SMART Board™ 8070i
Interactive Display
Installation Guide

Trade-mark Notice
SMART Board, SMART Notebook, SMART Meeting Pro, smarttech and the SMART logo are trade-marks of SMART
Technologies ULC in the US and/or other countries. HDMI is a trade-mark or registered trade-mark of HDMI Licensing LLC.
All other third-party product and company names may be the trade-marks of their respective owners.
FCC warning
This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of
the US Federal Communications Commission Rules. These limits are designed to provide reasonable protection against
harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses
and can radiate radio frequency energy and, if not installed and used in accordance with the manufacturer’s instructions,
may cause harmful interference to radio communications. Operation of this equipment in a residential area is likely to
cause harmful interference in which case the user will be required to correct the interference at his own expense.
Patent list
US5448263; US6141000; US6320597; US6326954; US6337681; US6421042; US6563491; US6674424; US6741267;
US6747636; US6760009; US6803906; US6829372; US6919880; US6947032; US6954197; US6972401; US7151533;
US7184030; US7236162; US7289113; US7342574; US7379622; US7411575; US7499033; US7532206; US7619617;
US7626577; US7643006; US7692625; CA2058219; CA2252302; CA2386094; CA2453873; EP1297488; EP1739528;
ES2279823; JP4033582; JP4052498; JP4057200; ZL0181236.0; DE60124549; Other patents pending.
Copyright Notice
© 2011SMART Technologies ULC. All rights reserved. No part of this publication may be reproduced, transmitted,
transcribed, stored in a retrieval system or translated into any language in any form by any means without the prior
written consent of SMART Technologies ULC. Information in this manual is subject to change without notice and does
not represent a commitment on the part of SMART.
02/2011

Contents
Installing your interactive display 1
Components of your interactive display 1
Wall-mounting your interactive display 2
Installing the interactive display speakers 5
Cabling instructions for the interactive display 5
Connecting to power and to your room computer 6
Installing a guest laptop connection 7
Connecting external equipment to the bottom terminal panel 9
Turning on and turning off your interactive display 11
Installing SMART software 11
Hardware environmental compliance 15
Waste Electrical and Electronic Equipment regulations (WEEE directive) 15
Restriction of Certain Hazardous Substances (RoHS directive) 15
Batteries 15
Packaging 16
Covered electronic devices 16
China’s Electronic Information Products regulations 16
USConsumer Product Safety Improvement Act 16
California Air Resources Board – Airborne Toxic Control Measure 16
Restriction of Certain Chemicals (REACH directive) 17
Customer support 19
Online information and support 19
Training 19
Technical support 19
Dispatch and repair status 19
General inquiries 20
Warranty 20
Registration 20
i

Installing your interactive
display
Components of your interactive display
The following images identify the components of your interactive display.
Front view
Back view
I N S T A L L I N G Y O U R I N T E R A C T I V E D I S P L A Y
1

Wall-mounting your interactive display
Use a team of trained, professional installers equipped with a lifting device to install your
interactive display.
W W A R N I N G
lImproper installation can result in personal injury or product damage.
lYour interactive display weighs 119 kg (262 lb.). Refer to local building regulations to
ensure that your installation area can support this weight.
C C A U T I O N
Do not allow the weight of your interactive display to rest on the colour select module or the
bottom bezel because they are not designed to support product weight. Attach other
components whilst your interactive display is either still in its packaging or suspended from a
lifting device to prevent the weight of your interactive display from damaging the colour select
module.
I I M P OR T A N T
Save all product packaging so that it is available if you need to transport your interactive
display. If your original packaging is not available, you can purchase new product packaging
from your authorised SMART reseller.
Important mounting considerations for trained installers
Consider the following when mounting your interactive display on a wall:
lPlan your workflow to include cabling because some cable attachment points might not be
accessible post-installation.
I I M P OR T A N T
Speakers must be attached and speaker wires connected to your interactive display
before it is wall-mounted.
lTo wall-mount this interactive display, you require a standard VESA®400 mm × 400 mm
mounting plate, not included.
I N S T A L L I N G Y O U R I N T E R A C T I V E D I S P L A Y
2

lAttach the M12 eyebolts and washers included to assist in mounting.
W W A R N I N G
oIn order to aid in mounting or carrying, a lifting device must be used in conjunction
with the M12 attachable eyebolts. Do not attempt to mount or carry the display
using your own strength because the display may fall and cause personal injury.
oUse VESA-approved mounting hardware. Remove the M12 eyebolts after
installation.
lInspect the installation location to ensure that it can support the weight of your interactive
display.
lUse M8 screws to fasten the wall bracket. The length of the screws must be 14-15 mm
plus the thickness of the bracket and the washer. If using screws longer than 14-15 mm,
ensure sufficient depth.
lRecommended fasten force is 1125-1375 N·cm
lRefer to the instructions included with the mounting equipment for more detailed
information.
Selecting the mounting location
Consider the following when you select a location for your interactive display:
lThe wall must be strong enough to support your interactive display and the mounting
accessories. Your interactive display weighs 119 kg (262lb.).
lDo not install your interactive display in a location where a door or gate can hit it.
lDo not install your interactive display in an area where it will be subjected to strong
vibrations or dust.
lDo not install your interactive display near where the main power supply enters the
building.
I N S T A L L I N G Y O U R I N T E R A C T I V E D I S P L A Y
3

lDo not install your interactive display where people can easily grab and hang onto it or the
mounting apparatus.
lEnsure adequate ventilation or provide air conditioning around your interactive display so
that heat can flow away from the unit and mounting apparatus.
lWhen mounting your interactive display in a recessed area, such as in a wall, leave at least
10 cm (4") of space between your interactive display and the recess walls to ensure proper
ventilation.
Choosing the mounting height for your interactive display
Consider the heights of your users when choosing the mounting height for your interactive
display.
I N S T A L L I N G Y O U R I N T E R A C T I V E D I S P L A Y
4

Installing the interactive display speakers
Your interactive display comes with two 15 W speakers.
I I M P OR T A N T
Install the speakers on your interactive display before installing the interactive display on the
wall. Install the speakers whilst the interactive display is either still in its product packaging or
suspended from a lifting device.
Audio connection diagram
gTo connect the speakers
1. Attach the supplied speakers to the side of the interactive display with the included
screws.
2. Connect the speaker wires to the speaker connectors found on the right-hand side of the
back of your interactive display.
Cabling instructions for the interactive display
Your interactive display must be connected to a computer and a power source. The installed
computer connections consist of:
lA room computer connected to both the USB #1 and the VGA connector. This is the default
computer for the interactive display.
I N S T A L L I N G Y O U R I N T E R A C T I V E D I S P L A Y
5

lA guest laptop cable bundle connected to the USB #2 and RGB/HV connectors. The
cabling can be installed running to a remote location, such as a conference table. This
cabling is optional.
A wire bundle of these two connectors is not included with your interactive display, but is
available from your authorised SMART reseller. Refer to the interactive display
specifications document for ordering information.
You can switch inputs between your room computer and the guest laptop connection with the
input button in the front control panel or with the input button on the infrared remote control.
Connecting to power and to your room
computer
Your room computer is the default computer for your interactive display. Connect a VGA cable
and a USB cable from this computer to the VGA connector and USB #1 connector on your
interactive display.
Room computer connection diagram
gTo connect your interactive display to power and to your room computer
1. Connect the VGA cable included from your computer to the VGA connector on the terminal
panel.
I N S T A L L I N G Y O U R I N T E R A C T I V E D I S P L A Y
6
