Sauder Carson Forge Series User manual

NOTE: THIS INSTRUCTION
BOOKLET CONTAINS IMPORTANT
SAFETY INFORMATION.
PLEASE READ AND KEEP FOR
FUTURE REFERENCE.
English pg 1-10
Français pg 11-12
Español pg 13-14
Lot # 356130 10/16/13
Purchased: __________________
Be sure to give us a ring before
making any returns. 1-800-523-3987
Mirror
Carson Forge Collection | 415556
Need help? Visit Sauder.com to view video assembly tips or chat with a live rep.
Prefer the phone? Call 1-800-523-3987.
Share your journey!
sauder.com
Who's the fairest
of them all?

Part Identification
åWhile not all parts are labeled, some of the parts will have a label or an inked letter on the edge
to help distinguish similar parts from each other. Use this part identification to help identify similar parts.
A MIRROR PANEL (1)
B TOP/BOTTOM RAIL (2)
C SIDE RAIL (2)
D ATTACHMENT BAR (2)
E CHANNEL FRAME (1)
F MIRROR (1)
Table of Contents Assembly Tools Required
2
3
4-10
11-12
13-14
15
Part Identification
Hardware Identification
Assembly Steps
Français
Español
Warranty
No. 2 Phillips Screwdriver
Tip Shown Actual Size
415556 www.sauder.com/servicesPage 2
A
B
C
D
E
F
B
C
D

Hardware Identification
åScrews are shown actual size. You may receive extra hardware with your unit.
415556www.sauder.com/services Page 3
BLACK 9/16" LARGE HEAD SCREW - 13
1S
WOOD DOWEL - 4
15F
HIDDEN CAM - 8
1F
GLUE - 1
8M
BROWN 7/16" LARGE HEAD SCREW - 8
6S
MIRROR HANGER - 2
52M
DOUBLE DOWEL - 4
22F

Step 1 Look for this icon. It means a
video assembly tip is available at
www.sauder.com/services/tips
å Assemble your unit on a carpeted floor or on the empty
carton to avoid scratching your unit or the floor.
å Push eight HIDDEN CAMS into the RAILS (B and C).
415556 www.sauder.com/servicesPage 4 415556 www.sauder.com/servicesPage 4
Arrow
1F
Arrow
The arrow in the HIDDEN
CAM must point toward the
hole in the edge of the board.
Hole
B
C
B
C
(8 used)

å Fill four holes in the TOP/BOTTOM RAILS (B) 1/4 to 1/2 full
with GLUE (8M). Then, insert four WOOD DOWELS (15F)
into the holes. Wipe away the excess GLUE.
Step 2
415556www.sauder.com/services Page 5 415556www.sauder.com/services Page 5
B
B
Fill the holes 1/4 to 1/2 full with GLUE.
Inspect the parts thoroughly before
assembling. Disassembly of glued
parts is extremely dicult.
Caution
!
8M
15F
15F
Surface with
HIDDEN CAMS
Surface with
HIDDEN CAMS

å Insert one end of four DOUBLE DOWELS (22F) into the HIDDEN
CAM holes in the SIDE RAILS (C). Tighten four HIDDEN CAMS.
å Fill the holes in the SIDE RAILS (C) 1/4 to 1/2 full with GLUE (8M).
å Fasten the TOP/BOTTOM RAILS (B) to the SIDE RAILS (C). Tighten
four HIDDEN CAMS.
å NOTE: Be sure the WOOD DOWELS in the TOP/BOTTOM RAILS (B)
insert into the SIDE RAILS (C). Wipe away the excess GLUE.
Step 3
415556 www.sauder.com/servicesPage 6
8M
B
C
B
C
Surface with
HIDDEN CAMS
Surface with
HIDDEN CAMS
Fill the holes 1/4 to 1/2 full with GLUE.
Inspect the parts thoroughly before
assembling. Disassembly of glued
parts is extremely dicult.
Caution
!
22F
8M
22F
Surface
with
HIDDEN
CAMS
Surface
with
HIDDEN
CAMS
1
2

å Place the MIRROR (F) on top of the MIRROR PANEL (A).
å Wrap the CHANNEL FRAME (E) around both the MIRROR
and MIRROR PANEL.
å Carefully turn the unit over and fasten the CHANNEL
FRAME (E) to the MIRROR PANEL (A). Use eight BROWN
7/16" LARGE HEAD SCREWS (6S).
Step 4
415556www.sauder.com/services Page 7
A
E
F
Surface
without holes
Mirrored
surface
Surface
with holes
A
E
BROWN 7/16" LARGE HEAD SCREW
(8 used in this step)
6S
Edge without holes
Edge without holes

å Fasten the ATTACHMENT BAR (D) to the MIRROR PANEL (A).
Use five BLACK 9/16" LARGE HEAD SCREWS (1S).
å NOTE: The middle SCREW will go through both BARS.
Step 5
415556 www.sauder.com/servicesPage 8
BLACK 9/16" LARGE HEAD SCREW
(5 used in this step)
1S
A
D
D

å This unit can be hung vertically as shown in the upper diagram or
horizontally as shown in the lower diagram.
å Fasten two MIRROR HANGERS (52M) to the TOP/BOTTOM RAIL (B) as
shown in the upper diagram to hang the MIRROR vertically. Use four BLACK
9/16" LARGE HEAD SCREWS (1S).
å Fasten two MIRROR HANGERS (52M) to the TOP/BOTTOM RAILS (B)
as shown in the lower diagram to hang the MIRROR horizontally. Use four
BLACK 9/16" LARGE HEAD SCREWS (1S).
Step 6
415556www.sauder.com/services Page 9
BLACK 9/16" LARGE HEAD SCREW
(4 used in this step)
1S
B
B
B
52M Mirror hanging vertically
Mirror hanging horizontally 52M

Step 7
415556 www.sauder.com/servicesPage 10
D
D
B
B
Surface without
mirror hangers
Mirrored
surface
BLACK 9/16" LARGE HEAD SCREW
(4 used in this step)
1S
å Fasten the MIRROR assembly to the TOP/BOTTOM RAILS (B).
Use four BLACK 9/16" LARGE HEAD SCREWS (1S) through
the ATTACHMENT BARS (D).
å This completes assembly. Clean with your favorite furniture
polish or a damp cloth. Wipe dry.
