SEA ARM Instruction manual

Sistemi elettronici
di Aperture Porte e Cancelli
ARM
FITTING AND CONNECTION INSTRUCTIONS
ARM isanelectromechanical not reversibleoperatorwith articulated armandgrease lubrication forresidentialuse on bigpilasters
andleafswithamax.weightof180kgand1,8mlength.
24Vlowvoltagepowersupply forahighsafetyofuse.
Inversionincaseofobstacle.
Witharticulatedsteelarmwithadjustablemechanicalstopinopening.
ENGLISH
DIMENSIONS (mm)
ARM
230 V (±5%) 50/60 Hz
24V
40 W
-20°C +55°C
12 Kg
180 Kg
1,8 m
110°
TECHNICAL DATA
Power Supply
Motor
Power
Working temperature
Weight
Max weight of the gate
Max. weight of the leaf
Opening degrees
1-Operator1
2-Operator2
3-Stopinopening
4-Electronicunitincluded
5-Flashinglamp
6-Rxphotocell
7-Differentialswitch16a-0,03a
8-Txphotocell
9-Keyswitch(onrequest)
10-Radioreceiver+antenna
11-Columnforphotocell
12-Warningplate
STANDARD INSTALLATION
Fig. 2
12
3
5
3x1,5
2x1
6
7
8
9
10
11
11
22
,
5x
3x1
2x1
3x1
21
4
3
31
,
x 5
,2x1 5
2x1,5
Fig. 1
225
218
243
REV 05 - 10/2007

Sistemi elettronici
di Aperture Porte e Cancelli
1. GATE ARRANGEMENT
ItisnecessarytomakecontrolsonthegatetomakesuretheapplicationofARMautomationcanbepossible.
Makesurethat: Fig. 3
Limit Switch stop
in opening
Limit Switch stop
in closing
A. the gate fixed and moving parts have a strong and crush-
proofstructure;
B. thelengthofeachleafisnotover1,8meters;
C. theweightofeachleafisnotover180Kg;
D. the hinges are hardly anchored and are able to support the
torque of the operator; they do not have irregular movements
and/oranyfrictionduringthewholemovementoftheleaf;
The ARM operator comes with limit switch stop in opening,
nevertheless it is recommended to install mechanical limit
switch stops to be fixed on the ground in closing and opening
(Fig.3).
ARM
FITTING AND CONNECTION INSTRUCTIONS
A
B
A
B
90°
110°
150
200
150
200
200
150
200
220
250
150
Fig. 4
DIMENSIONS FOR THE INSTALLATION
PC: Point of central rotation
Opening angle
"
B
"
A
Min 150 mm
PC
130°
ENGLISH
REV 05 - 10/2007

Fig. 5
Sistemi elettronici
di Aperture Porte e Cancelli
ARM
FITTING AND CONNECTION INSTRUCTIONS
MOUNTING PLATE ATTACHMENT AND MOUNTING OF THE MOTOR
- Attach the mounting plate to the pilaster with 4 screws and 4 washers
(Fig.5).Makesurethattheplateispositionedperfectlylevelled.
- Mount the motor on the plate using the 3 furnished screws and
successively mount the carter, fixing it laterally with the 2 furnished
screws(Fig.6)
- Thetwoarticulatedarmsmustbeassembleddifferently,distinguishingtherightarmfromtheleftone.
SeeFig.7and8.
Note:Beforeinsertingthepivotslubricatethemwithwaterrepellentgrease
ASSEMBLING OF THE ARTICULATED ARM
RIGHT HAND MOUNTING
LEFT HAND MOUNTING
Fig. 7Fig. 7
Fig. 8Fig. 8
PIVOTS
ENGLISH
REV 05 - 10/2007
Fig. 6

Sistemi elettronici
di Aperture Porte e Cancelli
ARM
FITTING AND CONNECTION INSTRUCTIONS
ATTACHMENT OF THE ARTICULATED ARM TO THE MOTOR
- Fitthearticulatedarmintothemotorshaftandlockitwiththespecialscrews(Fig.9).
ENGLISH
REV 05 - 10/2007
Fig. 10
Fig. 9
Security box
External release
Optional external release

Sistemi elettronici
di Aperture Porte e Cancelli
ARM
FITTING AND CONNECTION INSTRUCTIONS
FIXING OF THE FRONT BRACKET
- Close theleafcompletely
- Releasethemotor(seenextparagraph)
- Extendthe articulated armasinFig.4,leantheadjustablefront bracket onthegateandmaketwomarksonthecentreofthetwo
buttonholes(Fig.11)
- Perforatetheleafandattachthefrontbracketwiththescrews(Fig.12)
- Beforetighteningthescrewsmovethefrontbrackettotherightortotheleftforagoodpositioningofthearmonthegate(Fig.13)
Fig. 11
Fig. 12 Fig. 13
ENGLISH
REV 05 - 10/2007

Sistemi elettronici
di Aperture Porte e Cancelli
ARM
FITTING AND CONNECTION INSTRUCTIONS
RELEASE SYSTEM
Toreleaseoperateasfollows:
- Turnthereleasedoorandinsertthefurnished hexagonalT-keyintothespecialhole(Fig.14)
- Turnthereleasekeyabout180°clockwise(Fig.15).
- Extractthekeyandclosethedoor
- Openmanuallytheleaf
Toblockagainoperateasfollows:
- Insertthehexagonalkeyandturnitabout180°anticlockwise
- Movetheleafmanuallytoallowthere-couplingofthegearbeforeusinginautomatic.
- Extractthekeyandclosethedoor
Fig. 14
180°
Fig. 15
UNLOCK
ENGLISH
REV 05 - 10/2007

Sistemi elettronici
di Aperture Porte e Cancelli
ARM
FITTING AND CONNECTION INSTRUCTIONS
MECHANICAL POSITIVE STOP ADJUSTMENT IN OPENING
- Releasethemotor
- Bringtheleafincompleteopeningortothedesiredopeningpoint.
-PutthestopbracketSonthestopwiththearticulatedarmandlockthescrew1(left-handsidemotorFig.16,right-handsideFig.
17).
RIGHT MOTOR
Electrical
cable outlet
ENGLISH
Fig. 16
Fig. 17
LEFT MOTOR
Electrical
cable outlet
S
1
S
1
REV 05 - 10/2007

Sistemi elettronici
di Aperture Porte e Cancelli
Sistemi elettronici
di Aperture Porte e Cancelli
SEA S.r.l.
Zona industriale 64020 S.ATTO Teramo - (ITALY)
Tel. [phone] r.a. Fax [phone]
www.seateam.com
[email protected]
ARM
FITTING AND CONNECTION INSTRUCTIONS
DECLARATIONOFCONFORMITY
SEAdeclaresunderitsresponsibilitythattheproducts
ARM
meetstheessentialrequisitesprovidedforbythefollowingEuropeanDirectiveandfollowingchanges:
89/392/CEE(MachineDirective)
89/336/CEE (ElectromagneticCompatibilityDirective)
73/23/CEE(LowTensionDirective)
SAFETYPRECAUTIONS:
All electrical work should conform to current regulations.A16A 0,030Adifferential switch must be incorporated into the source of
the operators main electrical supply and the entire system properly earth bonded. Always run mains carrying cables in separate
ductstolowvoltagecontrolcablestopreventmainsinterference.
INTENDEDUSE:
ARMoperatorhasbeendesignedtobeusedonlyfortheautomationofswinggates.
SPAREPARTS:
Toobtainsparepartscontact:
SEAS.r.l.-ZonaInd.leS.Atto,64020S.NicolòaTordino-Teramo-ITALIA
SAFETYANDENVIRONMENTALCOMPATIBILITY:
Don’twasteproductpackingmaterialsand/orcircuits.
Whenbeingtransportedthisproductmustbeproperlypackagedandhandledwithcare.
MAINTENANCEANDOUTOFSERVICE:
ThedecommissionandmaintenanceofARMmustonlybecarriedoutbyspecialisedandauthorisedpersonnel.
NOTE: THE MANUFACTURER CAN NOT BE DEEMED RESPONSIBLE FOR ANY DAMAGE OR INJURY CAUSED BY
IMPROPERUSEOFTHISPRODUCT.
SEAreservestherighttodochangesorvariationsthatmaybenecessarytoitsproductswithnoobligationtonotice.
RISKEXAMINATION
ThepointspointedbyarrowsinFig.18 arepotentiallydangerous.
The installer must take a close risk examination to prevent
crushing, conveying, cutting, grappling, trapping so to guarantee
asafeinstallationforpeople,thingsandanimals
(). Re. Laws in force in the country where the installation has been
made
Fig. 18
ENGLISH
REV 05 - 10/2007
