Sauder Harbor View 415002 User manual

PLEASE CONTACT US
BEFORE RETURNING
YOUR UNIT TO THE STORE
1-800-523-3987
www.sauder.com
Made in the USA
Archbold, OH
NOTE: THIS INSTRUCTION BOOKLET CONTAINS
IMPORTANT SAFETY INFORMATION.
PLEASE READ AND KEEP FOR FUTURE REFERENCE.
Lot #: 355369 08 / 21 / 13
Date Purchased: ____________________
English.................... Page 1-12
Français...............Pages 13-15
Espanol.............Páginas 16-18
415002
Full/Queen Headboard
Harbor View Collection

ASSEMBLY TOOLS REQUIRED
Hammer
No. 2 Phillips Screwdriver
Tip Shown Actual Size
ADULT ASSEMBLY REQUIRED
TABLE OF CONTENTS
Part Identification.......................3
Hardware Identification .............4
Assembly Steps....................5-12
Français..............................13-15
Espanol...............................16-18
Warranty...................................19
Page 2 www.sauder.com/services 415002

PART IDENTIFICATION: While not all parts are labeled, some of the parts will have a label or an inked
letter on the edge to help distinguish similar parts from each other. Use this PART IDENTIFICATION to help
identify similar parts.
A END 2
B TOP 1
C PANEL 3
D BACK 1
E VALANCE 1
F MOLDING 1
G HORIZONTAL MOLDING 3
H VERTICAL MOLDING 2
I RIGHT LEG 1
J LEFT LEG 1
K POST 2
Page 3
www.sauder.com/services415002
A
B
C
D
E
F
G
H
I
J
K
K
C
C
A
G
G
H

HARDWARE IDENTIFICATION
Screws are shown actual size. You may receive extra hardware with your unit.
Page 4 www.sauder.com/services 415002
NUT - 4
24M
WASHER - 4
13M
PROPEL NUT - 4
14M
SILVER 2" BOLT - 4
94S
BLACK 9/16" LARGE HEAD SCREW - 16
1S
ANGLE BRACKET - 8
5G
BLACK 1-1/4" FLAT HEAD SCREW - 9
7S
SILVER 1-1/4" BOLT - 4
48S
BLACK 1-7/8" FLAT HEAD SCREW - 5
2S
BROWN 1" FLAT HEAD SCREW - 28
12S
METAL PIN - 2
1R
BLACK 2" PAN HEAD SCREW - 6
66S
HEADBOARD
BRACKET - 2
42G

Look for this icon. It means a video
assembly tip is available at:
www.sauder.com/services/tips
1
1
S
t
e
p
Page 5
www.sauder.com/services415002
Assemble your unit on a carpeted floor or on the empty carton to avoid scratching your unit or the floor.
Fasten the VALANCE (E) to the TOP (B). Use five BLACK 1-7/8" FLAT HEAD SCREWS (2S).
Fasten two POSTS (K) to the TOP (B). Use four BLACK 1-1/4" FLAT HEAD SCREWS (7S).
BLACK 1-7/8" FLAT HEAD SCREW
(5 used for the VALANCE)
2S
BLACK 1-1/4" FLAT HEAD SCREW
(4 used for the POSTS)
7S
B
E
K
K
B
Curved edge
Finished edge
Finished surface

Page 6 www.sauder.com/services 415002
2
2
S
t
e
p
Fasten three PANELS (C) and two VERTICAL MOLDINGS (H) to the BACK (D). Use sixteen BROWN 1" FLAT
HEAD SCREWS (12S).
NOTE: The locator hole on the VERTICAL MOLDING must be located toward the bottom.
C
D
H
C
C
H
BROWN 1" FLAT HEAD SCREW
(16 used in this step)
12S
Finished surface
H
Unfinished
surface
There is a locator hole on the
unfinished surface of each
VERTICAL MOLDING.
These holes
must be here.
This edge and surface
have no holes.

Page 7
www.sauder.com/services415002
3
3
S
t
e
p
Fasten three HORIZONTAL MOLDINGS (G) to the BACK (D). Use six BROWN 1" FLAT HEAD SCREWS (12S).
NOTE: The HORIZONTAL MOLDINGS (G) must be against the PANELS (C).
BROWN 1" FLAT HEAD SCREW
(6 used in this step)
12S
Finished edge
Finished surface
Finished surface Finished surface
C
C
C
DG
G
G

Page 8 www.sauder.com/services 415002
4
4
S
t
e
p
Fasten eight ANGLE BRACKETS (5G) to the ENDS (A). Use eight BLACK 9/16" LARGE HEAD SCREWS (1S).
Fasten the ENDS (A) to the LEGS (I and J). Use eight BLACK 9/16" LARGE HEAD SCREWS (1S) through the ANGLE
BRACKETS (5G) on the ENDS (A)
Fasten the BACK (D) to the LEGS (I and J). Use six BROWN 1" FLAT HEAD SCREWS (12S)..
BLACK 9/16" LARGE HEAD SCREW
(16 used in this step)
1S
D
I
J
BROWN 1" FLAT HEAD SCREW
(6 used in this step)
12S
These holes
must be here.
These holes
must be here.
Surface with holes
(8 used)
5G
A
A
I
J

Page 9
www.sauder.com/services415002
5
5
S
t
e
p
NOTE: You may need someone's help to turn the unit over.
Insert two METAL PINS (1R) into the LEGS (I and J).
Fasten the MOLDING (F) to the PANELS (C). Use six BLACK 2" PAN HEAD SCREWS (66S).
NOTE: Be sure the METAL PINS (1R) in the LEGS (I and J) insert into the holes in the MOLDING (F).
Fasten the TOP (B) to the MOLDING (F). Use five BLACK 1-1/4" FLAT HEAD SCREWS (7S).
C
F
I
J
C
C
1R Flat edge BLACK 2" PAN HEAD SCREW
(6 used in this step)
66S
1R
Surface with
more holes
B
BLACK 1-1/4" FLAT HEAD SCREW
(5 used in this step)
7S
Finished surface
F
E

Page 10 www.sauder.com/services 415002
Using your hammer, gently tap four PROPEL NUTS (14M) into the holes in the LEGS (I and J).
For queen beds, fasten your bed frame to the LEGS (I and J). Use four SILVER 2" BOLTS (94S) through your bedframe and into the
PROPEL NUTS (14M) in the LEGS (I and J).
For full size beds, fasten the HEADBOARD BRACKETS (42G) to the LEGS (I and J). Use four SILVER 2" BOLTS (94S).
Then, attach your bedframe to the HEADBOARD BRACKETS (42G). Use four SILVER 1-1/4" BOLTS (48S), four
WASHERS (13M), and four NUTS (24M).
NOTE: Your bedframe must be attached to the headboard as indicated in this step.
This completes assembly. Clean with your favorite furniture polish or a damp cloth. Wipe dry.
14M
I
J
42G
42G
NUT
(4 used for the bedframe)
24M
WASHER
(4 used for the bedframe)
13M
SILVER 1-1/4" BOLT
(4 used for the bedframe)
48S
SILVER 2" BOLT
(4 used for the BRACKETS)
94S
14M
6
6
S
t
e
