SICK RMS3 Series User manual

OPERATING INSTRUCTIONS
RMS3xx
Radar sensors

Described product
RMS3xx
Manufacturer
SICK AG
Erwin-Sick-Str. 1
79183 Waldkirch
Germany
Legal information
This work is protected by copyright. Any rights derived from the copyright shall be
reserved for SICK AG. Reproduction of this document or parts of this document is only
permissible within the limits of the legal determination of Copyright Law. Any modifica‐
tion, abridgment or translation of this document is prohibited without the express writ‐
ten permission of SICK AG.
The trademarks stated in this document are the property of their respective owner.
© SICK AG. All rights reserved.
Original document
This document is an original document of SICK AG.
2O P E R A T I N G I N S T R U C T I O N S | RMS3xx 8021530/ZZN3/2018-06-14 | SICK
Subject to change without notice

Contents
1 About this document........................................................................ 5
1.1 Information on the operating instructions.............................................. 5
1.2 Explanation of symbols............................................................................ 5
2 Safety information............................................................................ 6
2.1 Intended use............................................................................................. 6
2.2 Improper use............................................................................................. 6
2.3 Limitation of liability................................................................................. 7
2.4 Modifications and conversions................................................................ 7
2.5 Requirements for skilled persons and operating personnel.................. 7
2.6 Operational safety and particular hazards.............................................. 8
3 Product description........................................................................... 10
3.1 Scope of delivery....................................................................................... 10
3.2 Status indicators....................................................................................... 10
4 Transport and storage....................................................................... 12
4.1 Transport................................................................................................... 12
4.2 Unpacking.................................................................................................. 12
4.3 Transport inspection................................................................................. 12
4.4 Storage...................................................................................................... 12
5 Mounting............................................................................................. 13
5.1 Mounting instructions............................................................................... 13
6 Electrical installation........................................................................ 14
6.1 Wiring notes.............................................................................................. 14
6.2 Connection diagram................................................................................. 15
6.3 Connecting the device electrically........................................................... 15
7 Operation............................................................................................ 17
7.1 General advice.......................................................................................... 17
7.2 Switching on / Switching off..................................................................... 17
7.3 Operation via SOPAS ET........................................................................... 17
8 Maintenance...................................................................................... 22
8.1 Maintenance............................................................................................. 22
9 Troubleshooting................................................................................. 23
9.1 General faults, warnings, and errors....................................................... 23
9.2 Repairs...................................................................................................... 23
9.3 Returns...................................................................................................... 23
9.4 Disposal..................................................................................................... 24
10 Technical data.................................................................................... 25
CONTENTS
8021530/ZZN3/2018-06-14 | SICK O P E R A T I N G I N S T R U C T I O N S | RMS3xx 3
Subject to change without notice

10.1 Features.................................................................................................... 25
10.2 Performance............................................................................................. 26
10.3 Interfaces.................................................................................................. 26
10.4 Mechanics/electronics............................................................................. 27
10.5 Ambient data............................................................................................. 28
11 Accessories........................................................................................ 29
12 Annex.................................................................................................. 30
12.1 EU declaration of conformity / Certificates............................................. 30
12.2 Licenses.................................................................................................... 30
CONTENTS
4O P E R A T I N G I N S T R U C T I O N S | RMS3xx 8021530/ZZN3/2018-06-14 | SICK
Subject to change without notice

1 About this document
1.1 Information on the operating instructions
These operating instructions provide important information on how to use devices from
SICK AG.
Prerequisites for safe work are:
•Compliance with all safety notes and handling instructions supplied.
•Compliance with local work safety regulations and general safety regulations for
device applications
The operating instructions are intended to be used by qualified personnel and electrical
specialists.
NOTE
Read these operating instructions carefully before starting any work on the device, in
order to familiarize yourself with the device and its functions.
The instructions constitute an integral part of the product and are to be stored in the
immediate vicinity of the device so they remain accessible to staff at all times. Should
the device be passed on to a third party, these operating instructions should be handed
over with it.
These operating instructions do not provide information on operating the machine or
system in which the device is integrated. For information about this, refer to the operat‐
ing instructions of the specific machine.
1.2 Explanation of symbols
Warnings and important information in this document are labeled with symbols. The
warnings are introduced by signal words that indicate the extent of the danger. These
warnings must be observed at all times and care must be taken to avoid accidents, per‐
sonal injury, and material damage.
DANGER
… indicates a situation of imminent danger, which will lead to a fatality or serious
injuries if not prevented.
WARNING
… indicates a potentially dangerous situation, which may lead to a fatality or serious
injuries if not prevented.
CAUTION
… indicates a potentially dangerous situation, which may lead to minor/slight injuries if
not prevented.
NOTICE
… indicates a potentially harmful situation, which may lead to material damage if not
prevented.
NOTE
… highlights useful tips and recommendations as well as information for efficient and
trouble-free operation.
ABOUT THIS DOCUMENT 1
