SINAMICS
SINAMICS G120
CU240B-2 and CU240E-2 Control
Units
Compact Operating Instructions
Edition 01/2017
01/2017
A5E39910322B AA
Fundamental safety
instructions
1
Scope of delivery
2
Installing
3
Commissioning
4
More information
5

Siemens AG
Division Digital Factory
Postfach 48 48
90026 NÜRNBERG
GERMANY
A5E39910322B AA
Ⓟ
01/2017 Subject to change
Copyright © Siemens AG 2015 - 2017.
All rights reserved
Legal information
Warning notice system
This manual contains notices you have to observe in order to ensure your personal safety, as well as to prevent
damage to property. The notices referring to your personal safety are highlighted in the manual by a safety alert
symbol, notices referring only to property damage have no safety alert symbol. These notices shown below are
graded according to the degree of danger.
DANGER
indicates that death or severe personal injury will result if proper precautions are not taken.
WARNING
indicates that death or severe personal injury may result if proper precautions are not taken.
CAUTION
indicates that minor personal injury can result if proper precautions are not taken.
NOTICE
indicates that property damage can result if proper precautions are not taken.
If more than one degree of danger is present, the warning notice representing the highest degree of danger will
be used. A notice warning of injury to persons with a safety alert symbol may also include a warning relating to
property damage.
Qualified Personnel
The product/system described in this documentation may be operated only by
personnel qualified
for the specific
task in accordance with the relevant documentation, in particular its warning notices and safety instructions.
Qualified personnel are those who, based on their training and experience, are capable of identifying risks and
avoiding potential hazards when working with these products/systems.
Proper use of Siemens products
Note the following:
WARNING
Siemens products may only be used for the applications described in the catalog and in the relevant technical
documentation. If products and components from other manufacturers are used, these must be recommended
or approved by Siemens. Proper transport, storage, installation, assembly, commissioning, operation and
maintenance are required to ensure that the products operate safely and without any problems. The permissible
ambient conditions must be complied with. The information in the relevant documentation must be observed.
Trademarks
All names identified by ® are registered trademarks of Siemens AG. The remaining trademarks in this publication
may be trademarks whose use by third parties for their own purposes could violate the rights of the owner.
Disclaimer of Liability
We have reviewed the contents of this publication to ensure consistency with the hardware and software
described. Since variance cannot be precluded entirely, we cannot guarantee full consistency. However, the
information in this publication is reviewed regularly and any necessary corrections are included in subsequent
editions.

CU240B-2 and CU240E-2 Control Units
Compact Operating Instructions, 01/2017, A5E39910322B AA 3
Table of contents
1 Fundamental safety instructions.............................................................................................................. 4
1.1 General safety instructions .......................................................................................................4
1.2 Industrial security ......................................................................................................................5
2 Scope of delivery .................................................................................................................................... 6
3 Installing ................................................................................................................................................. 7
3.1 Plugging the Control Unit onto the Power Module....................................................................7
3.2 Overview of the interfaces ........................................................................................................9
3.3 Terminal strips on CU240B-2 Control Units............................................................................11
3.4 Factory setting of the CU240B-2 interfaces............................................................................13
3.5 Terminal strips on CU240E-2 Control Units............................................................................15
3.6 Factory setting of the CU240E-2 interfaces............................................................................17
4 Commissioning ..................................................................................................................................... 19
4.1 Tools to commission the converter .........................................................................................19
4.2 Commissioning with BOP-2 operator panel............................................................................20
4.2.1 Quick commissioning with the BOP-2.....................................................................................20
4.2.2 Standard Drive Control ...........................................................................................................22
4.2.3 Dynamic Drive Control............................................................................................................24
4.2.4 Identifying the motor data and optimizing the closed-loop control .........................................26
4.3 Connecting the inverter to the fieldbus ...................................................................................28
4.4 Frequently required parameters .............................................................................................30
5 More information................................................................................................................................... 33
5.1 Overview of the manuals ........................................................................................................33
5.2 Technical support....................................................................................................................34
This manual describes how you install the CU240B-2 or CU240E-2 Control Unit of the
SINAMICS G120 inverter and commission it.
What is the meaning of the symbols in the manual?
Reference to further information in the manual
An operating instruction starts here.
This concludes the operating instruction.
Download from the Internet
DVD that can be ordered

CU240B-2 and CU240E-2 Control Units
4 Compact Operating Instructions, 01/2017, A5E39910322B AA
1
Fundamental safety instructions
1.1
General safety instructions
WARNING
Danger to life if the safety instructions and residual risks are not observed
If the safety instructions and residual risks in the associated hardware documentation are
not observed, accidents involving severe injuries or death can occur.
•Observe the safety instructions given in the hardware documentation.
•Consider the residual risks for the risk evaluation.
WARNING
Danger to life or malfunctions of the machine as a result of incorrect or changed
parameterization
As a result of incorrect or changed parameterization, machines can malfunction, which in
turn can lead to injuries or death.
•Protect the parameterization (parameter assignments) against unauthorized access.
•Respond to possible malfunctions by applying suitable measures (e.g. EMERGENCY
STOP or EMERGENCY OFF).

Fundamental safety instructions
1.2 Industrial security
CU240B-2 and CU240E-2 Control Units
Compact Operating Instructions, 01/2017, A5E39910322B AA 5
1.2
Industrial security
Note
Industrial security
Siemens provides products and solutions with industrial security functions that support the
secure operation of plants, systems, machines and networks.
In order to protect plants, systems, machines and networks against cyber
threats, it is
necessary to implement
– and continuously maintain – a holistic, state-of-the-art industrial
security concept. Siemens products and solutions only represent one component of such a
concept.
The customer is responsible for preventing unautho
rized access to its plants, systems,
machines and networks. Systems, machines and components should only be connected to
the enterprise network or the internet if and to the extent necessary and with appropriate
security measures (e.g. use of firewalls and
network segmentation) in place.
Additionally, Siemens’ guidance on appropriate security measures should be taken into
account. For more information about industrial security, please visit:
Industrial security (
http://www.siemens.com/industrialsecurity).
Siemens’ products and solutions undergo continuous development to make them more
secure. Siemens strongly recommends to apply product updates as soon as available and to
always use the latest product versions. Use of product versions that are no longer supported,
and failure to apply latest updates may increase customer’s exposure to cyber threats.
To stay informed about product updates, subscribe to the Siemens Industrial Security RSS
Feed at:
I
ndustrial security (http://www.siemens.com/industrialsecurity).
WARNING
Danger to life as a result of unsafe operating states resulting from software manipulation
Software manipulations (e.g. viruses, trojans, malware or worms) can cause unsafe
operating states in your system that may lead to death, serious injury, and property
damage.
•Keep the software up to date.
•Incorporate the automation and drive components into a holistic, state-of-the-art
industrial security concept for the installation or machine.
•Make sure that you include all installed products into the holistic industrial security
concept.
•Protect files stored on exchangeable storage media from malicious software by with
suitable protection measures, e.g. virus scanners.

CU240B-2 and CU240E-2 Control Units
6 Compact Operating Instructions, 01/2017, A5E39910322B AA
2
Scope of delivery
The delivery comprises at least the following components:
●A CU240B-2 or a CU240E-2 control unit with firmware, which is ready to run. Options for
upgrading and downgrading the firmware can be found on the Internet: Firmware
(http://support.automation.siemens.com/WW/news/en/67364620)
The fieldbus interface of the Control Unit depends on the Article No. The Article No., the
designation and the version of the hardware (e.g. 02) and firmware (e.g. 4.6) can be
found on the rating plate ①of the Control Unit.
Designation
Article number
Fieldbus
CU240B-2
6SL3244-0BB00-1BA1
USS, Modbus RTU
CU240B-2 DP
6SL3244-0BB00-1PA1
PROFIBUS DP
CU240E-2
6SL3244-0BB12-1BA1
USS, Modbus RTU
CU240E-2 F
6SL3244-0BB13-1BA1
CU240E-2 DP
6SL3244-0BB12-1PA1
PROFIBUS DP
CU240E-2 DP-F
6SL3244-0BB13-1PA1
CU240E-2 PN
6SL3244-0BB12-1FA0
PROFINET IO, EtherNet/IP
CU240E-2 PN-F 6SL3244-0BB13-1FA0
●Compact Operating Instructions in German and English
●The inverter contains open-source software (OSS). The OSS license terms are saved in
the inverter.
Transferring OSS license terms to a PC
Procedure
To transfer OSS license terms to a PC, proceed as follows:
1. Switch off the inverter power supply.
2. Insert an empty memory card into the card slot of the inverter.
Overview of the interfaces (Page 9)
3. Switch on the inverter power supply.
4. The inverter writes file "Read_OSS.ZIP" to the memory card within approximately
30 seconds.
5. Switch off the inverter power supply.
6. Withdraw the memory card from the inverter.
7. Insert the memory card into the card reader of a PC.
8. Please read the license terms.
You have transferred the OSS license terms to a PC.

CU240B-2 and CU240E-2 Control Units
Compact Operating Instructions, 01/2017, A5E39910322B AA 7
Installing
3
3.1
Plugging the Control Unit onto the Power Module
Permissible Power Modules
You may operate the Control Unit with the following Power Modules:
Power Module
✓= operation with Power Module permissible, --- = not per-
missible
CU240B-2
CU240E-2
PM230 IP20 and push-through
✓
✓
PM230 IP55 --- ✓
PM240P-2
✓
✓
PM240-2 ✓✓
PM250
✓
✓
Installing the Control Unit - General
Each Power Module has an appropriate holder for the Control Unit and a release
mechanism.
Inserting the Control Unit
Proceed as follows to plug the Control
Unit onto a Power Module:
1.
Place the two catches of the
Control Unit in the matching
grooves of the Power Module.
2.
Press the Control Unit onto the
Power Module until you hear that it
latches.
You have now plugged the Control
Unit onto the Power Module.
Removing the Control Unit
Remove the Control Unit from the Power Module by pressing the release mechanism.

Installing
3.1 Plugging the Control Unit onto the Power Module
CU240B-2 and CU240E-2 Control Units
8Compact Operating Instructions, 01/2017, A5E39910322B AA
Special features for the PM230 Power Module IP55, FSA … FSC
To insert or detach the Control Unit, you must
release eight
or ten fixing screws of the cover
and then remove the cover.
The Power Module release mechanism is
shown in the diagram.
Attach the cover again before you commission
the inverter. Do not damage the seal of the
cover when attaching it.
Adapter for operating a PM230 IP55 Power Module
For operating the Control Unit with a PM230 IP55 Power Module, FSA … FSC, an adapter is
required between the Control Unit and operator panel (BOP-2 or IOP).
The adapter, which is included in the scope of delivery of the Power Module, is too short for
the CU240E-2 Control Unit. The matching adapter for the CU240E-2 Control Unit can be
ordered through the KnorrTec company.
Article number 10055500
Figure 3-1 Insert the KnorrTec adapter on the interface for the operator panel

Installing
3.2 Overview of the interfaces
CU240B-2 and CU240E-2 Control Units
Compact Operating Instructions, 01/2017, A5E39910322B AA 9
3.2
Overview of the interfaces
Interfaces at the front of the Control Unit
To access the interfaces at the front of the Control Unit, you must lift the Operator Panel (if
one is being used) and open the front doors.
①
Memory card slot
②
Terminal strips
③
Bus termination, only for
USS and Modbus field
buses
④
Fieldbus interface at the lower side
⑤
Selecting the fieldbus
address
On all Control Units with
the exception of
CU240E
-2 PN and
CU240E
-2 PN-F
⑥
Status
LED
⑦
USB interface for connection to a PC
⑧
Switch for AI
0 and AI 1 1)
(U/I)
•
I0/4 mA … 20 mA
•
U -10/0 V … 10 V
⑨
Interface to the operator panel
1) AI 1 is not available on the CU240B-2 Control Unit
Table 3- 1 Number of inputs and outputs
Digital
inputs DI
Digital
outputs DO
Analog
inputs AI
Analog
outputs AO
Fail-safe digital
inputs F-DI 1)
CU240B-2, CU240B-2 DP
4
1
1
1
0
CU240E-2, CU240E-2 DP,
CU240E-2 PN
6 3 2 2 1
CU240E-2 F, CU240E-2 DP-F,
CU240E-2 PN-F
6 3 2 2 3
1) Each fail-safe digital input F-DI used takes up two digital inputs DI

Installing
3.2 Overview of the interfaces
CU240B-2 and CU240E-2 Control Units
10 Compact Operating Instructions, 01/2017, A5E39910322B AA
Table 3- 2 Permissible cable and wiring options
Solid or flexible conduc-
tors
Finely stranded con-
ductor with non-
insulated end sleeve
Finely stranded con-
ductor with partially
insulated end sleeve
Two finely stranded
conductors with the
same cross-section
with partially insulated
twin end sleeves
Wiring the terminal strip in compliance with EMC
●If you use shielded cables, then you must connect the shield to the mounting plate of the
control cabinet or with the shield support of the inverter through a good electrical
connection and a large surface area.
●Use the shield connection plate of the Control Unit as shield support and strain relief.
Table 3- 3 Article numbers
Shield connection kit 2 for the CU240B-2 and CU240E-2 Control Units with
all fieldbus interfaces except for PROFINET.
6SL3264-1EA00-0HA0
Shield connection kit 3 for the CU230P-2 and CU240E-2 Control Units with
PROFINET interface
6SL3264-1EA00-0HB0
Additional information about EMC-compliant wiring is available on the Internet: EMC
installation guideline (http://support.automation.siemens.com/WW/view/en/60612658)
Interfaces at the lower side of the CU240B-2 and CU240E-2 Control Units

Installing
3.3 Terminal strips on CU240B-2 Control Units
CU240B-2 and CU240E-2 Control Units
Compact Operating Instructions, 01/2017, A5E39910322B AA 11
3.3
Terminal strips on CU240B-2 Control Units
Terminal strips with wiring example
Figure 3-2 Wiring example of the digital inputs with the internal inverter 24 V power supply
All terminals labelled with reference potential "GND" are connected internally in the inverter.
Reference potential "DI COM" is electrically isolated from "GND".
→ if, as described above, you use the 24-V power supply from terminal 9 to supply the digital
inputs, then you must connect "GND" with "DI COM" at the terminals.
When an optional 24-V power supply is connected to terminals 31, 32, the Control Unit
remains in operation even after the Power Module has been disconnected from the line
supply. The Control Unit thus maintains the fieldbus communication, for example.
→ At terminals 31, 32, only connect a power supply that is in accordance with SELV (Safety
Extra Low Voltage) or PELV (Protective Extra Low Voltage).
→ if you also wish to use the power supply at terminals 31, 32 for the digital inputs, then you
must connect "DI COM" and "GND IN" with one another at the terminals.
You may use the internal 10V power supply or an external power supply for the analog input.
→ If you use the internal 10 V power supply, you must connect AI 0- to GND.

Installing
3.3 Terminal strips on CU240B-2 Control Units
CU240B-2 and CU240E-2 Control Units
12 Compact Operating Instructions, 01/2017, A5E39910322B AA
Additional options for wiring the digital inputs
Connecting P-switching contacts with an external
power supply
You must remove the jumper between
terminals 28 and 69 if it is necessary to
have electrical isolation between the
ex
ternal power supply and the internal
inverter power supply.
Connecting M-switching contacts with an external
power supply
It is not permissible that terminals 28
and 69 are connected with one another.

Installing
3.4 Factory setting of the CU240B-2 interfaces
CU240B-2 and CU240E-2 Control Units
Compact Operating Instructions, 01/2017, A5E39910322B AA 13
3.4
Factory setting of the CU240B-2 interfaces
The factory setting of the terminals depends on which fieldbus the Control Unit supports.
Control Units with PROFIBUS interface
The function of the fieldbus interface and digital inputs DI 0, DI 1 depends on DI 3.
--- No function.
DO 0: p0730
AO 0: p0771[0]
DI x: r0722.x
Speed setpoint (main setpoint): p1070[0] = 2050[1]
Figure 3-3 Factory setting of the CU240B-2 DP Control Unit

Installing
3.4 Factory setting of the CU240B-2 interfaces
CU240B-2 and CU240E-2 Control Units
14 Compact Operating Instructions, 01/2017, A5E39910322B AA
Control Units with USS interface
The fieldbus interface is not active.
--- No function.
DO 0: p0730
AO 0: p0771[0]
DI x: r0722.x
AI 0: r0755[0]
Speed setpoint (main setpoint): p1070[0] = 755[0]
Figure 3-4 Factory setting of the CU240B-2 Control Unit
Changing the function of the terminals
The function of the terminals marked in color in the two figures above, can be set.
In order that you do not have to successively change terminal for terminal, several terminals
can be jointly set using default settings ("p0015 Macro drive unit").
The terminal settings made in the factory described above correspond to the following
default settings:
●Default setting 12 (p0015 = 12): "Standard I/O with analog setpoint"
●Default setting 7 (p0015 = 7): "Fieldbus with data set switchover"
Further default settings can be found in the Operating Instructions.
Overview of the manuals (Page 33)

Installing
3.5 Terminal strips on CU240E-2 Control Units
CU240B-2 and CU240E-2 Control Units
Compact Operating Instructions, 01/2017, A5E39910322B AA 15
3.5
Terminal strips on CU240E-2 Control Units
Terminal strips with wiring example
Figure 3-5 Wiring example of the digital inputs with the internal inverter 24 V power supply
All terminals labelled with reference potential "GND" are connected internally in the inverter.
Reference potentials "DI COM1" and "DI COM2" are electrically isolated from "GND".
→ if, as described above, you use the 24-V power supply from terminal 9 to supply the digital
inputs, then you must connect "GND" with "DI COM1" and "DI COM2" at the terminals.
When an optional 24-V power supply is connected to terminals 31, 32, the Control Unit
remains in operation even after the Power Module has been disconnected from the line
supply. The Control Unit thus maintains the fieldbus communication, for example.
→ At terminals 31, 32, only connect a power supply that is in accordance with SELV (Safety
Extra Low Voltage) or PELV (Protective Extra Low Voltage).
→ if you also wish to use the power supply at terminals 31, 32 for the digital inputs, then you
must connect "DI COM1/2" and "GND IN" with one another at the terminals.
You may use the internal 10V power supply or an external power supply for the analog
inputs.
→ If you use the internal 10 V power supply, you must connect AI 0- or AI 1- to GND.

Installing
3.5 Terminal strips on CU240E-2 Control Units
CU240B-2 and CU240E-2 Control Units
16 Compact Operating Instructions, 01/2017, A5E39910322B AA
Additional options for wiring the digital inputs
Connecting P-switching contacts with an external
power supply
If you wish to connect the external and
the internal inverter power supply vol
t-
ages with one another, then you must
connect "GND" with termina
ls 34 and
69 at the terminals.
Connecting M-switching contacts with an external
power supply
Connect terminals 69 and 34 at the
te
rminals.

Installing
3.6 Factory setting of the CU240E-2 interfaces
CU240B-2 and CU240E-2 Control Units
Compact Operating Instructions, 01/2017, A5E39910322B AA 17
3.6
Factory setting of the CU240E-2 interfaces
The factory setting of the terminal strip depends on the Control Unit.
Control Units with PROFIBUS or PROFINET interface
The function of the fieldbus interface and digital inputs DI 0, DI 1 depends on DI 3.
--- No function.
DO x: p073x
AO 0: p0771[0]
DI x: r0722.x
Speed setpoint (main setpoint): p1070[0] = 2050[1]
Figure 3-6 Factory setting of CU240E-2 DP(-F) and CU240E-2 PN(-F) Control Units

Installing
3.6 Factory setting of the CU240E-2 interfaces
CU240B-2 and CU240E-2 Control Units
18 Compact Operating Instructions, 01/2017, A5E39910322B AA
Control Units with USS interface
The fieldbus interface is not active.
--- No function.
DO x: p073x
AO 0: p0771[0]
DI x: r0722.x
AI 0: r0755[0]
Speed setpoint (main setpoint): p1070[0] = 755[0]
Figure 3-7 Factory setting of the CU240E-2 and CU240E-2 F Control Units
Changing the function of the terminals
The function of the terminals marked in color in the two figures above, can be set.
In order that you do not have to successively change terminal for terminal, several terminals
can be jointly set using default settings ("p0015 Macro drive unit").
The terminal settings made in the factory described above correspond to the following
default settings:
●Default setting 12 (p0015 = 12): "Standard I/O with analog setpoint"
●Default setting 7 (p0015 = 7): "Fieldbus with data set switchover"
Further default settings can be found in the Operating Instructions.
Overview of the manuals (Page 33)

CU240B-2 and CU240E-2 Control Units
Compact Operating Instructions, 01/2017, A5E39910322B AA 19
Commissioning
4
4.1
Tools to commission the converter
Operator panel
An operator panel is used to commission, troubleshoot and control the inverter, as well as to
back up and transfer the inverter settings.
The
Intelligent Operator Panel (IOP)
is available for snapping onto the inverter, or as
handheld with a connecting cable to the inverter. The graphics-capable plain text display of
the IOP enables intuitive operation and diagnostics of the inverter.
The IOP is available in two versions:
●With European languages
●With Chinese, English and German
Additional information about the compatibility of the IOP and inverters is available in the
Internet:
Compatibility of the IOP and Control Units
(http://support.automation.siemens.com/WW/view/en/67273266)
The
Operator Panel BOP-2
for snapping onto the inverter has a two-line display for
diagnostics and operating the inverter.
Operating Instructions of the BOP-2 and IOP operator panels:
Overview of the manuals (Page 33)
PC tools
STARTER
and
Startdrive
are PC tools that are used to commission, troubleshoot and control
the inverter, as well as to back up and transfer the inverter settings. You can connect the PC
with the inverter via USB or via the PROFIBUS / PROFINET fieldbus.
Connecting cable (3 m) between PC and inverter: Article number 6SL3255-0AA00-2CA0
STARTER DVD: Article number 6SL3072-0AA00-0AG0
Startdrive DVD: Article number 6SL3072-4CA02-1XG0
STARTER (http://support.automation.siemens.com/WW/view/en/26233208)
Startdrive (http://support.automation.siemens.com/WW/view/en/68034568)
STARTER videos (http://www.automation.siemens.com/mcms/mc-drives/en/low-voltage-
inverter/sinamics-g120/videos/Pages/videos.aspx)
Startdrive tutorial (http://support.automation.siemens.com/WW/view/en/73598459)

Commissioning
4.2 Commissioning with BOP-2 operator panel
CU240B-2 and CU240E-2 Control Units
20 Compact Operating Instructions, 01/2017, A5E39910322B AA
4.2
Commissioning with BOP-2 operator panel
Plugging on an operator panel
Procedure
To plug an Operator Panel on the Control Unit, proceed as follows:
1.
Locate the lower edge of the Operator Panel into the matching
recess of the Control Unit.
2.
Plug the Operator Panel onto the inverter until the latch audibly
engages.
You have plugged an operator panel onto the Control Unit.
The operator panel is ready for operation when you connect the inverter
to the power supply.
4.2.1
Quick commissioning with the BOP-2
Starting quick commissioning
Preconditions
●The power supply is switched on.
●The operator panel displays setpoints and actual values.
Procedure
Proceed as follows to carry out quick commissioning:
Press the ESC key.
Press one of the arrow keys until the BOP-2 displays the "SETUP" menu.
To start quick commissioning, in the "SETUP" menu, press the OK key.
If you wish to restore all of the parameters to the factory setting before the quick
commissioning, proceed as follows:
1. Press the OK key.
2. Switchover the display using an arrow key: nO →YES
3. Press the OK key.
