Sauder Harbor View 414941 User manual

Need help? Visit Sauder.com to view video assembly tips or chat with a live rep.
Prefer the phone? Call 1-800-523-3987.
Share your journey!
sauder.com
NOTE: THIS INSTRUCTION
BOOKLET CONTAINS IMPORTANT
SAFETY INFORMATION.
PLEASE READ AND KEEP FOR
FUTURE REFERENCE.
Enlish p 1-18
Français p 19-21
Español p 22-24
Lot # 364751 08/28/14
Purchased: __________________
Be sure to ive us a rin before
makin any returns. 1-800-523-3987
5-Drawer Chest
Harbor View Collection | 414941
Stu a sock in it.
Or two.

Table of Contents Assembly Tools Required
Part Identification
Hardware Identification
Assembly Steps
Français
Español
Safety
Warranty
Hammer
Not actual size
No. 2 Phillips Screwdriver
Tip Shown Actual Size
Skip the power trip.
This time.
2-3
4
5-18
19-21
22-24
25-26
27
414941 www.sauder.com/servicesPae 2
Now you know
our ABCs.
Part Identification
åWhile not all parts are labeled, some of the parts will have a label or an inked letter on the ede
to help distinuish similar parts from each other. Use this part identification to help identify similar parts.
A RIGHT END (1)
B LEFT END (1)
C TOP (1)
D LOWER BRACE (2)
E UPPER BRACE (1)
F BACK (3)
G DRAWER FRONT (3)
H SMALL DRAWER FRONT (1)
I LOWER DRAWER FRONT (1)
J BOTTOM MOLDING (1)
K RIGHT MOLDING (1)
L LEFT MOLDING (1)
M SKIRT (1)
N FRONT MOLDING (1)
O MOLDING (1)
P DRAWER BRACE (5)
Q FOOT (2)
D24 SMALL RIGHT DRAWER SIDE (1)
D25 SMALL LEFT DRAWER SIDE (1)
D30 RIGHT DRAWER SIDE (4)
D31 LEFT DRAWER SIDE (4)
D170 SMALL DRAWER BACK (1)
D171 DRAWER BACK (4)
D945 DRAWER BOTTOM (5)

Part Identification
414941www.sauder.com/services Pae 3
D945
D945
D945
D170
D171
A
B
C
D
E
F
G
H
I
J
L
M
N
O
P
Q
D24
D25
D30
D31
D171 D30
D31
P
P
Q
D
F
F
K

Hardware Identification
åScrews are shown actual size. You may receive extra hardware with your unit.
414941 www.sauder.com/servicesPae 4
5L WARNING LABEL - 1
(Refer to step 12 for proper
location and application)
WARNING
Serious or fatal crushing injuries can occur
from furniture tip-over. To help prevent
tip-over:
• Place heaviest items in the lowest drawers.
• Unless specifically desined to accommodate, do not
set TVs or other heavy objects on top of this product.
• Never allow children to climb or han on drawers,
doors, or shelves.
• Never open more than one drawer at a time.
• If equipped with a drawer interlock system, do not
defeat or remove it.
Use of tip-over restraints may only reduce, but not
eliminate, the risk of tip-over.
This is a permanent label. Do not attempt to remove!
04/10 332296
35GA CABINET RIGHT - 5 35GB CABINET LEFT - 5 35GC DRAWER RIGHT - 5 35GD DRAWER LEFT - 5
SAFETY
STRAP - 1
60M SAFETY DRYWALL
ANCHOR - 1
61M
WASHER - 1
13M
BLACK 1-1/8" PAN HEAD SCREW - 4
9S
BLACK 1-1/8" MACHINE SCREW - 2
21S
SILVER 3/4" MACHINE SCREW - 16
20S
BLACK 9/16" LARGE HEAD SCREW - 1
1S
BLACK 1-5/8" PAN HEAD SCREW - 7
27S
BLACK 1-7/8" FLAT HEAD SCREW - 2
2S
BLACK 2-1/4" FLAT HEAD SCREW - 4
26S
10F TWIST-LOCK®
FASTENER - 11 FOOT SCREW - 2
23F
MOLDING
CONNECTOR - 2
16F
3S GOLD 5/16" FLAT HEAD SCREW - 40
METAL
PIN - 10
1R
KNOB - 2
5K
10A SLIDE CAM - 10
30S BLACK 1-9/16" FLAT HEAD SCREW - 25
HIDDEN
CAM - 11
1F CAM
DOWEL - 11
2F
PULL - 8
98K
Locate this nylon SAFETY
STRAP (60M) to be used
later in assembly. Do not
accidentally throw away.

Step 1 Look for this icon. It means a
video assembly tip is available at
www.sauder.com/services/tips
å Assemble your unit on a carpeted floor or on the empty
carton to avoid scratchin your unit or the floor.
å To bein assembly, push a SAUDER TWIST-LOCK®
FASTENER (10F) into the lare holes in the BRACES (D and E).
å NOTE: Do not push any TWIST-LOCK® FASTENERS into the
indicated holes in the UPPER BRACE (E) at this time. If you
need to remove a TWIST-LOCK® FASTENER from a hole,
pull the FASTENER back out of the hole. Pull at the front and
back edes, slowly workin the FASTENER out of the hole.
414941www.sauder.com/services Pae 5
Scan this QR code or go to this address:
http://qr.sauder.com/?ID=904
to watch a video on how to assemble your unit.
Do not tihten the TWIST-LOCK® FASTENERS in this step.
D
E
D
10F
10F
10F
Do not push TWIST-LOCK®
FASTENERS into these holes
at this time.
Do not push TWIST-LOCK®
FASTENERS into these holes
at this time.

å Push eleven HIDDEN CAMS (1F) into the BACKS (F) and
DRAWER BRACES (P). Then, insert the metal end of a
CAM DOWEL (2F) into each HIDDEN CAM.
Step 2
414941 www.sauder.com/servicesPae 6
Arrow
1F
2F
(11 used)
Arrow
1F
2F
Insert the metal end of the CAM
DOWEL into the HIDDEN CAM.
Arrow
Do not tihten the HIDDEN CAMS in this step.
P
P
P
P
P
F
F
F

å Fasten five CABINET RIGHTS (35GA) to the RIGHT
END (A) and five CABINET LEFTS (35GB) to the LEFT
END (B). Use twenty GOLD 5/16" FLAT HEAD
SCREWS (3S) throuh holes #1 and #3.
Step 3
414941www.sauder.com/services Pae 7
Remember:
Rihty tihty.
Lefty loosey.
B
A
Surface with
holes
1
2
3
1
2
3
Roller end
Roller end
GOLD 5/16" FLAT HEAD SCREW
(20 used in this step)
3S
Finished ede
Finished ede
Surface with
holes
1
2
3
1
2
3
1
2
3
1
2
3
1
2
31
2
31
2
31
2
3

å Tap two MOLDING CONNECTORS (16F) into the notches
in the MOLDINGS (K, L, and N).
Step 4
414941 www.sauder.com/servicesPae 8
L
N
16F
16F
K
Flat end
Flat end
Use your hammer to tap the MOLDING CONNECTOR (16F) into the notches in the MOLDINGS

å First, fasten the SKIRT (M) to the BOTTOM MOLDING (J). Use two BLACK 1-7/8" FLAT HEAD SCREWS (2S).
å Then, fasten the BOTTOM MOLDING (J) to one of the LOWER BRACES (D). Use four BLACK 1-1/8" PAN HEAD SCREWS (9S).
å Fasten the MOLDING (O) to the UPPER BRACE (E). Tihten three TWIST-LOCK® FASTENERS.
Step 5
414941www.sauder.com/services Pae 9
E
O
Surface with
TWIST-LOCK®
FASTENERS
M
J
D
Surface with
TWIST-LOCK®
FASTENERS
Unfinished
surface
BLACK 1-7/8" FLAT HEAD SCREW
(2 used for the SKIRTS)
2S
BLACK 1-1/8" PAN HEAD SCREW
(4 used for the BOTTOM MOLDING)
9S
Rounded ede
Finished surface
These holes
must be here.
Dowel end
How to use the SAUDER TWIST-LOCK®FASTENER
1. Insert the dowel end of the FASTENER into the hole of the
adjoinin part.
NOTE: The dowel end of the FASTENER must remain fully
inserted in the hole of the adjoinin part while lockin
the FASTENER.
2. Tihten the FASTENER with a Phillips screwdriver as tiht
as possible.
These surfaces should be even.

å Insert three METAL PINS (1R) into the BACKS (F).
å Fasten the BACKS (F) to the LEFT END (B). Tihten three
HIDDEN CAMS.
å NOTE: Be sure the METAL PINS in the BACKS (F) insert
into the holes in the LEFT END (B).
Step 6
414941 www.sauder.com/servicesPae 10
Start Tihten
Arrow
Minimum
190 derees
Caution
Risk of damae or
injury. HIDDEN CAMS
must be completely
tihtened. HIDDEN
CAMS that are not
completely tihtened
may loosen, and parts
may separate. To
completely tihten:
Arrow
Maximum
210 derees
F
F
F
B
Surface with
HIDDEN CAMS
1R
Surface with
HIDDEN CAMS
Surface with
HIDDEN CAMS
Surface
with
holes
Finished ede
