Sharp UX-B700 User manual

UX-B700 FACSIMILE
MODEL
UX-B700
OPERATION MANUAL
FACSIMILE
1. Installation
2. Sending Faxes
3. Receiving Faxes
4. Making Copies
5. Answering Machine
Connection
6. Special Functions
7. Printing Lists
8. Maintenance
9. Troubleshooting
IMPORTANT
PLEASE KEEP THE EXTERNAL & INTERNAL PACKAGING SAFE.
PLEASE DO NOT THROW IT AWAY.
IN THE UNLIKELY EVENT OF A HARDWARE FAILURE, OUR
REPAIR CENTRE WILL ASK YOU TO PUT YOUR SHARP
FACSIMILE IN THIS BOX.
THANK YOU FOR YOUR ASSISTANCE.

MAINS PLUG WIRING INSTRUCTIONS
This equipment is fitted with a moulded type mains plug which incorporates a detachable
fuse cover, under no circumstances should the plug be used without the fuse cover fitted.
In the unlikely event of the socket outlet in your home not being compatible with the plug
supplied, cut off the mains plug and fit an appropriate type observing the wiring code
below.
DANGER: The fuse from the cut-off plug should be removed and the plug should be
disposed of in a safe manner. Under no circumstances should the cut-off plug be
inserted into a socket outlet as a serious electric shock may occur.
If you are not sure how to do this, get help from a qualified electrician.
IMPORTANT
The wires in this mains lead are coloured in accordance with the following code:
GREEN-AND-YELLOW: Earth
BLUE: Neutral
BROWN: Live
As the colours of the wires in the mains lead of this apparatus may not correspond with
the coloured markings identifying the terminals in your plug, proceed as follows:The wire
which is coloured GREEN-AND-YELLOW must be connected to the terminal in the plug
which is marked by the letter E, or by the safety earth symbol or coloured green or
green-and-yellow.The wire which is coloured BLUE must be connected to the terminal
which is marked with the letter Nor coloured black.The wire which is coloured BROWN
must be connected to the terminal which is marked with the letter Lor coloured red.
This apparatus must be protected by a 13A fuse in the mains plug or distribution board.
"WARNING: THIS APPARATUS MUST BE EARTHED"
This equipment complies with the requirements of Directive 1999/5/EC.
Dieses Gerät entspricht den Anforderungen der EU-Richtlinie 1999/5/EG.
Cet appareil est conforme aux exigences de la directive 1999/5/CE.
Este aparato satisface las exigencias de las Directiva 1999/5/CE.
Quest’apparecchio è conforme ai requisiti delle direttiva 1999/5/CE.
Dit apparaat voldoet aan de eisen van de richtlijn 1999/5/EG.
Este equipamento obedece às exigências da directiva 1999/5/CE.
Ησυσκευή αυτή ανταποκρίνεται στις απαιτήσεις των οδηγια 1999/5/ΕK.
Denna utrustning uppfyller kraven enligt direktiv 1999/5/EC.
Dette udstyr overholder kravene i direktiv 1999/5/EF.
Dette produktet oppfyller kravene i direktiv 1999/5/EC.
Tämä laite täyttää direktiivi 1999/5/EY.
This is a facsimile product operating in British and Irish analogue public switched telephone networks which
follow the TBR21 Standard.
The Declaration of Conformity can be viewed at the following URL address.
http://www.sharp.de/doc/UX-B700.pdf
all.book Page 1 Friday, April 1, 2005 9:53 AM

1
Introduction
*When Ink Save mode is enabled.
**Based on Sharp Standard No. 1 Chart at standard resolution, excluding time for protocol
signals (i.e., ITU-T phase C time only).
Automatic dialling Rapid Key Dialling: 18 numbers
Speed Dialling: 81 numbers
Print cartridge Initial cartridge
Approx. yield 300 pages at 4% coverage*
Replacement cartridge: SHARP UX-C70B
Approx. yield 600 pages at 4% coverage*
Memory size** 1.8 MB (approx. 100 average pages)
Modem speed 14,400 bps with auto fallback to lower speeds.
Transmission time** Approx. 6 seconds (only when ECM is on)
Scanning Resolution Horizontal: 8 lines/mm
Vertical:
Standard: 3.85 lines/mm
Fine /Halftone: 7.7 lines/mm
Super fine: 15.4 lines/mm
Print resolution 600 ×600 dpi
Automatic document
feeder 20 pages max. (A4 size, 80 g/m2paper)
Recording system Thermal inkjet
Halftone (grayscale) 64 levels
Compression scheme MR, MH, MMR
Welcome, and thank you for
choosing a SHARP inkjet
fax machine! The features
and specifications of your
inkjet fax are shown below..
all.book Page 1 Friday, April 1, 2005 9:53 AM

2
As a part of our policy of continuous improvement, SHARP reserves the right to make design
and specification changes for product improvement without prior notice. The performance
specification figures indicated are nominal values of production units. There may be some
deviations from these values in individual units.
Paper tray capacity
(60 - 80 g/m2paper)
Approx. 200 A4-size sheets
(at room temperature; maximum stack height
should not cover the line on the tray)
Compatibility ITU-T (CCITT) G3 mode
Input document size Automatic feeding:
Width: 148 to 210 mm / Length: 140 to 297 mm
Manual feeding:
Width: 148 to 210 mm / Length: 140 to 600 mm
Effective scanning width 210 mm max.
Effective printing width 203 mm max.
Contrast control Automatic/Dark selectable
Reception modes TEL / FAX / A.M. / TEL/FAX
Copy function Single/Multi/Sort (99 copies/page)
Telephone function Yes (cannot be used if power fails)
Applicable telephone line Public switched telephone network (TBR21) / PBX
Display 16-digit LCD display
Power requirements 230V AC, 50 Hz
Operating temperature 15 - 32°C
Humidity 25 - 80% RH
Power consumption Standby: 5.0 W
Maximum: 35 W
Dimensions (without
attachments)
Width: 372 mm
Depth: 259 mm
Height: 203 mm
Weight (without
attachments)
Approx. 5.0 kg
all.book Page 2 Friday, April 1, 2005 9:53 AM

3
Important safety information
Do not disassemble this machine or attempt any procedures not described in this manual.
Refer all servicing to qualified service personnel.
Do not install or use the machine near water, or when you are wet. For example, do not use the
machine near a bath tub, wash bowl, kitchen sink or laundry tub, in a wet basement, or near a
swimming pool. Take care not to spill any liquids on the machine.
Unplug the machine from the telephone socket and then the power outlet and consult a
qualified service representative if any of the following situations occur:
- Liquid has been spilled into the machine or the machine has been
exposed to rain or water.
- The machine produces odors, smoke, or unusual noises.
- The power cord is frayed or damaged.
- The machine has been dropped or the housing damaged.
Do not allow anything to rest on the power cord, and do not install the machine where people
may walk on the power cord.
This machine must only be connected to a 230 V, 50 Hz, earthed (3-prong) outlet. Connecting
it to any other kind of outlet will damage the machine and invalidate the warranty.
Never insert objects of any kind into slots or openings on the machine. This could create a risk
of fire or electric shock. If an object falls into the machine that you cannot remove, unplug the
machine and consult a qualified service representative.
Do not place this machine on an unstable cart, stand or table. The machine could be seriously
damaged if it falls.
Never install telephone wiring during a lightning storm.
Never install telephone sockets in wet locations unless the socket is specifically designed for
wet locations.
Never touch bare telephone wires or terminals unless the telephone line has been
disconnected at the network interface.
Use caution when installing or modifying telephone lines.
Avoid using a telephone (other than a cordless type) during an electrical storm. There may be
a remote risk of electric shock from lightning.
Do not use a telephone to report a gas leak in the vicinity of the leak.
The power outlet must be installed near the equipment and must be easily accessible.
all.book Page 3 Friday, April 1, 2005 9:53 AM

4
Table of Contents
A Look at the Operation Panel 6
1. Installation 8
Unpacking Checklist . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Attachments . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Loading Printing Paper . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Connecting the Power Cord . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Installing the Print Cartridge . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Connecting the Telephone Line Cord. . . . . . . . . . . . . . . . . . . . . . . . 21
Entering Your Name and Fax Number . . . . . . . . . . . . . . . . . . . . . . . 23
Setting the Date and Time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Setting the Reception Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Flash Select Setting for PBX . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Volume Adjustment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
2. Sending Faxes 31
Transmittable Documents. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Loading the Document . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Adjusting the Resolution and Contrast . . . . . . . . . . . . . . . . . . . . . . . 34
Sending a Fax by Normal Dialling . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Sending a Fax by Automatic Dialling . . . . . . . . . . . . . . . . . . . . . . . . 38
Batch Page Numbering . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
Sending a Fax From Memory . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
3. Receiving Faxes 55
Using TEL/FAX Mode. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
Using FAX Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
Using TEL Mode. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58
Optional Reception Settings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60
Substitute Reception to Memory . . . . . . . . . . . . . . . . . . . . . . . . . . . 63
4. Making Copies 64
all.book Page 4 Friday, April 1, 2005 9:53 AM

Table of Contents
5
5. Answering Machine Connection 66
Connecting an Answering Machine . . . . . . . . . . . . . . . . . . . . . . . . . 66
Using the Answering Machine Connection . . . . . . . . . . . . . . . . . . . . 67
Optional A.M. Mode Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68
6. Special Functions 72
Caller ID (Requires Subscription to Service) . . . . . . . . . . . . . . . . . . 72
Blocking Reception of Unwanted Faxes . . . . . . . . . . . . . . . . . . . . . . 77
PBX operations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 78
Polling (Requesting a Fax Transmission) . . . . . . . . . . . . . . . . . . . . . 79
7. Printing Lists 84
8. Maintenance 89
Cleaning the Machine . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 89
Improving Print Quality . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 92
9. Troubleshooting 97
Problems and Solutions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 97
Messages and Signals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 102
Clearing Paper Jams . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 105
Quick Reference Guide 108
Index 109
all.book Page 5 Friday, April 1, 2005 9:53 AM

6
Display
This displays messages and prompts to help you operate the machine.
FUNCTION key
Press this key followed by the arrow keys to select special functions and
settings.
RESOLUTION / RECEPTION MODE key
When a document is in the feeder, press this key to adjust the resolution for
faxing or copying. At any other time, press this key to select the reception
mode (an arrow in the display will point to the currently selected reception
mode).
Rapid Dial Keys
Press one of these keys to dial a fax number automatically.
Number keys
Use these keys to dial numbers, and enter numbers and letters when storing
auto-dial numbers.
SPEED DIAL key
Press this key to dial a fax or voice number using an abbreviated 2-digit
Speed Dial number.
A Look at the Operation Panel
1
2
3
4
5
6
DEF
A.M.TEL/FAX
1 2 3
4 5 6
7 8 9
0
TEL FAX
MNO
WXYZ
ABC
JKL
TUV
GHI
01 02 03 04 05 06
07 08 09 10 11 12
13 14 15 16/POLL 17/G1 18/G2
PQRS
RESOLUTION /
R
SPEED DIAL
FUNCTION
COPY/HELP
STOP
REDIAL
ZA
UP
DOWN
START/
MEMORY
SPEAKER
RECEPTION MODE
13 4
5710 912
11
8
6
2
13
PANEL RELEASE
BUSINESS INKJET FACSIMILE
all.book Page 6 Friday, April 1, 2005 9:53 AM

7
SPEAKER key
Press this key to listen to the line and fax tones through the speaker when
faxing a document.
7
R key
If you are on a PBX, use this key to transfer calls and make enquiry calls. If
the PBX is a flash-type PBX, use the key to dial out.
PANEL RELEASE
Grasp here and pull up to open the operation panel.
COPY/HELP key
When a document is in the feeder, press this key to make a copy of a
document. At any other time, press this key to print out the Help List, a quick
reference guide to the operation of your fax machine.
STOP key
Press this key to cancel an operation before it is completed.
START/MEMORY key
Press this key after dialling to begin fax transmission. Press this key before
dialling to send a fax through memory. The key can also be pressed in the
date and time display to show the percentage of memory currently used.
Arrow keys
Use these keys to scroll through and select settings, and to search for auto-
dial numbers.
11
10
9
8
12
13
Monitoring phone conversations
When speaking through the handset, you can press to allow a
third person to listen to the conversation through the speaker. (To turn off the
speaker, press the key again.)
To adjust the volume of the speaker when monitoring a conversation, press
for high or for low (the volume setting reverts to low each time the
handset is replaced).
Note that the speaker cannot be used for speaking; it is only for listening.
To avoid feedback (a loud howling sound), be sure to turn off the speaker
(press once again) before you replace the handset.
SPEAKER
UP
DOWN
SPEAKER
all.book Page 7 Friday, April 1, 2005 9:53 AM

8
1. Installation
Unpacking Checklist
If any are missing,
contact your
dealer or retailer.
Before setting up,
make sure you
have all of the
following items.
Operation
manual
Handset Handset
cord
Telephone
line cord
Rapid Key
labels
Print
cartridge
Paper tray
Paper tray
cover
Document tray Document
exit support
Extension
phone adapter
all.book Page 8 Friday, April 1, 2005 9:53 AM

Attachments
9
1. Installation
Attachments
Points to keep in mind when setting up
Do not place the
machine in direct
sunlight.
Do not place the
machine near heaters
or air conditioners.
Keep dust away from
the machine.
About condensation
If the machine is moved from a cold to a warm place, it is possible that
condensation may form on the scanning glass, preventing proper scanning of
documents for transmission. To remove the condensation, turn on the power and
wait approximately two hours before using the machine.
Removing the packing tape
1 Open the print compartment cover.
•Press as shown and pull the cover
toward you.
2 Remove the tape.
all.book Page 9 Friday, April 1, 2005 9:53 AM

Attachments
10
Connecting the handset
Connect the handset as shown and place it on the handset rest.
♦The ends of the handset cord are identical, so they will go into either
socket.
Make sure the handset
cord goes into the
socket marked with a
handset symbol on the
side of the machine!
Use the handset to make ordinary phone calls,
or to transmit and receive faxes manually.
3 Close the printer cover.
all.book Page 10 Friday, April 1, 2005 9:53 AM

Attachments
11
1. Installation
Attaching the paper trays
Attach the paper tray.
Pull the paper plate
toward you and attach
the paper tray cover.
Paper plate
1
2
Attach the document
tray.
all.book Page 11 Friday, April 1, 2005 9:53 AM

Attachments
12
Attach the document exit support.
Pull out the received
document tray.
all.book Page 12 Friday, April 1, 2005 9:53 AM

Loading Printing Paper
13
1. Installation
1 Pull the paper plate toward you, and
remove the paper tray cover from the
paper tray.
2 Pull the paper plate toward you and insert the stack of paper into the
tray, PRINT SIDE UP .
•If paper remains in the tray, take it out and combine it into a single stack
with the new paper.
3 Pull the paper plate toward you and
replace the paper tray cover.
Loading Printing Paper
You can load up to 200 sheets of A4-size, 60 - 80 g/m2paper in the paper tray
(at room temperature; maximum stack height should not be higher than the
line on the tray).
The stack should
not be higher
than this line
Be sure to load the paper so that
printing takes place on the print side
of the paper. Printing on the reverse
side may result in poor print quality.
all.book Page 13 Friday, April 1, 2005 9:53 AM

Connecting the Power Cord
14
Connecting the Power Cord
Plug the power cord into a 230 V, 50 Hz, earthed (3-prong) AC outlet.
Caution!
♦Make sure you have removed all of the packing tape before plugging
in the power cord (see page 9). Plugging in the power cord without doing
so may damage the machine.
♦The power outlet should be installed near the equipment and be easily
accessible.
Note: If your area experiences a high incidence of lightning or power surges,
we recommend that you install surge protectors for the power and telephone
lines. Surge protectors can be purchased at most telephone specialty stores.
“CHECK CARTRIDGE” normally
appears in the display the first
time you plug in the machine.
This message appears until you
install the print cartridge.
The machine does not have
a power on/off switch, so
the power is turned on and
off by simply plugging in or
unplugging the power cord.
all.book Page 14 Friday, April 1, 2005 9:53 AM

Installing the Print Cartridge
15
1. Installation
Installing the Print Cartridge
Caution!
Do not open the print compartment cover of the machine while it is
printing. If opened while printing, printing will stop.
Note: Keep ink cartridges sealed in their packages until you are ready to install
them. It is recommended that you do not use a cartridge that has been left unused
for a long time after opening, as the print quality may be considerably degraded.
♦Make sure the power cord of the machine is plugged in and paper is loaded
before installing or replacing the print cartridge.
1 Open the operation panel.
The initial starter print
cartridge included with
your fax can print about
300 A4-size pages.
When replacing the print
cartridge, use a SHARP
UX-C70B cartridge. One
cartridge can print about
600 A4r-size pages.
If PRINTER ERROR or PRINTER ERROR/CHECK PAPER appears...
In the event that the display shows either of the above messages, you must clear the
error before installing the print cartridge. The error can usually be cleared by opening
and closing the print compartment cover (see Step 2), or if a paper jam has occurred, by
removing the paper jam (see page 106).
The above
yields are at 4%
coverage in INK
SAVE mode.
all.book Page 15 Friday, April 1, 2005 9:53 AM

Installing the Print Cartridge
16
2 Open the print compartment cover.
•Press as shown and pull the cover
toward you.
3 Remove only the tape from the the new
cartridge.
•Important: Make sure you remove all
of the tape.
•CAUTION! DO NOT touch the gold
contact area of the cartridge.
4 Make sure the cartridge holder is
between the “CARTRIDGE EXCHANGE
AREA” arrows on the label, and then
pull the green lever and open the
cartridge holder cover.
•If you are replacing the cartridge,
remove the old cartridge. If you are
going to use the old cartridge again,
place it in an air-tight container.
•CAUTION! DO NOT touch the contact
area inside the carriage carrier.
Note: If the print compartment cover is left
open for approximately 30 minutes with a
cartridge installed, the cartridge will
automatically return to its home position. To
make the cartridge return to the CARTRIDGE
EXCHANGE AREA when this has happened,
close the cover and then open it again.
all.book Page 16 Friday, April 1, 2005 9:53 AM

Installing the Print Cartridge
17
1. Installation
5 Insert the new print cartridge into the
cartridge holder.
6 Place your index finger on the tab as
shown and close the cartridge holder
cover with your thumb. Make sure the
cover clicks into place.
7 Close the print compartment cover.
8 Close the operation panel, pressing
down firmly on both front corners to
make sure it clicks into place.
Display:
1=NEW, 2=OLD
CHANGE CARTRIDGE
all.book Page 17 Friday, April 1, 2005 9:53 AM

Installing the Print Cartridge
18
9 Press (NEW) if the cartridge you
installed is new.
Press (OLD) if the cartridge you
installed is old.
10 Press .
If you selected “OLD” in the previous
step, this completes the installation
procedure. (Note: If you find that print
quality is not satisfactory after
reinstalling the old cartridge, align the
cartridge as explained on page 92.)
If you selected “NEW”, the display will
show the alternating messages at
right. Continue with the following steps
to align the print cartridge.
11 Press to print an alignment page. (To enter an alignment value
without printing an alignment page, press .)
1
2
START/
MEMORY
1
2
1=PRINT,2=SET
ALIGN CARTRIDGE
Display when “NEW” is
selected:
OK: PRESS START
NEW CART.: OK?
Display when “1” is selected:
If you select the wrong number by mistake,
press and repeat the selection.
STOP
all.book Page 18 Friday, April 1, 2005 9:53 AM
