INSTRUCTIONS FOR:
TOPCHEST & ROLLCAB COMBINATION 6 DRAWER
with BALL BEARING RUNNERS
MODEL Nos: AP2200BB SERIES
1. SAFETY
2. INTRODUCTION
3. SPECIFICATIONS
4. ASSEMBLY
1.1. GENERAL SAFETY
 WARNING! Ensure Health & Safety, local authority, and general workshop practice regulations are adhered to when using this Topchest &
Rollcab combination.
Locate the Topchest & Rollcab combination in a suitable working area.
 Keep the work area clean, uncluttered and ensure there is adequate lighting.
Keep the Topchest & Rollcab combination clean and tidy in accordance with good workshop practice.
Keep children and unauthorised persons away from the working area.
 DO NOT use the Topchest & Rollcab combination for any purpose other than that for which it is designed.
 DO NOT move the Topchest & Rollcab combination with drawers open.
 DO NOT open more than one drawer at the same time.
 DO NOT step on the drawers.
 DO NOT use in damp work areas.
 WARNING! The warnings, cautions and instructions referred to in this instruction manual cannot cover all possible conditions and situations that may
occur. It must be understood that common sense and caution are factors which cannot be built into this product, but must be applied by the operator.
The economical way to buy American PRO Ball Bearing quality chests. Supplied packed one inside the other.
This mid-size combo has smooth 25mm ball bearing runners and all the features of the professional chests except that the rollcab is not lockable and
the castors are Ø75mm. These boxes are not interchangeable with the rest of the American PRO Ball Bearing range.
g.1 g.2
4.1. Remove the bolts, nuts and washers from the base of the rollcab (g.1), and then lift off the body to uncover the topchest.
4.2. Remove the screws from the base (g.2), and separate from the topchest, discard the screws.
Note: Place protective material onto the ground to avoid damaging the back of the topchest.
Model No: AP2200BB......
4 Drawer Topchest
Overall Size: 600 x 260 x 340mm
Small Drawer (3): 510 x 225 x 35mm
Medium Drawer (1): 510 x 225 x 85mm
2 Drawer Rollcab
Overall Size: 616 x 295 x 703mm
Medium Drawer (2): 515 x 275 x 65mm
AP2200BB SERIES Issue: 1 - 07/03/16
Original Language Version
© Jack Sealey Limited
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE THE PRODUCT
CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR PERSONAL INJURY AND WILL
INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these
instructions and maintained properly, give you years of trouble free performance.
Refer to
Instruction
Manual

01284 757500
01284 703534
[e-mail]
www.sealey.co.uk
Web
email
NOTE: It is our policy to continually improve products and as such we reserve the right to alter data, specifications and component parts without prior notice.
IMPORTANT: No liability is accepted for incorrect use of this product.
WARRANTY: Guarantee is 12 months from purchase date, proof of which will be required for any claim.
4.3. Turn the rollcab upside down and place the base into position as shown in g.3A.
Note: Place protective material onto the ground to avoid damaging the top of the rollcab.
4.4. Position the corner brackets (g.3B) and secure using bolts, washers and nuts.
4.5. Attach the back panel to the base using two bolts, washers and nuts.
4.6. Ensure the base is square in the rollcab and tighten all nuts fully (g.3C).
4.7. Place the rollcab upright and place the topchest on top as shown in g.4.
6. MAINTENANCE
5. OPERATION
6.1. Periodically lubricate the drawer slides (g.5).
6.2. Clean the surfaces with a soft cloth and a mild water/detergent solution.
6.3. Check all xings and tighten if required.
5.1. To lock the top chest, close all drawers, then insert one lock bar into the back slot inside the top compartment. Close the lid and lock with the
key.
g.3
g.4 g.5 AP2200BB.V2
