SMC Networks IZG10 User manual

Blow setting function p. 1
Select from continuous blow or pulse blow.
Trigger setting function p. 1
Trigger linked/Trigger lock/OFF timer can be selected.
Flow rate adjustment function p. 2
Flow adjustment valve with indicator enables handheld
flow adjustment.
Lighting LED
Reduced operating force
Easy to hold grip
*1 Distance: 150 mm,
Operating pressure: 0.2 MPa
Rapid static
neutralization
0.3 s*1
*1 Body weight
*1
Lightweight
200 g
Only
CAT.ES100-134A
IZG10 Series
Gun Type Ionizer

MTrigger lock
Trigger operation turns Blow
ON. Blow remains ON until
another trigger input turns
Blow OFF.
MTrigger linked
Trigger ON/OFF and Blow ON/
OFF are linked.
MContinuous blow
Blows ionized air continuously.
MPulse blow
Pulse blow saves air.
Product
operation
Trigger
Blow
ON
OFF
ON
OFF
Continuous blow or pulse blow
Timer set time (3, 5, 7 s)
Continuous blow or pulse blow
Continuous blow or pulse blow
Product
operation
Trigger
Blow
ON
OFF
ON
OFF
Product
operation
Trigger
Blow
ON
OFF
ON
OFF
Selection of trigger setting
Mode setting switch
Selection of blow setting
Blow and trigger setting can be selected.
Set no. Blow setting Trigger setting
0
Continuous blow
Trigger linked
1 Trigger lock
2
OFF timer
3 s
3 5 s
4 7 s
5
Pulse blow
Trigger linked
6 Trigger lock
7
OFF timer
3 s
8 5 s
9 7 s
MOFF timer
Trigger operation turns Blow
ON. Blow remains ON for set
time then automatically turns
OFF.
Timer set time: 3 s, 5 s, 7 s
1
3
5
1
2
Trigger
Lighting
LED
p. 9
4
1
Gun Type Ionizer IZG10 Series

q Turn
counterclockwise.
w Pull forward
to remove.
q Turn
counterclockwise.
w Pull forward
to remove.
¡ Flow rate of ionized air can be adjusted on the gun.
¡ The flow rate can be controlled numerically.
Number of needle rotations Flow rate [L/min (ANR)]
2 21
4 60
6 124
7 200
Supply pressure: 0.4 MPa
With flow adjustment valve (with indicator)
Lighting LED
Easy cleaning and replacement of emitters
High visibility LEDs
qRemoval of nozzle wRemoval of emitter
Direction q
Direction w
3
5
2
4
Power ON Ion generation
Incorrect high voltageMaintenance indicator
Turns ON when lowered
static neutralization perfor-
mance due to the contami-
nation, wear, or breakage
of the emitter is detected.
Rear mounted LEDs are
easy to see during operation.
Turns ON when a high
voltage output error, such
as emitter short circuit or
abnormal discharge oc-
curs.
Easy to find particles on the workpiece
2
Gun Type Ionizer IZG10 Series

Application Examples
For the static neutralization and
dust removal of resin parts
For the static neutralization and
dust removal of resin parts
For the dust removal of resin
products
For the static neutralization and
dust removal of electric substrates
For the dust removal when
detaching from film
For the static neutralization and
dust removal of resin parts with the
ionizer suspended from above
Technical Data: Static Neutralization Characteristics
qInstallation Distance and Discharge Time p. 4
w Static Neutralization Range p. 5
e Pressure — Flow Rate Characteristics p. 6
How to Order p. 7
Accessories (for Individual Parts) p. 7
Specifications p. 8
AC Adapter Specifications p. 8
Parts Description p. 8
CONTENTS
Description of LED Indicators p. 8
Alarm p. 8
Mode Switch Setting p. 9
Wiring p. 9
Dimensions p. 10
Related Products p. 11
Specific Product Precautions p. 12
Safety Instructions Back cover
Gun Type Ionizer IZG10 Series
3
Gun Type Ionizer IZG10 Series

IZG10 Series
Technical Data
qInstallation Distance and Discharge Time (Discharge Time from 1000 V to 100 V)
Static Neutralization Characteristics
*Static neutralization characteristics are based on data using a charged plate
(dimensions: 150 mm x 150 mm, capacitance: 20 pF) as defined in the U.S. ANSI
standards (ANSI/ESD STM3.1-2015). Use this data only as a guideline for model
selection because the values vary depending on the material and/or size of the subject.
Installation distance [mm]
Discharge time [s]
50 100 1500
5.0
4.5
4.0
3.5
3.0
2.5
2.0
1.5
1.0
0.5
0.0
0.05 MPa
0.2 MPa
0.1 MPa
0.3 MPa
0.4 MPa
0.5 MPa
0.6 MPa
Installation distance [mm]
Discharge time [s]
50 100 1500
8.0
7.0
6.0
5.0
4.0
3.0
2.0
1.0
0.0
0.05 MPa
0.2 MPa
0.1 MPa
0.3 MPa
0.4 MPa
0.5 MPa
0.6 MPa
Installation distance [mm]
Discharge time [s]
15000 150 300 450 600 750 900 1050 1200 1350
5.0
4.5
4.0
3.5
3.0
2.5
2.0
1.5
1.0
0.5
0.0
0.05 MPa
0.1 MPa
0.2 MPa
0.3 MPa
0.4 MPa
0.5 MPa
0.6 MPa
Installation distance [mm]
Discharge time [s]
15000 150 300 450 600 750 900 1050 1200 1350
8.0
7.0
6.0
5.0
4.0
3.0
2.0
1.0
0.0
0.05 MPa 0.1 MPa
0.2 MPa
0.3 MPa
0.4 MPa
0.5 MPa
0.6 MPa
Installation distance [mm]
Discharge time [s]
50 100 150 2000
5.0
4.5
4.0
3.5
3.0
2.5
2.0
1.5
1.0
0.5
0.0
0.05 MPa
0.2 MPa
0.1 MPa
0.3 MPa
0.4 MPa
0.5 MPa0.6 MPa
Installation distance [mm]
Discharge time [s]
50 100 150 2000
0.05 MPa
0.2 MPa
0.1 MPa
0.3 MPa
0.4 MPa0.5 MPa0.6 MPa
8.0
7.0
6.0
5.0
4.0
3.0
2.0
1.0
0.0
Installation distance [mm]
Discharge time [s]
150 300 450 6000
5.0
4.5
4.0
3.5
3.0
2.5
2.0
1.5
1.0
0.5
0.0
0.05 MPa
0.2 MPa
0.1 MPa
0.3 MPa
0.4 MPa
0.5 MPa0.6 MPa
Installation distance [mm]
Discharge time [s]
150 300 450 6000
0.05 MPa
0.2 MPa
0.1 MPa
0.3 MPa
0.5 MPa
0.6 MPa 0.4 MPa
8.0
7.0
6.0
5.0
4.0
3.0
2.0
1.0
0.0
1) Number of needle rotations [2]
5) Number of needle rotations [2]
4) Number of needle rotations [Max.]
8) Number of needle rotations [Max.]
2) Number of needle rotations [4]
6) Number of needle rotations [4]
3) Number of needle rotations [6]
7) Number of needle rotations [6]
Mode setting switch: Continuous blow
Mode setting switch: Pulse blow
4

wStatic Neutralization Range (Discharge Time from 1000 V to 100 V)
Static Neutralization Characteristics
Distance [mm]
1500 0 150 300 450 600 750 900 1050 1200 1350
200
150
100
50
−50
−100
−150
−200
0.5 s 1 s 1.5 s 2 s 2.5 s
Distance [mm]
1500 0 150 300 450 600 750 900 1050 1200 1350
200
150
100
50
−50
−100
−150
−200
0.5 s 1 s 1.5 s 2 s
2.5 s
Distance [mm]
1500 0 150 300 450 600 750 900 1050 1200 1350
200
150
100
50
−50
−100
−150
−200
0.5 s 1 s 1.5 s
2 s
Distance [mm]
1500 0 150 300 450 600 750 900 1050 1200 1350
200
150
100
50
−50
−100
−150
−200
0.5 s 1 s
1.5 s
Distance [mm]
1500 0 150 300 450 600 750 900 1050 1200 1350
200
150
100
50
−50
−100
−150
−200
0.5 s 1 s 1.5 s 2 s 2.5 s
Distance [mm]
1500 0 150 300 450 600 750 900 1050 1200 1350
200
150
100
50
−50
−100
−150
−200
0.5 s 1 s 1.5 s
2 s
Distance [mm]
1500 0 150 300 450 600 750 900 1050 1200 1350
200
150
100
50
−50
−100
−150
−200
0.5 s 1 s
1.5 s
1) Supply pressure: 0.05 MPa Flow rate consumption: 80 L/min (ANR)
3) Supply pressure: 0.2 MPa Flow rate consumption: 188 L/min (ANR)
5) Supply pressure: 0.4 MPa Flow rate consumption: 316 L/min (ANR)
7) Supply pressure: 0.6 MPa Flow rate consumption: 450 L/min (ANR)
2) Supply pressure: 0.1 MPa Flow rate consumption: 119 L/min (ANR)
4) Supply pressure: 0.3 MPa Flow rate consumption: 253 L/min (ANR)
6) Supply pressure: 0.5 MPa Flow rate consumption: 390 L/min (ANR)
Mode setting switch: Continuous blow, Number of needle rotations [Max.]
*Static neutralization characteristics are based on data using a charged plate
(dimensions: 150 mm x 150 mm, capacitance: 20 pF) as defined in the U.S. ANSI
standards (ANSI/ESD STM3.1-2015). Use this data only as a guideline for model
selection because the values vary depending on the material and/or size of the subject.
5
IZG10 Series

ePressure — Flow Rate Characteristics
Static Neutralization Characteristics
How to measure
Pressure [MPa]
Flow rate [L/min (ANR)]
0.1 0.2 0.3 0.4 0.5 0.60
500
450
400
350
300
250
200
150
100
50
0
Flow setting: Max. Flow setting: 7
Flow setting: 6
Flow setting: 4
Flow setting: 0
Flow setting: 2
Air supply
measurement
Pressure
measurement
Connecting tube:
O.D. ø8 x I.D. ø5, 50 mm
Mode setting switch: Continuous blow
*Static neutralization characteristics are based on data using a charged plate
(dimensions: 150 mm x 150 mm, capacitance: 20 pF) as defined in the U.S. ANSI
standards (ANSI/ESD STM3.1-2015). Use this data only as a guideline for model
selection because the values vary depending on the material and/or size of the subject.
6
Technical Data IZG10 Series

How to Order
Accessories (for Individual Parts)
Gun Type Ionizer
IZG10 Series
IZG10 08 01 01
RoHS
One-touch fitting
Symbol Applicable tubing O.D.
08 ø8 (Metric)
09 ø5/16" (Inch)
AC adapter, Power supply cable
Symbol Type
01 AC adapter (With AC cord*1)
02 AC adapter (Without AC cord)
03 Power supply cable (For 24 VDC wiring)
*1 AC cord is only for use in Japan. (Rated voltage
125 V, Plug JIS C 8303, Inlet IEC 60320-C13)
M2IZS30 A0201IZS30
(10 replacement felt pads)(With 1 felt pad, 1 rubber
grindstone, and 2 replacement
felt pads)
A0202IZS30
(1 replacement rubber grindstone)
Felt pad Rubber
grindstone
AC adapter
Power supply cable (For 24 VDC wiring)
Emitter assembly Cleaning kit
Nozzle assembly
IZG10
IZG10
IZG10
IZG10
CG
CP
NT
A001 01
AC adapter
1With AC cord*1
2Without AC cord
*1 AC cord is only for use in Japan. (Rated voltage
125 V, Plug JIS C 8303, Inlet IEC 60320-C13)
AC cord
AC adapter body
The nozzle is specific for this product. Do not use any other nozzle. Doing so will adversely affect static neutralization performance.
Caution
Power supply cable
(For AC adapter)
Cable length: 3 m
Cable length: 3 m
*A protective cap is attached to the tip of the emitter when shipped.
Please remove the cap before use.
7

Specifications
Parts Description
Description of LED Indicators
AC Adapter Specifications
Input voltage*4100 to 240 VAC
50/60 Hz
Output voltage 24 VDC ±5%
Output current 0.8 A max.
Ambient
temperature 0 to 40°C
Ambient humidity 20 to 80% Rh
Standards/
Directive CE, cUL
*4 The AC cord included with the AC adapter is
only for use in Japan. (Rated voltage 125 V,
Plug JIS C 8303, Inlet IEC 60320-C13)
LED Indicators
No. Display LED color Description Contents
qPWR Green Power supply
indicator
Green LED turns ON when power is supplied, and the LED
flashes when the voltage is outside of the specification range.
wION/
HV
Green/
Red
Static neutralization
operation/Incorrect
high voltage indicator
Green LED turns ON during static neutralization.
Red LED turns ON when a high voltage abnor-
mality is present.
eNDL Green Maintenance
indicator
Green LED turns ON when lowered static
neutralization performance due to the con-
tamination or wear of the emitter is detected.
wq e
w r
y
t
u
q
Ionizer model IZG10
Ion generation method Corona discharge type
Method of applying high voltage High frequency AC type
Applied voltage*1±2.5 kV
Offset voltage*2Within ±10 V
Air supply*3
Fluid Air (Clean dry air)
Operating pressure 0.05 to 0.6 MPa
Connecting tube size ø8 (Metric), ø5/16" (Inch)
Power supply voltage 24 VDC ±10% (21.6 to 26.4 V)
Current consumption 90 mA (typ.)
Ambient temperature 0 to 40°C (No freezing)
Ambient humidity 35 to 65% Rh (No condensation)
Material Case: PBT Emitter: Tungsten
Weight (Body only) 200 g
Standards/Directive CE
*1 Measured with a high pressure probe of 1000 MΩand 5 pF
*2 Measurement value based on a charged plate (dimensions: 150 mm x 150 mm, capacitance:
20 pF) as defined in the U.S. ANSI standards (ANSI/ESD STM3.1-2015)
The distance between the charged plate and the ionizer: 150 mm, the operating pressure is
0.2 MPa.
*3 Static neutralization is not possible without supplying compressed air. Without compressed
air, ozone or NOx generated by the ion generation process may accumulate and adversely
affect the product and peripheral equipment.
No. Description Contents
qNozzle Discharge ionized air
wSlide cover
Protective cover for the mode setting switch
eMode setting
switch
Switch for setting blow and trigger
(Default setting: Set no. 0)
r
Flow adjustment
knob (With indicator)
Turn the knob to adjust the flow rate.
Press the knob to lock the setting.
tTrigger
Switch to turn on and off static neutralization
yOne-touch fitting Supply port of compressed air
uPower supply
connector
Connector for power supply, F.G., and
external switch inputs
iLighting LED
Illuminate the object during static neutralization
LED indicator
i
*Inside of the slide cover
e
Alarm
The LEDs are used for notification of malfunctions.
Note that ion generation may either continue or stop depending on the type of abnormality.
Alarm name Ion generation LED Description Action to reset
alarm
PWR ION/HV NDL
Power supply failure Stop Green (Flashing) OFF OFF Connected power supply voltage is outside of specification. Supply power again.
Incorrect high voltage Stop Green (ON) Red (ON) OFF The high voltage output has dropped. Supply power again.
CPU failure Stop Green (Flashing) Red (Flashing) Green (Flashing) CPU error due to noise, etc. Supply power again.
Maintenance
indication Continue Green (ON) — Green (ON)
When static neutralization performance is reduced
due to contamination, wear, or damage of the emitters
—
8
Gun Type Ionizer IZG10 Series

Wiring
Mode Switch Setting
Power Supply Cable Wiring
Identification color Signal name Description
Red DC (+) Connect the power supply (+) terminal.
White
External switch signal*1 Blow starts by connecting to DC (–).
Green F.G.
Frame ground of the product: Connect to Ground with resistance of 100 Ωor less.
Black DC (–) Connect to the power supply (–) terminal.
Blow or trigger setting can be selected by using the mode setting switch.
Open the slide cover and using a flat bladed screwdriver rotate the dial to select the setting number 0 to 9, referring to the table below.*1
Ensure the slide cover is closed when setting is complete.
*1 Default setting: Set no. 0
Table for Mode Setting Switch
Set no. Blow setting Trigger setting
0
Continuous
blow
Trigger linked
1 Trigger lock
2
OFF timer
3 s
3 5 s
4 7 s
5
Pulse blow
Trigger linked
6 Trigger lock
7
OFF timer
3 s
8 5 s
9 7 s
Mode setting switch
Slide
AC adapter type IZG10-m01, 02
·Connect the M8 connector on the power cable for AC adapter to the power connector on the main unit. Connect the plug of the AC
cord*1to a commercial power outlet with a ground terminal (100 to 240 VAC, 50/60 Hz).
·Ensure the ground terminal is correctly connected. The ground terminal is connected to the frame ground (F.G.) of this product. Static
neutralization performance is achieved by using the F.G. connection to maintain the same electrical potential as the reference potential
of the operating environment.
·The input ground terminal and the output DC (−) terminal of the AC adapter (IZG10-CG1, 2 ordered separately) are electrically
connected. Do not connect any equipment other than this product. Otherwise, a failure or electric shock may result.
Power supply cable type IZG10-m03
· Connect the user equipment for the power supply and external switch input according to Power Supply Cable Wiring table.
·Ensure the green F.G. wire is correctly grounded. Static neutralization performance is achieved by maintaining the same electrical
potential as the reference potential of the operating environment.
Ionizer body AC adapter (With AC cord)
AC adapter body
Power supply cable (For AC adapter)
Power supply connector
Plug with
ground terminal
Connection
AC cord
(Not included for the IZG10-02)
Ionizer body
Ionizer body Power supply cable
(For 24 VDC wiring)
Main circuit
+24 V
Red DC (+)
Black
DC (–)
White
External switch signal∗1
Green F.G.
INPUT
+24 V
Be sure to ground.
(Ground resistance: 100 Ωor less)
−
+24 VDC
Power supply connector
Semi-stripped
3 mm
Red
White
Green
Black
Internal circuits and wiring example
Connection
Power supply cable
(For 24 VDC wiring)
*1 The external switch signal is used in an
OR configuration with the trigger input.
When the external switch signal is not
used, cut back the semi-strip wire to
prevent any contact with the conductor.
*1 The rated voltage of the AC cable supplied with IZG10-m01 is 125 V, and the plug is JIS C 8303 type B for Japanese domestic use. If the product is
used in an area with a higher voltage rating (220 or 240 VAC), select IZG10-m02 without AC power cable, and use an AC cable with an IEC 60320-C13
ground terminal connector, suitable for the power supply voltage.
9
IZG10 Series

8 147
138
133
(157)
33
ø5
24
Power supply connectorOne-touch fitting
Applicable tubing O.D.
(Refer to Table 1.)
(32.8)
ø4
3000
60
1830
AC cord
(Not included for the IZG10-CG2)
AC adapter body
50
Power supply cable (For AC adapter)
3190 100
33
ø10
ø10
Terminal semi-stripped
Power supply cable
(For 24 VDC wiring)
Dimensions
AC adapter IZG10-CGm
Power supply cable (For 24 VDC wiring) IZG10-CP
Table 1
Model Applicable tubing O.D.
IZG10-08m-01 ø8 (Metric)
IZG10-09m-01 ø5/16" (Inch)
Cable Specifications
No. of cable wires/Size 4 cores/AWG26
Conductor nominal cross section 0.15 mm2
Insulator O.D./Identification color 0.85 mm/Red, Black, White, Green
Sheath material Lead-free PVC
Outside diameter 4 mm
Model AC cord
IZG10-CG1 Included
IZG10-CG2 None
10
Gun Type Ionizer IZG10 Series

IZG10 Series
Related Products
Related Products
2-Color Display Digital Flow Switch
PFMB Series
Clean Air Module LLB Series
Recommended pneumatic circuit diagram
1 2 3 4 5 6
1 2 3
4 5
6
Removes moisture
in the compressed
air
Eliminates solid
foreign matter such as
powder particles in the
compressed air
Air Dryer IDF Series Air Filter AF/AFF Series
Eliminates oil mist
which is difficult to
eliminate with an air
filter
Mist Separator AFM/AM Series
Flow range: Max. 12000 L/min
Flow ratio 100 : 1
Flow range: Max. 2000 L/min
Flow ratio 100 : 1
3-Color Display Digital Flow Switch
PF3A7mH Series
For Clean Room
Built-in hollow fiber element Nominal filtration rating: 0.01 μm
Hollow fiber elements with over 99.99% filtering efficiency do not contaminate workpieces.
Clean Air Filter SFD Series
Decreases the air
consumption by setting to
an appropriate pressure
Regulator AR Series
Flexible
Max. operating pressure: 0.8 MPa (at 20°C)
For moving applications
*Colors other than black are available as
made-to-order specifications.
Polyurethane Coil Tubing TCU Series S Couplers KK/KKH Series
One-touch fitting type standardized (KK)
Uses ultra high-impact PBT resin (KKH)
Finger Valve VHK-A Series
The valve direction clearly indicates whether the valve is open or closed.
Small knob operating force (0.04 to 0.14 N·m)
KK
KKH
Modularized digital flow switch, regulator,
ON/OFF valve, restrictor, and filter
LLB4
LLB3
*Please contact SMC for clean room compatible
ionizers.
Install an air dryer (IDF series), air filter (AF/AFF series),
and/or mist separator (AFM/AM series) to obtain clean
compressed air (compressed air quality of Class 2.4.3.,
2.5.3., 2.6.3 or higher according to ISO 8573-1:2010
(JIS B 8392-1:2012) is recommended for operation).
Caution
IZG10
11

IZG10 Series
Specific Product Precautions 1
Be sure to read this before handling the products.
Refer to the back cover for safety instructions.
Selection
Warning
1. This product is intended to eliminate static electrici-
ty from the equipment for factory automation.
If considering using the product for other applications (espe-
cially those indicated in warning (4) on the back cover), please
consult with SMC beforehand.
2. Do not operate the product beyond the specifications.
If the product is used outside of the specification range, it may
cause malfunction, failure or damage to the product, leading to
an electric shock, explosion or fire.
3. Do not operate the product outside of the specified
ambient temperature and humidity range.
Malfunction, failure, or damage to the product can result. Even
within the specification range, freezing and condensation can
cause malfunction, failure, or damage in environments where
sudden temperature changes and temperature cycles are ap-
plied.
4. Use the product within the specified power supply
voltage range.
Using outside of the specified power supply voltage can cause
a malfunction, damage, electrical shock, or fire.
5. Use clean compressed air as fluid. (Compressed air
quality of Class 2.4.3., 2.5.3., 2.6.3 or higher accord-
ing to ISO 8573-1:2010 (JIS B 8392-1:2012) is recom-
mended for operation.)
This product is not explosion proof. Never use a flammable gas
or an explosive gas as a fluid and never use this product in the
presence of such gases. Please contact us when fluids other
than compressed air are used.
6. This product is not explosion-protected.
Never use this product in locations where the explosion of dust
is likely to occur or flammable or explosive gases are used.
This can cause a fire.
Caution
1. Clean specification is not available with this prod-
uct.
When using in a clean room environment, confirm the required
cleanliness before use.
A minute amount of particles are generated due to wearing of
the emitters while the product is operating.
Wiring / Piping
Warning
1. Select the power supply capacity based on the prod-
uct specifications.
If the power supply capacity and voltage do not sat-
isfy the product specifications, it will cause product
failure or malfunction.
2. To maintain product performance, the power supply
connected shall be UL listed Class 2 certified by Na-
tional Electric Code (NEC) or evaluated as a limited
power source provided by UL60950.
3. Stop the electrical supply and remove the com-
pressed air supply before any wiring (including in-
sertion and removal of the connector) and piping is
performed. Otherwise, an electrical shock or acci-
dent may occur.
Wiring / Piping
Warning
4.To maintain the product performance, connect the
product to power supply cable or AC adapter
ground terminal with a resistance of 100 Ωor less. If
the product is not grounded, it is not possible to
maintain the performance and may lead to product
failure or malfunction.
5. If the ionizer wiring and high power lines are routed
together, this product may malfunction due to noise.
Therefore, use a separate wiring route for this prod-
uct.
6. Flush the piping before use. Before piping this prod-
uct, exercise caution to prevent particles, water
drops, or oil contents from entering the piping.
7. If a valve is placed immediately before the product,
regardless of the operational state of the trigger, in-
stantaneous air release may occur when com-
pressed air is supplied.
8. Confirm that the wiring and piping are correct be-
fore supplying power and compressed air. Incorrect
wiring and piping will lead to product damage or
malfunction.
9. Ensure the safety of wiring, piping, and surrounding
conditions before supplying power and compressed
air.
Handling
Warning
1. Do not use the product without mounting the desig-
nated nozzle.
2. Confirm that the nozzle is not loose and does not
have play before supplying compressed air. If the
nozzle is loose, tighten it by hand until it stops turn-
ing (guideline value for hand tightening torque: 0.1
to 0.2 N·m). Static neutralizing performance is re-
duced if the nozzle is loose.
3. Be sure to wear protective eyewear when operating
the product to protect your eyes from scattering de-
bris.
4. Do not direct the tip of the nozzle at the face or oth-
er parts of a human body. It may cause danger to
personnel.
5. Do not use the product to clean or remove toxic
substances or chemicals.
6. Do not drop, step on, or hit the product. It may cause
damage to the product.
7. Do not use the product to disturb public order or
public hygiene.
8. This product is not a toy.
9. After blowing, make sure to hang the product on a
hook, etc.
12

IZG10 Series
Specific Product Precautions 2
Be sure to read this before handling the products.
Refer to the back cover for safety instructions.
Handling
Warning
10. Make sure that no twist, turn, tensile force or mo-
ment are applied to the One-touch fitting, tube and
power cable during use or storage. Such actions
may lead to product damage or broken wires.
11. Do not allow foreign matter or tools to enter the
nozzle.
The inside of the nozzle contains emitters. If a metal tool
makes contact with the emitters, it can cause electric shock,
resulting in a sudden movement by the operator that can
cause further injuries such as hitting the body on peripheral
equipment. Also, if the tool damages the emitter, the ionizer
may fail or cause an accident.
Nozzle
One-touch fitting
Emitters are under high voltage. Never touch the
emitters. Contact with or close proximity to the
emitters may result in an electric shock. The reac-
tion to such a shock could lead to further injuries
due to collisions with surrounding equipment.
Danger High Voltage
12. If a valve is placed immediately before the product,
regardless of the operational state of the trigger,
instantaneous air release may occur when com-
pressed air is supplied.
13. If the supply pressure of compressed air is less
than the product specification (0.05 MPa), the valve
in the product may not operate correctly. Only use
the product with a supply pressure within the prod-
uct specification range.
Operating Environment / Storage Environment
Warning
1. Do not use this product in an enclosed space.
This product utilizes the corona discharge phenomenon. A
small amount of ozone and NOx will be generated. When the
product is used in an enclosed space, the ozone concentration
can increase, if so the smell of ozone may be uncomfortable or
irritating. Even if the operating area is not an enclosed space,
but multiple products are used in a small area, ozone concen-
tration can still increase. The operating environment must al-
ways be ventilated.
2. Take preventative measures against ozone.
Pneumatic equipment used around this product should have
ozone-prevention measures. Also, regularly check that there is
no deterioration due to ozone.
3. Be sure to supply compressed air.
Static neutralization is not possible without supplying com-
pressed air. Without compressed air, ozone or NOx generated
by the ion generation process may accumulate and adversely
affect the product or peripheral equipment.
4. Use the product within the specified ambient tem-
perature range.
The specified ambient temperature range is 0 to 40°C. Do not
use the product in locations where the ambient temperature
changes suddenly even within the specifications or if the tem-
perature difference of the fluid relative to the ambient tempera-
ture is large condensation may occur.
Operating Environment / Storage Environment
Warning
5. Environments to avoid
Avoid using and storing this product in the following environ-
ments since they may cause damage to this product.
a. Environments where the ambient temperature is outside of
the product specification
b. Environments where the ambient humidity is outside of the
product specification
c. Environments where abrupt temperature changes may
cause condensation
d. Environments where corrosive gas, flammable gas, or other
volatile flammable substances are stored
e. Environments where the product may be exposed to con-
ductive powder such as iron powder or dust, oil mist,
salt, organic solvent, spatter, machining chips, particles,
cutting oil (including water and any liquids), etc.
f. Environments where ventilated air from an air conditioner is
directly applied to the product
g. Enclosed or poorly ventilated environments
h. Environments that are exposed to direct sunlight or heat ra-
diation
i. Environments where strong electromagnetic noise is gener-
ated, such as strong electrical and magnetic fields or sup-
ply voltage spikes
j. Environments where static electricity is generated
k. Environments where a strong high frequency occurs
l. Environments that are subject to potential lightning strikes
m. Environments where the product may receive direct impact
or vibration
n. Environments where the product may be subjected to forc-
es or weight that could cause physical deformation
6. Do not use an air containing mist or dust.
The air containing mist or dust will cause the static neutraliza-
tion performance to decrease and shorten the maintenance
cycle. Install an air dryer (IDF series), air filter (AF/AFF series),
and/or mist separator (AFM/AM series) to obtain clean com-
pressed air (compressed air quality of Class 2.4.3., 2.5.3.,
2.6.3 or higher according to ISO 8573-1:2010 (JIS B 8392-
1:2012) is recommended for operation).
7.This product and AC adapter are not resistant to
lightening surge.
8. Effects on implantable medical devices
The electromagnetic waves emitted from this product may in-
terfere with implantable medical devices such as cardiac pace-
makers and cardioverter defibrillators, resulting in the malfunc-
tion of the medical device or other adverse effects. Please use
extreme caution when operating equipment which may have
an adverse effect on your implantable medical device. Be sure
to thoroughly read the precautions stated in the catalog, oper-
ation manual, etc., of your implantable medical device, or con-
tact the manufacturer directly for further details on what types
of equipment need to be avoided.
13

IZG10 Series
Specific Product Precautions 3
Be sure to read this before handling the products.
Refer to the back cover for safety instructions.
Maintenance
Warning
1. Periodically inspect the ionizer and clean the emit-
ters.
· Check regularly if the product is operating with undetected
failures or not.
· The maintenance must be performed by an operator who has
sufficient knowledge and experience.
· If the product is used for an extended period with dust pre-
sent on the emitters, the static neutralization performance will
be reduced. It is recommended to clean the emitters periodi-
cally. (Emitter contamination level is different depending on
the operating environment and supply pressure.)
· When the maintenance LED turns ON, clean the emitters and
confirm the static neutralization performance.
· If the static neutralization performance is not recovered after
cleaning, it is possible that emitters are worn. Replace the
emitter assembly.
This product contains a high voltage generation circuit. When
performing maintenance inspection, be sure to confirm that the
power supply to the ionizer is turned off. Never disassemble or
modify the ionizer, as this may not only impair the product’s func-
tionality but could cause an electric shock or electric leakage.
Danger High Voltage
2. When cleaning or replacing the emitter, be sure to
turn off the power supply or compressed air supply
to the body.
Maintenance of the product with power or compressed air sup-
plies connected can cause an electric shock or accident.
3. Securely mount the emitters.
If emitters are not securely mounted, they may eject or release
when compressed air is supplied to the product.
4. Do not touch the emitters directly.
They have a sharp end and touching them may cause injury.
5. Do not disassemble or modify the product.
Otherwise, an electrical shock, damage and/or a fire may oc-
cur. Also, the disassembled or modified products may not
achieve the performances guaranteed in the specifications,
and exercise caution because the product will not be warran-
tied.
6. Do not operate the product with wet hands.
Otherwise, an electric shock or accident may occur.
Caution
1. Periodically check the following items and replace
the parts if necessary.
a. Contamination and wear of emitters
b. Loosening and damage of nozzles
c. Twists or crushing of connected tubes
d. Hardness and deterioration of connected tubes
e. Air leakage
14

Safety Instructions
Be sure to read the “Handling Precautions for SMC Products” (M-E03-3) and “Operation Manual” before use.
Caution
SMC products are not intended for use as instruments for legal
metrology.
Measurement instruments that SMC manufactures or sells have not been
qualified by type approval tests relevant to the metrology (measurement) laws
of each country. Therefore, SMC products cannot be used for business or
certification ordained by the metrology (measurement) laws of each country.
Compliance Requirements
∗1) ISO 4414: Pneumatic fluid power – General rules relating to systems.
ISO 4413: Hydraulic fluid power – General rules relating to systems.
IEC 60204-1: Safety of machinery – Electrical equipment of machines.
(Part 1: General requirements)
ISO 10218-1: Manipulating industrial robots – Safety.
etc.
Caution indicates a hazard with a low level of risk which,
if not avoided, could result in minor or moderate injury.
Caution:
Warning indicates a hazard with a medium level of risk which,
if not avoided, could result in death or serious injury.
Warning :
Danger :
Danger indicates a hazard with a high level of risk which,
if not avoided, will result in death or serious injury.
Warning Caution
1. The compatibility of the product is the responsibility of the
person who designs the equipment or decides its
specifications.
Since the product specified here is used under various operating conditions,
its compatibility with specific equipment must be decided by the person who
designs the equipment or decides its specifications based on necessary
analysis and test results. The expected performance and safety assurance
of the equipment will be the responsibility of the person who has determined
its compatibility with the product. This person should also continuously
review all specifications of the product referring to its latest catalog
information, with a view to giving due consideration to any possibility of
equipment failure when configuring the equipment.
2. Only personnel with appropriate training should operate
machinery and equipment.
The product specified here may become unsafe if handled incorrectly. The
assembly, operation and maintenance of machines or equipment including
our products must be performed by an operator who is appropriately trained
and experienced.
3. Do not service or attempt to remove product and machinery/
equipment until safety is confirmed.
1. The inspection and maintenance of machinery/equipment should only be
performed after measures to prevent falling or runaway of the driven
objects have been confirmed.
2. When the product is to be removed, confirm that the safety measures as
mentioned above are implemented and the power from any appropriate
source is cut, and read and understand the specific product precautions
of all relevant products carefully.
3. Before machinery/equipment is restarted, take measures to prevent
unexpected operation and malfunction.
4. Contact SMC beforehand and take special consideration of
safety measures if the product is to be used in any of the
following conditions.
1. Conditions and environments outside of the given specifications, or use
outdoors or in a place exposed to direct sunlight.
2. Installation on equipment in conjunction with atomic energy, railways, air
navigation, space, shipping, vehicles, military, medical treatment,
combustion and recreation, or equipment in contact with food and
beverages, emergency stop circuits, clutch and brake circuits in press
applications, safety equipment or other applications unsuitable for the
standard specifications described in the product catalog.
3. An application which could have negative effects on people, property, or
animals requiring special safety analysis.
4. Use in an interlock circuit, which requires the provision of double interlock
for possible failure by using a mechanical protective function, and
periodical checks to confirm proper operation.
1. The product is provided for use in manufacturing industries.
The product herein described is basically provided for peaceful use in
manufacturing industries.
If considering using the product in other industries, consult SMC beforehand
and exchange specifications or a contract if necessary.
If anything is unclear, contact your nearest sales branch.
Limited warranty and Disclaimer/
Compliance Requirements
The product used is subject to the following “Limited warranty and Disclaimer” and
“Compliance Requirements”.
Read and accept them before using the product.
Limited warranty and Disclaimer
1. The warranty period of the product is 1 year in service or 1.5 years after
the product is delivered, whichever is first.∗2)
Also, the product may have specified durability, running distance or
replacement parts. Please consult your nearest sales branch.
2. For any failure or damage reported within the warranty period which is clearly our
responsibility, a replacement product or necessary parts will be provided.
This limited warranty applies only to our product independently, and not to any
other damage incurred due to the failure of the product.
3. Prior to using SMC products, please read and understand the warranty terms
and disclaimers noted in the specified catalog for the particular products.
∗2) Vacuum pads are excluded from this 1 year warranty.
A vacuum pad is a consumable part, so it is warranted for a year after it is delivered.
Also, even within the warranty period, the wear of a product due to the use of the vacuum pad
or failure due to the deterioration of rubber material are not covered by the limited warranty.
1. The use of SMC products with production equipment for the manufacture of
weapons of mass destruction (WMD) or any other weapon is strictly prohibited.
2. The exports of SMC products or technology from one country to another are
governed by the relevant security laws and regulations of the countries involved
in the transaction. Prior to the shipment of a SMC product to another country,
assure that all local rules governing that export are known and followed.
These safety instructions are intended to prevent hazardous situations and/or
equipment damage. These instructions indicate the level of potential hazard with
the labels of “Caution,” “Warning” or “Danger.”They are all important notes for
safety and must be followed in addition to International Standards (ISO/IEC)∗1),
and other safety regulations.
Safety Instructions
