Sealey TRM5.V2 User manual

THREAD REPAIR MASTER KITS
MODEL NO’S: TRM5.V2, 6.V2, 8.V2, 9.V2, 10.V2, 12.V2,
14.V2
Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these instructions,
and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURYAND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
1. SAFETY
WARNING! Ensure Health and Safety, local authority and general workshop practice regulations are adhered to when using tools.
8DO NOT use tools if damaged.
8DO NOT use this tool for purposes other than for which it is designed.
9Maintain tools in good and clean condition for best and safest performance.
9Wear approved eye protection.Afull range of personal safety equipment is available from your Sealey stockist.
9Wear suitable clothing to avoid snagging. DO NOT wear jewellery and tie back long hair.
9Keep children and unauthorised persons away from the work area.
8DO NOT use the thread repair set when you are tired or under the influence of alcohol, drugs or intoxicating medicine.
9Account for all tools and parts being used, DO NOT leave them in or near an engine. Return all parts to the case and store this in a
safe, dry, childproof location.
WARNING! Failure to comply with these instructions may result in damage to the thread repair set or work piece and/or personal injury.
WARNING! The warnings referred to in this guide cannot cover all possible conditions and situations that may occur. It must be
understood that common sense and caution are factors which cannot be built into this product, but must be applied by the operator.
2. INTRODUCTION
Creates a stronger internal thread in soft metals. Ideal for repairing damaged or stripped internal threads. Protects tapped threads against wear
and damage. Set includes drill bit, thread tap, insert installation and lug breaking tool. Supplied with three di󰀨erent lengths of thread insert.
3. SPECIFICATION
4. INSTRUCTIONS
Refer to
instruction
manual
Wear eye
protection
TRM.V2 kits Issue:1 28/03/22
Original Language Version
© Jack Sealey Limited
Model No: Replacement inserts Thread lengths Thread size
TRM5.V2 TRM5R 3.5, 5, 7mm (5 of each) M5 x 0.8mm
TRM6.V2 TRM6R 4, 6, 9 (5 of each) M6 x 1mm
TRM8.V2 TRM8R 6, 9, 12mm (5 of each) M8 x 1.25mm
TRM9.V2 TRM9R 7, 14mm (3 of each), 11mm (x4) M9 x 1.25mm
TRM10.V2 TRM10R 7.5, 15mm (3 of each), 11mm (x4) M10 x 1.5mm
TRM12.V2 TRM12R 9, 18mm (2 of each), 14mm (x4) M12 x 1.75mm
TRM14.V2 TRM14R 10, 21mm (1 of each), 16mm (x3) M14 x 1.25mm
4.1 Drill out the damaged thread using the correctly sized twist drill
bit provided. 4.2 Tap drilled hole using screw tap provided.

Original Language Version
© Jack Sealey Limited
4.3 Load thread insert into installation tool. 4.4 Screw insert into threaded hole.
4.5 Remove the tag from the insert using the breaking pin tool. 4.6 Thread is repaired and ready to use.
Sealey Group, Kempson Way, Suffolk Business Park, Bury St Edmunds, Suffolk. IP32 7AR
01284 757500 01284 703534 [e-mail] www.sealey.co.uk
ENVIRONMENT PROTECTION
Recycle unwanted materials instead of disposing of them as waste. All tools, accessories and packaging should be sorted, taken to
a recycling centre and disposed of in a manner which is compatible with the environment. When the product becomes completely
unserviceable and requires disposal, drain any fluids (if applicable) into approved containers and dispose of the product and fluids
according to local regulations.
Note: It is our policy to continually improve products and as such we reserve the right to alter data, specifications and component parts without prior
notice.
Important: No Liability is accepted for incorrect use of this product.
Warranty: Guarantee is 12 months from purchase date, proof of which is required for any claim.
TRM.V2 kits Issue:1 28/03/22
