Sealey FDT3.V2 User manual

FOLD DOWN TELESCOPIC TRESTLE 200KG
CAPACITY
MODEL NO: FDT3.V2
Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these
instructions, and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
1. SAFETY
9Familiarise yourself with this products application and limitations, as well as the specific potential hazards attributed to the trestle.
9Maintain the trestle in good condition.
9Replace or repair damaged parts. Use recommended parts only. Non authorised parts may be dangerous and will invalidate the
warranty.
9Keep the trestle clean for best and safest performance.
9Locate the trestle in a suitable working area for its function, keep area clean, tidy, free from unrelated materials and ensure there is
adequate lighting.
9Ensure the workpiece is correctly secured on the trestle/trestles before commencing work activity.
9Maintain correct balance and footing. Ensure the floor is not slippery and wear non-slip steel toe-capped shoes/boots.
9Keep children and unauthorised persons away from the working area.
8DO NOT use the trestle for any purpose other than that for which it is designed.
8DO NOT make any modifications to the trestle.
8DO NOT operate the trestle if any parts are missing or if the “over centre” locking links are not in the correct positions.
8DO NOT exceed the rated capacity of the trestle.
8DO NOT stand on the trestle or use as a platform.
9When not in use, stand or store in a safe, dry location.
WARNING! The warnings, cautions and instructions in this manual cannot cover all possible conditions and situations that
may occur. It must be understood by the operator that common sense and caution are factors which cannot be built into this
product, but must be applied by the operator.
2. INTRODUCTION
Manufactured from square section steel tube the trestle is ideal for supporting large/long workpieces when cutting, drilling etc. Trestle beam
has seven-position height adjustment and includes pivoted end stops to retain the workpiece. Legs fold in for easy transportation and storage.
3. SPECIFICATION
Model No: ................................................................FDT3.V2
Beam Width: .............................................................. 690mm
Capacity:...................................................................... 200kg
Folded (W x D x H): ................................680 x 150 x 840mm
Height Adjustment:............................................ 800-1300mm
Unfolded (W x D x H): .............................680 x 580 x 800mm
Nett Weight: ..................................................................... 6kg
FDT3.V2 Issue 3 (HF) 10/12/18
Original Language Version
© Jack Sealey Limited
Refer to
instructions
Wear eye
protection
Wear protective
gloves
Wear safety
footwear

4. CONTENTS
Description Qty
“A” Frame Sub Assembly 2
Bottom Cross Bar 2
Intermediate Cross Bar 1
Top Cross Bar Fabrication 1
Telescopic Uprights 2
M8 Fixings c/w Nuts & Washers 8-sets
M6 Phillips Machine Screws c/w Nuts & Washers 8-sets
Latch Shoulder Screw c/w M5 Nuts & Washers 2-sets
M5 Phillips Machine Screws c/w Nuts & Washers 2-sets
Check contents from list. In the unlikely event of a missing component please contact your Sealey stockist.
5. ASSEMBLY
5.1. TOOLS REQUIRED:
5.1.1. 13mm spanner, 10mm spanner, 8mm spanner and Phillips screwdrivers for M6 & M5.
5.2. ASSEMBLY
5.2.1. Fit intermediate cross bar to pre-assembled “A” frames (NB! Diagonally opposed latch positions). DO NOT fully tighten xings.
5.2.2. Fit bottom cross bars to “A” frames. DO NOT fully tighten xings.
5.2.3. From diagrams, rstly latch (Fig 1) and then “over centre” lock (Fig 2) “A” frame both sides. Tighten all screws.
5.2.4. Sub assemble telescopic uprights to top cross bar (M8 xings). Fit with interference “Pips” outermost and DO NOT fully tighten
xings.
5.2.5. Lower sub assembled telescopic uprights into “A” frames and intermediate cross bar guides. This will require a small force as the
interference “Pips” pass through the guides.
5.2.6. Insert “dog legged” pin through any of the holes in the telescopic uprights. Rotate pin to the “safe” retained position. Tighten top
cross bar xings. With “A” frames latched and locked both sides, height set, the trestle is ready for use.
Pre-assembled "A" Frame legs, Upright
Supports, "Dog Leg" Pin & Chain
M8 Fixings (13mm) c/w Nuts & Washers
Swivel Stop (deployed)
Latch Shoulder Screw c/w
Locknut and Washer.
"Dog Leg" Pin & Chain
(shown in retained position)
Top Cross Bar
M6 Phillips Machine Screws c/w Nuts & Washers
Telescopic Upright
Bottom Cross Bar
Intermediate Cross Bar
Telescopic Upright
M5 Phillips Machine
Screws c/w Nuts &
Washers
Interference
"Pip"
FDT3.V2 Issue 3 (HF) 10/12/18
Original Language Version
© Jack Sealey Limited

Sealey Group, Kempson Way, Suffolk Business Park, Bury St Edmunds, Suffolk. IP32 7AR
01284 757500 01284 703534 [e-mail] www.sealey.co.uk
ENVIRONMENT PROTECTION
Recycle unwanted materials instead of disposing of them as waste. All tools, accessories and packaging should be sorted, taken to
a recycling centre and disposed of in a manner which is compatible with the environment. When the product becomes completely
unserviceable and requires disposal, drain any fluids (if applicable) into approved containers and dispose of the product and fluids
according to local regulations.
Note: It is our policy to continually improve products and as such we reserve the right to alter data, specifications and component parts without prior
notice.
Important: No Liability is accepted for incorrect use of this product.
Warranty: Guarantee is 12 months from purchase date, proof of which is required for any claim.
Parts support is available for this product. To obtain parts, email [e-mail] or telephone [phone]
Latched
"Over Centre" Locked
Latch
g.1 g.2
