Sauder The Edge Water 409045 User manual

Need help? Visit Sauder.com to view video assembly tips or chat with a live rep.
Prefer the phone? Call 1-800-523-3987.
Share your journey!
sauder.com
NOTE: THIS INSTRUCTION
BOOKLET CONTAINS IMPORTANT
SAFETY INFORMATION.
PLEASE READ AND KEEP FOR
FUTURE REFERENCE.
English pg 1-19
Français pg 20-22
Español pg 23-25
Lot # 370878 03/25/15
Purchased: __________________
Be sure to give us a ring before
making any returns. 1-800-523-3987
You could totally write
a novel on this.
Desk with Digital Dock
The Edge Water Collection | 409045

Table of Contents Assembly Tools Required
Part Identification
Hardware Identification
Assembly Steps
Français
Español
Safety
Warranty
Hammer
Not actual size
No. 2 Phillips Screwdriver
Tip Shown Actual Size
Skip the power trip.
This time.
3
4
5-19
20-22
23-25
26
27
409045 www.sauder.com/servicesPage 2
Short Screwdriver
(provided)

Part Identification
åWhile not all parts are labeled, some of the parts will have a label or an inked letter on the edge
to help distinguish similar parts from each other. Use this part identification to help identify similar parts.
Now you know
our ABCs.
A RIGHT END (1)
B LEFT END (1)
C UPRIGHT (2)
D TOP (1)
E FLIP-UP TOP (1)
F BOTTOM (1)
G SHELF (1)
H BACK (1)
I BRACE (1)
J RIGHT FRONT (1)
K LEFT FRONT (1)
L RIGHT FRONT/LEFT REAR LEG (2)
M LEFT FRONT/RIGHT REAR LEG (2)
N KEYBOARD FRONT (1)
O KEYBOARD BACK (1)
P KEYBOARD SIDE (2)
Q KEYBOARD SHELF (1)
R BACK STRETCHER (1)
S RIGHT STRETCHER (1)
T LEFT STRETCHER (1)
U FOOT (4)
A
B
C
C
D
E
F
G
H
I
K
L
L
M
M
N
O
P
P
Q
R
S
T
U
U
U
J
409045www.sauder.com/services Page 3

Hardware Identification
åScrews are shown actual size. You may receive extra hardware with your unit.
409045 www.sauder.com/servicesPage 4
METAL BRACKET - 8
AA
BLACK 9/16" LARGE HEAD SCREW - 24
OO
HOLE PLUG - 2
HH
BLACK 1-5/8" PAN HEAD SCREW - 4
KK
BLACK 1-7/8" FLAT HEAD SCREW - 3
JJ
BLACK 7/8" MACHINE SCREW - 2
MM
BROWN 1-1/2" FLAT HEAD SCREW - 6
LL
CAM COVER - 14
II
XTWIST-LOCK®FASTENER - 11
HINGE - 2
CC
QQ GOLD 5/16" FLAT HEAD SCREW - 8
SILVER 5/8" FLAT HEAD SCREW - 4
NN
SILVER 9/16" LARGE HEAD SCREW - 2
PP
PULL - 2
EE
CAM SCREW - 37
8F GROMMET - 1 BB
HIDDEN CAM - 37
1F
FELT DISC CARD - 1
GG
KEYBOARD HINGE - 2
DD
CORD CLIP - 4
FF
VEXTENSION RAIL - 2 WEXTENSION SLIDE -2
(EXTENSION SET SHOWN SEPARATED)

Step 1 Look for this icon. It means a
video assembly tip is available at
www.sauder.com/services/tips
å Assemble your unit on a carpeted floor or on the empty
carton to avoid scratching your unit or the floor.
å To begin assembly, push a SAUDER TWIST-LOCK®
FASTENER (X) into the large holes in the RIGHT END (A)
and LEFT END (B). Repeat this step for the UPRIGHTS (C)
and SHELF (G).
å NOTE: Do not tighten theTWIST-LOCK® FASTENERS at
this time.
409045www.sauder.com/services Page 5
A
B
Do not tighten the TWIST-LOCK® FASTENERS in this step.
(11 used)
X

å Push thirty-seven HIDDEN CAMS (1F) into the ENDS (A and B),
UPRIGHTS (C), BOTTOM (F), SHELF (G), BACK (H), BRACE (I),
FRONTS (J and K), and STRETCHERS (R, S, and T).
Step 2
409045 www.sauder.com/servicesPage 6
A
B
C
C
F
G
H
IJ
K
R
S
T
Arrow
Arrow
1F
The arrow in the HIDDEN
CAM must point toward the
hole in the edge of the board.
Hole
Arrow
1F (37 used)
1F
Arrow

å Turn thirty-seven CAM SCREWS (8F) into the ENDS (A and B),
BACK (H), BRACE (I), FRONTS (J and K), LEGS (L and M), and
STRETCHERS (S and T).
Step 3
409045www.sauder.com/services Page 7
A
B
H
IJ
K
S
T
L
L
M
M
8F
8F
(37 used)
These holes will not be used.
Remember:
Righty tighty.
Lefty loosey.

å Fasten the ENDS (A and B) and STRETCHERS (S and T)
to the LEGS (L and M). Tighten twelve HIDDEN CAMS.
å Fasten the FEET (U) to the LEGS (L and M). Use four
BLACK 1-5/8" PAN HEAD SCREWS (KK).
Step 4
409045 www.sauder.com/servicesPage 8
A
B
S
T
L
L
M
M
U
U
12
This hole must be here.
This hole must be here.
Surface with HIDDEN CAMS
Surface with
HIDDEN CAMS
Surface with
HIDDEN CAMS
Surface with HIDDEN CAMS
BLACK 1-5/8" PAN HEAD SCREW
(4 used in this step)
KK

å Fasten the SHELF (G) to the BACK STRETCHER (R).
Tighten three TWIST-LOCK® FASTENERS.
Step 5
409045www.sauder.com/services Page 9
G
R
Unfinished surface
Finished edge
Rounded edge
How to use the SAUDER TWIST-LOCK®FASTENER
1. Insert the dowel end of the FASTENER into the hole of the
adjoining part.
NOTE: The dowel end of the FASTENER must remain fully
inserted in the hole of the adjoining part while locking
the FASTENER.
2. Tighten the FASTENER with a Phillips screwdriver as tight
as possible.
Dowel end

å Fasten the SHELF (G), BACK (H), and BACK
STRETCHER (R) to the RIGHT FRONT/LEFT
REAR LEG (L) and LEFT STRETCHER (T). Tighten
five HIDDEN CAMS.
å Fasten the BOTTOM (F) to the BACK (H). Tighten three
HIDDEN CAMS.
Step 6
409045 www.sauder.com/servicesPage 10
B
F
GH
R
T
Surface with HIDDEN CAMS
Surface with HIDDEN CAMS
Surface with HIDDEN CAMS
1
2
Finished edge
L
