Sauder 410375 User manual

NOTE
register your new purchase online
www.sauder.com
For immediate service,
our website is available
24 hours a day, 7 days a week
to order replacement parts,
access assembly tips,
register your product,
and view Sauder products.
Mon-Fri - 9am-5:30pm ET
United States and Canada (except holidays)
Consumer Services 1-800-523-3987
DO NOT RETURN YOUR UNIT
TO THE STORE
Contact us first
Most replacement parts ship from our
facility in one or two business days.
www.sauder.com
THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION.
PLEASE READ AND KEEP FOR FUTURE REFERENCE.
Record the date you purchased this unit and save the booklet for
future reference.
If you ever need to contact Sauder about this unit, refer to the lot #
and the model # when calling our toll-free number. For more
information about our furniture, company, or to order replacement
parts, please visit our web site.
06 / 08 / 12
Lot #: 345560
Date Purchased: ____________
5-Shelf Bookcase
Model # 410375
Assembly Instructions
The back pages of this book are French and Spanish
instructions.
Les pages de arrière de ce livre sont des instructions
françaises en español.
Se incluyen las instrucciones françaises en español en
el dorso de este folleto. Para facilitar su uso, se puede
desprenderlas fácilmente.

RIGHT
END - 1
ALEFT
END - 1
BLOWER RIGHT
END - 1
C
LOWER LEFT
END - 1
DTOP - 1 EBOTTOM - 1 F
SHELF - 1
G
BACK - 1
I
LARGE
BACK - 1
H
ADJUSTABLE
SHELF - 3
JEND
MOLDING - 2
K
PARTS IDENTIFICATION
While not all parts are labeled, some of the parts will have a label or an inked letter on the edge to help
While not all parts are labeled, some of the parts will have a label or an inked letter on the edge to help
distinguish similar parts from each other. Use this
distinguish similar parts from each other. Use this
PARTS IDENTIFICATION
PARTS IDENTIFICATION
to help identify similar parts.
to help identify similar parts.
410375

BASE - 1
LTOP
MOLDING - 1
MSHELF
MOLDING - 3
N
SKIRT - 1
OLOWER END
MOLDING - 2
P
PART IDENTIFICATION (CONTINUED):
HARDWARE IDENTIFICATION
SAFETY BRACKET - 1
S
CAM COVER - 8
U
HIDDEN CAM - 12
Q2 CAM DOWEL - 12 R2
ANGLE BRACKET - 8
T
HOLE PLUG - 3
VMETAL PIN - 12 W
410375

SCREWS SHOWN ACTUAL SIZE
SCREWS SHOWN ACTUAL SIZE
Using a SCREW that is too long will caus
Using a SCREW that is too long will caus
e
e
d
d
a
a
mage. Before beginning assembly, separate
mage. Before beginning assembly, separate
each type of SCREW. Carefully study the SCREW diagrams below
each type of SCREW. Carefully study the SCREW diagrams below
(
(SHOWN ACTUAL SIZE
)
)
.
.
Pay close attention to the color of each SCREW. You may receive extra hardware with your unit.
Pay close attention to the color of each SCREW. You may receive extra hardware with your unit.
HAMMER
1
ASSEMBLY TOOLS REQUIRED
NO. 2 PHILLIPS SCREWDRIVER
TIP SHOWN ACTUAL SIZE
BLACK 1-1/8” PAN HEAD SCREW - 3
Y
BLACK 9/16” LARGE HEAD SCREW - 17
Z
NAIL - 55
AA
BLACK 1-7/8” FLAT HEAD SCREW - 5
X
410375

2
A
B
D
C
F
Do not tighten the HIDDEN CAMS in this step.
Arrow
Insert the metal end of the CAM
DOWEL into the HIDDEN CAM.
www.sauder.com/services
Look for this icon. It means a
video assembly tip is available at:
www.sauder.com/services/tips
Assemble your unit on a carpeted floor or on the empty carton to avoid scratching your unit or the floor.
Push twelve HIDDEN CAMS (Q2) into the ENDS (A and B), LOWER ENDS (C and D), and BOTTOM (F). Then, insert the
metal end of the CAM DOWELS (R2) into the HIDDEN CAMS.
410375
(12 used)
Arrow
Q2
R2

3
A
B
E
Notched edge
Notched edge
Long finished edge
Caution
Risk of damage or
injury. Hidden Cams
must be completely
tightened. Hidden
Cams that are not
completely tightened
may loosen, and parts
may separate.
To completely tighten:
Start Tighten
Arrow
Arrow
Maximum
210 degrees
Minimum
190 degrees
Fasten the ENDS (A and B) to the TOP (E). Tighten four HIDDEN CAMS.
410375

4
Fasten the TOP MOLDING (M) to the TOP (E). Use three BLACK 1-1/8” PAN HEAD SCREWS (Y).
Insert three HOLE PLUGS (V) into the holes in the TOP MOLDING (M).
E
VCurved edge
M
BLACK 1-1/8” PAN HEAD SCREW
(3 used in this step)
Y
www.sauder.com/services
410375

5
A
B
K
K
Slide the END MOLDINGS (K) onto the notched edges of the ENDS (A and B).
* U.S. Patent No. 5,499,886
Slide the END MOLDINGS (K)
onto the notched edges.
www.sauder.com/services
410375

6
A
B
Fasten the SHELF (G) to the ENDS (A and B). Use four BLACK 1-7/8” FLAT HEAD SCREWS (X).
Long finished edge
G
Surface with
more holes
www.sauder.com/services
X
BLACK 1-7/8” FLAT HEAD SCREW
(4 used in this step)
410375

7
Fasten the LOWER LEFT END (D) to the SHELF (G). Tighten two HIDDEN CAMS.
Notched edge
DG
Maximum
210 degrees
Minimum
190 degrees
Arrow
www.sauder.com/services
