ShoreStation SS1053DE User manual

SS1053DE / SS10531DE
Dock Mount Hoist with Electric Drive Winch
Your Shore-Station PWC Boat Hoist is designed to give years of dependable service. Following the instructions
in the operator’s manual will insure its dependability and more important, YOUR safety. Read through this entire
operator’s manual before attempting to operate your hoist. Our goal is your safety - help us help you by knowing
and observing the operating precautions and limitations you will find listed herein. If you do not understand any
of these instructions, please ask your dealer for his personal attention to your questions.
Midwest Industries, Inc.
Ida Grove, IA 51445
SS1053DE Dock Mount Hoist 1000 lbs. w/
Electric Winch
66003 Lower Frame Wment 853/8531
66427 Bunk Bundle 853D
68505 Hardware Box 1053D Dock Mtg Elec
67425 Leg Bundle SS853DE
66033 Platform Bundle 853D
SS10531DE Dock Mount Hoist 1000 lbs. w/
Electric Winch
66003 Lower Frame Wment 853/8531
66427 Bunk Bundle 853D
68505 Hardware Box 1053D Dock Mtg Elec
67426 Leg Bundle SS8531DE
66033 Platform Bundle 853/8531
SS1053DE / SS10531DE Bundles Required
Midwest Industries, Inc. Ida Grove, IA 51445 [phone] www.shorestation.com M402105
Page 1

Midwest Industries, Inc. Ida Grove, IA 51445 [phone] www.shorestation.com M402105
Page 2
Replacement Parts
304390* 84” WINCH STRAP- SS1053DSE/
SS10531DSE
* DL Replacement Numbers

SS1053DE / SS10531DE Parts Drawing
Midwest Industries, Inc. Ida Grove, IA 51445 [phone] www.shorestation.com M402105
Page 3

1. Bundles as shown. 2. Install the aluminum base pad channel
clamp to the base pad using two (2) 3/8” X
1” hex bolts and two (2) 3/8” flange lock nuts.
3. Mount the adjustable leg to the base pad
channel using a 1/2” X 4-1/2” hex bolt and
secure with a 1/2” flange lock nut.
4. Mount the lower frame weldment (Ref.#6)
to the winch post extrusion (Ref.#13) using
two (2) 3/8” X 5-3/16” X 3-7/8” square u-bolts
(Ref.#30) as shown. Secure with 3/8” flange
lock nuts.
5. Mount the guide post tube (Ref.#9) to the
opposite end of the lower frame weldment
using a leg adjustment pin (Ref.#10). Secure
with a hitch pin clip (Ref.#46).
6. Also mount the guide post tube to the
opposite end of the lower frame tube using
two (2) 3/8” X 3-7/8” X 3-7/8” SUB’s. Secure
with 3/8” flange lock nuts.
7. Slide the platform assembly (Ref.#17) into
the winch post extrusion (Ref.#13) as shown.
8. Slide the opposite end of the platform
assembly over the guide post tube as shown.
Note: Be sure that the cable end is in the
knotch in the end of the guide post.
9. Run the threaded end of the cable through
the lower frame weldment as shown.
Tools Required
9/16” Socket/Wrench
3/4” Socket/Wrench
Midwest Industries, Inc. Ida Grove, IA 51445 [phone] www.shorestation.com M402105
Page 4

Midwest Industries, Inc. Ida Grove, IA 51445 [phone] www.shorestation.com M402105
Page 5
10. Secure the cable end to the under side
of the lower frame weldment with a 3/8” flat
washer and 3/8” hex nut.
11. Mount the electric winch to the winch
mounting plate using two (2) 1/2” X 1” hex
bolts in the top two (2) mounting holes and
one (1) 3/8” X 1” hex bolt in the single lower
mounting hole. Secure with two (2) 1/2” lock
washers and two (2) 1/2” hex nuts. Secure
the 3/8” X 1” hex bolt with a 3/8” lock washer
and a 3/8” hex nut.
12. Mount the electric winch assembly that
is attached to the mounting plate to the winch
post using four (4) 3/8” X 3-3/4” hex bolts
Slide the electric control holder over the end
of the one of the lower 3/8” X 3-3/4” hex bolts
on either side of the electric winch. See
diagram on page 2. Secure with four (4) 3/8”
flange lock nuts. Place the electric controller
unit into the electric control holder.
13. Connect the end of the winch strap to the
platform weldment assembly as shown.
14. Mount the stop plate (Ref.#12) to the
winch post extrusion using two (2) 3/8” X
3-3/4” hex bolts (Ref.#22). Secure with 3/8”
flange lock nuts.
NOTE: The strap must be free of any
twisting.
16. Mount the hoist attach plate (Ref.#11) to
the winch post mounting plate over the six
(6) 3/8” X 1-1/2” carriage bolts as shown.
Secure with 3/8” flange lock nuts.
15. Place the winch post mounting plate
(Ref.#19) to the dock angle using six (6) 3/8”
X 1-1/2” carriage bolts (Ref.#28).
17. Lay the dock mounting angle (Ref.#20)
onto the dock. (Do not secure to the dock
until step 18 has been done.) Mount the dock
bumpers (Ref.#3) and secure with 3/8”
medium lock washers (Ref.#34) and 3/8” hex
nuts (Ref.#38).
18. Secure the dock mounting angle
(Ref.#20) onto the dock with three (3) 5/16”
X 2-1/4” carriage bolts (Ref.#29) and three
(3) 5/16” hex nuts (Ref.#40).

19. Insert the black plastic cap (Ref.#56) into
the guide post tube as shown.
21. Mount the bunk with brackets onto the
platform weldment using two (2) 1/2”
v-shaped u-bolts (Ref.#32), two (2) spacers
(Ref.#52) and two (2) 1/2” hex lock nuts
Do NOT use unit
without a ground
fault
interruptor at
the power source.
Failure to do so
may result in
electrical shock.
Installation must be
done by a qualified
electrician.
4811455
Removing Boat from Hoist
1. Standing on dock, lower hoist
until PWC is supported by hoist
platform but nearly floating free.
2. Board PWC.
3. Once seated, with engine
idling in reverse, lower hoist
until PWC begins to exit hoist.
Returning Boat to Hoist
1. Upon returning, platform will
be at proper loading height.
Position PWC on hoist.
2. Raise hoist until PWC rests
solidly on hoist platform.
3. Exit PWC. Rotate controller
back to dock side as you exit.
4. While standing on dock, raise
hoist to maximum height.
SAFETY
INSTRUCTIONS
DO NOT submerge
controller in water.
“IN”
“OUT”
“RUN”
- Raises hoist
- Lowers Hoist
- Energizes
winch sytsem
IMPORTANT: Use caution
while raising and lowering hoist.
Read Owner’s Manual before
operating hoist.
Electrical shock may result.
IN OFF
OUT ON
4811460
Electric Drive Winch
(Ref.#43) per bunk as shown. Note: The
short end of bunk from galvanized
mounting channel goes to the right of the
winch handle. Repeat on other bunks.
Bunks should be spaced to fit your
watercraft before tightening. Bunks should
also be angled toward the center of the
platform. NOTE: To enter the dock hoist
from the other end - reverse the bunk
assembly.
Midwest Industries, Inc. Ida Grove, IA 51445 [phone] www.shorestation.com M402105
Page 6

Safety Tips
“The best insurance policy is safety”
After the hoist installation is complete, it is important to next check and see that the winch mechanism is functioning properly. This is easily
accomplished by raising the empty platform about one-fourth the way up and releasing your grasp on the lift handle. If the winch is operating
properly, the clutch brake will automatically hold the platform at any position. Perform this same test in the half, three-fourths and full lift
positions. Next, repeat this same procedure with your boat on the hoist. If the lift handle begins to freely spin down from any of these test
positions, at no time should you attempt to prevent it from doing so. Such action could result in injury to arms and hands. Instead simply let
the platform spin down into the water. Doing so will neither damage your hoist nor your watercraft.
If for some reason your winch mechanism does not function as described call your authorized Shore Station dealer. Do not tamper with the
winch mechanism.
SAFETY PRECAUTIONS
DO NOT OPERATE THIS HOIST WITHOUT FIRST STUDYING THIS OWNER’S MANUAL
1. See to it that you, your family, and anyone else who uses the hoist looks upon the unit not as a toy, but a piece of heavy equipment
that deserves your respect and good judgment.
2. Before allowing anyone to operate the unit, be sure they fully understand the proper operating procedure.
3. Do not exceed maximum capacity unit, overloading may cause mechanical failure and serious personal injury.
4. All persons should stand clear and should not be allowed to board your watercraft when it is being raised or lowered.
5. If you choose to remove the winch cover and inspect or work on the winch, be sure the platform is completely lowered.
6. It is a good safety policy to restrict children, as well as adults, from playing on or near the hoist.
7. Service winch annually. IMPORTANT: Winch maintenance schedule must be followed to avoid possible failure and injury. See winch
owner’s manual for instructions.
8. Check cable for wear or fraying and also stress on cable attaching ends. If this occurs, replace cable immediately.
9. Be sure the hoist is installed level, severe out of level installation may cause hoist hand up and serious personal injury.
10. Do not work on you watercraft or hoist with watercraft on the hoist.
11.Check all sheaves, make sure they are turning and operating properly.
12. Check fasteners on cable ends to be positive they are threaded properly (see setting up instructions).
13. If the winch handle begins to freely spin down for any reason, at no time should you attempt to prevent it from doing so. Such action
could result in injury to arms and hands. Instead, simply let the platform spin down into the water. Doing so will neither damage your
watercraft or hoist.
14. Never pick up on platform of hoist while trying to move, position, or transport hoist. Doing so may cause serious personal injury.
15. Never stand or walk on hoist platform while in any raised position. Doing so may cause serious personal injury.
SAFETY MAINTENANCE
It is recommended that your Shore Station hoist be thoroughly inspected at least once each season:
1. Tighten all bolts.
2. Check pulleys and make sure they are all turning freely.
3. Inspect all cables for fraying, wearing or deteriorating. If any signs appear, replace cables.
4. Check frame thoroughly.
5. Check winch as per manufacturer’s specifications.
Midwest Industries, Inc. Ida Grove, IA 51445 [phone] www.shorestation.com M402105
Page 7

After final assembly, you are now ready for installation. Once the location is determined you need to find the water depth and the dock height.
Using a pole or a 2X4, insert it into the water and locate solid bottom to water level. Mark both the water level and the top of the on the 2X4.
Remove the pole and measure the distance from solid bottom to water level.
You must allow 17” for the lower cross member and bunk height, then add floatation allowance plus the water distance to the top of the dock
figure, dock mount tube should be set at this measurement. Subtract this measurement from the lake bottom to the top of the dock
measurement to get the leg extension measurement. NOTE: Allowances may have to be made for uneven lake bottom in the leg setting
measurement.
The distance of dock to water line plus 29” equals position to set the top of the dock mount tube.
