Sealey PPHY User manual

CAT IV 1000V HIGH VOLTAGE TESTER
HYBRID VEHICLES
MODEL NO: PPHY
Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these
instructions, and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
1. SAFETY
WARNING! Please read manual carefully before any operation. This manual includes safety warning and safety requirement, which
help user to operate the equipment safely.
9After measuring AC/DC voltage source for 3 minutes, the tester must take a rest for 1 minute.
8 Nevermeasurethevoltagebeyondspecied(1000V).
8DO NOToperatetheequipmentnearammablegasses.
8DO NOT operating the equipment with wet hands.
9 Keephandsandngersbehindthebarriersduringmeasurements.
8DO NOT unlock and open the battery case during measurements.
9 Conrmthefunctionoftheequipmentwithaknownsourcebeforemeasureunknownvoltagesource.
8DO NOT make any measurement when there is abnormal condition, such as broken case or exposed metal parts are present an the
instrument, test probes, and cables.
8DO NOT modify the equipment.
9Take extreme caution when operating with a live circuit.
9 LEDonlyfunctionproperlywhentemperatureisbetween0~50°C.
9Before using a voltage detector with audible indicator at locations with a high background noise level, it has to be determined
whether the audible signal is perceptible.
2. INTRODUCTION
ProfessionaltwopolevoltagetesterCATIV1000Vforcheckinghigh
voltage on electric/hybrid vehicles. Suitable for checking AC mains and
DCpowersuppliesbetween6-1000VDCand24-1000VAC.Canalso
be used for checking voltage and polarity on car batteries and
continuity testing of DC circuits. Includes a self-test function and
illuminationlight.EN61243-3,IP65,CEcertied.Requires2xAAA
1.5Vbatteries(notsupplied).
3. SPECIFICATION
Model No:.................................................................... PPHY
Accuracy: .............................................................+/-(3%+3)V
CAT Category:..................................................CATIV1000V
IPRating: ........................................................................IP65
Maximum Current:...................................... <3.5mA@1000V
Power:..................................2xAAABatteries(notsupplied)
Voltage: ..................................... 6-1000VDC&24-1000VAC
4. PREPARATION
4.1. POWER ON/ SELF-DIAGNOSTIC
4.1.1. Pressthe“ON/OFF”buttononthemainproberstandthen
 onthesecondprobe,shortthetwometalprobes(g.2).The
power will automatically turn on, and the equipment start a
self-diagnostic test.
4.1.2. AllindicatorsonLCDwilllightup(g.3),andbuzzerwillsoundduringthenormalself- 
diagnostic test.
8DO NOT operate the equipment if any abnormality occurs during the self-diagnostic test.
4.1.3. LCDwillash5timeswhenbatterypowerislowerthan2.2±0.1V.Pleasechangethebattery.
4.2. TROUBLE SHOOTING
4.2.1. Ifanyofthefollowinghappens,openthebatterycaseandcloseitagainafter5seconds.
 Conductaself-diagnostictestafterclosingthecaseagainsee4.1.
Problems:(1)Cannotperformself-diagnostictestbeforeoraftertheoperationoftheequipment.
 (2)Cannotautopoweroff.
Main Probe (+)
Second Probe (-)
Illumination Light
Non Contact Voltage Sensor
Non contact voltage indicator
LCD Display
Probe Barrier
Probe Barrier
Light/ Non contact sensing switch
Power Switch
DC positive (+) indicator
DC negative (-) indicator
Probe Clip
Power Switch
g.1
g.2
PPHYIssue118/07/19
Original Language Version
© Jack Sealey Limited
ReferTo
Instructions
Electrical
Shock
Hazard
Wear Eye
Protection
Wear Protective
HighVoltage
Gloves
Warning!: Use
HighVoltage
Safety Mat
Suitable For Live
Working
1 000 V

5. OPERATION
5.1. MEASUREMENT
WARNING! Please read the manual carefully.
9 Performaself-diagnostictesttoinsuretheLCDandbuzzer
function properly.
9Please conform the equipment with a known voltage source.
9When the device is in use make sure hands are behind the probe
barrier.
WARNING!Astheequipmenthashigherimpedance(about
 300kΩ),capacitorandinductorvoltagemayindicate.
5.2. AC/ DC POLARITY MEASUREMENT (ON SECOND PROBE)
5.2.1. Connectingtwoprobestotwoportsofthevoltagesource(g.4).
5.2.2. Withoutpressinganybutton,thepolarityofAC/DC(24V-1000V)
will be indicated on the second test probe.
5.2.3. AC:bothpolaritylightsup.(+)DC:DC+lightsupand(-)DC:DC-
lights up.
5.2.4. Thedirectionofthemainprobewilldetermine(+)DCor(-)DC.If
main probe is on the positive port, DC+ lights up, and vice verse.
5.2.5. This function will be cancelled if either of the ON/OFF buttons
are pressed.
5.3. VOLTAGE MEASUREMENT
5.3.1. VOLTAGE AND POLARITY
5.3.2. Connectingtwoprobestotwoportsofthevoltagesource(g.4).
5.3.3. PresstheON/OFFbuttonsonbothprobesatsametime.VoltageandpolaritywillbedisplayedontheLCD.(DC6-1000V;
 AC24-1000V;AC/+DC/-DC).
5.3.4. The direction of the main probe will determine DC+ or DC-. If main probe is on the positive port,
DC+ lights up, and vice versa.
WARNING!Ifonlyoneofthebuttonshaspressed,errorvoltagevalueAC23V-AC55Vwillbe 
 displayedontheLCDwhenvoltageisgreaterthanAC300V.
5.3.5. HIGH VOLTAGE INDICATION
5.3.6. LCD will display“”whenvoltagesource≥100VAC/VDC(g.5).
5.3.7. PHASE ROTATION
5.3.8. Phaserotationmeasurementisonlyfor3phase(4lines)system.Usingtherighthandholdthe 
 mainprobehandle(behindthebarrier)properlyduringthemeasurement(becauseoneofthe 
 sensingareasisonthemainprobehandle).
5.3.9. LCD will display voltage between phases.
5.3.10. Iftherotationisclockwise,LCDwilldisplay“R”(g.6).
5.3.11. Iftherotationiscounter-clockwise,LCDwilldisplay“L”(g.7).
5.3.12. Testingtips:Thismeasurementusetesterasavirtualground;ifequipmentoruserisnotwith 
proper insulation condition, measurement may not function properly.
5.4. NON-CONTACT VOLTAGE SENSING
5.4.1. To switch on the function, press the “LIGHT/NOT-CONTACT SENSING SWITCH”, LCD will
display “DE-”.
5.4.2. Non-contact voltage indicator“”onthetoprightofthemainprobewilllightupandbuzzer 
 willsoundwhenthesensorisnearelectromagneticeldgreaterthan90VAC.
5.4.3. Press the “LIGHT/NON-CONTACT SENSING SWITCH” again to switch off the function.
5.4.4. This function will automatically switch off after 3 minutes.
5.5. CONTINUITY
WARNING! Make sure there is no live voltage in the circuit before testing continuity.
5.5.1. Connecting the two probes to the circuit to be tested, press both ‘ON/OFF SWITCH” on two
 probes,ifthecircuithascontinuity,allindicatorontheLCDwillash,andbuzzerwillsound.
WARNING! If there is continuity in the circuit, the instrument will perform a self-diagnostic test.
5.6. ILLUMINATION
5.6.1. Longpressandholdthe“LIGHT/NON-CONTACTVOLTAGESENSINGSWITCH”to 
switch on the illumination light.
WARNING! Illumination function and non-contact voltage sensing function share the
same button, be aware when using these two functions.
Non Contact
Voltage
Indicator
Voltage Value
Battery Power
Indicator
Voltage Bar Graph
Indicator
Phase
Direction
High Voltage
Warning
DC Indication
AC Indication
DC Positive (+)
Polarity
DC Negative (-)
Polarity
g.3
g.4
g.5
g.6
g.7
Original Language Version
© Jack Sealey Limited PPHYIssue118/07/19

Sealey Group, Kempson Way, Suffolk Business Park, Bury St Edmunds, Suffolk. IP32 7AR
01284 757500 01284 703534 [e-mail] www.sealey.co.uk
ENVIRONMENT PROTECTION
Recycleunwantedmaterialsinsteadofdisposingofthemaswaste.Alltools,accessoriesandpackagingshouldbesorted,takento
a recycling centre and disposed of in a manner which is compatible with the environment. When the product becomes completely
unserviceableandrequiresdisposal,drainanyfluids(ifapplicable)intoapprovedcontainersanddisposeoftheproductandfluids
according to local regulations.
Note: It is our policy to continually improve products and as such we reserve the right to alter data, specifications and component parts without prior
notice.
Important: No Liability is accepted for incorrect use of this product.
Warranty:Guaranteeis12monthsfrompurchasedate,proofofwhichisrequiredforanyclaim.
6. MAINTENANCE
6.1. BATTERY REPLACEMENT
WARNING! Disconnect the device from the voltage source and switch off when
replacing the batteries.
6.1.1. IfLCDashes5timesitwillswitchoffautomaticallyduringselfdiagnosticsorvoltage 
measurement, this indicates the equipment has run out of battery. Please change the batteries.
6.1.2. BatterypowerlevelwillalsodisplayontheLCDduringthevoltagemeasurement;please
note the battery power level when using.
 (1)Unlockthebatterycapbyusingacoin.
 (2)Openthebatterycapandreplacethebattery.Beawareofthebatterypolarity(g.8).
 (3)Putbackthebatterycapandlockitwithacoin.
WARNING! Please make sure the battery cap is locked before any operation.
6.2. CLEANING & STORAGE
9Use a light damp cloth with neutral detergent for cleaning the instrument. DO NOT use
abrasives or solvent.
8DO NOT expose the instrument to direct sun, high temperature, humidity or damp.
9 Removebatterieswhentheinstrumentisnotgoingtobeusedforalongperiod.
8DO NOT lock the battery cap without batteries. g.8
