes that lines up with the holes in the LEFT END. Turn a
SCREW into these holes.
å NOTE: The LONG EXTENSION SLIDES will be used later for the LARGE DRAWERS.
3
3/8" FLAT HEAD SCREW
(4 used in this step)
22
Push the black lever and pull the SLIDE from the RAIL.
3
4
Open end
7
Pae 11www.sauder.com/service429556

Step 6
A
H
F
å Insert four LARGE WOOD DOWELS (10) into the
LEFT END (A).
å Carefully fasten the BOTTOM (F), BACK (H) and SKIRT (K)
to the LEFT END (A). Tihten six HIDDEN CAMS
å NOTE: Be sure the WOOD DOWELS in the LEFT END
insert into the BACK and BOTTOM.
1
Surface with
HIDDEN CAMS
Surface with
HIDDEN CAMS
Open end
Pae 12 www.sauder.com/service 429556
K
10

å Insert two LARGE WOOD DOWELS (10) into the LEFT
END (A).
å Push a BACK SKIRT (V) onto the LARGE WOOD
DOWELS (10) in the LEFT END (A).
Step 7
H
F
V
A
10
The seam
should be here.
Pae 13www.sauder.com/service429556

Step 8
C
C
å Turn five CAM SCREWS (9) into the LEFT UPRIGHT (C).
å Flip the LEFT UPRIGHT (C) over and turn six CAM
SCREWS (9) into the opposite surface.
å Then, push three HIDDEN CAMS (7) into the LEFT
UPRIGHT (C).
F
L
I
P
O
V
E
R
9
1
7
Arrow
9
9
Pae 14 www.sauder.com/service 429556

Step 9
C
å Fasten two SHORT EXTENSION RAILS (1) to the LEFT UPRIGHT (C). Use six 3/8" FLAT HEAD SCREWS (22).
å NOTE: For each EXTENSION RAIL, turn a SCREW into the hole shown in the enlared diaram. Then, slide the inner
cartride of the EXTENSION RAIL in to find the other holes that lines up with the holes in the LEFT UPRIGHT. Turn a
SCREW into these holes.
3/8" FLAT HEAD SCREW
(6 used in this step)
22
1
1
Open end
Pae 15www.sauder.com/service429556

Step 10
C
å Fasten a LONG EXTENSION RAIL (3) to the LEFT UPRIGHT (C). Use four 3/8" FLAT HEAD SCREWS (22).
å NOTE: For each EXTENSION RAIL, turn a SCREW into the hole shown in the enlared diaram. Then, slide the inner
cartride of the EXTENSION RAIL in to find the other holes that lines up with the holes in the LEFT UPRIGHT. Turn a
SCREW into these holes.
3
3/8" FLAT HEAD SCREW
(4 used in this step)
22
Open end
Pae 16 www.sauder.com/service 429556

å Insert six LARGE WOOD DOWELS (10) into the
LEFT BOTTOM (F), BACK (H) and BACK SKIRT (V).
å Fasten LEFT UPRIGHT (C) to the LEFT BOTTOM (F), BACK (H)
and SKIRT (K). Tihten six HIDDEN CAMS.
å NOTE: Be sure the LARGE WOOD DOWELS in the LEFT
BOTTOM, BACK and BACK SKIRT insert into the LEFT UPRIGHT.
Step 11
H
F
C
Surface without
HIDDEN CAMS
1
V
Pae 17www.sauder.com/service429556
10
K

å Push fourteen HIDDEN CAMS (7) into the BACK (H),
SKIRT (K) and RIGHT BOTTOM (Y).
å Then, turn two CAM SCREWS (9) into the exact holes
shown in the SKIRT (K).
Step 12
Y
9
(14 used)
H
K
7
Arrow
7
Arrow
Arrow
7
7
Arrow
Arrow
7
1
Pae 18 www.sauder.com/service 429556

Step 13
Y
Y
H
å Insert two LARGE WOOD DOWELS (10) into the SKIRT (K).
å Fasten the SKIRT (K) to the RIGHT BOTTOM (Y). Tihten
two HIDDEN CAMS.
å NOTE: Be sure the LARGE WOOD DOWELS in the SKIRT
insert into the RIGHT BOTTOM.
å Insert two LARGE WOOD DOWELS (10) into the BACK (H).
å Push the RIGHT BOTTOM (Y) onto the LARGE WOOD
DOWELS (10) in the BACK (H).
K
10
Surface with
HIDDEN CAMS
10
Surface with
HIDDEN CAMS
K
Surface with
HIDDEN CAMS
1
These small holes
should be here.
Pae 19www.sauder.com/service429556

Step 14
D
D
å Turn five CAM SCREWS (9) into the RIGHT UPRIGHT (D).
å Flip the RIGHT UPRIGHT (D) over and turn six CAM
SCREWS (9) into the opposite surface.
å Then, push three HIDDEN CAMS (7) into the RIGHT
UPRIGHT (D).
F
L
I
P
O
V
E
R
9
1
7
Arrow
9
