Sauder Harbor View 420474 User manual

Need help? Visit Sauder.com to view video assembly tips or chat with a live rep.
Prefer the phone? Call 1-800-523-3987.
Share your journey!
sauder.com
NOTE: THIS INSTRUCTION
BOOKLET CONTAINS IMPORTANT
SAFETY INFORMATION.
PLEASE READ AND KEEP FOR
FUTURE REFERENCE.
Enlish p 1-36
Français p 37-40
Español p 41-44
Lot # 392154 08/15/16
Purchased: __________________
Be sure to ive us a rin before
makin any returns. 1-800-523-3987
Corner Computer Desk
Harbor View Collection | Model 420474
For all your
newfanled gadgetry.

Table of Contents Assembly Tools Required
Part Identification
Hardware Identification
Assembly Steps
Français
Español
Safety
Warranty
Hammer
Not actual size
No. 2 Phillips Screwdriver
Tip Shown Actual Size
A DOOR RIGHT END (1)
B DOOR LEFT END (1)
C DRAWER RIGHT END (1)
D DRAWER LEFT END (1)
E RIGHT UPRIGHT (1)
F LEFT UPRIGHT (1)
G2 TOP (1)
H2 SMALL TOP (1)
I MODESTY PANEL (2)
J BOTTOM (1)
K BACK (2)
L BRACE (2)
M DOOR (1)
N DRAWER FRONT (1)
O SMALL DRAWER FRONT (2)
P ADJUSTABLE SHELF (1)
Q2 KEYBOARD UPRIGHT (2)
U KEYBOARD SHELF (1)
X BASE (2)
AA RIGHT MOLDING (1)
BB LEFT MOLDING (1)
D24 SMALL RIGHT DRAWER SIDE (2)
D25 SMALL LEFT DRAWER SIDE (2)
D28 RIGHT DRAWER SIDE (1)
D29 LEFT DRAWER SIDE (1)
D78 DRAWER BACK (1)
D109 SMALL DRAWER BACK (2)
D707 DRAWER BOTTOM (1)
D716 SMALL DRAWER BOTTOM (2)
2-3
4-5
6-36
37-40
41-44
45-46
47
Now you know
our ABCs.
Part Identification
åWhile not all parts are labeled, some of the parts will have a label or an inked letter on the ede
to help distinuish similar parts from each other. Use this part identification to help identify similar parts.
420474 www.sauder.com/servicesPae 2
Electric drill with 1/8" bit
(ONLY in indicated step)

Part Identification
420474www.sauder.com/services Pae 3
A
BC
D
E
F
G2
H2
I
J
K
L
M
Q2
U
X
AA
BB
I
K
Q2
X
L
P
D716
D707
D29
D28
D78
D109D25
D24
ON
D716
D109D25
D24
O

Hardware Identification
åScrews are shown actual size. You may receive extra hardware with your unit.
GG NUMBERED RIGHT
CABINET RAIL - 1 HH NUMBERED LEFT CABINET RAIL - 1 JJ NUMBERED LEFT DRAWER SLIDE - 1
II NUMBERED RIGHT
DRAWER SLIDE - 1
FILE ROD - 2
8B
35DA CABINET RIGHT - 2 35DB CABINET LEFT - 2 35DC DRAWER RIGHT - 2 35DD DRAWER LEFT - 2
TIE PLATE - 2
41G
HIDDEN CAM - 18
1F
CAM DOWEL - 18
2F HIDDEN
CONNECTOR - 4
5F
13H HINGE - 2
ANGLE
BRACKET - 10
5G
10A SLIDE CAM - 6 FILE GLIDE - 2
15B
KNOB - 1
5K PULL - 3 98K
420474 www.sauder.com/servicesPae 4
40AW CABINET RIGHT - 1 40AX CABINET LEFT - 1 40AY DRAWER RIGHT - 1 40AZ DRAWER LEFT - 1
METAL
BRACKET - 4
2G

Hardware Identification
FELT DISC CARD - 1
1M
åScrews are shown actual size. You may receive extra hardware with your unit.
420474www.sauder.com/services Pae 5
BLACK 1-1/8" PAN HEAD SCREW - 10
9S
BLACK 9/16" LARGE HEAD SCREW - 36
1S
CONNECTOR SCREW - 4
8S
BLACK 1-7/8" FLAT HEAD SCREW - 6
2S
18S BROWN 1" FLAT HEAD SCREW - 4
3S GOLD 5/16" FLAT HEAD SCREW - 28
BLACK 1/2" FLAT HEAD SCREW - 4
11S
GOLD 1" MACHINE SCREW - 1
50S
15S SILVER 5/8" MACHINE SCREW - 6
GROMMET - 1
10P
GROMMET CAP - 1
1P CORD CLIP - 5 4P
METAL PIN - 8
1R
NAIL - 30
1N
RUBBER SLEEVE - 4
2R
30S BLACK 1-9/16" FLAT HEAD SCREW - 12

å IMPORTANT: Follow the video to the riht for this option.
å IMPORTANT: Follow the video to the riht for this option.
DOOR ON RIGHT AND
DRAWERS ON LEFT
DOOR ON LEFT AND
DRAWERS ON RIGHT
420474 www.sauder.com/servicesPae 6

Look for this icon. It means a
video assembly tip is available at
www.sauder.com/services/tips
Step 1
å Assemble your unit on a carpeted floor or on the empty
carton to avoid scratchin your unit or the floor.
å Use your hammer to tap four HIDDEN CONNECTORS (5F)
with SCREWS into the KEYBOARD UPRIGHTS (Q2).
Step 2
å Insert a CONNECTOR SCREW (8S) into each
HIDDEN CONNECTOR (5F).
8S
5F
5F
STOP
If you purchased
the 420473
Hutch, assemble
that unit first.
Q2
Q2
420474www.sauder.com/services Pae 7

Step
å Push eihteen HIDDEN CAMS (1F) into the ENDS (A, B, C,
and D), UPRIGHTS (E and F), BOTTOM (J), and BRACES (L).
Then, insert the metal end of a CAM DOWEL (2F) into each
HIDDEN CAM.
Step 3
420474 www.sauder.com/servicesPae 8
Arrow
1F
2F
(18 used)
Arrow
1F
2F
Insert the metal end of the CAM
DOWEL into the HIDDEN CAM.
Arrow
Do not tihten the HIDDEN CAMS in this step.
C
D
E
F
J
A
BL
L

StepStep 4
35DA
35DA
35DB
35DB
å Fasten the CABINET RIGHTS (35DA) and CABINET
LEFTS (35DB) to the DRAWER ENDS (C and D). Use
eiht GOLD 5/16" FLAT HEAD SCREWS (3S) throuh
holes #1 and #3.
å Fasten the NUMBERED CABINET RAILS (GG and HH) to
the DRAWER ENDS (C and D). Use four GOLD 5/16" FLAT
HEAD SCREWS (3S) throuh holes #1 and #3.
å NOTE: The CABINET RAILS are marked "CABINET
RIGHT" and "CABINET LEFT" for easy identification.
GOLD 5/16" FLAT HEAD SCREW
(12 used in this step)
3S
Roller end
1
3
2
1
3
2
C
D
Surface with
HIDDEN CAMS
Surface with
HIDDEN CAMS
1
3
2
1
3
2
4
Roller end
1
3
2
1
3
2
4
HH
GG
Remember:
Rihty tihty.
Lefty loosey.
420474www.sauder.com/services Pae 9

Step
420474 www.sauder.com/servicesPae 10
Step 5
GOLD 5/16" FLAT HEAD SCREW
(4 used for the CABINET RAILS)
3S
Q2
Surface with
HIDDEN CONNECTORS
Roller end
Roller end
40AW
40AW
40AX
40AX
å Fasten a CABINET RIGHT (40AW) and a CABINET LEFT (40AX) to the
KEYBOARD UPRIGHTS (Q2). Use four GOLD 5/16" FLAT HEAD SCREWS (3S).
å NOTE: The CABINET RAILS are marked "CABINET RIGHT" and "CABINET
LEFT" for easy identification.
å NOTE: Be sure to use the exact holes shown.
å Fasten the METAL BRACKETS (2G) to the KEYBOARD UPRIGHTS (Q2). Use
four BLACK 9/16" LARGE HEAD SCREWS (1S).
å NOTE: Be sure the edes of the METAL BRACKETS are even with the edes of
the KEYBOARD UPRIGHTS.
Q2
Surface with
HIDDEN CONNECTORS
BLACK 9/16" LARGE HEAD SCREW
(4 used for the METAL BRACKETS)
1S
2G
2G
2G
2G

å Fasten the LEFT UPRIGHT (F) to the RIGHT UPRIGHT (E).
Use two BLACK 1-7/8" FLAT HEAD SCREWS (2S).
Step 6
420474www.sauder.com/services Pae 11
E
F
Surface with
HIDDEN CAM
Surface with
HIDDEN CAM
BLACK 1-7/8" FLAT HEAD SCREW
(2 used in this step)
2S
Ede with CAM DOWEL
Do not stand the unit upriht without the
BACK fastened. The unit may collapse.
Caution

Step
å Insert four METAL PINS (1R) into the ENDS (C and D).
å Fasten the ENDS (C and D) to the BRACES (L). Tihten
four HIDDEN CAMS.
å NOTE: Be sure the METAL PINS in the ENDS insert into
the holes in the BRACES.
Step 7
420474 www.sauder.com/servicesPae 12
Start Tighten
Arrow
Minimum
190 derees
Caution
Risk of damae or
injury. HIDDEN CAMS
must be completely
tihtened. HIDDEN
CAMS that are not
completely tihtened
may loosen, and parts
may separate. To
completely tihten:
Arrow
Maximum
210 derees
C
DL
L
Surface with
HIDDEN CAMS
Surface with
HIDDEN CAMS
Surface without
HIDDEN CAMS
Surface with
HIDDEN
CAMS
1R
(4 used)
These holes must be here.
Ede with CAM DOWELS

Step
420474www.sauder.com/services Pae 13
å Fasten four ANGLE BRACKETS (5G) to the DRAWER
ENDS (C and D) and BRACE (L). Use four BLACK 9/16"
LARGE HEAD SCREWS (1S).
å NOTE: Be sure the edes of the ANGLE BRACKETS are
even with the edes of the ENDS and BRACE.
å Fasten the BASE (X) to the DRAWER ENDS (C and D)
and BRACE (L). Use four BLACK 9/16" LARGE
HEAD SCREWS (1S).
Step 8
BLACK 9/16" LARGE HEAD SCREW
(8 used in this step)
1S
C
D
L
X
5G
5G
5G
(4 used)

Step
å Fasten the DOOR ENDS (A and B) to the BOTTOM (J).
Tihten four HIDDEN CAMS.
Step 9
420474 www.sauder.com/servicesPae 14
Arrow
Minimum
190 derees
Maximum
210 derees
A
B
J
Surface with
HIDDEN CAMS
Surface without
HIDDEN CAMS
Surface with
HIDDEN CAMS
These holes must be here.
Ede with CAM DOWELS

Step
420474www.sauder.com/services Pae 15
å Fasten four ANGLE BRACKETS (5G) to the DOOR
ENDS (A and B) and BOTTOM (J). Use four BLACK
9/16" LARGE HEAD SCREWS (1S).
å NOTE: Be sure the edes of the ANGLE BRACKETS are
even with the edes of the ENDS and BOTTOM.
å Fasten the BASE (X) to the DOOR ENDS (A and B)
and BOTTOM (J). Use four BLACK 9/16" LARGE
HEAD SCREWS (1S).
Step 10
BLACK 9/16" LARGE HEAD SCREW
(8 used in this step)
1S
5G
5G
5G
(4 used)
A
B
J
X

Step
å Carefully turn your unit over onto its front edes. Lay the
BACKS (K) over your unit.
å Make equal marins alon all three edes of the
BACKS (K). Push on opposite corners of your unit if
needed to make it "square".
å Fasten the BACKS (K) to your unit usin the NAILS (1N).
å NOTE: Perforations have been provided for access
throuh the BACK. Carefully cut out the rectanle in the
BACK for proper ventilation of your CPU.
Step 11
420474 www.sauder.com/servicesPae 16
Finished
surface
NAIL
(30 used in this step)
1N
Finished
surface
K
K
A
B
C
D
Ede without holes
Ede without holes
Do not stand the unit upriht without the
BACK fastened. The unit may collapse.
Caution

Step
420474www.sauder.com/services Pae 17
å IMPORTANT: You have the choice of assemblin the unit
two ways. If you want the drawers on the riht and the
DOOR on the left side of the desk, fasten the DRAWER
ENDS (C and D) to the SMALL TOP (H2) and the ENDS (A
and B) to the TOP (G2).
å If you want the drawers on the left and the DOOR on the
riht side of the desk, fasten the ENDS (A and B) to the
SMALL TOP (H2) and the ENDS (C and D) to the TOP (G2)
as shown in the lower diaram.
å NOTE: The followin steps in this book show the first option
with the DOOR on the left and drawers on the riht.
Step 12
H2
H2
G2
G2
C
D
C
D
DOOR ON RIGHT AND
DRAWERS ON LEFT
DOOR ON LEFT AND
DRAWERS ON RIGHT
A
A
B
B

å Fasten the DOOR ENDS (A and B) to the TOP (G2).
Tihten four HIDDEN CAMS.
Step 13
420474 www.sauder.com/servicesPae 18
Arrow
Minimum
190 derees
Maximum
210 derees
A
B
G2
The lare hole
must be here.
Surface with more holes
Rounded ede
X

å Fasten the LEFT MOLDING (BB) to the TOP (G2). Use
three BLACK 1-1/8" PAN HEAD SCREWS (9S).
å Fasten the UPRIGHTS (E and F) to the TOP (G2). Tihten
two HIDDEN CAMS.
Step 14
420474www.sauder.com/services Pae 19
Arrow
Minimum
190 derees
Maximum
210 derees
G2
EF
BB
Surface with
HIDDEN CAM
Surface with
HIDDEN CAM
BLACK 1-1/8" PAN HEAD SCREW
(3 used in this step)
9S
Curved ede

å Use a drill and a 1/8" drill bit to complete the two holes in the
DOOR RIGHT END (A).
å Fasten the MODESTY PANEL (I) to the LEFT UPRIGHT (F). Use
two BLACK 1-1/8" PAN HEAD SCREWS (9S).
å Fasten the MODESTY PANEL (I) to the DOOR RIGHT END (A).
Use two BLACK 1-7/8" FLAT HEAD SCREWS (2S).
Step 15
420474 www.sauder.com/servicesPae 20
F
I
A
BLACK 1-1/8" PAN HEAD SCREW
(2 used in this step)
9S
Use a 1/8" drill bit in the RIGHT END (A).
Cut-out
BLACK 1-7/8" FLAT HEAD SCREW
(2 used in this step)
2S
