Sauder 420612 User manual

Need help? Visit Sauder.com to view video assembly tips or chat with a live rep.
Prefer the phone? Call 1-800-523-3987.
Share your journey!
sauder.com
NOTE: THIS INSTRUCTION
BOOKLET CONTAINS IMPORTANT
SAFETY INFORMATION.
PLEASE READ AND KEEP FOR
FUTURE REFERENCE.
Enlish p 1-24
Français p 25-28
Español p 29-32
Lot # 502406 04/19/17
Purchased: __________________
Be sure to ive us a rin before
makin any returns. 1-800-523-3987
4-Drawer Chest
Palladia Collection | Model 420612
WARNING
CHOKING HAZARD - Small Parts
Not for children under 3 years.
Adult assembly required.

Table of Contents Assembly Tools Required
Part Identification
Hardware Identification
Assembly Steps
Français
Español
Safety
Warranty
Hammer
Not actual size
No. 2 Phillips Screwdriver
Tip Shown Actual Size
Skip the power trip.
This time.
3
4-5
6-24
25-28
29-32
33-34
35
420612 www.sauder.com/servicesPae 2

Part Identification
åWhile not all parts are labeled, some of the parts will have a label or an inked letter on the ede
to help distinuish similar parts from each other. Use this part identification to help identify similar parts.
Now you know
our ABCs.
A2 RIGHT END (1)
B2 LEFT END (1)
C2 TOP (1)
D BOTTOM (1)
D186 SMALL DRAWER BACK (1)
D203 LARGE DRAWER BACK (3)
D245 SMALL RIGHT DRAWER SIDE (1)
D247 LARGE RIGHT DRAWER SIDE (3)
D248 LARGE LEFT DRAWER SIDE (3)
D271 SMALL LEFT DRAWER SIDE (1)
D726 DRAWER BOTTOM (4)
E2 BACK (1)
G BASE (1)
H2 LARGE DRAWER FRONT (3)
L2 SMALL DRAWER FRONT (1)
M RIGHT MOLDING (1)
M64 DRAWER BRACE (4)
N LEFT MOLDING (1)
Q FRONT MOLDING (1)
R2 PLINTH (2)
S BOTTOM MOLDING (1)
T DRAWER FRONT MOLDING (1)
U BALLAST (1)
V BRACE (1)
A2
B2
C2
D
E2
G
H2
D203
D247
D248
D726
L2
M
N
D186
D245
D271
Q
R2
R2
T
S
V
U
420612www.sauder.com/services Pae 3
D726
M64
M64

Hardware Identification
åScrews are shown actual size. You may receive extra hardware with your unit.
LARGE DRAWER
FRONT BRACKET - 6
10G
TIE PLATE - 2
3G
10F TWIST-LOCK®
FASTENER - 10
MOLDING
CONNECTOR - 2
17F
METAL PIN - 2
1R
CAM SCREW - 9
8F
NAIL - 34
1N
HIDDEN CAM - 9
1F
420612 www.sauder.com/servicesPae 4
35AA UNIVERSAL CABINET RAIL - 8 35AC DRAWER RIGHT - 4 35AD DRAWER LEFT - 4
SAFETY DRYWALL
ANCHOR - 1
61M
SAFETY STRAP - 1
60M
Locate this nylon SAFETY
STRAP (60M) to be used
later in assembly. Do not
accidentally throw away.
WASHER - 1
13M
DRAWER FRONT
BRACKET - 1
8G
METAL BRACKET - 5
4G
11L WARNING LABEL - 1
(Refer to the last step for proper location and application)
WARNING AVERTISSEMENT ADVERTENCIA
Serious or fatal crushing injuries can
occur from furniture tipover.
To help prevent tipover:
• Install tipover restraint provided.
• Place heaviest items in the lower drawers.
• Unless specifically desined to
accommodate, do not set TVs or other
heavy objects on top of this product.
• Never allow children to climb or han on
drawers, doors, or shelves.
• Never open more than one drawer at a time.
(OR)
• Do not defeat or remove the drawer
interlock system.
Use of tipover restraints may only reduce,
but not eliminate, the risk of tipover.
This is a permanent label. Do not remove.
Des blessures graves ou fatales par écrasement
peuvent survenir si le mobilier bascule. Pour
prévenir le basculement:
• Installer le dispositif anti-basculement fourni.
• Placer les articles plus lourds dans les tiroirs inférieurs.
• Sauf si le meuble a été conçu spécialement à
cette fin, ne pas mettre de téléviseur ou d’autre
objets lourds sur le dessus de ce meuble.
• Ne jamais laisser d’enfants rimper sur les
tiroirs, les portes ou les étaères ou s’y aripper.
• Ne jamais ouvrir plus d’un tiroir à la fois.
(OU)
• Ne pas démanteler ou enlever le système de
verrouillae pour tiroir.
L’utilisation de dispositifs anti-basculement peut
réduire le risque de basculement, mais pas l’éliminer.
Cette étiquette est permanente. Ne pas l’enlever.
Lesiones graves o fatales por aplastamiento, pueden
ocurrir por el volcar de los muebles. Para ayudar a
prevenir que se volqué:
• Instalar la contención brindada para evitar que se volqué.
• Coloque los artículos más pesados en los cajones
inferiores.
• A menos que sea específicamente diseñado para
acomodar, no establezca televisores u otros objetos
pesados en la parte superior de este producto.
• Nunca permita que los niños se suban o se cueluen
de cajones, puertas o estantes.
• Nunca abra más de un cajón a la vez.
(O)
• No anule o elimine el sistema de bloqueo de los cajones.
El uso de la contención puede solamente reducir, pero
no eliminar, el riesgo de volcar.
Esta es una etiqueta permanente. No remover.
10/16 395783
KNOB SET - 8
130K

Hardware Identification
åScrews are shown actual size. You may receive extra hardware with your unit.
BLACK 1-1/8" PAN HEAD SCREW - 4
9S
GOLD 1" MACHINE SCREW - 2
50S
BLACK 9/16" LARGE HEAD SCREW - 31
1S
BLACK 1-1/4" FLAT HEAD SCREW - 7
7S
BROWN 1-1/2" FLAT HEAD SCREW - 3
14S
3S GOLD 5/16" FLAT HEAD SCREW - 32
SILVER 1/2" MACHINE SCREW - 6
38S
420612www.sauder.com/services Pae 5
30S BLACK 1-9/16" FLAT HEAD SCREW - 20

Step 1 Look for this icon. It means a
video assembly tip is available at
www.sauder.com/services/tips
å Assemble your unit on a carpeted floor or on the empty carton
to avoid scratchin your unit or the floor.
å To bein assembly, push ten SAUDER TWIST-LOCK®
FASTENERS (10F) into the lare holes in the ENDS (A2 and B2).
å Repeat this step for the BOTTOM (D).
A2
B2
Do not tihten the TWIST-LOCK® FASTENERS in this step.
(10 used)
10F
10F
10F
420612 www.sauder.com/servicesPae 6

Step 2
å Push nine HIDDEN CAMS (1F) into the BOTTOM (D),
DRAWER BRACES (M64), and BRACE (V).
D
V
Arrow
Arrow
1F
The arrow in the HIDDEN
CAM must point toward the
hole in the ede of the board.
Hole
(9 used)
Arrow
1F
420612www.sauder.com/services Pae 7
M64
M64
M64
M64

å Turn nine CAM SCREWS (8F) into the ENDS (A2
and B2), LARGE DRAWER FRONTS (H2), SMALL
DRAWER FRONT (L2), and BOTTOM MOLDING (S).
Step 3
A2
B2
H2
H2
H2
L2
S
8F
Remember:
Rihty tihty.
Lefty loosey.
420612 www.sauder.com/servicesPae 8

StepStep 4
Glide end
Glide end
GOLD 5/16" FLAT HEAD SCREW
(16 used in this step)
3S
å Fasten the UNIVERSAL CABINET RAILS* (35AA) to the
ENDS (A2 and B2). Use sixteen GOLD 5/16" FLAT
HEAD SCREWS (3S) throuh holes #1 and #3.
å *patent pendin lide system
3
2
1
1
2
3
A2
B2
3
2
13
2
13
2
1
1
2
31
2
31
2
3
Surface with
TWIST-LOCK®
FASTENERS
Surface with
TWIST-LOCK®
FASTENERS
Finished ede
Finished ede
420612www.sauder.com/services Pae 9
VIEW THE DRAWER GLIDE VIDEO

Step
å Insert two METAL PINS (1R) into the short edes of
the BRACE (V).
å Fasten the BRACE (V) to the ENDS (A2 and B2). Tihten
two HIDDEN CAMS.
å NOTE: Be sure the METAL PINS insert into the holes in
the ENDS.
Step 5
A2
B2
V
1R
Finished ede
Finished ede
Finished ede
Surface with HIDDEN CAMS
420612 www.sauder.com/servicesPae 10
1
2

Step
420612www.sauder.com/services Pae 11
Step 6
å Fasten the BOTTOM (D) to the ENDS (A2 and B2).
Tihten four TWIST-LOCK® FASTENERS.
D
Surface with TWIST-LOCK® FASTENERS
These holes must be here.
A2
B2
How to use the SAUDER TWIST-LOCK®FASTENER
1. Insert the dowel end of the FASTENER into the hole of the
adjoinin part.
NOTE: The dowel end of the FASTENER must remain fully
inserted in the hole of the adjoinin part while lockin
the FASTENER.
2. Tihten the FASTENER with a Phillips screwdriver as tiht
as possible.
Dowel end

Step
å Tap two MOLDING CONNECTORS (17F) into the notches
in the MOLDINGS (M, N, and Q).
å Fasten the MOLDINGS (M, N, and Q) to the TOP (C2).
Use seven BLACK 1-1/4" FLAT HEAD SCREWS (7S).
å NOTE: Do not overtihten the SCREWS
into the TOP.
Step 7
C2
M
M
N
N
QFinished surface
Finished surface
Finished surface
Rounded ede
BLACK 1-1/4" FLAT HEAD SCREW
(7 used in this step)
7S
Unfinished surface
Unfinished surface
Unfinished surface
Flat end
Flat end
17F
17F
Use your hammer to tap the
MOLDING CONNECTORS (17F)
into the notches in the MOLDINGS.
420612 www.sauder.com/servicesPae 12
Q
Surface
with holes

Step
420612www.sauder.com/services Pae 13
å Fasten the TOP MOLDINGS (M and N) to the ENDS (A2
and B2). Tihten four TWIST-LOCK® FASTENERS.
Step 8
A2
B2
M
N
Now miht be a
ood time to refresh
your drink.
Q

Step
å Fasten the BOTTOM MOLDING (S) to the BOTTOM (D).
Tihten three HIDDEN CAMS.
å Fasten two METAL BRACKETS (4G) to the BOTTOM (D).
Use two BLACK 9/16" LARGE HEAD SCREWS (1S).
å Fasten the PLINTHS (R2) to the ENDS (A2 and B2).
Tihten two TWIST-LOCK® FASTENERS.
å Fasten the PLINTHS (R2) to the BOTTOM (D). Use two
BLACK 9/16" LARGE HEAD SCREWS (1S).
Step 9
A2
B2 D
4G
S
R2
R2
Coved ede
Coved ede
Unfinished surface
420612 www.sauder.com/servicesPae 14
BLACK 9/16" LARGE HEAD SCREW
(4 used for the METAL BRACKETS)
1S

Step
420612www.sauder.com/services Pae 15
å Fasten the BALLAST (U) to the BOTTOM (D). Use four
BLACK 1-1/8" PAN HEAD SCREWS (9S).
å Fasten three METAL BRACKETS (4G) to the BALLAST (U).
Use three BLACK 9/16" LARGE HEAD SCREWS (1S).
å NOTE: Be sure the edes of the METAL BRACKETS are
even with the ede of the BALLAST.
å Fasten the BASE (G) to the BALLAST (U). Use three BLACK
9/16" LARGE HEAD SCREWS (1S).
Step 10
BLACK 9/16" LARGE HEAD SCREW
(6 used for the METAL BRACKETS)
1S
BLACK 1-1/8" PAN HEAD SCREW
(4 used in this step)
9S
G
U
4G

Step
å Carefully turn your unit over onto its front edes. Unfold the
BACK (E2) and lay it over your unit.
å Make equal marins alon all four edes of the BACK (E2). Push
on opposite corners of your unit if needed to make it "square".
å Fasten the BACK (E2) to your unit usin the NAILS (1N).
å Fasten two TIE PLATES (3G) to the PLINTHS (R2) and BASE (G).
Use four BLACK 9/16" LARGE HEAD SCREWS (1S).
Step 11
BLACK 9/16" LARGE HEAD SCREW
(4 used for the TIE PLATES)
1S
Printed information
must be facin up.
E2
G
3G
R2
R2
Do not stand the unit upriht without the
BACK fastened. The unit may collapse.
Caution
NAIL
(34 used in this step)
1N
420612 www.sauder.com/servicesPae 16

Step
420612www.sauder.com/services Pae 17
å Fasten the DRAWER FRONT MOLDING (T) to the SMALL
DRAWER FRONT (L2). Use three BROWN 1-1/2" FLAT
HEAD SCREWS (14S).
Step 12
Unfinished ede
Groove
These surfaces should be even.
L2
T
Be sure these
two holes line up
with each other.
BROWN 1-1/2" FLAT HEAD SCREW
(3 used in this step)
14S

StepStep 13
H2
D247
D248
L2 D245
D271
Groove
Groove
Groove
Groove
BLACK 9/16" LARGE HEAD SCREW
(16 used in this step)
1S
Push down
8G
10G
Tap down with your
screwdriver and hammer
420612 www.sauder.com/servicesPae 18
VIEW THE T-SLOT BOX VIDEO
å Pull the DRAWER FRONT BRACKETS (8G) apart and slide them into
the rooves in the SMALL DRAWER SIDES (D245 and D271).
å Fasten the SMALL DRAWER FRONT (L2) to the DRAWER FRONT
BRACKETS (8G). Use four BLACK 9/16" LARGE HEAD SCREWS (1S).
å Pull the LARGE DRAWER FRONT BRACKETS (10G) apart and slide
them into the rooves in the LARGE DRAWER SIDES (D247 and D248).
å Fasten the LARGE DRAWER FRONT (H2) to the LARGE
DRAWER FRONT BRACKETS (10G). Use four
BLACK 9/16" LARGE HEAD SCREWS (1S).
å Repeat this step for the remainin
two lare drawers.

Step
420612www.sauder.com/services Pae 19
Step 14
å Slide the DRAWER BOTTOM (D726) into the
grooves in the SMALL DRAWER SIDES (D245
and D271) and SMALL DRAWER FRONT (L2).
å Fasten the DRAWER BRACE (M64 ) to the SMALL
DRAWER FRONT (L2). Tighten one HIDDEN CAM.
å Fasten the SMALL DRAWER BACK (D186) to the SMALL DRAWER
SIDES (D245 and D271) and DRAWER BRACE (M64). Use five
BLACK 1-9/16" FLAT HEAD SCREWS (30S). Repeat this step for
the large DRAWERS.
12
3
Be sure the DRAWER
BOTTOM inserts into the
DRAWER FRONT roove.
L2
D245
D271
D726
D245
D271
D186
Unfinished
surface
Be sure the DRAWER
BOTTOM inserts into the
DRAWER BACK roove.
L2
Surface with
HIDDEN CAM
VIEW THE T-SLOT BOX VIDEO
M64
M64
With the palm of your hand,
tap the DRAWER BOTTOM
down into the roove.
30S
Start each screw a few turns before
completely tihtenin any of them.
BLACK 1-9/16" FLAT HEAD SCREW
(20 used in this step)
1
2

StepStep 15
420612 www.sauder.com/servicesPae 20
å Fasten a DRAWER RIGHT (35AC) to the SMALL RIGHT
DRAWER SIDE (D245) and a DRAWER LEFT (35AD) to
the SMALL LEFT DRAWER SIDE (D271). Use four GOLD
5/16" FLAT HEAD SCREWS (3S) throuh holes #1 and #2.
å NOTE: The lides are not intended to rotate.
å Repeat this step for the lare drawers.
1
2
1
2
Glide end
Glide end
D245
D271
L2
VIEW THE DRAWER GLIDE VIDEO
GOLD 5/16" FLAT HEAD SCREW
(16 used in this step)
3S
(4 screws per drawer)
