SICK MCS300P Manual

TECHNICAL INFORMATION
Title Page
These Instructions are intended exclusively
for trained personnel.
Unauthorized intervention voids the manu-
facturer's warranty.
Operating for Service Technicians
Technical Details
MCS300P
Multicomponent Analysis System

2 MCS300P · Technical Information · 8013265 V1-2 · © SICK AG
Document Information
Described Product
Product name MCS300P, MCS300P-Ex
Document Identification
Title: Technical Information MCS300P
Part No.: 8013265
Version: 1-2
Release: 2013-08
Manufacturer
SICK AG
Erwin-Sick-Str. 1 · D-79183 Waldkirch · Germany
Phone: [phone]
Fax: [phone]
E-mail: [e-mail]
Original document
The English edition 8013265 of this document is an original docu-
ment of SICK AG.
SICK AG assumes no liability for the correctness of an unauthor-
ized translation.
In case of doubt, contact SICK AG or your local representative.
Legal information
Subject to change without notice.
© SICK AG. All rights reserved.

MCS300P · Technical Information · 8013265 V 1-2 · © SICK AG 3
Warning Symbols
Warning Levels / Signal Words
DANGER
Risk or hazardous situation which will result in severe personal
injury or death.
WARNING
Risk or hazardous situation which could result in severe personal
injury or death.
CAUTION
Hazard or unsafe practice which could result in less severe or
minor injuries and/or property damage.
NOTICE
Hazard which could result in property damage.
Information Symbols
Hazard (general)
Hazard by voltage
Hazard by explosive substances/mixtures
Hazard by corrosive substances
Hazard by toxic substances
Hazard by unhealthy substances
Hazard by high temperature or hot surface
Important technical information for this device
Important information on electric or electronic func-
tions
Supplementary information
Link to information at another place

Contents
4 MCS300P · Technical Information · 8013265 V1-2 · © SICK AG
1 Important Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
1.1 Validity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
1.2 Responsibility of user. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
1.2.1 Designated users . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
1.2.2 Special local conditions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
2 Product Description. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
2.1 Functional principle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
2.2 SOPAS ET (PC program) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
2.2.1 Modbus-TCP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
2.2.2 OPC (option) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
2.3 Circuit board. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
3Operation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
3.1 SOPAS ET (Description) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
3.1.1 Changing the user level . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
3.1.2 Grayed out fields - input not possible . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
3.1.3 Using menus with assignments and calculations. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
3.2 Menu tree (in SOPAS ET) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
3.3 Measuring Screen. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
3.3.1 Measuring Screen 1 .. x . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
3.3.1.1 Scaling the Measuring Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
3.4 Diagnosis . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
3.4.1 Control value . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
3.4.1.1 Zero drift. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
3.4.1.2 Reference energy . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
3.4.1.3 Intensity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
3.4.2 Sensor values . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
3.4.2.1 Temperatures . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
3.4.2.2 Hardware . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
3.4.3 Signals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
3.4.3.1 Measuring signals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
3.4.3.2 Digital signals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
3.4.3.3 Analog signals. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
3.4.3.4 Real values . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
3.4.3.5 Integer and filtered values . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
3.4.4 Logbook . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
3.4.5 System status . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
3.4.6 System information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Contents

Contents
MCS300P · Technical Information · 8013265 V 1-2 · © SICK AG 5
3.5 Parameterization . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
3.5.1 Measuring components. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
3.5.1.1 Global definitions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
3.5.1.2 Definition measuring components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
3.5.2 Measuring screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
3.5.2.1 Measuring box . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
3.5.2.2 Bargraph . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
3.5.2.3 Line writer. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
3.5.3 I/O . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
3.5.3.1 Addressing system . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
3.5.3.2 Hardware map . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
3.5.3.3 Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
3.5.4 Variables and Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
3.5.4.1 Timer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
3.5.4.2 Cyclic trigger (CTi) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
3.5.5 Formulas . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .35
3.5.6 Temperature control. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
3.5.7 Logbook. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
3.5.8 Instrument display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
3.5.9 System parameter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
3.5.10 Modbus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
3.6 Adjustment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
3.6.1 Parameter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .38
3.6.1.1 Concentration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
3.6.1.2 Adjustment factors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
3.6.1.3 Start times . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
3.6.2 Manual adjustment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
3.6.3 Automatic adjustment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
3.7 Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .40
3.7.1 Tests . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
3.7.2 Operating states . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
3.7.3 Hardware reset . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
3.7.4 Reset messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
3.7.5 Service log . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
3.8 Tags (identifiers) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42

Contents
6 MCS300P · Technical Information · 8013265 V1-2 · © SICK AG

Important Information
MCS300P · Technical Information · 8013265 V 1-2 · © SICK AG 7
Subject to change without notice
MCS300P
1Important Information
Main hazards
Main instructions for operation
Own responsibility

8 MCS300P · Technical Information · 8013265 V1-2 · © SICK AG
Important Information
Subject to change without notice
1.1 Validity
1.2 Responsibility of user
1.2.1 Designated users
This Technical Information is aimed at qualified persons familiar with the MCS300P and
who, based on their device-specific training and knowledge of the device as well as knowl-
edge of the relevant regulations, can assess the tasks given and recognize the dangers
involved.
1.2.2 Special local conditions
Follow all local laws, regulations and company-internal operating directives applicable at
the respective installation location of the equipment.
This Manual is valid for the MCS300P and MCS300P-Ex.
It is only valid in combination with the "Operating Instructions MCS300P" or
"Operating Instructions MCS300P-Ex".

Product Description
MCS300P · Technical Information · 8013265 V 1-2 · © SICK AG 9
Subject to change without notice
MCS300P
2Product Description
Functional principle
Characteristics

10 MCS300P · Technical Information · 8013265 V1-2 · © SICK AG
Product Description
Subject to change without notice
2.1 Functional principle
MCS300P is a non-dispersive process photometer.
Fig. 1 Beam path
●Depending on the device type, the radiation source used is an IR or VIS radiator.
●The measuring beam goes through the sample cell and is specifically absorbed
depending on the sample gas composition.
●Interference and gas filters swiveled into the beam path on filter wheels select the
measurement wavelength.
●The detector receives the successive measurement and reference radiation.
– With the measuring filter swiveled in, the signal depends on the sample gas compo-
sition.
– With the reference filter swiveled in, a concentration-independent signal is gener-
ated.
By computation of both signals, the MCS300P determines the measured variable
"absorption” which is then, to a wide extent, independent from the changes of the opti-
cal characteristics of the photometer.
After correction of possible disturbance variables, the determined absorption is con-
verted to the concentration value via the linearization function.
●As an option, a filter wheel with an internal adjustment standard is available which sim-
ulates a test with a test medium.
Source Chopper Cell Filter wheels with
measuring filters
Detector
Filter wheel with
adjustment standard

Product Description
MCS300P · Technical Information · 8013265 V 1-2 · © SICK AG 11
Subject to change without notice
2.2 SOPAS ET (PC program)
SOPAS ET can be used to set the MCS300P parameters and provides access to the
MCS300P logbook.
SOPAS ET runs on an external PC connected via the Ethernet interface to the MCS300P
(MCS300P Operating Instructions).
2.2.1 Modbus-TCP
Modbus®is a communication standard for digital controls to connect a »Master« device
with several »Slave« devices. The Modbus protocol defines the communication commands
only but not their electronic transfer; therefore it can be used with different digital inter-
faces (for MCS300P: Ethernet).
Configuration: →p. 30, §3.5.3.3
2.2.2 OPC (option)
OPC is a standardized software interface that allows to exchange data between different
applications.
The SICK OPC server (part of SOPAS ET) is required.
System bus: Ethernet.
Configuration: →p. 30, §3.5.3.3

12 MCS300P · Technical Information · 8013265 V1-2 · © SICK AG
Product Description
Subject to change without notice
2.3 Circuit board
Electrical connections on the circuit board in the sender unit
Fig. 2 Electrical connections in the sender unit
Pt100
Line: AWG26-15
Controller 2 limiter
Controller 1 limiter
Controller 2
Controller 1 (cell)
Heaters
Output voltage as mains voltage
Capacity: Max. 550 VA (per output)
Line: AWG24-12
Heater Line Pin
Heater 1
(cell)
L1 4
N5
PE 6
Heater 2 L1 7
N8
PE 9
CAN Line
CAN1
(internal)
ISOGND
LOW
HIGH
CAN2
External I/O
ISOGND
LOW
HIGH

Operation
MCS300P · Technical Information · 8013265 V 1-2 · © SICK AG 13
Subject to change without notice
MCS300P
3Operation
Configuration
Advanced operation
Adjustments

14 MCS300P · Technical Information · 8013265 V1-2 · © SICK AG
Operation
Subject to change without notice
3.1 SOPAS ET (Description)
Operator menus and measured value displays are also available on an external PC via Eth-
ernet for user comfort (with the engineering tool SOPAS ET).
The SICK Open Portal for Applications and Systems (SOPAS) is an engineering tool for com-
munication with analyzers and sensors.
SOPAS is based on the following techniques:
●Device communication via Ethernet (TCP/IP).
●A common engineering tool for the various product lines.
●Universal device description file as the data source for all relevant device data and
parameters required for communication and display.
3.1.1 Changing the user level
In SOPAS ET
1Click: Authorized Operator in the dialog window in SOPAS ET
2Enter the password.
3.1.2 Grayed out fields - input not possible
Displays in grayed out fields cannot be changed.
3.1.3 Using menus with assignments and calculations
Example: Menu: MCS300P/Parameterization/I/O/Data/Digital outputs
(The bottom lines of the example depend on the menu)
SOPAS ET is on the CD-ROM enclosed with the MCS300P.
User level Password
Authorized operator HIDE[1]
[1] Upper case mandatory
Entry field Significance
Save Store current entries
Mark Create group
▸ Click "Mark" and then click the desired lines.
▸ To cancel "Mark":
Click "Mark" again and then click on an empty line.
Edit For editable menus: Call up the Settings menu for the line
▸ Click the desired line. Then click "Edit".
Show For non-editable menus: display settings for the line.
▸ Click the desired line. Then click "Show".
Copy Copy marked lines
Replace Insert copied lines before a marked line.
Next Call up the "Next function group".

Operation
MCS300P · Technical Information · 8013265 V 1-2 · © SICK AG 15
Subject to change without notice
3.2 Menu tree (in SOPAS ET)
Menu Reference
Measuring screen →p. 17, §3.3
Measuring Screen xx
Diagnosis →p. 20, §3.4
Control values →p. 20, §3.4.1
Zero drift
Reference display
Intensity
Sensor values →p. 21, §3.4.2
Temperatures
Hardware
Signals →p. 22, §3.4.3
Measuring signals
Digital signals
Analog signals
Real values
Integer and filtered values
Logbook →p. 23, §3.4.4
System status →p. 24, §3.4.5
System information →p. 24, §3.4.6
Parameterization →p. 25, §3.5
Measuring components →p. 25, §3.5.1
Global definitions
Definition measured value components
Measuring component xx
Measuring screen →p. 26, §3.5.2
Measured value xx
I/O →p. 29, §3.5.3
Hardware map
CAN Bus address 0..3 (N1 .. N2)
Data
OPC outputs (OPCOi)
Modbus outputs (MBOi)
Modbus inputs (MBIi)
Digital inputs (DIi)
Digital outputs (DOi)
Analog inputs (AIi)
Analog outputs (AOi)
Variables and Functions →p. 32, §3.5.4
Timer
Stop watches (SWi)
Cyclic trigger (CTi)
Limit values (LIi)
Real values (RVi)
Real constants (RCi)
Integer values (IVi)
Boolean values (BVi)
Filtered values (FVi)
Formulas →p. 35, §3.5.5
Temperature control →p. 35, §3.5.6
Logbook →p. 35, §3.5.7
Instrument display →p. 36, §3.5.8
System parameter →p. 36, §3.5.9
Modbus →p. 37, §3.5.10
Adjustment →p. 38, §3.6
Parameter →p. 38, §3.6.1
Concentration
Adjustment factors

16 MCS300P · Technical Information · 8013265 V1-2 · © SICK AG
Operation
Subject to change without notice
Start times
Manual adjustment →p. 39, §3.6.2
Automatic adjustment →p. 39, §3.6.3
Maintenance →p. 40, §3.7
Tests →p. 40, §3.7.1
Digital inputs
Digital outputs
Analog inputs
Analog outputs
Operating states →p. 40, §3.7.2
Hardware Reset →p. 41, §3.7.3
Reset messages →p. 41, §3.7.4
Service log →p. 41, §3.7.5
Menu Reference

Operation
MCS300P · Technical Information · 8013265 V 1-2 · © SICK AG 17
Subject to change without notice
3.3 Measuring Screen
Menu: Measuring
3.3.1 Measuring Screen 1 .. x
Menu: Measuring/Measuring Screen 1 .. x
Depending on the parameters set, the Measuring Screen is shown as measuring box, bar
graph or line writer.
Measuring box
The measured values are shown numerically in the measuring box.
Bar graph
The measured values are shown as a graphic bar in the bar graph.
Parameter settings of Measuring Screens: →p. 26, §3.5.2
Scaling of Measuring Screens: →p. 19, §3.3.1.1
Only the Measuring Screens are shown for which parameters have
been set.
▸ Double-click the desired Measuring Screen.
Component
Unit
Measured value
Component Measured value Unit

18 MCS300P · Technical Information · 8013265 V1-2 · © SICK AG
Operation
Subject to change without notice
Line writer and data storage
The measured values are shown numerically as measuring box and as time diagram in the
line writer.
Data memory functions
▸ Start:
Start data storage.
The data for which parameters have been set are saved (independent from the graphic
representation) (→p. 28, §3.5.2.3).
Max. 65536 entries per curve are saved in a file, afterwards a new file (with ascending
index) is automatically created.
▸ A dialog field to enter a target file (.txt) is displayed
The following is shown above the line diagram:
▸ Stop:
Stop recording.
▸ View:
View the recorded data.
A dialog field to select the file with the saved values is shown.
The following is then shown above the line diagram:
▸ Reset:
Delete all shown lines (no effect on data storage).
Measuring box
Line writer
The measured values that
have been activated are
shown (→p. 19, §3.3.1.1).
The line writer starts with the
representation only when the
display is called up for the
first time.
Changing the user level
deletes the history of the line
display.

Operation
MCS300P · Technical Information · 8013265 V 1-2 · © SICK AG 19
Subject to change without notice
3.3.1.1 Scaling the Measuring Screen
Touch the screen to display a scaling screen:
▸ Font color (The colors of the line writer are predefined)
▸ Precision of Measuring Screen
Example:
-2: 123.45
-1: 1234.5
0: 12345
1: 123450
▸ Scale start value
▸ Scale end value
(line diagram: for y-axis)
▸ Display of lines active / not active
(for line writer)

20 MCS300P · Technical Information · 8013265 V1-2 · © SICK AG
Operation
Subject to change without notice
3.4 Diagnosis
3.4.1 Control value
3.4.1.1 Zero drift
Menu: Diagnosis/Control values/Zero drift
3.4.1.2 Reference energy
Menu: Diagnosis/Control values/Reference energy
3.4.1.3 Intensity
Menu: Diagnosis/Control values/Intensity
The intensities (energies) and amplification levels of the measured components are shown
in this menu.
Leave the evaluation of this information to SICK Customer Service.
The zero drift since the last "Reset” of the zero
drift (e.g., during maintenance) is shown and
reset in this menu.
The zero drift is recalculated during each zero
adjustment and displayed in Absorption.
This value can be used for system diagnosis.
Typical cause: Decrease in lamp energy, contami-
nation of cell windows.
▸ Reset the zero drift
The current reference energy (in percent) is
shown and reset in this menu.
This value is monitored automatically. If the value
is below a limit value (default: 60%), the
MCS300P switches to the "Maintenance request”
classification.
Typical cause: Contamination of the cell windows.
▸ Reset the reference energy
