SMARTBoard® E70
SETUP AND MAINTENANCE GUIDE
FOR MODEL SPNL-4070

smarttech.com/kb/170534
Product registration
If you register your SMART product, we’ll notify you of new features and software upgrades.
Register online at smarttech.com/registration.
Keep the following information available in case you need to contact SMARTSupport.
Serial number:
Date of purchase:
Licenses
The terms HDMI and HDMI High-Definition Multimedia Interface, and the HDMI logo are trademarks or registered trademarks of HDMI Licensing LLC in the United
States and other countries
FCC warning
This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses and
can radiate radio frequency energy and, if not installed and used in accordance with the manufacturer’s instructions, may cause harmful interference to radio
communications. Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct the
interference at his own expense.
Trademark notice
SMARTBoard, SMARTNotebook, smarttech, the SMART logo and all SMART taglines are trademarks or registered trademarks of SMARTTechnologiesULC in
the U.S. and/or other countries. Windows is either a registered trademark or a trademark of Microsoft Corporation in the U.S. and/or other countries. All other
third-party product and company names may be trademarks of their respective owners.
Copyright notice
© 2013–2016SMARTTechnologiesULC. All rights reserved. No part of this publication may be reproduced, transmitted, transcribed, stored in a retrieval system
or translated into any language in any form by any means without the prior written consent of SMARTTechnologiesULC. Information in this manual is subject to
change without notice and does not represent a commitment on the part of SMART.
This product and/or use thereof covered by one or more of the following U.S. patents.
www.smarttech.com/patents
10/2016

i smarttech.com/kb/170534
Important information
WARNING
lFailure to follow the installation instructions shipped with theSMART product could result in
personal injury and product damage which may not be covered by the warranty.
lDo not open or disassemble the SMART product. You risk electrical shock from the high
voltage inside the casing. Opening the casing also voids the warranty.
lDo not stand (or allow children to stand) on a chair to touch the surface of the SMART
product. Rather, mount the product at the appropriate height.
lTo reduce the risk of fire or electric shock, do not expose the SMART product to rain or
moisture.
lIf the SMART product requires replacement parts, make sure the service technician uses
replacement parts specified by SMARTTechnologies or parts with the same characteristics
as the original.
lEnsure that any cables that cross the floor to the SMART product are properly bundled and
marked to avoid a trip hazard.
lUseonly extension cords and outlets that can fully accommodate this product’s polarized
plug.
lUse the power cable provided with this product. If a power cable is not supplied with this
product, please contact your supplier. Use only power cables that match the AC voltage of
the power outlet and that comply with your country’s safety standards.
lIf the glass is broken, do not touch the liquid crystal. To prevent injury, handle glass
fragments with care when disposing of them.
lUse only VESA®-approved mounting hardware.
lDo not insert objects inside the cabinet ventilation holes, because they could touch
dangerous voltage points and cause electric shock, fire or product damage which may not
be covered by the warranty.
lDo not place any heavy objects on the power cable. Damage to the cable could cause
shock, fire or product damage which may not be covered by the warranty.

IMPORTANT INFORMATION
ii smarttech.com/kb/170534
lDisconnect all the interactive flat panel's power cables from the wall outlet and seek
assistance from qualified service personnel if any of the following occurs:
oThe power cable or plug is damaged
oLiquid is spilled into the interactive flat panel
oObjects fall into the interactive flat panel
oThe interactive flat panel is dropped
oStructural damage, such as cracking, occurs
oThe interactive flat panel behaves unexpectedly when you follow operating
instructions

iii smarttech.com/kb/170534
Contents
Important information i
Chapter 1: About your interactive flat panel 1
Feature highlights 1
Included accessories 2
Chapter 2: Mounting your interactive flat panel 3
Choosing a mounting location 4
Choosing a mounting height 4
Cable management 4
Connecting your interactive flat panel 5
Configuring your computer’s screen resolution 6
Chapter 3: Using your interactive flat panel 9
Using the remote control 9
Using the control panel 12
On-screen display menu 13
Multi Media mode 14
Cleaning the interactive flat panel 16
Chapter 4: Troubleshooting your interactive flat panel 19
Locating the serial number 19
Resolving common touch control and resolution issues with Windows and Mac operating
systems 20
Resolving image issues 22
Appendix A: Configuring and calibrating your SMARTBoard E70 interactive flat panel with
Windows 23
Configuring your touch and display settings for the SMARTBoard E70 23
Appendix B: Calibrating your interactive flat panel with MacOSX 31
Calibrating your SMARTBoard E70 31
Appendix C: Hardware environmental compliance 33
Waste Electrical and Electronic Equipment and Battery regulations (WEEE and
BatteryDirectives) 33
Batteries 33
More information 33
Index 35

Chapter 1
1 smarttech.com/kb/170534
Chapter 1: About your interactive flat panel
Feature highlights 1
Included accessories 2
Pen and pen tray 2
Remote control 2
Included cables 2
This chapter describes the features of your SMARTBoard® E70 interactive flat panel and provides
information about product parts and accessories.
Feature highlights
Designed specifically for classrooms, the
SMARTBoard E70 interactive flat panel combines a
premium touch experience with the power of
SMARTNotebook® collaborative learning software
on a 70" display.
The high-definition, shadow-free 70" (177.8 cm) LED
display features low friction coated glass that
enables fingers to glide smoothly over the surface,
facilitating a natural touch experience. The interactive
flat panel also virtually eliminates glare and provides
an optimal view from any angle in the classroom,
delivering an unparalleled viewing and writing
experience to offer the best value for classrooms.
The multitouch interactive flat panel features freestyle multi-user interaction anywhere on the
display with Windows®7 or Windows8 operating systems, enabling students to collaborate
without limitations.

CHAPTER 1
ABOUT YOUR INTERACTIVE FLAT PANEL
2 smarttech.com/kb/170534
Included accessories
The following accessories are included with your interactive flat panel:
Pen and pen tray
Two pens are included with your interactive flat panel.
Remote control
The remote control enables you to access the on-screen menus and to change the display and
input settings.
Included cables
VGA - RGB video input
Power cable - AU/NZ, NA, UK and EU
USB cable - touch interface

Chapter 2
3 smarttech.com/kb/170534
Chapter 2: Mounting your interactive flat panel
Choosing a mounting location 4
Choosing a mounting height 4
Cable management 4
Connecting your interactive flat panel 5
Configuring your computer’s screen resolution 6
Recommended computer screen resolution 6
Windows 7 and Windows 8 operating systems 7
MacOSX operating system software 8
WARNING
The weight of the interactive flat panel is 169.8 lb. (77 kg), refer to your local building code to
ensure the wall and the mount being used can support this installation. Use appropriating
hardware in accordance to building code and always use 3 or more people to lift and install E70
interactive flat panel.
l
Model Weight (lb.) Weight (kg)
SPNL-4055 116 lb 13 oz 53 kg
SPNL-4065 153 lb 69.4 kg
l
Model Mounting plate
SPNL-4055 600 mm × 400 mm
SPNL-4065 600 mm × 400 mm
l
Model Screw length Fasten force
SPNL-
4055
25 mm where the total wall mount bracket and washer
thickness is less than 7 mm.
97.36–177.01 in-lb.
(11–20 N·m)
SPNL-
4065
30 mm where the total wall mount bracket and washer
thickness is less than 7 mm.
97.36–177.01 in-lb.
(11–20 N·m)

CHAPTER 2
MOUNTING YOUR INTERACTIVE FLAT PANEL
4 smarttech.com/kb/170534
Choosing a mounting location
Consider the following when you select a location for the interactive flat panel:
lThe wall must be strong enough to support the interactive flat panel and the mounting
equipment. The interactive flat panel weighs 169.8 lb. (77 kg).
lSelect a wall with a flat, regular surface and sufficient clearance to accommodate your
interactive flat panel. Mount the interactive flat panel in a location that’s central to your
audience’s viewing direction.
lChoose a location for the interactive flat panel that’s far from bright light sources, such as
windows and strong overhead lighting. IR lighting can cause issues with the performance of
the cameras and can lead to unintentional or missed touches.
For mobile or adjustable installation options, contact your authorized SMART reseller
(smarttech.com/where).
Choosing a mounting height
Consider the general height of the user community when you choose the height for the interactive
flat panel.
The flat panel height is based on the midpoint between the reach of the students and the teacher.
Cable management
When you connect cables to the interactive flat panel from a computer and other peripheral
devices, ensure that the cables aren’t a trip hazard. Use channels and raceways to safely secure
and hide cables. Contact your authorized SMART reseller for these accessories.

CHAPTER 2
MOUNTING YOUR INTERACTIVE FLAT PANEL
5 smarttech.com/kb/170534
IMPORTANT
Do not connect the power cable to a power outlet until you have connected all cables to the
interactive flat panel.
Connecting your interactive flat panel
The connector panel is at the bottom of the interactive flat panel.
NOTE
The power, PC-RGB (VGA) and USB cable are included with your interactive flat panel.
No. Connector Details
1 AC power AC power pass-through
2 USB B receptacle Computer to interactive flat
panel touch interface

CHAPTER 2
MOUNTING YOUR INTERACTIVE FLAT PANEL
6 smarttech.com/kb/170534
No. Connector Details
3 Video in Component video receptacle
4Service port WARNING
Do not use this connector.
This service connector for
the interactive flat panel
must be used only by a
qualified technician.
5 USBA Media port (see Multi media
mode)
6 Video in Composite video receptacle
7 Video in PC-RGB (VGA)
IMPORTANT
If you see flickering or the display is not sized correctly
pressing the Auto button will help with the adjustment
process. Ensure that you check and change E70 display to
recommended resolution for best performance.
8 Audio in Stereo 3.5 mm connector (from
computer)
9 Video in HDMI®
Configuring your computer’s screen resolution
When you connect a computer to the interactive flat panel, you may have to adjust the computer’s
screen resolution to achieve the best image quality and touch performance.
Recommended computer screen resolution
NOTE
SMARTrecommends using 1920 × 1080 or 1280 × 720 screen resolutions for best image quality
and touch performance.

CHAPTER 2
MOUNTING YOUR INTERACTIVE FLAT PANEL
7 smarttech.com/kb/170534
The table below lists the recommended computer screen resolutions for your interactive flat
panel:
1920 × 1080 *1280 × 768
1600 × 1200 1280 × 720 *
1280 × 1024 1024 × 768
1360 × 768 800 × 600
1280 × 960 640 × 480
The resolutions marked with an asterisk (*) are recommended for best image quality and touch
performance.
Windows 7 and Windows 8 operating systems
To configure your computer’s screen resolution
NOTE
This procedure varies depending on your version of the Windows operating system and your
system preferences.
1. Right-click the desktop and then select Screen Resolution.
2. Click Display > SMARTE70.
From the Display drop-down menu, select your interactive flat panel.
3. From the Resolution drop-down menu, select a screen resolution. See Recommended
computer screen resolution on the previous page for more information.
4. Click OK.
The computer applies the new screen resolution. See Configuring and calibrating your
SMART Board E70 interactive flat panel with Windows for setup and extended display
settings.

CHAPTER 2
MOUNTING YOUR INTERACTIVE FLAT PANEL
8 smarttech.com/kb/170534
MacOSX operating system software
To configure your Mac computer’s screen resolution
1. Select the Apple ( ) menu > System Preferences.
The System Preferences dialog box appears.
2. Click Displays.
3. Select a screen resolution from the list. Refer to Recommended computer screen resolution
on page6 for more information.
The computer applies the new screen resolution. See Calibrating your SMARTBoard E70
interactive flat panel with Mac OS X for setup and extended display settings.

Chapter 3
9 smarttech.com/kb/170534
Chapter 3: Using your interactive flat panel
Using the remote control 9
Using the control panel 12
On-screen display menu 13
Picture settings 13
Audio settings 13
Setup settings 14
Time settings 14
Multi Media mode 14
Compatible file formats 15
Video 15
Audio 15
Images 15
Cleaning the interactive flat panel 16
Preventing condensation 16
This chapter describes the basic operation and setup of your interactive flat panel.
Using the remote control
Use the remote control to access on-screen menus and to change the interactive flat panel’s
settings.

CHAPTER 3
USING YOUR INTERACTIVE FLAT PANEL
10 smarttech.com/kb/170534
No. Button Details
1 PC Selects the VGA input
2 HDMI Select the HDMI input
3 [Number buttons] Press buttons on the number pad to change channels
4 VOL +/- Increase or decrease the audio output level
5 [Up and down buttons] Select a menu option in the on-screen display menu
6 MENU Display the on-screen display menu

CHAPTER 3
USING YOUR INTERACTIVE FLAT PANEL
11 smarttech.com/kb/170534
No. Button Details
7 [Left and right buttons] lSelect an option in the on-screen display menu
lUse the right button to increase a value
lUse the left button to decrease a value
8 INFO Display the current video source
9 STILL Turn still picture mode on or off
10 AUTO Automatically adjusts the VGA video input
IMPORTANT
This automatically adjusts the image to match the
settings the display adapter is sending. In most cases,
this will solve touch issues. You can adjust the display
settings of the interactive flat panel if needed.
11 [Media buttons] For use in Multi Media mode
12 S.MODE Switch between stereo and mono sound
13 P.MODE Switch between color modes
14 EXIT Close the on-screen display menu
15 INPUT Switch video inputs
16 MUTE Mute the sound
17 CH +/- Change channels
18 P.SIZE Select the video aspect ratio
19 SLEEP Set the sleep timer
20 VIDEO Select the RCA input
21 Power Turns the interactive flat panel on or off
22 Multi Media button Display the Multi Media mode

CHAPTER 3
USING YOUR INTERACTIVE FLAT PANEL
12 smarttech.com/kb/170534
Using the control panel
Use the control panel on your interactive flat panel to access the on-screen display menu and
adjust settings.
No. Button Details
1 Power Turn the interactive flat panel on or turn off
2 UP Move the highlighted area up to select items in the on-
screen display menu
3 DOWN Move the highlighted area down to select items in the
on-screen display menu
4 VOL+ Move the highlighted area left to select items in the on-
screen display menu, increase the audio output level or
increase a value
5 VOL- Move the highlighted area right to select items in the on-
screen display menu, decrease the audio output level or
decrease a value
6 MENU Display the on-screen display menu
7 INPUT Select a video input for the interactive flat panel

CHAPTER 3
USING YOUR INTERACTIVE FLAT PANEL
13 smarttech.com/kb/170534
On-screen display menu
You can access the on-screen display (OSD) menu by pressing MENU on the side panel of your
interactive flat panel or on the remote control. To exit the OSD menu, press MENU on the
interactive flat panel's side panel, or press EXITon the remote control.
Picture settings
Option Value Function
Mode
Custom
Standard
Mild
Vivid
Sets the picture mode
Brightness 0-100 Sets the overall brightness of the image and background
Contrast 0-100 Sets the brightness of the image in relation to the background
Tint 0-100 Sets the tint of the screen
Color 0-100 Sets the image color intensity
Color Temp Normal
Warm
Cold
Sets the color temperature
Audio settings
Option Value Function
Surround [N/A] Turns the surround sound on or off
Sound Mode Music
Standard
User
News
Movie
Sets the audio mode
Auto
Volume
[N/A] Turns the automatic volume adjustment on or off

CHAPTER 3
USING YOUR INTERACTIVE FLAT PANEL
14 smarttech.com/kb/170534
Setup settings
Option Value Function
Menu
Language
[Languages] Sets the on-screen display menu’s language
Menu Trans. [N/A] Sets the on-screen display menu’s transparency
Screen
Mode
16:9
4:3
Zoom1
Zoom2
Sets the image size
Reset [N/A] Resets all Setup options
Software
Update
[N/A] NOTE
Software updates should be performed only by a system
administrator. Please contact your authorized SMARTreseller if
you require further assistance.
Time settings
Option Value Function
Time mode Automatic
Manual
Sets the time mode
Time [N/A] Sets the time manually
Sleep Time [N/A] Sets the sleep timer
On Timer [N/A] Turns on the On Time function
On Time [N/A] Sets a time when the interactive flat panel turns on
Volume 0-100 Sets the volume when the interactive flat panel turns on
Off Timer [N/A] Turns on the Off Time function
Off Time [N/A] Sets a time when the interactive flat panel turns off
Multi Media mode
You can play video files, view images and listen to music stored on a USB drive. Use the remote
control to pause, fast-forward and rewind videos.
