Sesamo Digidor User manual

1 (CONTENTS)
Sesamo - Digidor
EN
Digidor

2 (CONTENTS)
Sesamo - Digidor
EN
CONTENTS
CONTENTS .............................................................................................................................................................................2
GENERAL INFO - INSTALLATION WIRING AND .....................................................................................................................3
NAVIGATION MODE MENU ..................................................................................................................................................5
FIRST SET UP..........................................................................................................................................................................6
SCREEN ..................................................................................................................................................................................7
SELECTION MENU’: LOGIC – SETTINGS - DIAGNOSTIC .........................................................................................................8
SETTINGS .............................................................................................................................................................................10
DIAGNOSTIC ........................................................................................................................................................................12
CHECK-UP ........................................................................................................................................................................13
SENSORS’ STATUS – I/O ..............................................................................................................................................14
SYSTEM DIGNOSTIC.....................................................................................................................................................18
POWER SUPPLY DIAGNOSTIC......................................................................................................................................19
INFO.................................................................................................................................................................................20
RESET ...............................................................................................................................................................................21
PARAMETERS SETTING........................................................................................................................................................22
PASSWORD..........................................................................................................................................................................25
MODIFY PASSWORD .......................................................................................................................................................26
PASSWORD TO LOCK THE KEYBOARD ............................................................................................................................28
DATE AND TIMINGS ............................................................................................................................................................29
CALENDAR SETTING ............................................................................................................................................................30
REDUCED LOGICS ................................................................................................................................................................32
START-UP.............................................................................................................................................................................33
MAINTENANCE....................................................................................................................................................................37
FIRMWARE UPDATE........................................................................................................................................................38
SET A DEFAULT ................................................................................................................................................................39
LANGUAGE SELECTION........................................................................................................................................................40
SIGNAL TABLE......................................................................................................................................................................41

3 (CONTENTS)
Sesamo - Digidor
EN
GENERAL INFO - INSTALLATION WIRING AND
“DIGIDOR” programmer has been designed to work with all models of SESAMO operators, designed to be used from the
end user to set the different logic of operation of the automatic door, either from the installer for the setting and
commissioning, maintenance and securing the automatic door. DIGIDOR must be installed on the internal side of the
building.
H=100mm
B=50mm
SP=16mm

4 (CONTENTS)
Sesamo - Digidor
EN























   



     


























   




 



Cod. PF37.32
Use suitable tools and do not press too much to avoid
damages- EN

5 (CONTENTS)
Sesamo - Digidor
EN
NAVIGATION MODE MENU
ICON
KEY
FUNCTION
ENTER
Confirmation
ESC
Exit from the menu / cancel
UP
Scroll up
DOWN
Scroll down
RIGHT
Scroll right
LEFT
Scroll left
OPENING
COMMAND
Pressing at the same time
Right and Left Key will send
a commend to the door to
open
SELECTION
AREA
Indicates
logic/function/setting

6 (CONTENTS)
Sesamo - Digidor
EN
FIRST SET UP
Push buttons: NAVIGATION MODE MENU
Language selection
Scroll up
Scroll down

7 (CONTENTS)
Sesamo - Digidor
EN
SCREEN
Key selection: NAVIGATION MODE MENU
By pressing any key to enter:
SELECTION MENU’: LOGIC –
SETTINGS - DIAGNOSTIC
Icon peripheral
connection:
SIGNAL TABLE
Icon service: SIGNAL TABLE
Icon connection: SIGNAL TABLE
Logic selected and active:
SELECTION MENU’: LOGIC –
SETTINGS -
DIAGNOSTICSELECTION
MENU’: LOGIC –
SETTINGS -
DIAGNOSTIC
Timing: DATE AND TIMINGS

8 (CONTENTS)
Sesamo - Digidor
EN
SELECTION MENU’: LOGIC –SETTINGS - DIAGNOSTIC
Key selection: NAVIGATION MODE MENU
Setting:
▪logic
▪menu
Scroll up
Scroll down
Back to SCREEN
Selected icon
If present it indicates that the function
has been set:
REDUCED LOGICS

9 (CONTENTS)
Sesamo - Digidor
EN
ist of icons present in the menu:
Sliding Swing
ICONS
DESCRIPTION
Stop close
Stop open
One way
Automatic
Partial opening
One way
Partial opening
Automatic
Partial opening
Stop open
Manual
Partial opening
Manual
Menu SETTINGS
Menu DIAGNOSTIC
ICONS
DESCRIPTION
Stop close
Stop open
One way
Automatic
Manual opening
Menu SETTINGS
Menu DIAGNOSTIC
DIGIDOR PROGRAMMER IS SELF-SETTING
ACCORDING TO THE TYPE OF OPERATOR
CONNECTED (SWING / SLIDING).
IT DOES NOT REQUIRE ANY SPECIAL SETTING OR
FIRMWARE DIFFERENT FROM THE
AUTOMATIONS!!!

10 (CONTENTS)
Sesamo - Digidor
EN
SETTINGS
To enter the setting menu enter a password (refer to PARAMETERS SETTING ).
The are two menus:
•Menu for installer –default password: 1234
•Menu for end user –default password: 1111
Key selection: NAVIGATION MODE MENU
Enter the selected menu
Scroll up
Scroll dows
Back to SCREEN
Icon selected
IT IS RECCOMENDED TO CHANGE THE DEFAULT
PASSWORD WITH YOUR OWN PASSWORD!!!!!!!!!

11 (CONTENTS)
Sesamo - Digidor
EN
List of icons of the menu ONLY for the installer:
END USER MENU is without:
•Start-up
•Maintenance
•Parameters adjustment –only setting partial opening (winter mode)
ICONS
DESCRIPTION
PARAMETERS
SETTING
PASSWORD
DATE AND TIMINGS
CALENDAR SETTING
REDUCED LOGICS
START-UP
MAINTENANCE
LANGUAGE
SELECTION

12 (CONTENTS)
Sesamo - Digidor
EN
DIAGNOSTIC
Key selection: NAVIGATION MODE MENU
Available menu:
•CHECK-UP
•INFO
•RESET
Scroll up
Scroll down
Back to SCREEN
Icon selected

13 (CONTENTS)
Sesamo - Digidor
EN
CHECK-UP
Key selection: NAVIGATION MODE MENU
Available menu:
•SENSORS’ STATUS –I/O
•SYSTEM DIGNOSTIC
•POWER SUPPLY DIAGNOSTIC
Scroll up
Scorro verso il basso
Back to DIAGNOSTI
Icon selected

14 (CONTENTS)
Sesamo - Digidor
EN
SENSORS’ STATUS –I/O
Three diagnostic screens on sensor status –I/O
Screen 1 di 3 Screen 2 di 3 Screen 3di 3
Key selection: NAVIGATION MODE MENU
Screen scroll
Back to menu CHECK-UP
Screen scroll
An error description / sensor
status window appears (refers to
message chart)
Selection of contact
Selection of contact
Contact
selected
Contact
selected
Contact
selected

15 (CONTENTS)
Sesamo - Digidor
EN
Messages chart screen 1 DI 3 –OPENING SENSORS:
STATUS
MESSAGE
ACTION REQUIRED
ENTER / ESC to go
back
ENTER / ESC to go
back

16 (CONTENTS)
Sesamo - Digidor
EN
Messages chart screen 2 DI 3 –SAFETY SENSORS:
STATUS
MESSAGE
ACTION REQUIRED
ENTER / ESC to go
back
ENTER / ESC to go
back
ENTER / ESC to go
back

17 (CONTENTS)
Sesamo - Digidor
EN
Messages chart screen 3 DI 3 –INPUT AUX-OUPUT:
STATUS
MESSAGE
ACTION REQUIRED
ENTER / ESC to go
back
ENTER / ESC to go
back

18 (CONTENTS)
Sesamo - Digidor
EN
SYSTEM DIGNOSTIC
Two diagnostic screens:
Screen 1/2 Screen 2/2
Key selection: NAVIGATION MODE MENU
Info 1
Info 3
Info 4
Info 5
Scroll screens
Back to meu CHECK-UP
Scroll screens
Info 2
Info 6

19 (CONTENTS)
Sesamo - Digidor
EN
POWER SUPPLY DIAGNOSTIC
Two diagnostic screens:
Screen 1/2 Screen 2/2
Key selection: NAVIGATION MODE MENU
Info 1
Info 2
Info 3
Info 4
Scroll screen
Back to menu CHECK-UP
Scroll screens

20 (CONTENTS)
Sesamo - Digidor
EN
INFO
Four system information screens:
Screen 1 di 4 Screen 2 di 4 Screen 3di 4 Screen 4 di 4
Key selectionNAVIGATION MODE MENU
Scroll screens
Back to menu CHECK-UP
Scroll screens
