ISTRUZIONI PER INSTALLAZIONE USO E MANUTENZIONE
INSTALLATION, USE AND MAINTENANCE INSTRUCTION
SU-DD20

The symbol on the product or on its packaging indicates that this product may not be treated as household
waste. Instead it shall be handed over to the applicable collection point for the recycling of electrical and
electronic equipment. By ensuring this product is disposed of correctly, you will help prevent potential
negative consequences for the environment and human health, which could otherwise be caused by
inappropriate waste handling of this product. For more detailed information about recycling of this product,
please contact your local city ofce, your household waste disposal service or the shop where you pur-
chased the product. This appliance is marked according to the European directive 2012/19/EC on waste
electrical and electronic equipment (WEEE).
3
MIDDLE

IMAGES
4MIDDLE

Fig. 2
Fig. 1 Fig. 1A
Fig. 3
Fig. 4 Fig. 5
5
MIDDLE

Fig. 6
Fig. 9 Fig. 10
6MIDDLE

Fig. 11
Fig. 12
7
MIDDLE

EN
Keep these instructions for use with the ap-
pliance. If the appliance should be sold or
passed on to others, make sure that the in-
structions are passed on with it. We thank you
for taking note of these suggestions before
installing and using the appliance. They have
been written for your personal safety and the
safety of others.
TO THE ATTENTION
OF THE USER
WARNING
● It is not allowed to cook food over open ames
(ambé) or operate gas hobs without pots or pans
on them under the hood itself (the ames sucked
into the hood might damage the appliance).
● Frying under the appliance must be done un-
der constant supervision as hot oils and fats may
ignite. Respect the guidelines for cleaning and re-
placement of grease lters. Accumulated deposits
of grease are a re hazard.
● This appliance must not be used over cook tops
powered by wood or coal or in any case, over cook
tops with power levels that could damage the ap-
pliance.
Never use steam or high-pressure devices for cle-
aning your hood (regulations regarding electrical
safety).
● Never use the cooker hood without the grease
lters.
Constantly seeking to improve our products, we
reserve the right to modify their technical, func-
tional, or aesthetic characteristics deriving from
their upgrading.
In the case of the version with external motor,
fornormal downdraft operation, it is necessary to
use a suctioning unit (external motor) made by the
same manufacturer.
The air collected must not be conveyed into a ue
used for smoke or fumes from appliances powered
by anything other than electricity (central heating
systems, etc.). As far as discharging exhaust air is
concerned, please follow the guide-lines given by
competent authorities.
SAFTEY INSTRUCTIONS
These hoods have been designed for personal
use in the home. The appliance must be used by
adults. Make sure that the appliance is out of re-
ach of children and that they do not use it to play
with. Make sure that children do not operate the
controls.
● When the appliance is delivered, check the ove-
rall appearance of the packaging.
Any remarks should be written on the delivery cou-
pon, of which you keep a copy.
Your appliance is designed for normal domestic
use. It is not designed for commercial or industrial
use, or for purposes other than those for which it
was designed.
● Any consequences of or damage from incorrect
installation or incorrect use of the appliance will not
be covered by the manufacturer’s guarantee.
● Do not ever change or try to change the charac-
teristics of this appliance. This would be a danger.
Repairs must be performed only by an authorised
technician.
Always disconnect the hood before carrying out
cleaning or maintenance operations.
● Adequately ventilate the room when a cooker ho-
odand other appliances, powered by energy other
than electricity, are used simultaneously, so that
the hood does not suck any combustion fumes.
It is designed to work in both suctioning mode,
with outside evacuation, and ltering mode.
8MIDDLE

EN
DESCRIPTION OF THE APPLIANCE ................................................................................... 10
INSTALLING THE PRODUCT ............................................................................................... 11
Grease lter removal, mounting the activated charcoal lter ............................................... 12
Electrical connection of the hood ......................................................................................... 12
HOW THE COOKER HOOD WORKS ................................................................................... 14
CLEANING THE PRODUCT ................................................................................................. 15
OPERATIONAL ANOMALIES ................................................................................................ 16
AFTER SALES SERVICE ...................................................................................................... 16
CONTENTS
9
MIDDLE

DESCRIPTION OF
THE APPLIANCE
EN
BACK AIR OUTLET
(Fitting supplied)
LOWER AIR OUTLET
(Supplied pipe)
MIDDLE SU-DD20
10 MIDDLE

EN
INSTALLING THE
PRODUCT
1.
2.
3.
4.
Secure the product inside the furniture by
using the specic brackets provided.
Proceed to the installation of the brackets in
the sides of the product, in the specic hoo-
ks, as shown in g. 4-5. Mount the rear bra-
ckets on both sides of the product, lift them up
until they touch the support cabinet and then
tighten the nuts “H” (g.4).
Then x the front bracket bringing it to touch
on the cabinet by tightening the screws “I”, as
shown in gure 5.
Be careful to pull the screws “I” gently, by
hand and without using electric screwdrivers,
otherwise you could damage the product.
If the Downdraft is equipped with external mo
tor, place the intake unit (external motor) and
settle the exhaust air duct.
Then t the air outlet ducts between the exter
nal motor and the product. Select the air out-
let among the two available options and t the
union supplied with the appliance.
If you intend to use the rear exit air, you will rst
have to remove the ange from product, install
the product in the furniture then restore the an-
ge as shown in g. 6.
For the installation of the external motor, refer to
the relative booklet.
Place the metal box containing the electronic
components in an easily reachable area for
possible technical assistance operations, by
connecting the related connectors (g. 7).
Connect the product to the external motor with
the 6-pole connector as shown in g. 8.
Connect the product to the power supply and
check that the red button is in the fully down
position (g.12).
After completing the installation and connec
ting the appliance to the power supply, activa
te the product as indicated in the “HOW THE
COOKER HOOD WORKS” part.
With the front panel open, install the grease l-
ters (g.9 “D”) complete with carbon lter (g.9
“E”) through the special grid (g.9 “C”), in case
of ltering version, while in case of suction
version, insert only the grease lter (g.9 “D”).
5.
6.
7.
8.
9.
10.
Before carrying out the appliance installation,
please check that all components are not da-
maged, in such a case contact your retailer
and do not carry out any installation operation.
Furthermore, please read carefully all of the
following installation instructions.
● Use an air exhausting pipe whose maximum
length does not exceed 5 meters.
● Limit the number of elbows in the piping, since
each elbow reduces the air capacity of 1 linear
meter. (Ex.: if you use no. 2 x 90° elbows, the
length of piping should not exceed 3 meters).
● Avoid abrupt direction changes.,
● Use a 150 mm. constant diameter pipe for
the whole length.
● Use piping approved by standards in force.
The manufacturer shall not be deemed re-spon-
sible for air capacity or noise problems caused
by failure to comply with the above instructions
and no warranty on the product shall be provided.
Before making the hole, check that there are
no structural or other parts inside the cabinet,
where the appliance is to be placed, which
could hinder a proper installation.
Check that the dimensions of the product and
the ones of the cook top are compatible with
the cabinet so that the installation can be car-
ried out properly.
Carry out a rectangular hole of the dimen-
sions of 490mm x A, (g. 1A), the dimension
A changes depending on the size of the hob.
The product is equipped with two angles to
support the hobs (g. 2), before installing the
product check the actual need for these com-
ponents and if not remove them by removing
the screws in g. 3.
Install the product in the hole drilled, inserting
it from above (Fig. 1).
11
MIDDLE

EN
HOW TO USE THE COOKER HOOD
This appliance is intended to suck cooking fumes,
greases and steam. It has been designed to work
in both suctioning mode, with outside evacuation,
and ltering mode.
Outside - discharge version
The cooker hood can be mounted in the version
with outside discharge of suctioned air: in this case
it is necessary to connect the exhausting channel
to the outside (exhausting pipes are not supplied
with the products.)
Filtering mode
In case fumes and vapour cannot be evacuated
outside, the appliance can be used in the ltering
mode.
Activated charcoal lters are required for this type
of cooker hood.
Air recycled conveyed outside furniture.
CAUTION
Installation must comply with the regulations
in force regarding the ventilation of enclosed
environments. The use of discontinued ducts
is not allowed without the approval of a quali-
ed technician.
REMOVAL OF GREASE FILTER, MOUNTING
THE CARBON FILTER (Fig.9)
The assembly and disassembly of grease lters
and carbon lters must be made with the down
draft in the open position. For this, actuate the
opening of the front as indicated by the operation
section.
Remove the grease lter (g.9 “D”), place the car-
bon lter (g.9 “E”) inside the special grid (g.9
“C”) and insert the grid on the grease lter using
special tabs.
If there is liquid inside the product, it is possible to
remove it by removing the caps located under the
hood housing (g.11).
Place the metal box containing the electronic
components at a distance of no less than 65
cm from cook tops or in any case, 65 cm from
the suctioning surface of the cookerhood.
ELECTRICAL CONNECTION
OF THE COOKER HOOD
WARNING
We recommend installing the metal box con-
taining the electronic components at least 10
cm above oor level and at a suitable distan-
ce from all heat sources (e.g. oven sides or
cook top).
NOTA
This appliance is tted with an H05 VVF 3 con-
ductor, 0.75 mm2 (neutral, phase, and ground)
power cord.
This can be connected up to a 220 - 240 V
mono-phase electrical network through a CEI
60083 approved power socket, which must
remain accessible after installation, in com-
pliance with installation regulations.
We decline any responsibility in case of ac-
cidents caused by a lack of ground connec-
tion or incorrect ground connection. The
appliance must be fed through a differential
protection device (RCD), with a nominal resi-
dual current not exceeding 30mA. If the power
cord is damaged, call the after-sales service
to avoid any risk.
CAUTION
After having replaced the lters, reinstall the
front stainless steel pan’el, otherwise the
Downdraft is not enabled to function.
WARNING
12 MIDDLE

EN
The downdraft connection to the electrica
nework must be carried out only by profes-
sional and qualied technicians.
The downdraft must be connected to a pro-
perly installed and suitable electrical network.
The electrical system must comply with
VDE0100 standard.
WARNING
If the cooker hood presents any anomaly, di-
sconnect the appliance or remove the fuse
corresponding to the appliance power di-
sconnecting line.
DANGER
If the appliance has no plug or if the plug is not
easily accessible, then a device needs to be tted
to cut it off from the electric network; this device
must have an opening distance between contacts
on all poles of at least 3 mm.
ELECTRICAL CONNECTION
This appliance complies with the European
Directives 2006/95/EC (Low Voltage Direc-
tive) and 2004/108/EC (Electromagnetic Com-
patibility).
NOTE
While installing the appliance and carrying main-
tenance operation, make sure it is disconnected
from the electrical network or the fuses are cut out
or removed.
Check that:
• Power is enough.
• Feeder lines (mains) are in good conditions.
• The cables diameter complies with
installation regulations.
13
MIDDLE

EN
6-Key push button panel (g.10)
A: 10 minutes timer, after which the suction motor
is turned off and the front is closed.
The setting of the function is signaled by indicator
ashing speed (B).
B: the suction motor speed indicator.
The 4 LEDs emit a RED light and light up accor-
ding to the set speed.
First speed : 1 LED ON
Second speed : 2 LEDs ON
Third speed : 3 LEDs ON
Fourth speed : 4 LEDs ON
C: the key is only active with open front (90°). For
each selection of the function there is an increase
of
the suction motor speed, up to the fourth speed.
D: the key is only active with open front (90°).
Each time you select the function you have a spe
ed decrease of the suction motor, up to the rst
speed.
E: with the product off, at the rst touch it
starts the opening of the front panel until it re-
aches the opening of 90°, once the opening is
reached the second speed of the suction motor
is automatically set.
Pressing the button further stops the intake
motor and closes the front panel completely.
HOW THE COOKER
HOOD WORKS
Other functions:
Automatic turn off:
After 4 hours of continuous operation from the last
setup, the appliance turns off automatically.
Grease lters saturation
After 30 hours of operation, the speed indica tors
“D” will all ash simultaneously, signaling the gre-
ase lters saturation. To reset this alarm, hold the
“TIMER” button down for at least 3 seconds, while
the extractable unit is open.
14 MIDDLE

EN
Careful maintenance ensures proper operation and good performances over time.
CLEANING THE
PRODUCT
The hood must be disconnected from the electrical network, both by unplugging the appliance
from the socket and activating the magnetic circuit breaker (safety cut-out), before removing the
metal grease lters. After cleaning operations, replace the metal grease lters as outlined in the
installation instructions.
CAUTION
MAINTENANCE HOW TO PROCEED? ACCESSORY PRODUCTS TO
USE
External surfaces and
accessories
Do not use metallic scrubbers, abra-
sive products, or hard brushes.
To clean the external surfaces of the
cookerhood and the light housing
screen use only commercially avail-
able household detergents diluted in
water. Then rinse with clean water
and dry with a soft cloth.
grease lter
Activated charcoal
lter
After 30 hours of operation, the
downdraft will signal the grease lter
saturation. Saturation is indicated
byashing RED color LED speed in-
dicator, when the cooker hood is off.
To reset, hold down the timer button
for at least 3 seconds, while the
hood is OFF.
In the recirculation mode, the active
charcoal lter must be replaced pe-
riodically.
To remove the charcoal lter rst of all
it is necessary to remove the grease
lter and then pull the plastic key of
the panel itself, in order to disengage
it from its seating.
Follow these steps in reverse order to
insert the active charcoal lter.
Replace the used charcoal lter on an
average of every six months.
The grease lters can be washed by
hand or in the dishwasher. These l-
ters need to be cleaned on a regular
basis, because otherwise they may
represent a re risk.
Ret the grease lters and front pa-
nel, making sure that the panis pro-
perly tted at the sides so that it it
does not cause the downdraft to stop
operating.
15
MIDDLE

EN
OPERATIONAL
ANOMALIES
PROBLEM SOLUTION
The cooker hood
does not work...
The cooker hood has
low performances...
The cooker hood
stops in the middle of
operation.
Check that:
● There is not a power outage.
● A specic speed has actually been selected.
● The red reset key, found over the electrical system box, is pushed.
Check that:
● The motor speed selected is sufcient for the quantity of fumes and
vapors present in the room.
● The kitchen is ventilated well enough to allow air for intake.
● The charcoal lter is not worn out.( ltering version cooker hood).
● The air outlet channel is free and compliant with paragraph no. 2.
● The non-return valves of the suctioning unit are free to rotate.
Check that:
● There is not a power outage.
● The omnipolar device has not tripped.
AFTER SALES SERVICE
Any maintenance operation on your appliance should be carried out by:
● Either your retailer;
● Or another qualied professional technician, authorized for that brand.
16 MIDDLE

Three Year Limited Warranty
YOU MUST REGISTER THE PURCHASE OF YOUR PRODUCT ON LINE AT
www.siriuscappe.com/usa/warranty.htm TO CONVALIDATE YOUR WARRANTY.
YOU CAN FIND THE DATA OF YOUR HOODS ON A LABEL INSIDE THE HOOD. JUST REMOVE
THE GREASE FILTER TO READ IT.
Sirius S.P.A.
Zona industriale Berbentina 6/A
60041 SASSOFERRATO (AN)
ITALY
Sirius after sale service
Telephone (toll free): 1-877-474-8770
Email: [e-mail]
Register Online! www.siriuscappe.com/usa/warranty.htm
WARRANTY SERVICE
To qualify for warranty service, you must notify Sirius After sale service at the email address
stated below or call toll free USA 1-877-474-8770 and provide the model number, description
of the fault or defect and original date of purchase. Sirius reserves the right to request proof
of original purchase. Sirius will at its sole option and discretion replace products that arrive
damaged through shipping, provided shipping damage is reported as stated above WITHIN 5
BUSINESS DAYS OF RECEIPT of the shipped product or products.
ONE YEAR SERVICE REPAIR WARRANTY:
During the rst year from date of original purchase, Sirius will, at its option, repair or replace, without
charge, any product or part which is found to be defective under normal use and service.
THREE YEAR PARTS WARRANTY:
For three years from date of purchase, Sirius will provide free of charge, non-consumable replacement
parts which are found to be defective under normal use and service.
WHO IS COVERED:
Sirius warrants to the original consumer purchaser of its products that such products will be free from
defects in materials and workmanship for a period of three years from the original date of purchase.
There are no other warranties, express or implied, including, but not limited to, implied warranties of
merchantability or tness for a particular purpose or application.
WHAT IS NOT COVERED:
This warranty does not extend to lters, lamps, batteries, ducts and ductwork components. This war-
ranty does not cover normal maintenance and service or products or parts which have been subject to
misuse, negligence, accident, improper maintenance or repair, faulty installation or installation contrary
to recommended installation instructions. The warranty on glass screens is limited to manufacturing
defects only and expressly excludes cracks and breakages as a result of faulty installation. Labor and
associated costs associated directly with removal and re-installation are expressly excluded.
The duration of any implied warranty is limited to the three year period as specied for the express
warranty. Some states and provinces do not allow limitation on how long an implied warranty lasts, so
the above limitation may not apply to you.

18 MIDDLE

19
MIDDLE

90009100200 - 03/20
