SMART KAPP iQ PRO 65 User manual

smarttech.com/docfeedback/171136
1
Quick reference guide
This quick reference guide explains how to use your SMARTBoard® 8000 series interactive flat
panel and SMARTkapp iQ features.
Installing the SMARTkappiQ Pro interactive flat
panel
A number of resources are available to help you install the SMARTkapp iQ Pro 55, 65, 65-V2 or 75
interactive flat panel and SMART MeetingPro® software.
Installation guides
lSMARTkapp iQ Pro 55 and 65 installation instructions (smarttech.com/kb/170836)
lSMARTkapp iQ Pro 65-V2 installation instructions (smarttech.com/kb/171107)
lSMARTkapp iQ Pro 75 installation instructions (smarttech.com/kb/170996)
The textless installation guides provide step-by-step instructions for installing the SMARTkappiQ
Pro interactive flat panel. You can also watch the SMARTkappiQ Pro interactive flat panel
installation video for instructions (youtu.be/0y22vE0dm80).
Administrator’s guide
SMARTkapp iQ Pro administrator’s guide (smarttech.com/kb/171000)
The administrator’s guide provides the following information:
lMounting the interactive flat panel
lConnecting power and devices
lSetting up the interactive flat panel and room computer for the first time
lMaintaining and troubleshooting the interactive flat panel

QUICK REFERENCE GUIDE
SMART KAPP IQ PRO INTERACTIVE FLAT PANEL
2
SMART MeetingPro software administrator’s guide
SMART MeetingPro software administrator’s guide (smarttech.com/kb/170518)
The SMARTMeeting Pro administrator’s guide provides the following information about the
SMART MeetingPro software:
lCustomizing
lDeploying
lConfiguring
lUpdating
lUninstalling
Turning the board on
1. Turn on the room computer.
2. Flick the power switch beside the AC power inlet to the ON (I) position.
3. Press the Standby button on the front control panel.
Front control panel
The front control panel contains the Standby, Input
Select, Mute and volume control buttons.
Use the Input Select button to switch to the computer
that has SMARTMeeting Pro software installed.

QUICK REFERENCE GUIDE
SMART KAPP IQ PRO INTERACTIVE FLAT PANEL
3
Basic gestures
The SMARTkapp iQ board supports a variety of gestures within apps, including panning, scaling,
rotating and zooming in and out.
Zoom in Pan
Erase (with hand)
Zoom out Erase (with pen)
Cleaning
To clean the screen
1. Turn off any connected computers.
2. Press the Standby button on the front control panel twice.
3. Turn off the interactiveflatpanel by flicking the power switch beside the AC power inlet.
4. Wipe the screen with a lint-free, non-abrasive cloth.
Cleaning tips
lIf dry-erase markers are used on the screen, remove the ink as soon as possible with a lint-
free, non-abrasive cloth.
lDo not use cleaning solution or glass cleaner on the interactiveflatpanel screen, because
they can deteriorate or discolor the screen.

QUICK REFERENCE GUIDE
SMART KAPP IQ PRO INTERACTIVE FLAT PANEL
4
Switching modes
To present information, you can use board in computer mode and pick up the pen and start writing
without connecting your mobile device. If you want to save or share your notes, switch to
SMARTkapp iQ mode and connect your mobile device.
You can switch between your computer and SMARTkapp iQ mode by pressing the Input Select
button on the front control panel and selecting HDMI (computer and SMARTMeeting Pro
software) or OPS/HDMI2 (SMARTkapp iQ).
Using SMARTkapp iQ
SMARTkapp iQ is a whiteboard and a suite of apps that runs from an embedded appliance.
Designed specifically to complement individual, small group and whole-room collaboration,
SMARTkapp iQ fully integrates with mobile devices, including tablets, smartphones, laptops and
Chromebooks.
Using the launcher
The launcher contains all your apps and settings.
To open the launcher
Press the Home button on the screen.
The launcher appears.
To close the launcher
Select an app, press the Home button or tap anywhere on the screen.
The launcher closes.
Using the Whiteboard
You can draw on the Whiteboard with the pen and use basic gestures to manipulate
content. SMART Ink is available only while using the Input app and when SMARTProduct
Drivers is installed on the connected computer.

QUICK REFERENCE GUIDE
SMART KAPP IQ PRO INTERACTIVE FLAT PANEL
5
To use the Whiteboard with your mobile device
Task Solution
Before you connect
to a session
Ensure you’ve downloaded the SMARTkapp app from the App Store or
Google Play™
Connect and start a
session
1. Start the SMARTkapp app on your mobile device.
2. Hold the mobile device’s rear facing camera to the board’s QR code
until the QRcode appears in the center of the app.
TIPS
oConnect your mobile device to the board as soon as you
enter the classroom, as only one mobile device can be
connected to the board at a time.
oTo disconnect a student’s device from the board, press
Disconnect on the board.
Save a snapshot of a
session
Connect to the board and press Capture on the board or in the
SMARTkapp app.
View a snapshot To view a saved snapshot on your mobile device, tap Sessions and tap
the thumbnail to view it.
Sharing a snapshot 1. View a snapshot on your mobile device.
iOS device: Tap Export and then select Save to Camera Roll or
Share as PDF.
Android device: Tap Menu and then select Share as Image or
Share as PDF.
Invite others to a
session (up to 250
people)
1. Connect your mobile device to the board.
2. From the SMARTkapp app, tap Invite and then select Send Link.
3. Select the app you want to use to send the invitation.
When others connect, remote participants can use their own device or
SMARTkapp iQ board to add content to the session.
To erase all notes on the Whiteboard
NOTE
Not all SMARTkapp iQ models have the Whiteboard Library enabled.

QUICK REFERENCE GUIDE
SMART KAPP IQ PRO INTERACTIVE FLAT PANEL
6
1. Press the Erase All icon.
2. Press Yes, Save it to save the Whiteboard session to the Library and erase the Whiteboard.
OR
Press No, discard it to erase the Whiteboard. The session isn’t saved to the Library.
OR
Press Cancel to return to the Whiteboard. Your notes are not erased.
Using the Whiteboard Library
The Whiteboard Library stores Whiteboard sessions on the AM30 appliance. You can open the
Library and continue a saved session on the board.
Using the Browser
You can use a web browser on the SMARTkapp iQ board.
Using Input
You can display content from your computer on the board when you connect a
computer to the AM30 appliance. To take full advantage of the board’s touch and ink
features, download and install SMARTsoftware:
smarttech.com/en/Home+Page/Support/Browse+Support/Download+Software.
To display content on the board
NOTE
Make sure the OPS/HDMI input source is selected.
1. Connect a computer to the AM30 appliance’s HDMI in and USB receptacles.
2. Open the launcher.
The launcher appears.
3. Press Input .
The board detects the connection.
4. The computer’s desktop appears on the screen.

QUICK REFERENCE GUIDE
SMART KAPP IQ PRO INTERACTIVE FLAT PANEL
7
Using Screen Share
You can share content wirelessly on the SMARTkapp iQ board from your computer or
mobile device. Make sure the board and your mobile device or computer are on the
same network.
IMPORTANT
For more information about the Screen Share app, see the SMARTkapp iQ user’s guide
(smarttech.com/en/kb/170812) or visit the support page
support.smarttech.com/en/hardware/kapp.
To share content using the Chrome browser
1. On the board, open the launcher.
The launcher appears.
2. Press Screen Share .
3. On your computer, open the Chrome browser.
4. Open the tab you want to share on the board.
5. In the top right corner of your browser, click the Cast icon .
6. Select the board’s name.
When you’re sharing content, the Cast icon turns blue.
NOTE
For troubleshooting tips for the Chrome browser, see
support.smarttech.com/docs/hardware/kapp/kapp-iq/en/troubleshooting/screenshare-
troubleshooting/more-screensharing-troubleshooting_Chrome.cshtml.
To share content from a Windows computer
You can use the Chrome browser to share content from your Windows computer. See To share
content using the Chrome browser above.
You can purchase AirParrot, an application that allows you to share your display, a single
application or a media file. See airsquirrels.com/airparrot/features/win.

QUICK REFERENCE GUIDE
SMART KAPP IQ PRO INTERACTIVE FLAT PANEL
8
NOTE
For troubleshooting tips for Screen Share on a Windows computer, see
support.smarttech.com/docs/hardware/kapp/kapp-iq/en/troubleshooting/screenshare-
troubleshooting/more-screensharing-troubleshooting_Windows.cshtml.
To share content from an Apple device
NOTE
For troubleshooting tips for an Apple product, see
support.smarttech.com/docs/hardware/kapp/kapp-iq/en/troubleshooting/screenshare-
troubleshooting/more-screensharing-troubleshooting_Apple.cshtml.
1. On the SMARTkapp iQ board, open the launcher.
The launcher appears.
2. Press Screen Share .
3. On your Mac computer, click the Airplay icon in the menu bar.
4. Select the board’s name.
The Airplay icon turns blue when your Mac computer is sharing content with AirPlay.
To share content from an Android mobile device
1. Download the Google Cast app from Google Play.
2. On the board, open the launcher.
The launcher appears.
3. Press Screen Share .
4. On your Android mobile device, open the Google Cast app.
5. In the top left corner, press the navigation drawer .
6. Press Cast Screen.
7. Select the board’s name.
If you don’t see the board you want, press MORESETTINGS to show more boards.

QUICK REFERENCE GUIDE
SMART KAPP IQ PRO INTERACTIVE FLAT PANEL
9
NOTE
For troubleshooting tips for an Android mobile device, see
support.smarttech.com/docs/hardware/kapp/kapp-iq/en/troubleshooting/screenshare-
troubleshooting/more-screensharing-troubleshooting_Android.cshtml.
To stop sharing content to the board
TIP
You can disconnect your mobile device or computer to stop sharing content to the board.
1. Tap the board.
The overlay appears.
2. In the top right corner of the screen, press .
3. The message “Want to disconnect?” appears. Press Yes.
Using SMART MeetingPro
SMART MeetingPro software is an easy-to-use whiteboard application that enhances your
meeting productivity and collaboration. Use SMART MeetingPro to enrich brainstorming sessions,
meetings and presentations. The following section shows you how to work with SMART
MeetingPro.
Switch display
modes
Switch display modes to access SMART MeetingPro’s collaboration
features. Follow these steps:
1. On the front of the SMARTkappiQ Pro interactive flat panel, press
and select HDMI1.
The log on screen appears.
NOTE
To return to SMARTkappiQ, press and select OPS/HDMI.
2. Enter your log on credentials.
Your Windows desktop appears with the SMART MeetingPro toolbar.

QUICK REFERENCE GUIDE
SMART KAPP IQ PRO INTERACTIVE FLAT PANEL
10
Use the pen tools Similar to SMARTkappiQ, you can pick up one of the provided pens and
draw on the interactive flat panel. However, in SMART MeetingPro, you have
access to the SMARTInk™ dynamic toolbar. This toolbar lets you change the
properties of the pen while you’re in SMART MeetingPro mode. You can
change:
lPen type
lColor
lLine style
lLine start
lLine end
lThickness
lTransparency
NOTE
The available properties depend on the pen type that you select.
To open the dynamic toolbar for one of the pens, just pick up one of the pens
and the dynamic toolbar will appear. When you first open the dynamic
toolbar, it appears minimized. To view the toolbar in full mode, press it.
Minimized dynamic toolbar
Expanded dynamic toolbar
For more information, see the SMART MeetingPro software user’s guide
(smarttech.com/kb/170897) or SMART MeetingPro Help
(bit.ly/meetprohelp4_1).

QUICK REFERENCE GUIDE
SMART KAPP IQ PRO INTERACTIVE FLAT PANEL
11
Use the
whiteboard
Use Whiteboard mode to create presentations and compile information for
meetings. You can write notes and draw objects, manipulate text and images
and work with information you captured from other applications. When you’re
done, you can present your file or email your file to meeting participants.
Use the desktop Use Desktop mode to interact with the room computer’s applications. You
can write or draw digital ink over computer applications using SMARTInk™
while presenting content to others.
More information See the SMART MeetingPro software user’s guide
(smarttech.com/kb/170897) or visit SMART MeetingPro Help
(bit.ly/meetprohelp4_1) for more detailed information about using SMART
MeetingPro software.

QUICK REFERENCE GUIDE
SMART KAPP IQ PRO INTERACTIVE FLAT PANEL
12
Connecting computers to the SMARTkapp iQ
Some models of the AM30 appliance include computer connectors. To
the board’s touch features and use a pen to draw and write, follow
these steps:
By connecting a computer to the AM30 appliance instead of the board,
you can quickly switch between the computer and other SMARTkapp
iQ features.
NOTE
If the computer you’re connecting has SMARTInk and SMART Product Drivers installed, you can
write and draw on the board.
1. Connect a computer to the AM30 appliance using USB and HDMI cables.
2. Download and install SMARTProduct Drivers and SMARTInk on your computer. See
smarttech.com/us/Support/Browse+Support/Download+Software.
3. Use the Input app.
NOTE
When you connect a computer to the AM30 appliance, make sure the input source is OPS/HDMI.
Resolving touch and video issues
If you’re having touch or video issues, ensure the USB and HDMI cables connecting the room
computer to the interactive flat panel are secure. The USB cable controls touch, and the HDMI
cable controls the video.

QUICK REFERENCE GUIDE
SMART KAPP IQ PRO INTERACTIVE FLAT PANEL
13
Resources
Resource URL
Support page support.smarttech.com/hardware/kapp
User’s guides and online help lSMARTkappiQ Pro user’s guide
(smarttech.com/kb/171128)
lSMART MeetingPro software user’s guide
(smarttech.com/kb/170897)
lSMART MeetingPro software Help
(bit.ly/meetprohelp4_1)
FAQs and quick reference guides lSMARTkappiQ FAQs (smarttech.com/kb/170954)
lSMARTkappiQ security information
(smarttech.com/kb/170956)
lSMART MeetingPro quick reference
(smarttech.com/kb/170976)
Training lTechnical training (
support.smarttech.com/docs/training/technical/kapp/
kapp-iq-pro/kapp-iq-pro.htm)
lTraining for SMART visual collaboration solutions
(bit.ly/training4businessSMART)
Installation and administration
guides
lSMARTkappiQ Pro 55 and 65 installation instructions
(smarttech.com/kb/170836)
lSMARTkappiQ Pro 65-V2 installation instructions
(smarttech.com/kb/171107)
lSMARTkappiQ Pro 75 installation instructions
(smarttech.com/kb/170996)
lSMART MeetingPro software system administrator’s
guide (smarttech.com/kb/170518)
Troubleshooting lKnowledge base and communities
(community.smarttech.com)
lSMARTkappiQ troubleshooting guide
(bit.ly/kappiQtrouble)
Specifications lSMARTkappiQ Pro 55 specifications
(smarttech.com/kb/170994)
lSMARTkappiQ Pro 65 specifications
(smarttech.com/kb/170995)
lSMARTkappiQ Pro 65-V2 specifications
(smarttech.com/kb/171093)
lSMARTkappiQ Pro 75 specifications
(smarttech.com/kb/170997)
lSMART MeetingPro 4 release notes
(smarttech.com/kb/170982)

QUICK REFERENCE GUIDE
SMART KAPP IQ PRO INTERACTIVE FLAT PANEL
14
smarttech.com/support
smarttech.com/contactsupport
© 2017SMARTTechnologiesULC. All rights reserved. SMARTBoard, smarttech, the SMART logo and all SMART taglines are trademarks or registered
trademarks of SMARTTechnologiesULC in the U.S. and/or other countries. All third-party product and company names may be trademarks of their respective
owners. Contents are subject to change without notice. 01/2017.
