SICK MPS-G User manual

OPERATING INSTRUCTIONS
MPS-G with 2/3 switching points and IO-Link (up
to 8 switching points)
Magnetic cylinder sensors

Described product
MPS-G
Manufacturer
SICK AG
Erwin-Sick-Str. 1
79183 Waldkirch
Germany
Legal information
This work is protected by copyright. Any rights derived from the copyright shall be
reserved for SICK AG. Reproduction of this document or parts of this document is
only permissible within the limits of the legal determination of Copyright Law. Any modi‐
fication, abridgment or translation of this document is prohibited without the express
written permission of SICK AG.
The trademarks stated in this document are the property of their respective owner.
© SICK AG. All rights reserved.
Original document
This document is an original document of SICK AG.
2O P E R A T I N G I N S T R U C T I O N S | MPS-G with 2/3 switching points and IO-Link (up to 8 switching points) 8028195/2022-11-30 | SICK
Subject to change without notice

Contents
1 About this document........................................................................ 5
1.1 Further information................................................................................... 5
1.2 Symbols and document conventions...................................................... 5
2 Safety information............................................................................ 6
2.1 Intended use............................................................................................. 6
2.2 Improper use............................................................................................. 6
2.3 Limitation of liability................................................................................. 6
2.4 Requirements for skilled persons and operating personnel.................. 6
2.5 Hazard warnings and operational safety................................................. 7
2.6 Notes on UL approval............................................................................... 7
3 Product description........................................................................... 8
3.1 Product ID.................................................................................................. 8
3.1.1 Device view............................................................................... 8
3.2 Product characteristics............................................................................ 8
3.2.1 Product features...................................................................... 8
3.3 Operating principle................................................................................... 9
3.3.1 Principle of operation.............................................................. 9
3.3.2 Detection range....................................................................... 10
3.3.3 Position output......................................................................... 10
3.3.4 Switching behavior after Manual Teach of up to 3 switching
points........................................................................................ 11
3.3.5 Switching behavior after Dynamic Teach of 2 switching
points........................................................................................ 12
3.3.6 Switching behavior after Dynamic Teach of 3 switching
points........................................................................................ 15
4 Transport and storage....................................................................... 20
4.1 Transport................................................................................................... 20
4.2 Transport inspection................................................................................. 20
4.3 Storage...................................................................................................... 20
5 Mounting............................................................................................. 21
5.1 Mounting requirements............................................................................ 21
5.2 Optional accessories................................................................................ 21
5.3 Mounting................................................................................................... 21
6 Electrical installation........................................................................ 22
6.1 Safety......................................................................................................... 22
6.1.1 Notes on electrical installation............................................... 22
6.1.2 Wiring instructions................................................................... 22
6.2 Connections.............................................................................................. 24
6.2.1 Pin assignment/Connection diagram + wire colors.............. 24
6.3 Connecting the supply voltage................................................................. 24
CONTENTS
8028195/2022-11-30 | SICK O P E R A T I N G I N S T R U C T I O N S | MPS-G with 2/3 switching points and IO-Link (up to 8 switching points) 3
Subject to change without notice

7 Commissioning.................................................................................. 26
7.1 Overview of commissioning steps........................................................... 26
7.2 Positioning on drive.................................................................................. 26
7.3 Put the sensor into operation for the first time...................................... 26
8 Operation............................................................................................ 28
8.1 General notes on operation..................................................................... 28
8.2 Operating and status indicators.............................................................. 28
8.2.1 Control element....................................................................... 28
8.2.2 Status indicators...................................................................... 28
8.3 Teach-in mode........................................................................................... 29
8.3.1 Dynamic Teach-in..................................................................... 30
8.3.2 Manual teach-in....................................................................... 32
8.4 Operation via IO-Link................................................................................ 36
8.4.1 Process data structure............................................................ 36
8.4.2 General functions.................................................................... 37
8.4.3 Configuration options via IO-Link............................................ 37
8.4.4 Actuator diagnostic functions................................................. 44
9 Troubleshooting................................................................................. 48
10 Maintenance...................................................................................... 49
11 Decommissioning............................................................................. 50
11.1 Replace device.......................................................................................... 50
11.2 Disassembly and disposal....................................................................... 50
11.3 Returning devices..................................................................................... 50
12 Technical data.................................................................................... 51
12.1 Dimensional drawing................................................................................ 52
13 Glossary.............................................................................................. 54
14 Annex.................................................................................................. 56
14.1 Teach routine at a glance......................................................................... 56
14.2 Conformities and certificates................................................................... 57
CONTENTS
4O P E R A T I N G I N S T R U C T I O N S | MPS-G with 2/3 switching points and IO-Link (up to 8 switching points) 8028195/2022-11-30 | SICK
Subject to change without notice

1 About this document
1.1 Further information
You can find the product page with further information under the SICK Product ID at:
pid.sick.com/{P/N}.
P/N corresponds to the part number of the product.
The following information is available depending on the product:
•Data sheets
•These publication in all available languages
•CAD files and dimensional drawings
•Certificates (e.g., declaration of conformity)
•Other publications
•Software
•Accessories
1.2 Symbols and document conventions
Warnings and other notes
DANGER
Indicates a situation presenting imminent danger, which will lead to death or serious
injuries if not prevented.
WARNING
Indicates a situation presenting possible danger, which may lead to death or serious
injuries if not prevented.
CAUTION
Indicates a situation presenting possible danger, which may lead to moderate or minor
injuries if not prevented.
NOTICE
Indicates a situation presenting possible danger, which may lead to property damage if
not prevented.
NOTE
Highlights useful tips and recommendations as well as information for efficient and
trouble-free operation.
Instructions to action
bThe arrow denotes instructions to action.
1. The sequence of instructions is numbered.
2. Follow the order in which the numbered instructions are given.
✓The tick denotes the results of an action.
ABOUT THIS DOCUMENT 1
8028195/2022-11-30 | SICK O P E R A T I N G I N S T R U C T I O N S | MPS-G with 2/3 switching points and IO-Link (up to 8 switching points) 5
Subject to change without notice

2 Safety information
2.1 Intended use
The sensor from the MPS-G product family is an intelligent, magnetic position sensor.
It is used for non-contact detection of the piston stroke of pneumatic drives with axially
magnetized permanent magnets.
SICK AG assumes no liability for losses or damage arising from the use of the product,
either directly or indirectly. This applies in particular to use of the product that does not
conform to its intended purpose and is not described in this documentation.
2.2 Improper use
•The sensor does not constitute a safety-relevant device according to the EC Machi‐
nery Directive (2006/42/EC).
•The sensor must not be used in explosion-hazardous areas.
•Any other use that is not described as intended use is prohibited.
•Any use of accessories not specifically approved by SICK AG is at your own risk.
•The sensor is not suitable for outdoor applications.
NOTICE
Danger due to improper use!
Any improper use can result in dangerous situations.
Therefore, take note of the following information:
bThe sensor should be used only in line with intended use specifications.
bAll information in these operating instructions must be strictly complied with.
2.3 Limitation of liability
Applicable standards and regulations, the latest state of technological development,
and our many years of knowledge and experience have all been taken into account
when assembling the data and information contained in these operating instructions.
The manufacturer accepts no liability for damage caused by:
■Failing to observe the operating instructions
■Improper use
■Use by untrained personnel
■Unauthorized conversions
■Technical modifications
■Use of unauthorized spare parts, consumables, and accessories
With special variants, where optional extras have been ordered, or owing to the latest
technical changes, the actual scope of delivery may vary from the features and illustra‐
tions shown here.
2.4 Requirements for skilled persons and operating personnel
WARNING
Risk of injury due to insufficient training.
Improper handling of the sensor may result in considerable personal injury and material
damage.
■All work must only ever be carried out by the stipulated persons.
2 SAFETY INFORMATION
6O P E R A T I N G I N S T R U C T I O N S | MPS-G with 2/3 switching points and IO-Link (up to 8 switching points) 8028195/2022-11-30 | SICK
Subject to change without notice

The operating instructions state the following qualification requirements for the various
areas of work:
■Instructed personnel have been briefed by the operating entity about the tasks
assigned to them and about potential dangers arising from improper action.
■Skilled personnel have the specialist training, skills, and experience, as well as
knowledge of the relevant regulations, to be able to perform tasks assigned to
them and to detect and avoid any potential dangers independently.
■Electricians have the specialist training, skills, and experience, as well as knowl‐
edge of the relevant standards and provisions to be able to carry out work on
electrical systems and to detect and avoid any potential dangers independently. In
Germany, electricians must meet the specifications of the BGVA3 Work Safety
Regulations (e.g.,Master Electrician). Other relevant regulations applicable in
other countries must be observed.
The following qualifications are required for various activities:
Activities Qualification
Mounting, maintenance ■Basic practical technical training
■Knowledge of the current safety regulations in the workplace
Electrical installation,
device replacement
■Practical electrical training
■Knowledge of current electrical safety regulations
■Knowledge of the operation and control of the devices in their
particular application
Commissioning, configura‐
tion
■Basic knowledge of the design and setup of the described
connections and interfaces
■Basic knowledge of data transmission
■Knowledge of the operation and control of the devices in their
particular application
Operation of the devices in
their particular application
■Knowledge of the operation and control of the devices in their
particular application
■Knowledge of the software and hardware environment in the
application
2.5 Hazard warnings and operational safety
Please observe the safety notes and the warnings listed here and in other chapters
of these operating instructions to reduce the possibility of risks to health and avoid
dangerous situations.
2.6 Notes on UL approval
The device must be supplied by a Class 2 source of supply.
UL Environmental Rating: Enclosure type 1
SAFETY INFORMATION 2
8028195/2022-11-30 | SICK O P E R A T I N G I N S T R U C T I O N S | MPS-G with 2/3 switching points and IO-Link (up to 8 switching points) 7
Subject to change without notice

3 Product description
3.1 Product ID
3.1.1 Device view
1
5 6 7
2 3
4
Figure 1: Operating elements and status indicators
1Fixing screw, size 1.3 (Tightening torque MA = 0.1Nm)
2Physical zero position
3Cylinder type marking
(S = SMC/BIMBA/Schunk/PHD; F = FESTO/ZIMMER)
4Sensor head
5Operating element
63 x LED indicators
7Teach-in button
3.2 Product characteristics
3.2.1 Product features
The MPS-G with 2 / 3 digital switching points and IO-Link (up to 8 switching points) is
used either as a magnetic cylinder sensor for non-contact detection of 2 end positions
or intermediate positions (up to 3 individually adjustable switching points in one hous‐
ing) or via IO-Link as a position sensor for non-contact linear position measurement
mainly in pneumatic cylinders, grippers and slides.
When using IO-Link, up to 8 switching points can also be set and additional actuator
diagnostic data can be recorded and output.
•Stroke traveled
•Cycle time
•Dwell time of the piston
•Travel time of the piston
•Average piston velocity
•Current measured field strength
•Maximum measured field strength
•Cycle count
•Total distance traveled by the piston
•Operating hours
•Power-on/power-off cycles
3 PRODUCT DESCRIPTION
8O P E R A T I N G I N S T R U C T I O N S | MPS-G with 2/3 switching points and IO-Link (up to 8 switching points) 8028195/2022-11-30 | SICK
Subject to change without notice

A description of the diagnostic functions can be found in section 8.4.4.
Target application
•Double end position detection via 2 digital switching points
→ Substitute for two individual cylinder switches
•Detection of 3 positions via 3 digital switching points, e.g. for gripper process
(open without object / object gripped / closed without object)
→ Substitute for three individual cylinder switches
•Position measurement for short stroke in systems with IO-Link
•Detection of 8 positions via 8 switching points, e.g. for gripper process (gripping of
objects of different sizes)
Mechanical standard variants
The mechanical standard variants differ in the geometry of the sensor head, the length
of the connection cable between the head and control panel, the length of the connect‐
ing cable between the control panel and connection and in the connection.
1 2 3 4
Q2
PWR
Q1
Figure 2: MPS-G structure
1Sensor head:
Festo slot (F)
SMC slot (S)
2Head / Control panel connection cable
3Sensor connecting cable
4Sensor connection
Table 1: Mechanical variants
Part number Type desig‐
nation
Sensor
head
Connec‐
tion
cable
Functional scope
(output)
Connecting cable
1127842 MPS-G50 ... F 0.1m 2/3Q and IO-Link 0.5m, M8 knurled screw
1127843 MPS-G50 ... S 0.1m 2/3Q and IO-Link 0.5m, M8 knurled screw
1127844 MPS-G50 ... S 0.5m 2/3Q and IO-Link 0.5m, M8 knurled screw
1127845 MPS-G50 ... F 0.1m 2/3Q and IO-Link 0.3m, M12
1127846 MPS-G50 ... S 0.1m 2/3Q and IO-Link 0.3m, M12
1127847 MPS-G50 ... S 0.5m 2/3Q and IO-Link 0.3m, M12
3.3 Operating principle
3.3.1 Principle of operation
The MPS-G determines the position of an encoder magnet via a row of 2 sensor
elements located in the sensor head.
Axially and diametrically magnetized magnets can be detected since the two sensor
elements measure the field strength in both the X- and Y-direction.
PRODUCT DESCRIPTION 3
8028195/2022-11-30 | SICK O P E R A T I N G I N S T R U C T I O N S | MPS-G with 2/3 switching points and IO-Link (up to 8 switching points) 9
Subject to change without notice

y y
xx
y y
xx
1
2
3
1
2
4
m
m
y (radial)
x (axial)
1Sensor element 1
2Sensor element 2
3Axially magnetized magnet
4Diametrically magnetized magnet
3.3.2 Detection range
The sensor is designed for a detection range of 50mm. The zero point / physical
zero position is marked with arrows on the sensor head and is located roughly at the
center point of the sensor. From the zero point, -25mm are measured to the cable and
+25mm to the fixing screw.
50 (1.97)
25.3 (1.00)
0- 25 (0.98)+ 25 (0.98)
1
2
3
Figure 3: Detection range
1Detection range
2Housing length
3Zero point / physical zero position
3.3.3 Position output
The sensor can output a linearized position in a detection range of approx. 50mm
(depends on the drive).
Via IO-Link, the detection range of 50mm (-25mm ... 25mm) corresponds to 5,000
digits (-2,500digits ... 2,500digits). I.e. 1 digit corresponds to 10µm.
When leaving the detection range, the value 32,760 or -32,760 digits1) is displayed.
If the field strength is no longer sufficient, 32764 is output as per the Smart Sensor
profile.
1) 1digit corresponds to 10µm.
3 PRODUCT DESCRIPTION
10 O P E R A T I N G I N S T R U C T I O N S | MPS-G with 2/3 switching points and IO-Link (up to 8 switching points) 8028195/2022-11-30 | SICK
Subject to change without notice

0
-32760
32760
1
32
4
5
6
Figure 4: Zero point / physical zero position
1Zero point / physical zero position
2Positive positions
3Negative positions
4Sensor detection range: 2,500 digits ... -2,500 digits
5Piston position
6Sensor position output
3.3.4 Switching behavior after Manual Teach of up to 3 switching points
Switching behavior after Manual Teach is as follows per switching point during operation:
PRODUCT DESCRIPTION 3
8028195/2022-11-30 | SICK O P E R A T I N G I N S T R U C T I O N S | MPS-G with 2/3 switching points and IO-Link (up to 8 switching points) 11
Subject to change without notice

1
1
Qint.SP1
+ 25 mm
OFF
ON
OFF
OFF
ON
OFF
+ 25 mm
– 25 mm
– 25 mm
ON ON OFF OFF
OFF OFF
ONON
Qint.SP1
2 3 2
2 3 2
Figure 5: Switching behavior after Manual Teach
1Direction of movement of the magnet
2Hysteresis
3Width of the switching point
There is no Dynamic Pilot during manual teach-in of the switching points. The switching
point width is 2mm according to the factory setting and can be adjusted via the Teach
menu (1 – 5mm).
3.3.5 Switching behavior after Dynamic Teach of 2 switching points
If the sensor, during Dynamic Teach, detects teach 2 x piston status v = 0, 2 switching
points are set.
NOTE
The dynamic teach-in and the dynamic pilot only start working from a speed of v
>0.025m/s.
Example: Arrangement of switching points for dynamic teach-in of 2 switching points
on a pneumatic cylinder
The 2 switching points are always arranged as follows during dynamic teach-in: Qint1
lies in the direction of the cable connection and Qint2 in the direction of the sensor
fixing screw. It does not matter which position is approached first.
3 PRODUCT DESCRIPTION
12 O P E R A T I N G I N S T R U C T I O N S | MPS-G with 2/3 switching points and IO-Link (up to 8 switching points) 8028195/2022-11-30 | SICK
Subject to change without notice

Table 2: Switching behavior with 2 switching points
1.) Output position v= 0.
No switching point is
defined at the output posi‐
tion of the magnet.
v = 0
2.) Movement in the direc‐
tion of the sensor fixing
screw
3.) First stop: First posi‐
tion is defined for switching
point
1. Stop
v = 0
4.) Movement in the direc‐
tion of the cable side
1. Stop
5.) Second stop: Second
position for switching point
and arrangement of Qint2
(see fixing screw) and
Qint1 (cable set) are
defined
1. Stop:
Qint 2
2. Stop:
Qint 1
v = 0
Switching behavior after Dynamic Teach of 2 switching points is the following during
operation:
PRODUCT DESCRIPTION 3
8028195/2022-11-30 | SICK O P E R A T I N G I N S T R U C T I O N S | MPS-G with 2/3 switching points and IO-Link (up to 8 switching points) 13
Subject to change without notice

ON
Qint2
OFF
v = 0 v ≠ 0
v = 0
or
v ≠ 0 v ≠ 0 v ≠ 0 v = 0
Qint2
ON
Qint
OFF
Qint
OFF
Qint1
ON
Qint1
ON
Qint1
ON
ON
OFF
Qint1
ON
Qint2
OFF
v = 0 v ≠ 0 v ≠ 0
v = 0
or
v ≠ 0 v ≠ 0 v = 0
Qint2
ON
Qint2
ON
Qint2
ON
Qint
OFF
Qint1
ON
Qint1
ON
ON
OFF
Qint1
v = 0
or
v ≠ 0
Qint
OFF
1
2 3 23
4
5 6
4
2 3 23
5 6
Figure 6: Overview
1Max. range of movement of drive
2Tolerance
3Hysteresis
4Direction of movement of the magnet
5End position in the direction of the fixing screw
6End position in the direction of the cable connection
ON
Qint2
OFF
v = 0 v ≠ 0
v = 0
or
v ≠ 0 v ≠ 0 v ≠ 0 v = 0
Qint2
ON
Qint
OFF
Qint
OFF
Qint1
ON
Qint1
ON
Qint1
ON
ON
OFF
Qint1
1
2 3 23
4
5 6
Figure 7: Movement in the direction of the fixing screw
3 PRODUCT DESCRIPTION
14 O P E R A T I N G I N S T R U C T I O N S | MPS-G with 2/3 switching points and IO-Link (up to 8 switching points) 8028195/2022-11-30 | SICK
Subject to change without notice

ON
Qint2
OFF
ON
OFF
Qint1
v = 0 v ≠ 0 v ≠ 0
v = 0
or
v ≠ 0 v ≠ 0 v = 0
Qint2
ON
Qint2
ON
Qint2
ON
Qint
OFF
Qint1
ON
Qint1
ON
v = 0
or
v ≠ 0
Qint
OFF
1
2 3 23
4
5 6
Figure 8: Movement in the direction of the cable connection
3.3.6 Switching behavior after Dynamic Teach of 3 switching points
If the sensor, during Dynamic Teach, detects teach 3 x piston status v = 0, 3 switching
points are set.
Example: Arrangement of switching points for dynamic teach-in of 3 switching points
on a pneumatic internal or external gripper
The switching points are assigned as follows:
Qint1 = idle
Qint2 = object
Qint3 = noobject
The assignment of the idle and no object states to gripper open or gripper closed
depends on the gripper type:
1. External gripper:
Table 3: External gripper
Gripper open
without object
idle
Gripper closed
with object
object
Gripper open
without object
idle
Gripper closed
without object
noobject
Gripper open
without object
idle
v = 0
v = 0
1. Stop
v = 0
1. Stop
2. Stop
v = 0 1. Stop
2. Stop
3. Stop
v = 0
Qint 2
Qint 1
Qint 3
PRODUCT DESCRIPTION 3
8028195/2022-11-30 | SICK O P E R A T I N G I N S T R U C T I O N S | MPS-G with 2/3 switching points and IO-Link (up to 8 switching points) 15
Subject to change without notice

No switching
point is defined
on the output
position of the
magnet
First position is
defined for
switching point
Second position
is defined for
switching point
Third position is
defined for
switching point
Switching points
are assigned to
the positions
After the teach-in process, the Qints are assigned as follows:
•Qint1 gripper open without object (idle)
•Qint2 gripper closed with object (object)
•Qint3 gripper closed without object (noobject)
2. Internal gripper:
Table 4: Internal gripper
Gripper open with
object
Gripper closed
without object
idle
Gripper open
without object
noobject
Gripper closed
without object
idle
Gripper open with
object
object
v = 0
1. Stop
v = 0
2. Stop
1. Stop
v = 0
2. Stop
1. Stop
v = 0
3. Stop: Qint 2
2. Stop: Qint 3
1. Stop: Qint 1
No switching
point is defined
on the output
position of the
magnet
First position is
defined for
switching point
Second position
is defined for
switching point
First position is
already defined
and is not saved
again
Third position is
defined for
switching point.
After the teach-in process, the Qints are assigned as follows:
•Qint1 gripper closed without object (idle)
•Qint2 gripper open with object (object)
•Qint3 gripper open without object (noobject)
Switching behavior after Dynamic Teach of 3 switching points is the following during
operation:
3 PRODUCT DESCRIPTION
16 O P E R A T I N G I N S T R U C T I O N S | MPS-G with 2/3 switching points and IO-Link (up to 8 switching points) 8028195/2022-11-30 | SICK
Subject to change without notice

ON
Qint3 Qint2
OFF
v = 0 v ≠ 0
v = 0
or
v ≠ 0
v = 0
or
v ≠ 0 v ≠ 0 v ≠ 0 v = 0
Qint2
ON
Qint2
OFF
Qint
OFF
Qint
OFF
Qint1
ON
Qint1
ON
Qint1
ON
ON
OFF
Qint1
ON
Qint3 Qint2
OFF
v = 0 v ≠ 0 v ≠ 0
v = 0
or
v ≠ 0 v ≠ 0 v = 0
Qint2
ON
Qint2
ON
Qint2
ON
Qint
OFF
Qint
OFF
Qint1
OFF
Qint1
ON
ON
OFF
Qint1
v = 0
or
v ≠ 0
ON
Qint3 Qint2
OFF
v ≠ 0 v ≠ 0
v = 0
or
v ≠ 0
Qint
OFF
Qint
OFF
Qint
OFF
Qint1
ON
ON
OFF
Qint1
v ≠ 0
v = 0
Qint3
ON
v ≠ 0
Qint
OFF
v = 0
or
v ≠ 0
Qint
OFF
v = 0
or
v ≠ 0
Qint
OFF
v = 0
or
v ≠ 0
Qint
OFF
Qint1
ON
v ≠ 0
Qint1
ON
v = 0
ON
Qint3 Qint2
OFF
v ≠ 0 v = 0
v = 0
or
v ≠ 0
Qint
OFF
Qint
OFF
Qint
OFF
ON
OFF
Qint1
v = 0
Qint3
ON
v ≠ 0
Qint3
ON
Qint3
ON
v = 0
or
v ≠ 0
Qint
OFF
Qint
OFF
Qint
OFF
v ≠ 0
Qint1
ON
v = 0
v ≠ 0 v ≠ 0
v = 0
or
v ≠ 0
Qint
OFF
1
2
4
3 2 3 23
5 6
7
5 6
2
4
3 2 3 23
5 6
7
5 6
2
4
323 23
56
7
4 6
2
4
3 2 3 23
56
7
4 6
Figure 9: Overview
1Max. range of movement of drive
2Tolerance
3Hysteresis
4no object
5object
6idle
7Direction of movement of the magnet
PRODUCT DESCRIPTION 3
8028195/2022-11-30 | SICK O P E R A T I N G I N S T R U C T I O N S | MPS-G with 2/3 switching points and IO-Link (up to 8 switching points) 17
Subject to change without notice

ON
Qint3 Qint2
OFF
v = 0 v ≠ 0
v = 0
or
v ≠ 0
Qint2
ON
Qint2
OFF
Qint
OFF
Qint1
ON
ON
OFF
Qint1
Qint
OFF
Qint1
ON
v ≠ 0
Qint1
ON
v = 0
v = 0
or
v ≠ 0 v ≠ 0
1
2
4
3 2 3 23
5 6
7
6
5
Figure 10: Movement from idle to object
ON
Qint3 Qint2
OFF
v = 0 v ≠ 0
v = 0
or
v ≠ 0
Qint2
ON
Qint2
ON
Qint
OFF
ON
OFF
Qint1
Qint1
OFF
v ≠ 0
Qint1
ON
v = 0
v ≠ 0
Qint2
ON
v = 0
or
v ≠ 0
Qint
OFF
1
2
4
3 2 3 23
5 6
7
6
5
Figure 11: Movement from object to idle
3 PRODUCT DESCRIPTION
18 O P E R A T I N G I N S T R U C T I O N S | MPS-G with 2/3 switching points and IO-Link (up to 8 switching points) 8028195/2022-11-30 | SICK
Subject to change without notice

ON
Qint3 Qint2
OFF
v ≠ 0 v ≠ 0
v = 0
or
v ≠ 0
Qint
OFF
Qint
OFF
Qint
OFF
Qint1
ON
ON
OFF
Qint1
v ≠ 0
v = 0
Qint3
ON
v ≠ 0
Qint
OFF
v = 0
or
v ≠ 0
Qint
OFF
v = 0
or
v ≠ 0
Qint
OFF
v = 0
or
v ≠ 0
Qint
OFF
Qint1
ON
v ≠ 0
Qint1
ON
v = 0
1
2
4
3 2 3 23
5 6
7
46
Figure 12: Movement from idle to no object
ON
Qint3 Qint2
OFF
v ≠ 0 v = 0
v = 0
or
v ≠ 0
Qint
OFF
Qint
OFF
Qint
OFF
Qint
OFF
ON
OFF
Qint1
v = 0
Qint3
ON
v ≠ 0
Qint3
ON
v = 0
or
v ≠ 0
Qint
OFF
Qint
OFF
Qint
OFF
v ≠ 0
Qint1
ON
v = 0
v ≠ 0
Qint3
ON
v ≠ 0
v = 0
or
v ≠ 0
1
2
4
3 2 3 23
5 6
7
46
Figure 13: Movement from no object to idle
PRODUCT DESCRIPTION 3
8028195/2022-11-30 | SICK O P E R A T I N G I N S T R U C T I O N S | MPS-G with 2/3 switching points and IO-Link (up to 8 switching points) 19
Subject to change without notice

4 Transport and storage
4.1 Transport
For your own safety, please read and observe the following notes:
NOTE
Damage to the sensor due to improper transport.
■The device must be packaged for transport with protection against shock and
damp.
■Transport should be performed by specialist staff only.
■The utmost care and attention is required at all times during unloading and
transportation on company premises.
■Note the symbols on the packaging.
■Do not remove packaging until immediately before you start mounting.
4.2 Transport inspection
Immediately upon receipt at the receiving work station, check the delivery for complete‐
ness and for any damage that may have occurred in transit. In the case of transit
damage that is visible externally, proceed as follows:
■Do not accept the delivery or only do so conditionally.
■Note the scope of damage on the transport documents or on the transport compa‐
ny’s delivery note.
■File a complaint.
NOTE
Complaints regarding defects should be filed as soon as these are detected. Damage
claims are only valid before the applicable complaint deadlines.
4.3 Storage
Store the device under the following conditions:
■Recommendation: Use the original packaging.
■Do not store outdoors.
■Store in a dry area that is protected from dust.
■To allow any residual dampness to evaporate, do not package in airtight contain‐
ers.
■Do not expose to any aggressive substances.
■Protect from sunlight.
■Avoid mechanical shocks.
■Storage temperature: see "Technical data", page 51.
■Relative humidity see "Technical data", page 51.
■Do not expose to strong magnetic fields.
4 TRANSPORT AND STORAGE
20 O P E R A T I N G I N S T R U C T I O N S | MPS-G with 2/3 switching points and IO-Link (up to 8 switching points) 8028195/2022-11-30 | SICK
Subject to change without notice
