Sauder Lateral File Pacific View 427360 User manual

sauder.com
NOTE: THIS INSTRUCTION
BOOKLET CONTAINS IMPORTANT
SAFETY INFORMATION.
PLEASE READ AND KEEP FOR
FUTURE REFERENCE.
sauder.com
CONTACT US FIRST
BEFORE MAKING ANY RETURNS TO THE STORE.
sauder.com
CONTACT US FIRST
BEFORE MAKING ANY RETURNS TO THE RETAILER.
Visit sauder.com/service to order replacement parts, view video assembly tips, or chat with a live rep.
Prefer the phone? Give us a ring at 1-800-523-3987.
Customer Service is available Monday-Friday - 9 a.m. to 5:30 p.m. EST (except holidays)
Sauder.com
Share your journey!
Enlish p 1-24
Français p 25-28
Español p 29-32
Lateral File
Pacific View Collection | Model 427360
Lot # 542645 03/05/20
Purchased: __________________
Get all organized
and stu.

Table of Contents Assembly Tools Required
Part Identification
Hardware Identification
Assembly Steps
Français
Español
Safety
Warranty
No. 2 Phillips Screwdriver
Tip Shown Actual Size
3
4-5
6-24
25-28
29-32
33-34
35
427360 www.sauder.com/servicePae 2

Part Identification
åWhile not all parts are labeled, some of the parts will have a label or an inked letter on the edge
to help distinguish similar parts from each other. Use this part identification to help identify similar parts.
Now you know
our ABCs.
A RIGHT END (1)
B LEFT END (1)
C TOP (1)
D BOTTOM (1)
D61 DRAWER BACK (2)
D429 LEFT DRAWER SIDE (2)
D549 RIGHT DRAWER SIDE (2)
D729 DRAWER BOTTOM (2)
ELEFT FRONT/RIGHT
REAR LEG (2)
FRIGHT FRONT/LEFT
REAR LEG (2)
G TOP MOLDING (2)
H SIDE MOLDING (4)
J BOTTOM MOLDING (1)
K DRAWER MOLDING (1)
L BACK (2)
M DRAWER FRONT (2)
M63
DRAWER BRACE (2)
(Hidden part usin recycled
material. Color may vary.)
A
B
C
D
E
E
F
F
G
G
H
H
H
H
D61
J
K
L
L
M
D729
M63
D549
D429
427360www.sauder.com/service Pae 3

Hardware Identification
åScrews are shown actual size. You may receive extra hardware with your unit.
FILE BRACKET - 2
57G
10A SLIDE CAM - 4
CAM SCREW - 16
8F WOOD DOWEL - 16 15F
FILE BRACKET - 4
12B HIDDEN CAM - 22 1F
CAM DOWEL - 6
2F
34G INTERLOCK MECHANISM - 1 DRAWER
ACTUATOR - 2
62G
FILE ROD - 4
9B
FILE BAR - 4
1B
FILE GLIDE - 4
6B
(EXTENSION SET SHOWN SEPARATED)
EXTENSION SLIDE - 4
40MC
EXTENSION RAIL - 4
40MA
PULL - 2
190K
427360 www.sauder.com/servicePae 4
MOLDING
CONNECTOR - 4
16F

Hardware Identification
åScrews are shown actual size. You may receive extra hardware with your unit.
BLACK 1-1/8" PAN HEAD SCREW - 8
9S
GOLD 1" MACHINE SCREW - 4
50S
BLACK 9/16" LARGE HEAD SCREW - 8
1S
BROWN 7/16" LARGE HEAD SCREW - 8
6S
BLACK 1/2" FLAT HEAD SCREW - 9
11S
BLACK 1-15/16" FLAT HEAD SCREW - 4
113S
30S BLACK 1-9/16" FLAT HEAD SCREW - 10
3S GOLD 5/16" FLAT HEAD SCREW - 16
427360www.sauder.com/service Pae 5

Hardware Usage Guide
HOW TO USE A HIDDEN CAM & CAM DOWEL
Cam Screw
Hidden Cam
Arrow
Push a HIDDEN CAM into
the part. The arrow in the
HIDDEN CAM must point
toward the hole in the
edge of the board.
Hole
2. 3.
1
2
Insert the CAM SCREW into the HIDDEN CAM.
Tighten the HIDDEN CAM.
HOW TO USE A HIDDEN CAM & CAM SCREW
Turn the CAM SCREW until
the shoulder is against the
surface of the part.
1.
2. Insert the metal end of the CAM
DOWEL into the HIDDEN CAM.
1. Push a HIDDEN CAM into
the part. The arrow in the
HIDDEN CAM must point
toward the hole in the edge
of the board.
Hole
Arrow
Metal end
Hidden Cam
Cam Dowel
Start Tighten
Arrow
Minimum
190 degrees
Caution
Risk of damage or
injury. HIDDEN CAMS
must be completely
tightened. HIDDEN
CAMS that are not
completely tightened
may loosen, and parts
may separate. To
completely tighten:
Arrow
Maximum
210 degrees
3.
427360 www.sauder.com/servicePae 6

Step 1 Look for this icon. It means a video assembly tip is
available at www.sauder.com/service/tips
Find the numbered video or scan the QR code.
å Assemble your unit on a carpeted floor or on the empty
carton to avoid scratchin your unit or the floor.
å Push sixteen HIDDEN CAMS (1F) into the ENDS (A and B).
å Fasten a SIDE MOLDING (H) to each of the ENDS (A and B).
Use four BLACK 1-1/8" PAN HEAD SCREWS (9S).
å NOTE: Do not overtihten the SCREWS into the END.
A
H
B
1
9S
BLACK 1-1/8" PAN HEAD SCREW
(4 used in this step)
1F
Arrow
1F
Arrow
(16 used)
1F
Arrow
427360www.sauder.com/service Pae 7
Just think. The sooner
you do this, the sooner
you do somethin else.
The hole is closer
to this ede.
H

å Separate the EXTENSION SLIDES (40MC) from the EXTENSION RAILS (40MA) as shown in the upper diaram below. Be
prepared, the parts are reasy.
å Fasten the EXTENSION RAILS (40MA) to the ENDS (A and B). Use eiht GOLD 5/16" FLAT HEAD SCREWS (3S) throuh
holes #1 and #4.
å NOTE: For each EXTENSION RAIL, turn a SCREW into the hole shown in the enlared diaram. Then, slide the inner cartride
of the EXTENSION RAIL in to find the other hole that lines up with the hole in the ENDS. Turn a SCREW into this hole.
å NOTE: The EXTENSION SLIDES will be used later for the DRAWERS.
Step 2
A
B
7
Open end
Push the black lever in and pull the SLIDE from the RAIL.
40MA40MC
Open end
GOLD 5/16" FLAT HEAD SCREW
(8 used for the RAILS)
3S
1
1
1
1
2
2
2
2
3
3
3
3
4
4
4
4
427360 www.sauder.com/servicePae 8

Step 3
å Fasten the INTERLOCK MECHANISM (34G) to the RIGHT
END (A). Use three BLACK 1/2" FLAT HEAD SCREWS (11S).
A
BLACK 1/2" FLAT HEAD SCREW
(3 used in this step)
11S
34G
427360www.sauder.com/service Pae 9

Step 4
å Push four HIDDEN CAMS (1F) into the TOP (C).
å Insert the metal end of a CAM DOWEL (2F) into each
HIDDEN CAM in the short edes of the ENDS (A and B).
å Fasten the ENDS (A and B) to the TOP (C). Tihten four
HIDDEN CAMS.
C
A
C
B
1F
Arrow
1F
Arrow
2F
Metal end
2F
Metal end
1
427360 www.sauder.com/servicePae 10
Surface with
HIDDEN CAMS
Surface without
HIDDEN CAMS

Step 5
å Turn eiht CAM SCREWS (8F) into one LEFT FRONT/RIGHT
REAR LEG (E), one of the RIGHT FRONT/LEFT REAR LEGS (F) and
one of the TOP MOLDINGS (G).
å Insert four WOOD DOWELS (15F) into the LEGS (E and F).
å Gently tap two MOLDING CONNECTORS (16F) into the notches in
the FRONT LEGS (E and F) and TOP MOLDING (G).
å Repeat this step for the other LEGS and TOP MOLDING.
15F
8F
8F
(16 used)
1
427360www.sauder.com/service Pae 11
16F
Flat end
Flat end
16F
E
F
G
Use your hammer to ently tap the MOLDING
CONNECTORS (16F) into the notches in the LEGS.

StepStep 6
å Fasten the LEGS (E and F) and TOP MOLDING (G) to
the ENDS (A and B) and TOP (C). Tihten sixteen
HIDDEN CAMS.
å NOTE: Be sure the WOOD DOWELS in the LEGS insert
into the ENDS.
E
F
F
E
G
G
C
B
A
1
427360 www.sauder.com/servicePae 12

StepStep 7
å Fasten the BRACKETS (57G) to the ENDS (A and B) and
LEGS (E and F). Use four BLACK 9/16" LARGE HEAD
SCREWS (1S).
å Fasten the DRAWER MOLDING (K) to the BRACKETS on
the ENDS (A and B) and LEGS (E and F). Use four BLACK
9/16" LARGE HEAD SCREWS (1S).
å NOTE: There are no pre-drilled holes in the MOLDING.
The SCREWS will tihten into the roove.
The roove
is closer to
this ede.
F
E
B
K
A
427360www.sauder.com/service Pae 13
BLACK 9/16" LARGE HEAD SCREW
(8 used in this step)
1S
57G

Step
å Insert four WOOD DOWELS (15F) into the TOP (C).
å Insert the BACKS (L) between the ENDS (A and B), and place
the BACKS (L) onto the WOOD DOWELS in the TOP (C).
å Insert four WOOD DOWELS (15F) into the BACKS (L).
Step 8
B
A
C
L
L
15F
15F
15F
427360 www.sauder.com/servicePae 14
Finished surface Finished surface
The finished
edes should be
facin each other.

Step
427360www.sauder.com/service Pae 15
Step 9
å Slide the BOTTOM MOLDING* (J) onto the notched ede of
the BOTTOM (D).
å NOTE: The MOLDING should be centered on the BOTTOM.
å *U.S. Patent No. 5,499,886
D
J
These edes
should be even.
Notched ede
The roove
is closer to
this ede.
Now miht be a
ood time to refresh
your drink.

Step
å Fasten the BOTTOM (D) to the ENDS (A and B). Use four
BLACK 1-15/16" FLAT HEAD SCREWS (113S).
å NOTE: You should start each SCREW a few turns before
completely tihtenin any of them.
Step 10
D
B
A
BLACK 1-15/16" FLAT HEAD SCREW
(4 used in this step)
113S
113S
427360 www.sauder.com/servicePae 16

Step
427360www.sauder.com/service Pae 17
å Fasten the remainin two SIDE MOLDINGS (H) to
the ENDS (A and B). Use four BLACK 1-1/8" PAN
HEAD SCREWS (9S).
å NOTE: Do not overtihten the SCREWS into the END.
Step 11
B
H
H
A
The hole is closer
to this ede.
9S
BLACK 1-1/8" PAN HEAD SCREW
(4 used in this step)

StepStep 12 9
å Insert the DRAWER SIDES (D429 and D549) at an angle
into the slot at each end of the DRAWER FRONT (M). å Slide the DRAWER BOTTOM (D729) into the grooves in the DRAWER SIDES (D429 and D549)
and DRAWER FRONT (M).
å Push one HIDDEN CAM (1F) into the DRAWER BRACE (M63).
Then insert the metal end of a CAM DOWEL (2F) into the
HIDDEN CAM.
å Fasten the DRAWER BRACE (M63) to the
DRAWER FRONT (M). Tighten one HIDDEN CAM.
å Fasten the DRAWER BACK (D61) to the DRAWER
SIDES (D429 and D549) and DRAWER BRACE (M63).
Use five BLACK 1-9/16" FLAT HEAD SCREWS (30S).
å Repeat this step for the other drawer.
12
34
Be sure the DRAWER
BOTTOM inserts into the
DRAWER FRONT roove.
D729
Unfinished
surface
30S
Start each screw a few turns before
completely tihtenin any of them.
BLACK 1-9/16" FLAT HEAD SCREW
(10 used in this step)
The tabs should insert freely
into the slots. Gently tilt the
DRAWER SIDES side to side
until the tabs slip into the slots.
With the palm of your hand,
tap the DRAWER BOTTOM
down into the roove.
Surface with
HIDDEN CAM M
M63
Hidden part usin
recycled material.
Color may vary.
M63
1
D549
M
Groove
M
D549
Arrow
1F
2F
Metal end
D61
Be sure the
DRAWER
BOTTOM
inserts into
the DRAWER
BACK roove.
M63
D549
427360 www.sauder.com/servicePae 18
(2 used)
D429
D429
D429

Step
427360www.sauder.com/service Pae 19
å Insert a SLIDE CAM (10A) into the DRAWER SIDES (D429 and D549).
å Fasten the EXTENSION SLIDES (40MC) to the DRAWER SIDES (D429 and D549). Use four GOLD 5/16" FLAT HEAD
SCREWS (3S) throuh holes #1 and #4.
å NOTE: The screw head in the CAM must be visible throuh the slotted hole in the SLIDE.
å Fasten a PULL (190K) to a DRAWER FRONT (M). Use two GOLD 1" MACHINE SCREWS (50S).
å Repeat this step for the other drawer.
Step 13
Open end
Open end
Screw head -
turn CAM to line
up holes in the
SLIDES with holes
in DRAWER SIDES
1
2
3
4
1
2
3
4
M
10A
10A
6
190K
GOLD 1" MACHINE SCREW
(4 used for the PULLS)
50S
D549
Drawer Slide
Center the screw in the oval hole.
GOLD 5/16" FLAT HEAD SCREW
(8 used for the SLIDES)
3S
(4 used)
D429

StepStep 14
å Fasten two FILE BRACKETS (12B) to a DRAWER FRONT (M)
and DRAWER BACK (D61). Use four BROWN 7/16" LARGE
HEAD SCREWS (6S).
å Repeat this step for the other drawer.
M
BROWN 7/16" LARGE HEAD SCREW
(8 used in this step)
6S
12B
12B
D61
427360 www.sauder.com/servicePae 20
6S
6S
