Sauder WHISKER User manual

If you have assembly questions or need a replacement part, please contact Sauder directly at
www.sauder.com or 800-445-1527.
Customer Service is available Monday-Friday - 9 a.m. to 5:30 p.m. EST (except holidays)
WHISKER CORNER CREDENZA
[e-mail] | 1.877.250.7729 | Mon-Fri, 9am-5:30pm EST

Table of Contents Assembly Tools Required
Part Identication
Hardware Identication
Hardware Usage Guide
Assembly Steps
Français
Español
Safety
Warranty
No. 2 Phillips Screwdriver
Tip Shown Actual Size
REGISTER YOUR NEW
PRODUCT ONLINE
For immediate service,
our website is available 24
hours per day, 7 days per
week, to order replacement
parts, access assembly tips,
register your product and
view Sauder products.
www.sauder.com/service
3
4
5
6-29
30-33
34-37
38
39
THANK YOU FOR PURCHASING THE WHISKER CORNER CREDENZA!
I am thrilled that Whisker and Sauder furniture have partnered
together to bring you the highest-quality pet furniture. At
Whisker, we design and deliver rened pet accessories that
delight both pets and people. Whisker and Sauder products
are made with environmentally responsible materials and
world-class manufacturing processes. Together, our companies
are bringing pet parents a premium line of stylish yet functional
pet furniture that is built to last. Enjoy!
Jacob Zuppke, President & CEO of Whisker
430043 whiskersupport.com Page 2

Part Identication
åWhile not all parts are labeled, some of the parts will have a label or an inked letter on the edge to
help distinguish similar parts from each other. Use this part identication to help identify similar parts.
Now you know
our ABCs.
A
D
B
C
A TOP (1)
B BOTTOM (1)
C LARGE LEFT BACK (1)
D LARGE RIGHT BACK (1)
E SMALL BACK (1)
F SMALL RIGHT END (1)
G SMALL LEFT END (1)
H SHELF (1)
J LEFT DOOR (1)
K BRACE (1)
L LARGE END (2)
M MOLDING (1)
N FOOT (1)
O RIGHT DOOR (1)
E
F
G
J
K
L
M
OH
N
L
430043whiskersupport.com Page 3

Hardware Identication
åScrews are shown actual size. You may receive extra hardware with your unit.
APPLIQUE CARD - 1
9
CAM SCREW - 10
1
1/2" HEX HEAD SCREW - 3
17 1/2" FLAT HEAD SCREW - 2
18
14 13/16" MACHINE SCREW - 4
2-3/8" HEX HEAD SCREW - 6
11
1-3/8" HEX HEAD SCREW - 4
13
HIDDEN CAM - 10
2WOOD DOWEL - 22 3
1/2" PAN HEAD SCREW - 12
16
L-WRENCH - 1
10
SHELF PIN - 4
5
4MAGNETIC
CATCH SET - 1
PULL - 2
87 GROMMET - 1HINGE SET - 2 6
5/8" FLAT HEAD SCREW - 2
15
1-9/16" FLAT HEAD SCREW - 10
12
430043 whiskersupport.com Page 4

Hardware Usage Guide
HOW TO USE A HIDDEN CAM & CAM SCREW OR CAM DOWEL
NOTE: Various CAM SCREWS or a CAM DOWEL may be used.
Cam Dowel
Cam Screws
Turn the CAM SCREW
or gently tap the
CAM DOWEL until the
shoulder is against the
surface of the part.
1.
3.
Insert the CAM SCREW or CAM DOWEL into
the HIDDEN CAM. Tighten the HIDDEN CAM.
1
2
2.
Arrow
Push a HIDDEN CAM into
the part. The arrow in
the HIDDEN CAM must
point toward the hole in
the edge of the board.
Hole
Hidden Cam
430043whiskersupport.com Page 5

Step 1
View our assembly video at
www.whisker.com/support
430043 whiskersupport.com Page 6
å Assemble your unit on a carpeted oor or on
the empty carton to avoid scratching your unit
or the oor.
å Push ten HIDDEN CAMS (2) into the LARGE
BACKS (C and D) and SMALL ENDS (F AND G).
å Insert two WOOD DOWELS (3) into the SMALL
BACK (E).
å Fasten the SMALL RIGHT END (F) to the SMALL
BACK (E). Use one 1-9/16" FLAT HEAD SCREW (12).
å NOTE: Be sure the WOOD DOWELS in the SMALL
BACK insert into the SMALL RIGHT END.
C
D
F
E
G
2
2
Arrow
(10 used)
3
3
1-9/16" FLAT HEAD SCREW
(1 used in this step)
12
Arrow
Arrow
Arrow
2
2
F

Step 2
430043whiskersupport.com Page 7
å You have the option to have the SHELF on the left
or right side.
å If you want the SHELF on the left go to Step 3.
å If you want the SHELF on the right go to Step 15
Shelf on left
Steps 3 - 14
Shelf on right
Steps 15 - 26

Step 3
430043 whiskersupport.com Page 8
å Insert two WOOD DOWELS (3) into the
SMALL BACK (E).
å Fasten the SMALL BACK (E) to the LARGE
LEFT BACK (C). Use one 1-9/16" FLAT HEAD
SCREW (12).
å NOTE: Be sure the WOOD DOWELS in
the SMALL BACK insert into the LARGE
LEFT BACK.
E
F
C
3
Surface with HIDDEN CAMS
These holes
must be here.
The SMALL RIGHT END (F)
should be towards this edge
(2 used)
SHELF ON THE LEFT
1-9/16" FLAT HEAD SCREW
(1 used in this step)
12

Step 4
430043whiskersupport.com Page 9
å Insert two WOOD DOWELS (3) into the LARGE LEFT
BACK (C).
å Fasten the LARGE RIGHT BACK (D) to the LARGE LEFT
BACK (C). Use one 1-9/16" FLAT HEAD SCREW (12).
å NOTE: Be sure the WOOD DOWELS in the LARGE
LEFT BACK insert into the LARGE RIGHT BACK.
å Turn one CAM SCREW (1) into the BOTTOM (B).
D
Surface with HIDDEN CAMS
B
1
1-9/16" FLAT HEAD SCREW
(1 used in this step)
12
SHELF ON THE LEFT
3
3
C

Step 5
430043 whiskersupport.com Page 10
å Carefully turn your unit onto its top.
å Insert six WOOD DOWELS (3) into the LARGE BACKS (C and D)
and SMALL RIGHT END (F).
å Fasten the BOTTOM (B) to the LARGE BACKS (C and D).
Use six 1-9/16" FLAT HEAD SCREWS (12).
å Fasten the BOTTOM (B) to the SMALL RIGHT END (F). Tighten
one HIDDEN CAM.
å NOTE: Be sure the WOOD DOWELS in the LARGE BACKS and
SMALL RIGHT END insert into the BOTTOM.
å Fasten the FOOT (N) to the BOTTOM (B). Use four 1/2" PAN
HEAD SCREWS (16).
B
F
C
D
3
1/2" PAN HEAD SCREW
(4 used for the FOOT)
16
(6 used)
1-9/16" FLAT HEAD SCREW
(6 used for the BOTTOM)
12
N
SHELF ON THE LEFT

Step 6
430043whiskersupport.com Page 11
å Carefully turn your unit onto its bottom.
å Insert one WOOD DOWEL (3) into the LARGE
RIGHT BACK (D).
å Fasten the SMALL LEFT END (G) to the LARGE
RIGHT BACK (D). Use one 1-9/16" FLAT HEAD
SCREW (12).
å NOTE: Be sure the WOOD DOWEL in the LARGE
RIGHT BACK inserts into the SMALL LEFT END.
D
G
These holes
must be here.
SHELF ON THE LEFT
1-9/16" FLAT HEAD SCREW
(1 used for the BOTTOM)
12
3

Step 7
430043 whiskersupport.com Page 12
å Fasten the LARGE ENDS (L) to the BOTTOM (B) and LARGE
BACKS (C and D). Tighten six 2-3/8" PAN HEAD SCREWS (11)
using the L-WRENCH (10).
å NOTE: You should start each SCREW a few turns before
completely tightening any of them.
C
LL
B
2-3/8" PAN HEAD SCREW
(6 used in this step)
11
10
For support, place packing
foam or books here.
SHELF ON THE LEFT
D

Step 8
430043whiskersupport.com Page 13
å Insert two WOOD DOWELS (3) into the
BOTTOM (B).
å Fasten the MOLDING (M) to the BOTTOM (B).
Tighten three 1/2" HEX HEAD SCREWS (17)
using the L-WRENCH (10).
å NOTE: Be sure the WOOD DOWELS in the
BOTTOM insert into the MOLDING.
M
3
1/2" HEX HEAD SCREW
(3 used in this step)
17
SHELF ON THE LEFT
B

Step 9
430043 whiskersupport.com Page 14
å Turn nine CAM SCREWS (1) into the TOP (A)
exactly as shown.
å Fasten the MAGNETIC CATCH from the
MAGNETIC CATCH SET (4) to the TOP (A). Use
two 5/8" FLAT HEAD SCREWS (15).
4
Magnetic side
A
5/8" FLAT HEAD SCREW
(2 used in this step)
15
1
(9 used)
Thinking outside
the litter box.
SHELF ON THE LEFT

Step 10
430043whiskersupport.com Page 15
4
8
J
J
1/2" FLAT HEAD SCREW
(2 used for the PLATES)
18
13/16" MACHINE SCREW
(4 used for the PULLS)
14
Surface
with fewer
holes
6
1/2" PAN HEAD SCREW
(4 used for the HINGES)
16
å Fasten one HINGE from one of the HINGE
SETS (6) to the LEFT DOOR (J). Use two 1/2"
PAN HEAD SCREWS (16)
å Fasten one of the PLATES from the MAGNETIC
CATCH SET (4) to the LEFT DOOR (J). Use one
1/2" FLAT HEAD SCREW (18).
å Fasten one of the PULLS (8) to the LEFT DOOR (J).
Use two 13/16" MACHINE SCREWS (14).
å Push one of the BUSHINGS from the HINGE SET (6)
onto the HINGE on the LEFT DOOR (J).
å Repeat this step for the RIGHT DOOR (O).
6
SHELF ON THE LEFT

Step 11
430043 whiskersupport.com Page 16
å Insert seven WOOD DOWELS (3) into the LARGE BACKS (C
and D) and SMALL ENDS (F and G).
å Fasten the TOP (A) to the LARGE BACKS (C and D) and
SMALL ENDS (F and G). Tighten ten HIDDEN CAMs.
å Fasten the TOP (A) to the LARGE ENDS (L). Tighten four
1-3/8" PAN HEAD SCREWS (13) using the L-WRENCH (10).
å NOTE: Be sure the WOOD DOWELS in the LARGE BACKS
and SMALL ENDS insert into the TOP.
F
G
A
L
CD
3
(7 used)
1-3/8" HEX HEAD SCREW
(4 used in this step)
13
10
SHELF ON THE LEFT

Step 12
430043whiskersupport.com Page 17
å Insert one of the BUSHINGS from the HINGE SET (6) into
the MOLDING (M). Then, insert one of the HINGES from
the HINGE SET (6) into the BUSHING.
å Insert the HINGE on the RIGHT DOOR (O) into the TOP (A).
å Fasten the remaining HINGE in the MOLDING (M) to the
RIGHT DOOR (O). Use two 1/2" PAN HEAD SCREWS (16).
å Repeat this step for the LEFT DOOR (J).
O
M
A
Surface with
PLATE
6
1/2" PAN HEAD SCREW
(4 used for the HINGES)
16
SHELF ON THE LEFT

Step 13
430043 whiskersupport.com Page 18
å Insert the GROMMET (7) into the large hole in the
BOTTOM (B).
å Push the BRACE (K) into the corner of the BOTTOM (B)
and LARGE BACKS (C and D).
å Peel APPLIQUES from the APPLIQUE CARD (9) and
stick them onto each visible HIDDEN CAM in the
LARGE BACKS (C and D).
K
B
D
C
7
9
SHELF ON THE LEFT

Step 14
430043whiskersupport.com Page 19
å Insert the SHELF PINS (5) into the hole locations of your choice
in the LARGE LEFT BACK (C) and SMALL RIGHT END (F). Set the
ADJUSTABLE SHELF (H) onto the SHELF PINS.
å NOTE: Please read the back pages of the instruction booklet
for important safety information.
å This completes assembly. Clean with a damp cloth. Wipe dry.
F
C
5
(4 used)
H
15 lbs.
60 lbs.
35 lbs.
SHELF ON THE LEFT
And to celebrate, why not share your success story at whisker.com or

Step 15
430043 whiskersupport.com Page 20
å Insert two WOOD DOWELS (3) into the
SMALL BACK (E).
å Fasten the SMALL BACK (E) to the LARGE
RIGHT BACK (D). Use one 1-9/16" FLAT HEAD
SCREW (12).
å NOTE: Be sure the WOOD DOWELS in the
SMALL BACK insert into the LARGE RIGHT BACK.
SHELF ON THE RIGHT
E
F
D
3
Surface with HIDDEN CAMS
These holes
must be here.
The SMALL RIGHT END (F)
should be towards this edge
(2 used)
1-9/16" FLAT HEAD SCREW
(1 used in this step)
12
