Sealey API16 User manual

1.1 GENERAL SAFETY
WARNING! Ensure Health & Safety, local authority, and general workshop practice regulations are adhered to when using workbenches
and associated workbench drawers.
WARNING! Use the workbench on level and solid ground, preferably concrete. Avoid tarmacadam since the workbench may sink into the
surface.
Locate the workbench in a suitable working area.
Keep the work area clean, uncluttered and ensure there is adequate lighting.
Keep the workbench clean and tidy in accordance with good workshop practice.
Keep children and unauthorised persons away from the working area.
 Use the supplied rubber caps on all exposed self tapping screw projections.
DO NOT remove a fully loaded drawer.
DO NOT use the workbench drawers for any purpose other than that for which they are designed.
DO NOT use the workbench drawers out of doors.
DO NOT get the workbench drawers wet or use in damp or wet locations or areas where there is condensation.
DO NOT clean the workbench drawers with any solvents which may damage the painted surfaces.
Note! The assembly of this product to the workbench will require assistance.
INSTRUCTIONS FOR:
INDUSTRIAL THREE DRAWER UNIT FOR
API SERIES WORKBENCHES
MODEL NO: API16
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE THE
PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these
instructions, and properly maintained, give you years of trouble free performance.
1. SAFETY
2. INTRODUCTION
Industrial quality slim-width triple drawer unit for our API Series of Industrial Workbenches, to give the option of more under bench access. All
drawers run on heavy-duty ball bearing drawer slides with a load bearing of 100kg and are tted with a safety locking catch to prevent
inadvertent opening. Each drawer is tted with dividers running back to front and then supplied with cross dividers for personalised storage
layout. Fitted with two high quality locks and supplied with two coded keys.
3. SPECIFICATION
Model No:.................................................................................... API16
Compatibility:.............................................. API1500, API1800, API2100
Overall Size:............................................................ 407 x 580 x 450mm
*Internal Drawer Size [x2] (WxDxH):......................... 300 x 450 x 70mm
*Internal Drawer Size [x1] (WxDxH):........................300 x 450 x 115mm
Maximum Drawer Capacty:..................................100kg (evenly spread)
*3 Drawer Units
4. CONTENTS
Item Description QTY
1 Enclosure c/w Ball Bearing Tracks 1
2 Drawer ["H"=70] c/w Runner Tracks 2
2A Drawer ["H"=115] 1
3 Central Mullion Partition [Drawer "H"=70] 2
3A Central Mullion Partition [Drawer "H"=115] 1
4 Transom Partition Plate [Drawer "H"=70] 8
4A Transom Partition Plate [Drawer "H"= 115] 4
5 Self Tapping Screw 24
6 Safety Cap 24
7 Bridge Channel (c/w captive nuts) 2
8 Hex Head Screw M8 x 20 c/w spring & plain washers 4 sets
9 Drawer Key (record the key code) 2
API16 Issue No.1 20/06/14
Original Language Version
© Jack Sealey Limited
1
2A
2
2
287mm
Centres
9
8
Stop
Drawer
roller path
Drawer roller
fig.2 fig.3
fig.1
88
8

API16 Issue No.1 20/06/14
fig.5
NOTE: It is our policy to continually improve products and as such we reserve the right to alter data, specifications and component parts without prior notice.
IMPORTANT: No liability is accepted for incorrect use of this product.
WARRANTY: Guarantee is 12 months from purchase date, proof of which will be required for any claim.
INFORMATION: For a copy of our latest catalogue and promotions call us on 01284 757525 and leave your full name and address, including postcode.
01284 757500
01284 703534
[e-mail]
Sole UK Distributor, Sealey Group,
Kempson Way, Suffolk Business Park,
Bury St. Edmunds, Suffolk,
IP32 7AR
www.sealey.co.uk
Original Language Version
© Jack Sealey Limited
Parts support is available for this product. To obtain a parts listing and/or diagram,
please log on to www.sealey.co.uk, email [e-mail] or telephone [phone].
287mm Centres Setting
(for enclosure tting)
5. ASSEMBLY
5.1. Drawer removal from enclosure
5.1.1. Unlock the drawer if required and open the drawer fully and squarely until it stops (g.2 & 4). The ratchet catch, which safely holds the
drawers shut, releases when the drawer handle is gripped. Remove the loose components, items 3,4,5 and 6.
5.1.2. With the drawer fully open against the stop, place one hand beneath the drawer and the other on the handle.
5.1.3. Lift the drawer and withdraw. See g.2 for drawer roller path and g.3 for the drawer roller.
5.2. Fitting the enclosure to the bench
5.2.1. Locate the two bridge channels from beneath the bench at the required centres (g.1) and (g.5). As a suggestion only; position the
bridge channels centrally about the bench width for best access.
5.2.2. Offer the empty dawer enclosure up to the bridge channels aligning slots to the captive nut holes in the bridge channels.
5.2.3. A second person is required to screw the enclosure to the bridge channels. DO NOT tighten at this stage.
5.2.4 With all four screws tted (item 8), with at least three threads engaged on each nut; slide the enclosure to the required position (g.6)
and tighten all screws.
5.3. Drawer Mullion Partition
5.3.1. Fit (item 3 and 3A) centrally with self tapping screws (item 5) through the pre-punched holes. Transom plates (item 4) partitioning as
required.
5.3.2. Fit the rubber safety caps (item 6) to all self tapping screw projections, from the underside of the drawer (g.4).
5.3.3. Locate the drawer rollers (g.3) with the enclosure runners (g.2) and slide the drawer/drawers fully back into the enclosure. Generally
the reverse of removal. DO NOT force at any stage.
fig.4
fig.6
Example position only
(drawers removed)
5 & 6
6. MAINTENANCE
Underside
6.1. Lubricate the drawer runner bearings and track with a general purpose grease every 6 months. Wipe off excess with a dry cloth.
Environmental Protection
Recycle unwanted materials instead of disposing of them as waste. All tools, accessories and packaging should be
sorted, taken to a recycling centre and disposed of in a manner which is compatible with the environment.
When the product becomes completely unserviceable and requires disposal, dispose of the product according to local
regulations.
3 & 4
3A & 4A
Ratchet catch
7
155 x 65 (4)
155 x 110 (4A)
Transom plates
(8)
View from
beneath
bench
