Siemens Gigaset 4010 User manual

Gigaset
4010
Be inspired
User Manual and
Safety Precautions
Se incluyen Instrucciones en Español
Sold by:
http://www.TWAcomm.com
Toll Free: [phone]

II
Congratulations
Congratulations on your purchase of the Siemens Gigaset 4010 telephone system!
This phones 2.4 GHz frequency and high-speed digital voice encoding provide re-
ception and voice clarity that is superior to other cordless phones. And, its digital
spread spectrum technology will provide you with secure, private conversations.
Please read the following important information.
For Siemens Customer Care Service, product operation
information, or for problem resolution, call toll-free
1-888-777-0211
7 a.m. to 10 p.m. Central Standard Time EVERY DAY
s
www.icm.siemens.com
DO NOT RETURN
THIS PRODUCT TO THE
STORE!

III
General
Quick reference
Handset
Turn handset on/off
(see page 6) Hold down 
Turn keypad protection on/
off (see page 6) Hold down 4
Turn tones on/off Hold down 5
Make an external call
(see page 11) 
Redial a number
(see page 14) If applicable, select an entry

Copy telephone number
to the Directory
(see page 14)
Dial from the Directory
(see page 15)  [Name] and/or 
Dial from the Call Log
(see page 21) If necessary 
Set the handset volume
(see page 30)

Make an internal call
(see page 11) For example:
or 
Call all handsets
(see page 11) 5or 
Transfer call to another
handset (see page 27) For example:
-+
Consultation Calls
(see page 27) For example:
-; End:
Set the date
(see page 7) 
Set the time
(see page 7)
Set the alarm clock
(see page 9) Enter the time
Backspace
(see page 35)
RDL


MENU SEND TO DIR OK

C LOG OK

MENU HS SETT
OK
H/SET VOL
OK

OK
INT INT 

INT INT
INT ALL
INT
INT MENU
EXIT
OK
MENU BASE SETT OK CLOCK OK
DATE OK
MENU BASE SETT
OK
CLOCK OK
TIME OK
MENU ALARM CLOCK
OK
OK

General
IV
Handset Diagram
Display and Soft keys

General
V
General
Display symbols
Automatic redial
key:
Opens the list
with the last five
telephone num-
bers dialed.
Mailbox icon:
Opens the messages/
entries in the Call Log/
Telco voice mail.
There are new messag-
es if the icon flashes.
Intercom key:
Call other regis-
tered handsets.
Menu key:
To access menu
(when the tele-
phone is idle or
during a call).
RDL INT MENU
 
Scroll through the menu by pressing
the soft key directly below the symbol.
Confirm the function selected.
End and save the setting.
  OK
,17 &

--

2.

ALARM CLOCK

General
VI

1
Gigaset 4015 Classic, USA, A31008-G4015-U101-1- 4010 BookTOC.fm 20.07.01
Table of Contents
Installing the Telephone System .............................. 2
Date and Time .......................................................... 7
Making Calls ........................................................... 11
Enhanced Telephone Features ............................... 14
Call Waiting ............................................................ 23
Handset Operation ................................................. 24
Individual Handset Settings ................................... 30
Base Station Settings ............................................. 32
Connecting the Base Station to a PBX ................... 33
Appendix ................................................................ 35
Troubleshooting ..................................................... 36
Customer Care for Cordless Products .................... 37
Safety Precautions ................................................. 39
Limited Warranty .................................................... 40
Menu ...................................................................... 42
Index ....................................................................... 44

2
Press Keys:
Installing the Telephone System
Installing the Telephone
System
The package contains the following:
• 1 Gigaset 4010 base station
• 1 Gigaset 4000 handset
• 1 power supply unit
• 1 telephone cord
• 1 belt clip
• 2 AA rechargeable NiCd batteries
• 1 User Manual
• 1 Quick Start Guide
Installing the Base Station
The base station is designed for operation in pro-
tected rooms with a temperature range from +40°F
to +100°F.
• IMPORTANT: For best reception, place the
base in a high central location, away from
other electrical devices.

3
Installing the Telephone System
Connecting the Base Station
• Only use the power supply unit included as indicated on the underside of
the base.
• Use the telephone cord supplied. Do not use any old cords.
• Do not use an outlet controlled by a wall switch.
• Insert plug on the telephone cord into telephone jack on base unit (clicks
into place)
• Place cord in cable channel on the bottom of the base
• Insert other end of plug into telephone jack on the wall
• The installation of the base unit should allow at least 8 inches between the
base and persons to be in compliance with FCC RF exposure guidelines
Power supply unit
(110 V AC/60 Hz
with cord )
• Insert the
small plug on
cord into
phone jack
• Place cord in
the base cable
channel
• insert power
supply unit
into wall outlet

4
Press Keys:
Installing the Telephone System
Setting Up the Handset
Remove the protective plastic film
from display.
Inserting the batteries
• Insert the batteries, as shown above.
• Place cover and push gently upward until it clicks
into place (the unit is shipped with the battery
cover off).
• To open, press the grooved area on the cover and
slide back.
Placing the Handset into the Base Station
and Charging the Batteries
Before using your handset, place it in the base sta-
tion with the display facing upward. After about one
minute, the handset's internal number is shown in
upper left hand corner of display (for example, “1”).
Note:
Your Gigaset is now ready for operation. Please set
date and the time (see page 7), so that the time of
incoming calls can be noted correctly.
• Use only “AA” rechargeable NiCd or NiMH
batteries. Do not use Alkaline, Lithium or
non-rechargeable batteries.
• Never use non-Siemens charging units as
these could damage the batteries and
phone.
For information on how to register additional
handsets (bought separately), see page 25.

5
Press Keys:
Installing the Telephone System
Leave the handset for about 12–14 hours in the
base station to charge the batteries. The charging
status symbol flashes on the handset, indicating
that the batteries are being charged:
Attaching the Belt Clip
Push the belt clip onto the back of the handset until
the tabs click into place.
KBatteries empty
(symbol flashes) IBatteries 2/3
charged
JBatteries 1/3
charged HBatteries fully
charged
• Once the initial charging operation is com-
pleted, replace your handset into the base
station after each call. Charging is con-
trolled electronically. This ensures opti-
mum charging and prolongs battery life.
• The batteries heat up during charging. This
is normal and not dangerous.
• The battery charging status is correctly dis-
played only after uninterrupted charging/
discharging. You should therefore avoid
opening the battery compartment unnec-
essarily.

6
Press Keys:
Installing the Telephone System
Turning Handset On/Off
To turn handset on/off, hold down the End key –
you will hear a confirmation beep*.
Turning Keypad Lock On/Off
You can disable the handset keys when carrying the
unit in your pocket or bag. This protects the keypad
against inadvertent activation. If there is an incom-
ing call, the key lock is automatically turned off and
turned on after the call has ended.
Answering a call: Press the Talk key.
4To turn keypad lock on/off, hold down the pound key
– you will hear the confirmation beep*.
Headset
• Insert the headset plug into the jack on the left
side of the handset.
• To answer a call, press the -key.
• To end a call, press the -key.
The handset is turned on as soon as you in-
sert the batteries and place the handset in
the base station.
911/Emergency Calls cannot be made when
the keypad is locked.
* Confirmation beep = rising tone sequence,
Error beep = falling tone sequence.
Headsets may be purchased separately.

7
Press Keys:
Date and Time
Date and Time
Setting the Date and the Time
The date and time settings are necessary in order
for the date and time of the arrival of messages/in-
coming calls to be displayed correctly. If you sub-
scribe to Caller ID, the time and date will be auto-
matically set with the first incoming call. If not,
manually set by using the steps below. You can also
set the clock mode, to the 12 hour mode (AM and
PM) or 24 hour mode.
Date
NNNNNNNNNNNN
MENU Open the Menu.
NNNNNNN NNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNN NNNNNNN
BASE SETT Scroll to Base Setting and press OK.
NNNNNNN NNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNN NNNNNNN
CLOCK Scroll to Clock and press OK.
NNNNNNN NNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNN NNNNNNN
DATE Select Date and press OK.
The current setting is displayed in the MM-DD-YY
mode.
For example:
L0-0L Enter the month/day/year (for example, 05-25-01 as
shown).
NNNNNNN NNNNNNN
 If necessary, skip to a digit to correct it.
NNNNNNN
Save the setting by pressing OK.
Time
NNNNNNNNNNNN
MENU Open the Menu.
NNNNNNN NNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNN NNNNNNN
BASE SETT Scroll to Base Setting and press OK.
NNNNNNN NNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNN NNNNNNN
CLOCK Scroll to Clock and press OK.
NNNNNNN NNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNN NNNNNNN
TIME Scroll to Time and press OK.
• The default setting is 12 hour mode.
• If you subscribe to Caller ID the date and
time may be sent from your telephone ser-
vice and will be automatically set..

8
Press Keys:
Date and Time
The current setting is displayed as HH:MM.
For example:
LL Enter the hours/minutes for example, 10:30 as
shown.
NNNNNNN NNNNNNN
 If necessary, skip to a digit to correct it.
NNNNNNN
Save the setting by pressing OK.
If 12 hour mode is set as Clock Mode:
NNNNNNN NNNNNNN
AM Select AM and press OK.
or
NNNNNNN NNNNNNN NNNNNNN
PM Scroll to PM and and press OK.
NNNNNNN
Save the setting by pressing OK.
Display Mode (12 or 24 Hours)
NNNNNNNNNNNN
MENU Open the Menu.
NNNNNNN NNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNN NNNNNNN
BASE SETT Scroll to Base Setting and press OK.
NNNNNNN NNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNN NNNNNNN
CLOCK Scroll to Clock and press OK.
NNNNNNN NNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNN NNNNNNN
CLOCK MODE Scroll to Clock Mode and press OK.
NNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNN NNNNNNN
24 H Select 24 hour mode and press OK.
or
NNNNNNN NNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNN NNNNNNN
12 H Scroll to 12 hour mode and press OK.
By default, the clock is set to the 12 hour
mode.

9
Press Keys:
Date and Time
Setting the Alarm
Your Gigaset has an alarm function to help you keep
track of your schedule.
Turning the Alarm On
The active alarm rings every day at the set time.
NNNNNNNNNNNN
MENU Open the Menu.
NNNNNNN NNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNN NNNNNNN
ALARM CLOCK Scroll to Alarm Clock and press OK
(marked with a ').
For example:
LL Enter the time for the alarm (hours/minutes).
For example, 10:30 AM as shown.
NNNNNNN NNNNNNN
 If necessary, skip to a digit to correct it.
NNNNNNN
Save the setting by pressing OK.
NNNNNNN NNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNN NNNNNNN
AM Then select AM or PM and press OK.
Turning the Alarm Off
The alarm clock is set, but you do not want the
alarm to sound.
NNNNNNNNNNNN
MENU Open the Menu.
NNNNNNN NNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNN NNNNNNN
ALARM CLOCK Scroll to Alarm Clock and press OK.
The alarm is turned off. The asterisk before the time
display is no longer shown.
A prerequisite for this function that you have
set date and time (see page 7).
,17


--

5'/

&
The asterisk
indicates that
the alarm
clock is set.

10
Press Keys:
Date and Time
Stopping the Alarm Sound
An alarm clock rings and the LED flashes (about 30
seconds). Press any key on the handset to turn off
the alarm sound.
Area Codes
To conveniently call back a user from the call log
(see page 21) you will need to key in and store the
code for the area where your telephone is installed
(Local Area Code). If it is installed in a Multiple Area
Code Area you will also have to key in and store the
Extra Codes for that area.
Local Area Code
NNNNNNNNNNNN
MENU Open the Menu.
NNNNNNN NNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNN NNNNNNN
BASE SETT Scroll to BASE SETT and press OK.
NNNNNNN NNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNN NNNNNNN
AREA CODES Scroll to AREA CODES and press OK.
NNNNNNN NNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNN NNNNNNN
LOC A CODE Scroll to LOC A CODE and press OK.
Key in your Local Area Code.
NNNNNNN
Confirm.
NNNNNNNNNNNN
SAVED Saved will be displayed.
Extra Codes
NNNNNNNNNNNN
MENU Open the Menu.
NNNNNNN NNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNN NNNNNNN
BASE SETT Scroll to BASE SETT and press OK.
NNNNNNN NNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNN NNNNNNN
AREA CODES Scroll to AREA CODE and press OK.
NNNNNNN NNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNN NNNNNNN
EXTRA CODE Scroll to EXTRA CODES. The first entry of list of
codes will be displayed.
NNNNNNNNNNNN
MENU Press Menu.
Key in the Extra Code.
NNNNNNN
Confirm.
NNNNNNNNNNNN
SAVED Saved will be displayed.
Repeat the last steps until all the Extra Codes for
your area have been keyed in.
There is no snooze setting. The alarm will
sound until turned off.

11
Press Keys:
Making Calls
Making Calls
Making an External Call
 Dial the telephone number. If necessary use the
backspace key to correct single digits.
Press the Talk key.
To end the call, press the End key.
Making Intercom Calls
Intercom calls are calls to other registered handsets
and does not tie up your telephone line (for exam-
ple, calls within your home from the kitchen to the
living room).
For example:
NNNNNNNN"""
-Press the Intercom soft key and enter the desired
handset's telephone number,
or
NNNNNNN NNNNNNN
  Select the desired handset and press the Talk key.
Paging All Handsets
NNNNNNNN"""
5Press the Intercom soft key and then press the Star
key
or
press the Talk key.
Ending a Call
Press the End key.
• You can also press the Talk key firstand
then enter the telephone number – each
digit is dialed immediately.
• You can cancel the dialing operation with
the End key.
• You can insert a pause, for example for in-
ternational calls, by holding down the Flash
key located in lower left hand corner of
handset.

12
Press Keys:
Making Calls
Answering a Call
Press the Talk key.
or
F? Pick up the handset from the base station or charg-
er (default: Auto talk, see page 31).
Answering Caller ID Calls
Caller ID is a service provided by the local telephone
company which allows your Gigaset to display the
name and number of the person who is calling you.
Contact your local telephone company to subscribe
to Caller ID service.
As incoming call is displayed if follows:
NNNNNNNNNNNNNNNNNNNNNNNNNNNN
5125551212 First the number of the incoming call is displayed as
follows.
NNNNNNNNNNNNNNNNNNNNNNNNNNNN
JANE DOE After a moment the name is then displayed as fol-
lows.
If the number is stored in your directory, only the
name stored will appear.
NNNNNNNNNNNNNNNNNNNNNNNNNNNN
<< >> If you have not applied for Caller ID service.
NNNNNNNNNNNNNNNNNNNNNNNNNNNN
PRV CALL If the number and/or name is suppressed by the
caller, PRV CALL will be displayed instead of the rel-
evant information.
NNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNN
OUT OF AREA If the number and/or name is not available to your
telephone company, OUT OF AREA will be dis-
played instead of the relevant information..
NNNNNNNNNNNNNNNNNNNNNNNNNNNN
UNKNOWN If the caller is unknown or no available Caller ID in-
formation is received by the local telephone
company.
• If the incoming name is longer than 12 let-
ters only the first 11 are displayed.
• If the incoming number is longer than 12
letters only the first 11 are displayed.

13
Press Keys:
Making Calls
Telco Voice Mail
If you subscribe to voice mail from your local tele-
phone company, you may use your Gigaset handset
to retrieve messages. It is recommended you store
the access number in the "1" key.
Storing Access Number for Retrieving Voice
Mail
NNNNNNNNNNNN
MENU Open the Menu.
NNNNNNN NNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNN NNNNNNN
VOICE MAIL Scroll to Voice Mail and press OK.
NNNNNNN NNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNN NNNNNNN
SET KEY 1 Scroll to Set Key 1 and press OK.
NNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNN NNNNNNN
VOICE MAIL Select Voice Mail and press OK.
NNNNNNN
Enter the access telephone number of the mailbox
and press OK.
• Once you have entered the voice mail ac-
cess number, simply hold down the 
key on the handset. You are directly con-
nected to the Telco voice mail system. Fol-
low the Telco instructions.
• Additional numbers can be stored after the
access number (password, pause). Hold
down the Flash key down to insert the
pause.
• The indication of a new message waiting
will be a flashing envelope . For more
information, see page 20. 7

14
Press Keys:
Enhanced Telephone Features
Enhanced Telephone
Features
In addition to standard telephoning, your Gigaset
offers a number of other fast, convenient features.
Redial
Your handset automatically saves the last five tele-
phone numbers dialed.
NNNNNNNNN
RDL Select RDL.
NNNNNNN NNNNNNN
Scroll to the desired telephone number.
Press the Talk key – the telephone number is dialed.
Delete the Redialing List
You can delete all numbers from your redialing list.
NNNNNNNNN
RDL Select RDL.
NNNNNNNNNNNN
MENU Open the Menu.
1Press the 6 key.
NNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNN NNNNNNN
DELETE Press OK at the prompt.
Copying the Redial Number to the Directory
NNNNNNNNN
RDL Select RDL.
NNNNNNN NNNNNNNNNNNN
MENU Select a telephone number and open the Menu.
NNNNNNN NNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNN NNNNNNN
SEND TO DIR Scroll to Send To Directory and press OK.
NNNNNNN
If necessary, change the telephone number or set
the number by pressing OK.
NNNNNNN
Using the keypad, edit the name and press OK.
For more information about the input of let-
ters and characters (see page 35).
