Sealey PC2950 User manual

IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS.
USE THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE
DAMAGE AND/OR PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. PLEASE KEEP INSTRUCTIONS SAFE FOR FUTURE USE.
1.2 GENERAL SAFETY
pWARNING! Water and Electricity are dangerous partners. Be extremely cautious and always be aware that this device uses an
electric motor. Always plug into a RCD (See electrical safety above). Unplug from mains before changing accessories or servicing.
pWARNING! DO NOT USE the washer if any part of the unit, gun, nozzle, detergent bottle, hose or cables is damaged. Replace or
repair using genuine parts only. Non-authorised parts may be dangerous and will invalidate your warranty. Always check connections
are correctly secured and not cracked or damaged in any way before using the machine.
pWARNING! Use washer on a flat, levelled surface, in a vertical position. Failure to do so will invalidate your warranty. NEVER
lay the washer down during use.
4Always be aware of the potential hazards that may occur during use. Study the applications and limitations of the washer before use.
4Keep the washer in good condition. Use an authorised agent to service the unit.
4Wear adequate protective clothing, goggles and anti-slip rubber soled footwear.
4Use where air can freely circulate around the washer to avoid the machine over-heating.
pWARNING! Ensure all persons and animals keep at a minimum distance of 16yards (15m) from the washer when in use.
pWARNING! The pressure washer must only be used with clean water. Non-filtered water or corrosive chemicals must not be used as
they will damage the cleaner.
4Ensue you comply with all local water supply regulations. Power washers may only be connected to mains drinking water supply
if a valve to prevent back flow is installed in the supply hose, or at the tap outlet.
4Position the washer as near to the water supply as possible.
4The supply hose must must be reinforced, and have an internal diameter of 1/2. The water supply must be at least equal to the cleaner
capacity. The water temperature must NOT exceed 140OF (60OC). The water supply pressure must NOT exceed 145psi (10 bar).
4Ensure the nozzle is aimed correctly at the working surface before activating the jet.
4Before operating the trigger, GRIP the gun firmly to counteract the recoil from the high pressure water jet.
pWARNING! Avoid sudden bursts of water as such will cause water pressure to drop and put extreme pressure on hoses and connectors.
4If, during operation, power failure occurs turn the electricity and water off for safety reasons (but see para. 5.4. Note b).
pWARNING! The high pressure jet will cause loose particles to be propelled at high speed, which may cause serious injury.
1. SAFETY INSTRUCTIONS
INSTRUCTIONS FOR:
PRESSURE WASHER
Model No: PC2950
PC2950 - 2 - 050802
Thank you for purchasing a Sealey product. Manufactured to a high standard this product will, if used according to these instructions and properly
maintained, give you years of trouble free performance.
1.1. ELECTRICAL SAFETY
p WARNING! It is the responsibility of the owner and the operator to read, understand and comply with the following:
You must check all electrical products, before use, to ensure that they are safe. You must inspect power cables, plugs, sockets and any other
connectors for wear or damage. You must ensure that the risk of electric shock is minimised by the installation of appropriate safety devices.
A Residual Current Circuit Breaker (RCCB) should be incorporated in the main distribution board. We also recommend that a Residual Current
Device (RCD) is used. It is particularly important to use an RCD with portable products that are plugged into a supply which is not protected
by an RCCB. If in any doubt consult a qualified electrician. You may obtain a Residual Current Device by contacting your Sealey dealer.
You must also read and understand the following instructions concerning electrical safety.
1.1.1. The Electricity at Work Act 1989 requires all portable electrical appliances, if used on business premises, to be tested by a qualified
electrician, using a Portable Appliance Tester (PAT), at least once a year.
1.1.2. The Health & Safety at Work Act 1974 makes owners of electrical appliances responsible for the safe condition of those appliances
and the safety of the appliance operators. If in any doubt about electrical safety, contact a qualified electrician.
1.1.3. Ensure that the insulation on all cables and on the appliance is safe before connecting it to the power supply. See 1.1.1. and 1.1.2.
and use a Portable Appliance Tester.
1.1.4. Ensure that cables are always protected against short circuit and overload.
1.1.5. Regularly inspect power supply cables and plugs for wear or damage and check all
connections to ensure that none is loose.
1.1.6. Important: Ensure that the voltage marked on the appliance matches the power supply
to be used and that the plug is fitted with the correct fuse - see fuse rating at right.
1.1.7. DO NOT pull or carry the appliance by the power cable.
1.1.8. DO NOT pull the plug from the socket by the cable.
1.1.9. DO NOT use worn or damaged cables, plugs or connectors. Immediately have any faulty
item repaired or replaced by a qualified electrician. When an ASTA/BS approved UK
3 pin plug is damaged, cut the cable just above the plug and dispose of the plug safely.
Fit a new plug according to the following instructions (UK only).
a) Connect the GREEN/YELLOW earth wire to the earth terminal E.
b) Connect the BROWN live wire to the live terminal L.
c) Connect the BLUE neutral wire to the neutral terminal N.
d) After wiring, check that there are no bare wires, that all wires have been correctly connected, that the cable outer insulation
extends beyond the cable restraint and that the restraint is tight.
Double insulated products, which are always marked with this symbol , are fitted with live (brown) and neutral (blue) wires only.
To rewire, connect the wires as indicated above - DO NOT connect either wire to the earth terminal.
1.1.10. Products which require more than 13 amps are supplied without a plug. In this case you must contact a qualified electrician to ensure that a
suitably rated supply is available. We recommend that you discuss the installation of an industrial round pin plug and socket with your electrician.
1.1.11. If an extension reel is used it should be fully unwound before connection. A reel with an RCD fitted is preferred since any appliance
plugged into it will be protected. The cable core section is important and should be at least 1.5mm2, but to be absolutely sure that the
capacity of the reel is suitable for this product and for others which may be used in the other output sockets, we recommend the use of
2.5mm2section cable. If extension reel is to be used outdoors, ensure it is marked for outdoor use.
FUSE RATING 13 AMP
Blue
Neutral
Wire
Yellow & Green
Earth Wire
Cable
Restraint
Brown
Live
Wire

pWARNING! DO NOT use the washer on any material containing asbestos as this may release hazardous asbestos particles
into the atmosphere.
pWARNING! DO NOT use the washer without a water supply. Dry running can seriously damage the unit.
8DO NOT obstruct ventilation grills during operation.
8DO NOT use the washer with flammable or toxic liquids or any other product. Only use recommended detergent. Non-recommended
detergents may corrode the machine cover and accessories.
8DO NOT jam the trigger in the operating position.
8DO NOT adjust any internal control valves, as they have been set at the factory.
8DO NOT leave the washer running unattended.
8DO NOT connect other appliances to the machine inlet or outlet.
8DO NOT use in damp or wet weather conditions.
8DO NOT move the unit by pulling the hoses or electrical cables. Use handle.
8DO NOT touch plug with wet hands, to avoid the risk of electrocution. Keep all connections dry and off the ground.
8DO NOT direct jet against yourself, other persons or animals, electrical equipment or the machine itself.
8DO NOT use washer if you are tired, under the influence of alcohol, drugs or intoxicating medication.
8DO NOT allow children or untrained persons to operate the washer.
pWARNING! Discharge residual pressure before disconnecting the washer hose. Pressure left in unit may cause injury.
4After use disconnect washer from electrical and water supplies and store in a safe, dry, childproof area.
By rotating the stream of water at
high speed, it is possible to increase
the effective cleaning pressure of
washer. We quote the pressure at
which the water leaves the pump as
Manifold Pressure and express the
cleaning power of the washer as the
Effective Cleaning Pressure.
2. SPECIFICATION & CONTENTS
DESCRIPTION OF ITEMS
Fig.1
1 Washer
2 Water Supply Fitting with Filter
3 Detergent Bottle
4Rotary Lance
5Gun with High Pressure Hose
6Fan Nozzle
7 Rotary Nozzle
Fig.2
A Feet
BElastic Strap
CSupport
DHandle
E Hose Reel Holder
FAxle
G Wheel x 2
HC-clip x 2
I Hub Cap x 2
JSupport
2.2. CONTENTS
Unpack the product and check contents against the list below. Also check that the machine has an identification plate or label. If label or parts
are damaged or missing contact your supplier immediately.
fig. 2
fig. 1
3. ASSEMBLY
3.1. Attach the two feet (fig.2.A) to the base of the washer using the screws provided.
3.2. Attach each end of strap (fig.2.B) to the lugs on the support (fig.2.C) as shown in fig.3.
3.3. Fit support (fig.2.C) and handle (fig.2.D) around top bar of washer, see fig.4. Secure with the two
screws provided, through the lower pair of holes in handle.
3.4. Attach one half of the hose reel holder (fig.2.E) to the base of handle and the other half to the rear of the
washer, using the screws provided.
3.5. Slide axle (fig.2.F) through hub of one wheel (fig.2.G), fit C-clip (fig.2.H) to groove in axle
(flat face towards wheel) and then press hub cap (fig.2.I) into wheel centre. See fig.5.
3.6. Slide axle through mounting holes in rear base of washer, see fig.6, and then fit second wheel and hub
cap as in 3.4.
3.7. Screw supply water fitting (fig.1.2) onto inlet port, on rear of washer just above axle. NOTE: This fitting
contains a filter, if an alternative fitting is used a suitable filter MUST be used.
3.8. Attach the support (fig 2.J) to the handle using the screw provided.
fig. 3
fig. 4
fig. 6
fig. 5
2.1. SPECIFICATION
Lance . . . . . . . . . . . . . . . .Rotating Nozzle Input Voltage . . . . . . . . . . . . . .230V
Manifold Pressure . . . . . . . . . . . . .1750psi Motor Speed . . . . . . . . . . .2800rpm
Effective Cleaning Pressure . . . . . .2950psi Max. Inlet Temp . . . . . . . . . . . .60OC
Water Flow . . . . . . . . . . . . . . . . . .420ltr/h Hose Length . . . . . . . . . . . . . .7.0m
Motor Power . . . . . . . . . . . . . . . . . .1800W Weight . . . . . . . . . . . . . . . . . . .13kg
PC2950 - 2 - 050802

5.1 Using the lance
5.1.1. Ensure the water intake is correctly connected, air can freely circulate around the washer and washer is standing upright.
5.1.2. Turn the mains water supply fully on.
5.1.3. Switch on the power by pressing the ON/OFF switch to ON (I depressed).
5.1.4. WARNING! Aim nozzle correctly at working surface. Disengage the trigger safety catch (press down, see fig.9) and pull the trigger
to start the washer. Note that releasing the trigger will stop the jet and turn off the motor.
5.1.5. Check the system to ensure there are no water leaks.
5.1.6. Keep the nozzle approximately 380mm (15) from the surface being cleaned.
5.2. Detergent
5.2.1. Fill the detergent bottle (fig.1.3) with the recommended Sealey pressure washer detergent.
5.2.2. Fit the detergent bottle to the gun in the same manner as for the lance, see 4.2.
5.2.3. Operate washer as for lance.
5.3. Using detergent
Dirt is dissolved by applying detergent to the dry surface. GRIP the gun firmly to counteract the recoil of the water jet and aim at the
working surface.
5.3.1. On vertical surfaces, work from the bottom upwards.
5.3.2. Leave the detergent to act for 1 - 2 minutes, but DO NOT allow the surface to dry out.
5.3.3. To wash down, remove the detergent bottle from the gun and replace with the lance.
5.4. On completion
5.4.1. Turn off at washer ON/OFF switch and disconnect from mains. Turn off the water supply.
5.4.2. Pull the gun trigger until no more water comes out of the nozzle. Washer is now depressurized.
5.4.3. Release trigger and engage the trigger safety catch (push up).
5.4.4. Remove lance from gun and store, nozzle-up, in one of the washer side compartments (fig.1.A). It is important that the nozzle is
stored in this fashion. If stored flat or nozzle-down the moving components in the nozzle are likely to seize.
5.4.5. Store detergent bottle in the position provided behind the handle.
5.4.6. Wipe the machine clean and dry and store in a clean, safe, dry, childproof location.
Notes: a) If the water pressure drops (i.e. someone using same water supply), the washer will not operate correctly. Immediately switch off
and wait until the pressure is restored.
b) Should the motor stop and fail to restart, the built in thermal cut-out may have tripped. Check to ensure the washer is connected
correctly to electrical and water supplies (also see troubleshooting). Wait 3 minutes for the cut-out to reset and re-start the
motor. If the motor continues to cut out contact your authorised service agent.
c) If storing the washer for a long period during winter, operate the washer with a non-corrosive, non-toxic anti-freeze before
storage. Keep detergents according to instructions on the container label.
5. OPERATING THE WASHER
fig. 8
p p
WARNING! Ensure you read, understand and apply Section 1 safety instructions.
p p
WARNING! Dry running can seriously damage the unit.
4. PREPARATION
pWARNING! Ensure pressure washer is switched off and unplugged from the electrical power supply before proceeding.
4.1. Insert the high pressure hose (fig.1.5) into the outlet port of the washer and screw on the outer sleeve until hand tight. See fig.7.
4.2. To connect the lance (fig.1.4) to the gun (fig.1.5) insert the bayonet end of the lance into the gun and twist to lock as in fig.8.
4.3. Connect the mains water supply hose (not supplied) to the water inlet on the pressure washer. DO NOT turn the water on at this
stage. The supply hose must be reinforced, and have an internal diameter of 1/2. The water supply must be at least equal to the
washer capacity. The water temperature must NOT exceed 140OF (60OC). The water supply pressure must NOT exceed 145psi (10 bar).
pWARNING! REMINDER: The pressure washer must only be used with clean water. Non-filtered water or corrosive chemicals must not
be used as these will damage the washer.
4.4. Ensure that the washer ON/OFF switch, see fig.7, is in the OFF position (O depressed).
4.5. Having carefully followed the safety instructions in Section 1, plug the washer into the mains power supply. The washer is now ready
for use as described in Section 5.
pWARNING! Ensure the pressure washer is switched off and unplugged from the electrical power supply and turned off at the
water supply tap before proceeding.
6.1. Keep the washer clean at all times.
6.2. Check and clean the supply water filter, part of fitting (fig.1.2), on a regular basis.
6.3. Take the nozzle cleaning tool (fig.1.8), detach the lance from the gun and remove any dirt from nozzle, then rinse.
6.4. Check washer, gun, lance, detergent bottle, hose, connections and cables for damage regularly. Repair or replace any damaged items
before next use. DO NOT open the casing, use authorised agent to service the washer.
6. MAINTENANCE
fig. 7
fig. 9
PC2950 - 2 - 050802

7. TROUBLESHOOTING GUIDE
8. DECLARATION OF CONFORMITY
Declaration of Conformity We, the sole importer into the UK of Sealey Power Products, declare that the product listed below is in conformity
with the following standards and directives.
The construction file for this product is held by the Manufacturer and may
be inspected, by a national authority, upon request to Jack Sealey Ltd.
For Jack Sealey Ltd. Sole importer into the UK of Sealey Power Products.
Pressure Washer Model PC2950
73/23/EEC Low Voltage Directive
89/336/EEC EMC Directive
98/37/EC Machinery Directive
5th June 2000
NOTE: It is our policy to continually improve products and as such we reserve the right to alter data, specifications and component parts without prior notice.
IMPORTANT: No responsibility is accepted for incorrect use of this equipment.
WARRANTY: Guarantee is 12 months from purchase, proof of which will be required for any claim.
INFORMATION: For a copy of our latest catalogue and promotions call us on 01284 757525 and leave your full name and address, including postcode.
SYMPTOM REASON REMEDY
Tripped thermal overload due to
overheating
Check for adequate power supply and cable condition
Leave unit to thaw naturally. The pressure washer should be
protected from the threat of freezing. Extensive pump damage
could otherwise occur. (see Section 5 Note c).
Use a suitable extension cable. See Section 1 Elect.Safety.
Pump does not reach required
pressure
Pressure drops during use or
noisy pump
Nozzle incorrect or worn
Dirty filter
Air being sucked into the system
Water pressure low
Worn or damaged pump components
Motor hums but does not start
when switched on
Plug is not connected
No electrical power
Pump sucking air
Pump defect
Water too hot
Dirty filter
Unsuitable mains voltage
Pump is frozen
Incorrect extension cable
The motor stops
Replace the nozzle
Clean filter
Check that hoses and fittings are air tight
Check that hoses/fittings are water tight and tap is fully open
Contact Authorised Service Agent
Check that hoses and fittings are air tight
Contact Authorised Service Agent
Reduce temperature
Clean or replace
Check plug connections and mains power supply is active
Check that the mains voltage matches the specifications
Switch off the motor and let machine cool for 3 minutes
Motor does not start when
switched on
Fluctuating pressure Inadequate water supply
Pump sucking air
Dirty filter
Fully open supply tap
Check that hoses and fittings are air tight
Check and clean
Signed by Mark Sweetman
Irregular jet Dirt in high pressure nozzle of spray
gun
Clean with probe provided
01284 757500 E-mail: [e-mail] Web: www.sealey.co.uk
01284 703534
Sole U.K. Distributor, Sealey Group,
Bury St. Edmunds, Suffolk.
PC2950 - 2 - 050802
