Sauder 409714 User manual

NOTE: THIS INSTRUCTION
BOOKLET CONTAINS IMPORTANT
SAFETY INFORMATION.
PLEASE READ AND KEEP FOR
FUTURE REFERENCE.
Enlish p 1-22
Français p 23-25
Español p 26-28
Lot # 358575 01/23/14
Purchased: __________________
Be sure to ive us a rin before
makin any returns. 1-800-523-3987
4-Drawer Chest
Shoal Creek Collection | 409714
Need help? Visit Sauder.com to view video assembly tips or chat with a live rep.
Prefer the phone? Call 1-800-523-3987.
Share your journey!
sauder.com
WARNING
CHOKING HAZARD - Small Parts
Not for children under 3 years.
Adult assembly required.

Table of Contents Assembly Tools Required
2-3
4-5
6-22
23-25
26-28
29-30
31
Part Identification
Hardware Identification
Assembly Steps
Français
Español
Safety
Warranty
Hammer
Not actual size
No. 2 Phillips Screwdriver
Tip Shown Actual Size
Skip the power trip.
This time.
409714 www.sauder.com/servicesPae 2
Part Identification
åWhile not all parts are labeled, some of the parts will have a label or an inked letter on the ede
to help distinuish similar parts from each other. Use this part identification to help identify similar parts.
A RIGHT END (1)
B LEFT END (1)
C TOP (1)
D BOTTOM (2)
E BACK (1)
F2 DRAWER BRACE (4)
G RIGHT FRONT LEG (1)
H LEFT FRONT LEG (1)
I REAR LEG (2)
J2 DRAWER FRONT (1)
O2 LARGE DRAWER FRONT (3)
S END MOLDING (2)
VV LARGE BACK (1)
D10 RIGHT DRAWER SIDE (1)
D11 LEFT DRAWER SIDE (1)
D132 LARGE RIGHT DRAWER SIDE (3)
D138 LARGE LEFT DRAWER SIDE (3)
D174 DRAWER BACK (1)
D175 LARGE DRAWER BACK (3)
D983 DRAWER BOTTOM (4)
Tape Measure

Part Identification Now you know
our ABCs.
409714www.sauder.com/services Pae 3
A
B
C
D
E
F2
G
H
I
J2
O2
S
VV
D
I
F2
S
D10
D983
D11
D132
D983
D138
D175
D174

Hardware Identification
åScrews are shown actual size. You may receive extra hardware with your unit.
SAFETY BRACKET - 1
WW
METAL BRACKET - 4
AA
HIDDEN CAM - 10
Y2
TWIST-LOCK® FASTENER - 8
X
PULL - 6
FF
CAM SCREW - 10
Z2
SLIDE CAM - 8
DD
HH DRAWER ACTUATOR - 4
KNOB - 3
BB
GG CABINET ACTUATOR - 4
40CB CABINET LEFT - 4 40CA CABINET RIGHT - 4 40CC DRAWER RIGHT - 4
40CD DRAWER LEFT - 4
METAL PIN - 4
EE
JJ INTERLOCK TRACK - 1 KK WARNING LABEL - 1
WARNING
!
Serious or fatal crushing injuries can
occur from furniture tip-over. To help
prevent tip-over:
• Place heaviest items in the lowest drawers.
• Unless specifically designed to accommodate, do not
set TVs or other heavy objects on top of this product.
• Never allow children to climb or hang on drawers,
doors, or shelves.
• Never open more than one drawer at a time.
• If equipped with a drawer interlock system, do not
defeat or remove it.
Use of tip-over restraints may only reduce,
but not eliminate, the risk of tip-over.
This is a permanent label. Do not attempt to remove!
04/10 332296
409714 www.sauder.com/servicesPae 4

Hardware Identification
åScrews are shown actual size. You may receive extra hardware with your unit.
409714www.sauder.com/services Pae 5
BLACK 1-1/8" MACHINE SCREW - 3
NN
SILVER 3/4" MACHINE SCREW - 12
OO BLACK 9/16" LARGE HEAD SCREW - 15 PP
BLACK 1-7/8" FLAT HEAD SCREW - 1
XX
BLACK 2-1/4" FLAT HEAD SCREW - 6
MM
GOLD 5/16" FLAT HEAD SCREW - 32
TT
BLACK 9/16" FLAT HEAD SCREW - 4
QQ
NAIL - 16
UU
BLACK 1-9/16" FLAT HEAD SCREW - 20
30S

Step 1 Look for this icon. It means a
video assembly tip is available at
www.sauder.com/services/tips
å Assemble your unit on a carpeted floor or on the empty
carton to avoid scratchin your unit or the floor.
å To bein assembly, push a SAUDER TWIST-LOCK®
FASTENER (X) into the lare holes in the ENDS (A and B).
å Repeat this step for the BOTTOMS (D).
409714 www.sauder.com/servicesPae 6
A
B
X(8 used)
Do not tihten the TWIST-LOCK® FASTENERS in this step.

å Push ten HIDDEN CAMS (Y2) into the ENDS (A and B)
and DRAWER BRACES (F2).
å Turn ten CAM SCREWS (Z2) into the FRONT
LEGS (G and H) and DRAWER FRONTS (J2 and O2).
Step 2
409714www.sauder.com/services Pae 7
F2
F2
F2
F2
O2
O2
O2
Z2
J2
G
H
A
B
Y2
Do not tihten the HIDDEN CAMS in this step.
Hole
(10 used)
(10 used)
Arrow
Arrow

Step 3
å Fasten the REAR LEGS (I) to the ENDS (A and B). Use six
BLACK 2-1/4" FLAT HEAD SCREWS (MM).
409714 www.sauder.com/servicesPae 8
A
B
I
I
Surface
without
TWIST
-
LOCK®
FASTENERS
Surface
without
TWIST
-
LOCK®
FASTENERS
BLACK 2-1/4" FLAT HEAD SCREW
(6 used in this step)
MM
Anled ede
Ede with
TWIST-LOCK®
FASTENERS
Ede with
TWIST-LOCK®
FASTENERS
Remember:
Rihty tihty.
Lefty loosey.

å Turn four BLACK 9/16" FLAT HEAD SCREWS (QQ) into
the ENDS (A and B) until the shoulders of the SCREWS
rest on the surfaces of the ENDS.
å Slide the END MOLDINGS (S) onto the ENDS (A and B).
Line up the rooves in the MOLDINGS over the heads of
the SCREWS in the ENDS.
Step 4
409714www.sauder.com/services Pae 9
A
BS
S
Apply pressure with your hands
as you uide the MOLDINGS over
the SCREWS and onto the ENDS.
These edes
should be even.
These edes
should be even.
Shoulder
BLACK 9/16" FLAT HEAD SCREW
(4 used in this step)
QQ

Step 5
å Fasten the FRONT LEGS (G and H) to the
ENDS (A and B). Tihten six HIDDEN CAMS.
409714 www.sauder.com/servicesPae 10
A
B
H
G
Anled ede
Surface
with
TWIST
-
LOCK®
FASTENERS
Surface
with
TWIST
-
LOCK®
FASTENERS
Anled ede
1
2
These surfaces
should be even.
These surfaces
should be even.

å The next three steps involve an important safety feature
desined to prevent more than one drawer from openin
at the same time.
å Insert four CABINET ACTUATORS (GG) into the holes
shown in the RIGHT END (A).
Step 6
409714www.sauder.com/services Pae 11
A
GG
GG
This pin must insert into the location
holes in the RIGHT END (A).

Step 7
å Diaram 1. Measure 1-1/2" from one end of the INTERLOCK TRACK (JJ). Position the INTERLOCK TRACK as shown.
å ACTUATOR / TRACK ATTACHMENT:
å Diaram 2. Tilt the first ede of the INTERLOCK TRACK (JJ) into the CABINET ACTUATOR (GG).
å Diaram 3. Rotate the INTERLOCK TRACK and apply force to snap the second ede into the CABINET ACTUATOR.
å Diaram 4. Repeat the ACTUATOR / TRACK ATTACHMENT for the next CABINET ACTUATOR while holdin the
previously completed CABINET ACTUATOR in its location hole. Repeat these steps until all ACTUATORS have been
attached. Visually check that all INTERLOCK TRACK edes have been snapped into the CABINET ACTUATORS as
shown in diaram 3.
å Diaram 5. Remove the INTERLOCK TRACK assembly from Diaram 4 and flip it over before insertin the
INTERLOCK TRACK (JJ) with CABINET ACTUATORS (GG) into the roove in the RIGHT END (A).
409714 www.sauder.com/servicesPae 12
2. 3.
1.
4.
GG
JJ
JJ
GG
A
The interlock system is a safety feature that prevents
more than one drawer from opening at the same
time. Do not use excessive force to open the drawers.
GG JJ
A
1-1/2"
JJ
STOP
Be sure the
interloack track
snaps into each
cabinet actuator.

å Fasten the CABINET RIGHT (40CA) and CABINET LEFT (40CB)
to the ENDS (A and B). Use sixteen GOLD 5/16" FLAT HEAD
SCREWS (TT) throuh holes #1 and #4.
Step 8
409714www.sauder.com/services Pae 13
43
2
1
2
3
4
A
B
The roller end should be
closer to the HIDDEN CAM.
GG
40CA
1
The roller end should be
closer to the HIDDEN CAM.
Roller end
Roller end
After fastenin the CABINET RAILS to the RIGHT END (A),
the CABINET ACTUATOR should touch the top ede of the
RAILS. If the ap is larer than 1/16", the drawers could lock
up and not open. If this happens, open two drawers at the
same time to override the interlock system. Remove the
drawers to re-adjust the INTERLOCK TRACK assembly.
43
2
1
43
2
1
43
2
1
1
2
34
1
2
34
1
2
34
GOLD 5/16" FLAT HEAD SCREW
(16 used in this step)
TT

Step 9
å Fasten the LEFT END (B) to the TOP (C). Tihten two
TWIST-LOCK® FASTENERS.
å Fasten four METAL BRACKETS (AA) to the BACK (E). Use
four BLACK 9/16" LARGE HEAD SCREWS (PP).
å NOTE: Be sure the METAL BRACKETS are even with the
ede of the BACK.
å Fasten the BACK (E) to the LEFT END (B). Use two BLACK
9/16" LARGE HEAD SCREWS (PP) throuh the METAL
BRACKETS and into the LEFT END.
409714 www.sauder.com/servicesPae 14
BC
E
AA
AA
The six holes on
other surface should
be located here.
How to use the SAUDER TWIST-LOCK®FASTENER
1. Insert the dowel end of the FASTENER into the hole of the
adjoinin part.
NOTE: The dowel end of the FASTENER must remain fully
inserted in the hole of the adjoinin part while lockin
the FASTENER.
2. Tihten the FASTENER with a Phillips screwdriver as tiht
as possible.
Dowel end
Do not stand the unit upriht without the
BACK fastened. The unit may collapse.
Caution
Finished ede
BLACK 9/16" LARGE HEAD SCREW
(6 used in this step)
PP
Surface
with holes

å Insert a METAL PIN (EE) into the hole in each short ede
of the BOTTOMS (D).
å Fasten the BOTTOMS (D) to the LEFT END (B). Tihten
two TWIST-LOCK® FASTENERS.
å NOTE: Be sure the METAL PINS in the BOTTOMS insert
into the holes in the LEFT END.
Step 10
409714www.sauder.com/services Pae 15
B
D
D
EE
EE
Surface without
TWIST-LOCK®
FASTENERS
Surface without
TWIST-LOCK®
FASTENERS
Finished ede
Finished ede
Now miht be a
ood time to refresh
your drink.

Step 11
å Fasten the RIGHT END (A) to the TOP (C) and BOTTOMS (D) as
shown in the upper diaram. Tihten four TWIST-LOCK® FASTENERS.
å NOTE: Be sure the METAL PINS in the BOTTOMS insert into the holes
in the RIGHT END.
å Fasten the RIGHT END (A) to the BACK (E). Use two BLACK 9/16" LARGE HEAD
SCREWS (PP) throuh the METAL BRACKETS and into the RIGHT END.
å Carefully turn your unit over onto its front edes. Lay the LARGE
BACK (VV) over your unit as shown in the lower diaram.
å Fasten the bottom ede of the LARGE BACK (VV) to the
BACK (E). Use six BLACK 9/16" LARGE HEAD SCREWS (PP).
å Fasten the top and side edes of the LARGE
BACK (VV) to your unit usin the NAILS (UU).
409714 www.sauder.com/servicesPae 16
A
C
D
D
E
E
VV
Printed
information
must be
facin up.
Use two BLACK 9/16" LARGE HEAD
SCREWS (PP) throuh the BRACKETS on
the BACK (E) and into the RIGHT END (A).
BLACK 9/16" LARGE HEAD SCREW
(8 used in this step)
PP
NAIL
(16 used in this step)
UU
Do not stand the unit upriht without the
BACK fastened. The unit may collapse.
Caution

Step 12
409714www.sauder.com/services Pae 17
å Insert the LARGE DRAWER SIDES (D132 and D138)
at an angle into the slot at each end of the LARGE
DRAWER FRONT (O2).
å Slide the DRAWER BOTTOM (D983) into the grooves
in the LARGE DRAWER SIDES (D132 and D138) and
LARGE DRAWER FRONT (O2).
å Fasten the DRAWER BRACE (F2) to the LARGE
DRAWER FRONT (O2). Tighten one HIDDEN CAM.
å Fasten the LARGE DRAWER BACK (D175) to the LARGE
DRAWER SIDES (D132 and D138) and DRAWER
BRACE (F2). Use five BLACK 1-9/16" FLAT HEAD
SCREWS (30S). Repeat this step for the other large drawers.
The smaller drawer will use DRAWER FRONT (J2), DRAWER
SIDES (D10 and D11), and DRAWER BACK (D174).
The tabs should insert freely into the
slots. Gently tilt the DRAWER SIDES side
to side until the tabs slip into the slots.
Surface with
HIDDEN CAM
12
34
Be sure the DRAWER
BOTTOM inserts into the
DRAWER FRONT roove.
With the palm of your hand, tap the
DRAWER BOTTOM down into the roove.
Groove
Arrow
Maximum
210 derees
Minimum
190 derees
Start each screw a few turns before
completely tihtenin any of them.
BLACK 1-9/16" FLAT HEAD SCREW
(20 used in this step)
30S
O2
O2
F2
O2
F2
VIEW THE T-LOCK BOX VIDEO
D138
D132
D138
D983
D132
D132
D138
D175
Unfinished
surface

Step 13
å Insert a SLIDE CAM (DD) into the LARGE LEFT
DRAWER SIDE (D138).
å Fasten a DRAWER LEFT (40CD) to a LARGE LEFT
DRAWER SIDE (D138). Use two GOLD 5/16" FLAT HEAD
SCREWS (TT) throuh holes #1 and #4.
å NOTE: The screw head in the CAM must be visible
throuh the slotted hole in the SLIDE.
409714 www.sauder.com/servicesPae 18
DD
1
2
34
Screw head - turn CAM to line
up the hole in the SLIDE with
the hole in the DRAWER SIDE.
D138
GOLD 5/16" FLAT HEAD SCREW
(8 used in this step)
TT
Roller end

å Flip the drawer over onto the LARGE LEFT DRAWER SIDE (D138).
å Insert a SLIDE CAM (DD) into the LARGE RIGHT DRAWER SIDE (D132).
å Diaram 1. Insert the tabs on a DRAWER ACTUATOR (HH) into the slots
in a RIGHT DRAWER SLIDE (40CC). You may need to insert one tab first,
then the other.
å Diaram 2. Visually check that the DRAWER ACTUATOR (HH) is seated in
the SLIDE (40CC).
å Diaram 3. If the DRAWER ACTUATOR is not seated, use your hammer to
ently tap the SLIDE until the tabs are properly seated in the slots.
å Now, fasten DRAWER RIGHT (40CC) to the LARGE RIGHT DRAWER
SIDE (D132). Use two GOLD 5/16" FLAT HEAD SCREWS (TT) throuh
holes #1 and #4.
å Repeat steps 13 and 14 for the other drawers.
Step 14
409714www.sauder.com/services Pae 19
3.
1.
DD
HH
HH
HH
43
40CC
Screw head - turn CAM to line
up the hole in the SLIDE with
the hole in the DRAWER SIDE.
Slot
These tabs must insert into the slots.
Seated
1
2
D132
D138
D132
GOLD 5/16" FLAT HEAD SCREW
(8 used in this step)
TT
2. Post

Step 15
å Fasten three KNOBS (BB) to the DRAWER FRONT (J2). Use
three BLACK 1-1/8" MACHINE SCREWS (NN).
å Fasten two PULLS (FF) to the LARGE DRAWER FRONT (O2).
Use four SILVER 3/4" MACHINE SCREWS (OO).
å Repeat this step for the other lare drawers.
409714 www.sauder.com/servicesPae 20
FF
J2
O2
BB
BLACK 1-1/8" MACHINE SCREW
(3 used for the KNOBS)
NN
SILVER 3/4" MACHINE SCREW
(12 used for the PULLS)
OO
