Sealey AP2405 User manual

INSTRUCTIONS FOR:
ROLLCAB 4-10 DRAWER
MODEL No's: AP2405, AP2406,
AP2407, AP2408 & AP2410
1. SAFETY PRECAUTIONS
2. INTRODUCTION AND SPECIFICATIONS
Thank you for purchasing a Sealey product. Manufactured to a high standard this product will, if used according to these instructions
and properly maintained, give you years of trouble free performance.
Important: READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS AND
CAUTIONS. USE THIS PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO
MAY CAUSE DAMAGE AND/OR PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. RETAIN THESE INSTRUCTIONS FOR FUTURE USE.
Read this manual carefully before using your rollcab.
 DO NOT open more than one drawer at a time.
 DO NOT step on the drawers.
 DO NOT let children near the rollcab.
 Ensure all drawers are fully closed and the self locking catch is activated, before moving the rollcab.
 Secure the brakes when rollcab is in the desired position.
Heavy gauge steel with double wall construction for extra strength and durability. Ball bearing drawer runners provide superior performance and carry
heavier loads. Each drawer tted with catch to prevent accidental opening when being transported around the workshop. Added security provided by
side mounted cylinder lock, supplied with two keys. Rubber grip side handles for comfort and ease when manoeuvring. Rust and solvent resistant
powder coat paint nish. Fitted with anti-shock protection on all four corners to prevent accidental damage. Features two Ø125mm swivel castors with
large toe locks and two xed wheels. Tough composite top for tting and securing top box or can be used as a workstation. Unique design tted with
perforated side panels for hanging tools and accessories.
Model No AP2405 AP2406 AP2407 AP2408 AP2410
Overall Size
Width 766mm
Depth 468mm
Height 958mm
Drawers (Qty)
Medium 3 3 5 6 10
Large 1212
X - Large 1 1
Drawer Width 533mm 533mm 533mm 533mm 533mm
Drawer Depth 391mm 391mm 391mm 391mm 391mm
Drawer Height (Medium) 58mm 58mm 58mm 58mm 58mm
Drawer Height (Large) 128mm 128mm 128mm 128mm
Drawer Height (X - Large) 195mm 195mm
AP2405
AP2406
AP2407
AP2408
AP2410
Original Language Version AP2405,2406,2407,2408,2410 Issue: 2 - 27/08/10

3.1. Each drawer is fitted with a catch mechanism on the right hand side, underneath the handle. To open drawer push the catch to the left to
release it and pull the drawer open (fig.1).
WARNING! Only open one drawer at a time and DO NOT overload the drawers, fig.2 shows the maximum weight per drawer size.
3.2. When moving the rollcab, ensure that the drawers are closed and locked (fig.3) to prevent accidental opening, release the brakes as shown
in fig.4 and move the rollcab using the handles to maintain full control. When the rollcab has been moved to the required location, lock the
brakes.
WARNING! DO NOT move across slopes of more than 5° as the rollcab may tilt over.
3. OPERATION
Fig.1
Fig.3
Fig.4
Fig.2
Optional Accessories
Model No Description
AP24ACC1 Perforated Storage Panel
AP24ACC2 Side Shelf with Paper Roll Holder
AP24ACC3 Document Holder
AP24ACC4 Waste Bin
AP24ACC5 Can and Bottle Holder
AP24ACC6 Drawer Divider 3 x 395 x 58mm
AP24ACC7 Drawer Divider 3 x 395 x 120mm
AP24ACC9 Short Hook Set x 10pcs
AP24ACC10 Medium Hook Set x 10pcs
notE: It is our policy to continually improve products and as such we reserve the right to alter data, specifications and component parts without prior notice.
IMPORTANT: No liability is accepted for incorrect use of this product.
WARRANTY: Guarantee is 12 months from purchase date, proof of which will be required for any claim.
INFORMATION: For a copy of our latest catalogue and promotions call us on 01284 757525 and leave your full name and address, including postcode.
