SEM51
User & Installation Manual
when Sirius ducting is used.
Full replacement warranty on parts and labour.
Year
Warranty
www.siriusbrand.com

2

3
BEFORE YOU INSTALL 4
BEFORE YOU INSTALL - MOTOR WIRING CONNECTION 4
BEFORE YOU INSTALL - DUCTING INFORMATION 5
INSTALLING THE SEM51 MOTOR 6
OPTIONAL MESH FILTER 8
BRACKET AND INTERNAL PIPE DIMENSIONS 9
SEM51 MOTOR WIRING DIAGRAM 10
WARRANTY INFORMATION 11
TABLE OF CONTENTS

4
This installation should only be performed by a qualified tradesperson. Where possible, use a trained Sirius recommended
installer (see Siriusbrand.com). Sirius will not be held responsible for issues that occur due to installation of product by an
unqualified tradesperson.
• Motor must be accessible for servicing purposes. If not, servicing may be refused unless access can be provided.
Prior to install please check minimum & maximum installation details on the Sirius website, FAQ under support tab.
Service is offered during normal business hours only, also appliances to have a clear access in a serviceable area.
• The ducting of the rangehood must not be connected to ducting which is used for exhausting other fumes from
appliances, such as central heating, boilers etc.
• For the external exhausting of the fumes, comply with the Australian building standards.
• Ventilate the room suitably according to the Australian building standards when the appliance is working together with
gas or oil appliances.
• The SEM motor is powered by the rangehood. Standard 10AMP GPO at the point of rangehood required.
• Before connecting the rangehood to the mains supply, make sure that the voltage indicated in the rating plate
corresponds to the mains voltage in the home.
• Before carrying out any sort of maintenance or cleaning operation, make sure that the appliance is disconnected from
the electrical mains.
IMPORTANT INFORMATION BEFORE INSTALLATION IN YOUR SIRIUS RANGEHOOD
• FLASHING NOT INCLUDED
• Sirius has metal and tiled roof flashing available in various sizes from your retailer,
or visit www.siriusbrand.com
• Rangehood and SEM5 XS316 must be a minimum of 2 metres between rangehood and motor for noise reduction
reasons.
• Only use ducting that falls within the necessary minimum and maximum length requirements as specified in the
installation guide.
• Try and minimise bends to the ducting for optimum performance.
• Use only suitable ducting as specified by Sirius. Under no circumstances is flexible ducting to be used as it creates
unwanted noise, vibration and can place the motor under unnecessary stress resulting in premature failure of the SEM
motor.
• Under no circumstances is the duct diameter is the duct diameter to be reduced. A constant minimum diameter of
150mm for the SEM 5 must be maintained at all times.
• Read the mounting and operating instructions of the rangehood carefully.
• The manufacturer cannot be held responsible for a decrease of the airflow or for an increase of noise level caused by
non-compliance with the instructions above.
BEFORE YOU INSTALL
WARNING
1. Remove the four screws holding the front of the housing in place to
expose the connections.
2. Following the wiring chart on the front of the housing, connect each wire
to the matching colour, making sure that this is done correctly before running
power to the unit.
3. Replace the cover and fix the four screws back into place.
MOTOR WIRING CONNECTION

5
The symbol on the product or on its packaging indicates that this product
may not be treated as house-hold waste. Instead it shall be handed
over to the applicable collection point for the recycling of electrical and
electronic equipment. By ensuring this product is disposed of correctly,
you will help prevent potential negative consequences for the environment
and human health, which could otherwise be caused by inappropriate
waste handling of this product. For more detailed information about
recycling of this product, please contact your local city office, your
household waste disposal service or the shop where you purchased the
product. This appliance is marked according to the European directive
2002/96/EC on waste electrical and electronic equipment (WEEE).
Sirius warranty covers only Sirius product. If you choose to install a non-Sirius branded accessory
such as flexible ducting, Sirius will only warrant the rangehood and motor. If installation is found to be
the cause of failure or issue then charges will apply for service and parts.
Flexible ducting is not permitted under any circumstances. Flexible ducting has been found to
increase noise levels, increase vibration and reduce airflow. Sirius Semi-rigid or solid ducting can be
used in lieu. There is a range available to suit any application.
Ducting available at www.siriusbrand.com
6 Year Warranty when Sirius Ducting is used. Full replacement warranty on parts and labour.
See website for terms & conditions.
A reduction in the duct diameter from stated ducting size will void warranty.
If you are in doubt about the ducting, please contact Sirius on 1300 762 219 prior to installation
WARNING
The appliance must be installed and
connected to the power supply only by a
qualified technician.
• There should be adequate ventilation of the room when the rangehood is used at the same time as
appliances burning gas or other fuels (not applicable to appliances that only discharge the air back into the
room)
• The details concerning the method and frequency of cleaning
• There is a fire risk if cleaning is not carried out in accordance with the instructions;
• Do not flambé under the range hood;
• CAUTION: Accessible parts may become hot when used with cooking appliances.
BEFORE YOU INSTALL - DUCTING INFORMATION

6
1. Pre determine the exit point where the roof
penetration will be and prepare a hole of 205 mm to
accommodate the motor flue.
2. Fix the Internal Bracket on the inside of the roof
cavity using the 9 x 25mm Screws Supplied in
the packaging. (Fig. 1) Please note that if there is
no timber supports to hold the Internal bracket,
horozontal timber supports (not supplied) may need to
be fitted.
3. Fit the roof flashing to the 200mm diameter steel
pipe (as on Fig. 2) and insert the pipe through the
roof penetration and internal bracket. Sirius Roof
Flashing can be purchased through your retailer or at
Siriusbrand.com. Metal roof flashing code: MRF G178,
Tiled Roof Flashing code: TRF G075
4. Fix the 200mm pipe to the internal bracket with the 8 x
supplied 9.5mm screws. Please note that the 200mm
pipe has no pre drilled holes and will need to be drilled
at the desired height by the installer. A minimum of
100mm exposed section of 200mm pipe is required to
accomodate the flashing. (Fig. 3)
INSTALLATION
(Fig. 3) 8 x 9.5mm long screws
(Fig. 2)
(Fig. 1)
NOTE
Please be aware for noise reasons the the
SEM51 motor is required to be a minimum or 2
metres from the location of the rangehood. 3-5
metres is best practice installation.
The motor has a 7 metre long control cable
which cannot be lengthened under any
circumstances. Any attempt to modify this
product in any way will immediately void the
manufacturer warranty.

7
5. Once the 200mm pipe is securely fitted to the internal
bracket, connect 150mm ducting to the motor.
Please note, do not use screws to fix the ductwork
to this section as it will prevent the non return valves
from opening during operation. Low grade flexible
ducting should not be used under any circumstances
as it will void the manyfacturer warranty. A minimum
requirement semi rigid duct work can be used. See
approved range of ducting at www.siriusbrand.com
6. Feed the attached ductwork and power cable through
the 200mm section of pipe into the roof cavity. (Fig. 4)
7. Fix the motor to the exposed section of the 200mm
pipe and secure in place with the supplied 8 x 5mm
screws. Please note that the exit point on the motor
needs to be positioned on the low side of the pitch on
the roof. (Fig 5.)
8. Run the motor power cable back to the location of
the rangehood and plug in the connections. Follow
the MOTOR WIRING CONNECTION instructions on
page 4 of this manual to connect the motor to the
rangehood.
(Fig. 5)
low side
(Fig. 4)
9. Run the ductwork from the motor location back to the
location of the rangehood. Connect the ductwork to
the plastic outlet collar on the rangehood and secure
in place. Please note, do not use screws to fix the
ductwork to the rangehood as it will prevent the non
return valves from opening during operation.
10. Plug the rangehood into a 10 amp GPO located within
1 Metre of the rangehood. Press the red reset button
until you feel a click, you will now have power to the
hood and motor and can begin operation of your
Sirius Rangehood.
Note: Never reduce the ducting diameter under any
circumstances as it will severly effect the performance
and increase noise level of your rangehood.
A 150mm constant diameter duct run is required.
Avoid abrupt changes in direction of your ductwork.
For every 90 degree bend, reduce your maximum
duct length by 1 metre. Example: 2 x 90 degree bend,
maximum duct length should not exceed 5 metres.
Sirius strongly recommend that the installation of
the SEM51 motor should only be performed by a
suitably qualified tradesperson. Sirius will not be held
responsible for any ongoing issues due to incorrect or
sub standard installation by an unqualified installer.
IMPORTANT
IMPORTANT

8
BAL40 MESH OPTIONAL
Part number: SPS-75105000598
Remove the 4 screws holding the existing ventillation
cover in place and take off. Fit the BAL40 mesh into place
and replace the 4 screws. Refer to Fig. 6.
(Fig. 6)

9
BRACKET AND INTERNAL PIPE DIMENSIONS
600mm
515mm
200mm diameter
254mm
Top view
Side view
Flue ceiling brace
254mm 71mm

10
SEM51 MOTOR WIRING DIAGRAM
