SII LP-2050-MF User manual

Wide Format Printer
Teriostar LP-2050 Series
LP-2050
Multifunction Model
Printer Model
LP-2050-MF
To operate your Printer correctly, read this manual
carefullybefore use.
After reading the manual, keep it in a place where you
canaccessit when required.
Quick Reference Guide
U00121382802

Your Printer is a Teriostar LP-2050 Series Wide Format Printer.
This manual describes the basic operation methods for both the LP-2050 and LP-2050-MF
models. For more detailed information, see the User's Manuals on the supplied CD-ROM.
Preface
Turning the Power On/O …………………… 3
Power On……………………………………………… 3
Power O……………………………………………… 3
Mode Buttons ………………………………… 3
Replacing the Paper …………………………… 4
Replacing the Toner Cartridge………………… 6
Replacing the Waste Toner Bottle …………… 8
Replacing the Charger Unit …………………… 10
Replacing the Process Cartridge ……………… 12
Part Names……………………………………… 14
Paper Jams……………………………………… 16
Copying
MF
………………………………… 20
Importing Images (Documents) to a Computer
MF 21
Operating the Printer from a Computer
MF
23
Troubleshooting ……………………………… 24
When an Error Message Appears…………………… 24
Smears on a Printout ……………………………… 24
Changing the Time Until Power Save Mode ……… 24
Automatic Paper Cutting After a Certain Time …… 24
Automatic Paper Cutting After Opening
and Closing a Door ………………………………… 25
Changing the Print Density ………………………… 25
Wrinkles on Tracing Paper ………………………… 25
Selecting Paper to Match the Print Data …………… 25
Missing Print or Slow Data Reception ……………… 26
Service Representatives ……………………… 29
Disposal Method …………………………………… 29
Table of Contents

3
Turning the Power On/Off
Power On
12
Power O
Press down for
1 sec. or longer
2
1
zCOPY button MF
Changes to copy mode, and the lamp at the button's
left lights up. For more details, see the separate User's
Manual for Multifunction Printer Operation.
zSUBMIT button MF
Changes to submission mode, and the lamp at the
button's left lights up. For more details, see the separate
User's Manual for Multifunction Printer Operation.
zSCAN button MF
Changes to scan mode, and the lamp at the button's
left lights up. For more details, see the separate User's
Manual for Multifunction Printer Operation.
zPRINT button
Changes to print mode and enables printing.
zMENU button
Changes to menu mode, which enables the Printer
setting specication.
Mode Buttons

4
Replacing the Paper
1
2
3
4
5
6
OkNo
7

5
TReplacing the Paper
8
60 cm
(23.63 inches)
9
10
Approximately 90°Approximately 90°
11

6
Replacing the Toner Cartridge
1
2
3
4
x10
x10
5
6

7
Disposing of Empty Toner Cartridges
Put the used toner cartridge into the bag provided in the box of the new toner cartridge, and dispose
of it according to the local regulations.
TReplacing the Toner Cartridge
7 8

8
Replacing the Waste Toner Bottle
1 2
x10
3
①
②
4

9
Disposing of Used Toner Bottles
Dispose of the waste toner bottle according to the local regulations.
TReplacing the Waste Toner Bottle
5
6
①
②
7

10
Replacing the Charger Unit
1Press down for
1 sec. or longer
2
3
4
5
6
7

11
TReplacing the Charger Unit
8
9
10
11
TIP
The charger unit can be installed in
either direction.
If lines or other defects appear on
the printout, inverting the charger
unit right and left sides may solve the
problem.

12
Replacing the Process Cartridge
1Press down for
1 sec. or longer
2
3
4
5
6
7
8
9

13
TReplacing the Process Cartridge
10 x5x5
11
12
13
①
③
②
①
③
②
14
15
①
②
③
16

14
Part Names
Front door
Drawer for rolls 1 and 2
Drawer for rolls 3 and 4
Printer Model Multifunction Model
Document table
Toner door
Scanner cover
Front Side

15
Process cartridge drawer
Fuser unit drawer
Filter cover
Waste toner door
Paper outlet slot
Latch button
Paper outlet cover
Rear Side
TPart Names

16
The door requiring action is displayed, in
accordance with the paper jam location.
Open the specied door and take the appropriate
action to remove the paper jam.
Paper jam in a Roll paper drawer
1
2
3
Paper jam in the front door
1
Paper Jams

17
2
3
Paper jam in the Fuser unit
1
2
When you cannot pull out the paper
easily:
①
②
3
TPaper Jams

18
Paper jam in a roll paper drawer or front
door
1
2
3
4
5
6
TPaper Jams

19
7
8
Original jam MF
1
2
3
4
5
TPaper Jams

20
Press COPY
Set the original
Position the original facing down. Set it in the Printer
aligned with the original width guide. The inserted original
is automatically pulled into the Printer, and set.
Copying MF
