SMC Networks EXW1-RDX# Series User manual

EXW1-TF2Z563EN
Page 1 of 2
Instruction Manual
SMC Wireless System - Compact Remote
Series EXW1-RDX# / -RDY# / -RDM#
The intended use of this product is to provide a connection from the SMC
wireless communication system to pneumatic devices.
1 Safety Instructions
These safety instructions are intended to prevent hazardous situations
and/or equipment damage. These instructions indicate the level of
potential hazard with the labels of “Caution,” “Warning” or “Danger.”
They are all important notes for safety and must be followed in addition
to International Standards (ISO/IEC)
*1)
, and other safety regulations.
*1)
ISO 4414: Pneumatic fluid power - General rules relating to systems.
ISO 4413: Hydraulic fluid power - General rules relating to systems.
IEC 60204-1: Safety of machinery - Electrical equipment of machines.
(Part 1: General requirements)
ISO 10218-1: Manipulating industrial robots -Safety. etc.
•Refer to product catalogue, Operation Manual and Handling
Precautions for SMC Products for additional information.
•Keep this manual in a safe place for future reference.
Caution
Caution indicates a hazard with a low level of risk which, if
not avoided, could result in minor or moderate injury.
Warning
Warning indicates a hazard with a medium level of risk
which, if not avoided, could result in death or serious injury.
Danger
Danger indicates a hazard with a high level of risk which, if
not avoided, will result in death or serious injury.
Warning
•Always ensure compliance with relevant safety laws and
standards.
All work must be carried out in a safe manner by a qualified person in
compliance with applicable national regulations.
2 Specifications
2.1 General specifications
2 Specifications (continued)
2.2 Electrical specifications – EXW1-RDX# Input unit
Item
Specifica
tion
US1 (for control / input)
power
supply
voltage
24 VDC ±10%
Current consumption
100 mA or less
Inputs
Number of points
16 points (2 points / connector)
In
put type
NPN
Connector type
e
-
CON (4 pins)
Max. supply current for
sensor
0.3 A / connector, 2 A/unit
ON current
0.5 mA Typ
.
OFF current
2 mA or less
ON voltage
11 V or more
OFF
current
5 V or less
Short circuit protection
Included
2.3 Electrical specifications – EXW1-RDY# Output unit
Item
Specification
US1 (for control / input)
power
supply
voltage
24 VDC ±10%
US2 (for output) power
voltage
24 VDC ±10%
Current
consumption (US1)
100 mA or less
Outputs
Number of points
16 points (2 points / connector)
Output type
NPN
Connector type
e
-
CON (4 pins)
Maximum load current
0.3 A / point, 2 A / unit
Short circuit protection
Included
2.4 Electrical specifications – EXW1-RDM# Input / Output unit
Item
EXW1
-
RDMP
#
EXW1
-
RDMN
#
US1 (for control / input)
power voltage drop
24 VDC ±10%
US2 (for output) power
voltage)
24 VDC ±10%
Current consumption (US1)
100 mA or less
Inputs
Number of points
8
points (2 points
/
connector)
In
put type
PNP
NPN
Connector type
e
-
CON (4 pins)
Max. supply current for
sensor
0.3 A / connector, 1 A / unit
ON current
0.5 mA
Typ
.
OFF current
2 mA or less
ON voltage
11 V or more
OFF current
5 V or less
Short circuit protection
Included
Outputs
Number of points
8 points (2 points / connector)
Output type
PNP
NPN
Connector type
e
-
CON (4 pins)
Maximum load current
0.3 A / point, 2 A / unit
Short circuit protection
Included
2 Specifications (continued)
2.5 Wireless Communication specifications
Item Specifications
Protocol SMC original protocol
(SMC encryption)
Radio wave type (spread) Frequency Hopping Spread Spectrum
(FHSS)
Frequency
band
2.4 GHz (2403 to 2481 MHz)
Frequency channel select
function (F.C.S.)
Supported
*1
Frequency channel
s
79 ch
max.
(Bandwidth: 1.0 MHz)
Communication speed
1 Mbps /
250 kbps
*
2
Communication distance Up to 100 m line of sight
(depending on the environment)
Radio Law certificates Refer to the operation manual on the
SMC website
*1: The number of selectable frequency channels varies depending on
the product number.
*2: Select a protocol before performing pairing (V.2.0: 1 Mbps, V.1.0: 250
kbps). Different communication speeds are mutually incompatible.
2.6 NFC Communication specifications
Item Specifications
Communication standard ISO / IEC14443B (Type-B)
Frequency 13.56 MHz
Communication speed 20 to 100 kHz (I2C)
Communication distance Up to 1 cm
* NFC component is a 13.56 MHz passive-type RFID tag.
3 Name and Function of parts
•Compact Remote Input unit (EXW1-RDX#)
•Compact Remote Output unit (EXW1-RDY#)
3 Name and Function of parts (continued)
•Compact Remote Input / Output unit (EXW1-RDM#)
No.
Item
Description
1 Mounting holes Mounting holes for compact wireless
base
(2 x M4).
2 PWR (Power connector) Supplies power to the compact
wireless
Remote.
3 RF connector
SMA coaxial connector for external
antenna (external antenna versions
only).
4 Fn (Pairing button) Press the button to select pairing
mode.
5 NFC antenna area Area in close contact with the NFC
reader / writer
(
"
○"
marks
the cent
re)
.
6 LED display Indicates the status of the compact
wireless
Remote.
7 FE terminal and
mounting hole (M4)
To be connected to Ground (for
improved noise immunity).
8 Connector for Inputs Connector for an input device.
(PIN2, PIN4: input)
.
9 Connector for Outputs Connector for an output device.
(PIN2, PIN4: output)
.
•Ground connection
The Ground connection to the FE terminal (M4 mounting hole) should be
as close as possible to the product and the grounding wire should be as
short as possible.
4 Installation
4.1 Installation
Warning
•Do not install the product unless the safety instructions have been read
and understood.
4.2 Mounting
Mount the unit with M4 screws (not supplied) using the 2 mounting holes
in the unit (Recommended torque: 0.8 ±10% N•m).
Item Specification
Enclosure rating IP20
Ambient operating temperature -10 to +50
°
C
Ambient storage temperature -20 to +60
°
C
Ambient humidity 35 to 85% RH (no condensation)
Withstand voltage
500 VAC for 1 minute between
external terminals (including the FE
terminal) and enclosure screws
Insulation resistance
10 MΩor more (500 VDC between
external terminals (including the FE
terminal) and enclosure screws
Vibration resistance
EN61131-2 compliant:
5 ≤f < 8.4 Hz 3.5 mm
8.4 ≤f < 150 Hz 9.8 m/s
2
Impact resistance EN61131-2 compliant:
147
m
/s
2
,
11
ms
Weight 130 g
ORIGINAL INSTRUCTIONS
2 x M4 Mounting holes

EXW1-TF2Z563EN
Page 1 of 2
Instruction Manual
SMC Wireless System - Compact Remote
Series EXW1-RDX# / -RDY# / -RDM#
The intended use of this product is to provide a connection from the SMC
wireless communication system to pneumatic devices.
1 Safety Instructions
These safety instructions are intended to prevent hazardous situations
and/or equipment damage. These instructions indicate the level of
potential hazard with the labels of “Caution,” “Warning” or “Danger.”
They are all important notes for safety and must be followed in addition
to International Standards (ISO/IEC)
*1)
, and other safety regulations.
*1)
ISO 4414: Pneumatic fluid power - General rules relating to systems.
ISO 4413: Hydraulic fluid power - General rules relating to systems.
IEC 60204-1: Safety of machinery - Electrical equipment of machines.
(Part 1: General requirements)
ISO 10218-1: Manipulating industrial robots -Safety. etc.
•Refer to product catalogue, Operation Manual and Handling
Precautions for SMC Products for additional information.
•Keep this manual in a safe place for future reference.
Caution
Caution indicates a hazard with a low level of risk which, if
not avoided, could result in minor or moderate injury.
Warning
Warning indicates a hazard with a medium level of risk
which, if not avoided, could result in death or serious injury.
Danger
Danger indicates a hazard with a high level of risk which, if
not avoided, will result in death or serious injury.
Warning
•Always ensure compliance with relevant safety laws and
standards.
All work must be carried out in a safe manner by a qualified person in
compliance with applicable national regulations.
2 Specifications
2.1 General specifications
2 Specifications (continued)
2.2 Electrical specifications – EXW1-RDX# Input unit
Item
Specifica
tion
US1 (for control / input)
power
supply
voltage
24 VDC ±10%
Current consumption
100 mA or less
Inputs
Number of points
16 points (2 points / connector)
In
put type
NPN
Connector type
e
-
CON (4 pins)
Max. supply current for
sensor
0.3 A / connector, 2 A/unit
ON current
0.5 mA Typ
.
OFF current
2 mA or less
ON voltage
11 V or more
OFF
current
5 V or less
Short circuit protection
Included
2.3 Electrical specifications – EXW1-RDY# Output unit
Item
Specification
US1 (for control / input)
power
supply
voltage
24 VDC ±10%
US2 (for output) power
voltage
24 VDC ±10%
Current
consumption (US1)
100 mA or less
Outputs
Number of points
16 points (2 points / connector)
Output type
NPN
Connector type
e
-
CON (4 pins)
Maximum load current
0.3 A / point, 2 A / unit
Short circuit protection
Included
2.4 Electrical specifications – EXW1-RDM# Input / Output unit
Item
EXW1
-
RDMP
#
EXW1
-
RDMN
#
US1 (for control / input)
power voltage drop
24 VDC ±10%
US2 (for output) power
voltage)
24 VDC ±10%
Current consumption (US1)
100 mA or less
Inputs
Number of points
8
points (2 points
/
connector)
In
put type
PNP
NPN
Connector type
e
-
CON (4 pins)
Max. supply current for
sensor
0.3 A / connector, 1 A / unit
ON current
0.5 mA
Typ
.
OFF current
2 mA or less
ON voltage
11 V or more
OFF current
5 V or less
Short circuit protection
Included
Outputs
Number of points
8 points (2 points / connector)
Output type
PNP
NPN
Connector type
e
-
CON (4 pins)
Maximum load current
0.3 A / point, 2 A / unit
Short circuit protection
Included
2 Specifications (continued)
2.5 Wireless Communication specifications
Item Specifications
Protocol SMC original protocol
(SMC encryption)
Radio wave type (spread) Frequency Hopping Spread Spectrum
(FHSS)
Frequency
band
2.4 GHz (2403 to 2481 MHz)
Frequency channel select
function (F.C.S.)
Supported
*1
Frequency channel
s
79 ch
max.
(Bandwidth: 1.0 MHz)
Communication speed
1 Mbps /
250 kbps
*
2
Communication distance Up to 100 m line of sight
(depending on the environment)
Radio Law certificates Refer to the operation manual on the
SMC website
*1: The number of selectable frequency channels varies depending on
the product number.
*2: Select a protocol before performing pairing (V.2.0: 1 Mbps, V.1.0: 250
kbps). Different communication speeds are mutually incompatible.
2.6 NFC Communication specifications
Item Specifications
Communication standard ISO / IEC14443B (Type-B)
Frequency 13.56 MHz
Communication speed 20 to 100 kHz (I2C)
Communication distance Up to 1 cm
* NFC component is a 13.56 MHz passive-type RFID tag.
3 Name and Function of parts
•Compact Remote Input unit (EXW1-RDX#)
•Compact Remote Output unit (EXW1-RDY#)
3 Name and Function of parts (continued)
•Compact Remote Input / Output unit (EXW1-RDM#)
No.
Item
Description
1 Mounting holes Mounting holes for compact wireless
base
(2 x M4).
2 PWR (Power connector) Supplies power to the compact
wireless
Remote.
3 RF connector
SMA coaxial connector for external
antenna (external antenna versions
only).
4 Fn (Pairing button) Press the button to select pairing
mode.
5 NFC antenna area Area in close contact with the NFC
reader / writer
(
"
○"
marks
the cent
re)
.
6 LED display Indicates the status of the compact
wireless
Remote.
7 FE terminal and
mounting hole (M4)
To be connected to Ground (for
improved noise immunity).
8 Connector for Inputs Connector for an input device.
(PIN2, PIN4: input)
.
9 Connector for Outputs Connector for an output device.
(PIN2, PIN4: output)
.
•Ground connection
The Ground connection to the FE terminal (M4 mounting hole) should be
as close as possible to the product and the grounding wire should be as
short as possible.
4 Installation
4.1 Installation
Warning
•Do not install the product unless the safety instructions have been read
and understood.
4.2 Mounting
Mount the unit with M4 screws (not supplied) using the 2 mounting holes
in the unit (Recommended torque: 0.8 ±10% N•m).
Item Specification
Enclosure rating IP20
Ambient operating temperature -10 to +50
°
C
Ambient storage temperature -20 to +60
°
C
Ambient humidity 35 to 85% RH (no condensation)
Withstand voltage
500 VAC for 1 minute between
external terminals (including the FE
terminal) and enclosure screws
Insulation resistance
10 MΩor more (500 VDC between
external terminals (including the FE
terminal) and enclosure screws
Vibration resistance
EN61131-2 compliant:
5 ≤f < 8.4 Hz 3.5 mm
8.4 ≤f < 150 Hz 9.8 m/s
2
Impact resistance EN61131-2 compliant:
147
m
/s
2
,
11
ms
Weight 130 g
ORIGINAL INSTRUCTIONS
2 x M4 Mounting holes

EXW1-TF2Z563EN
Page 1 of 2
Instruction Manual
SMC Wireless System - Compact Remote
Series EXW1-RDX# / -RDY# / -RDM#
The intended use of this product is to provide a connection from the SMC
wireless communication system to pneumatic devices.
1 Safety Instructions
These safety instructions are intended to prevent hazardous situations
and/or equipment damage. These instructions indicate the level of
potential hazard with the labels of “Caution,” “Warning” or “Danger.”
They are all important notes for safety and must be followed in addition
to International Standards (ISO/IEC)
*1)
, and other safety regulations.
*1)
ISO 4414: Pneumatic fluid power - General rules relating to systems.
ISO 4413: Hydraulic fluid power - General rules relating to systems.
IEC 60204-1: Safety of machinery - Electrical equipment of machines.
(Part 1: General requirements)
ISO 10218-1: Manipulating industrial robots -Safety. etc.
•Refer to product catalogue, Operation Manual and Handling
Precautions for SMC Products for additional information.
•Keep this manual in a safe place for future reference.
Caution
Caution indicates a hazard with a low level of risk which, if
not avoided, could result in minor or moderate injury.
Warning
Warning indicates a hazard with a medium level of risk
which, if not avoided, could result in death or serious injury.
Danger
Danger indicates a hazard with a high level of risk which, if
not avoided, will result in death or serious injury.
Warning
•Always ensure compliance with relevant safety laws and
standards.
All work must be carried out in a safe manner by a qualified person in
compliance with applicable national regulations.
2 Specifications
2.1 General specifications
2 Specifications (continued)
2.2 Electrical specifications – EXW1-RDX# Input unit
Item
Specifica
tion
US1 (for control / input)
power
supply
voltage
24 VDC ±10%
Current consumption
100 mA or less
Inputs
Number of points
16 points (2 points / connector)
In
put type
NPN
Connector type
e
-
CON (4 pins)
Max. supply current for
sensor
0.3 A / connector, 2 A/unit
ON current
0.5 mA Typ
.
OFF current
2 mA or less
ON voltage
11 V or more
OFF
current
5 V or less
Short circuit protection
Included
2.3 Electrical specifications – EXW1-RDY# Output unit
Item
Specification
US1 (for control / input)
power
supply
voltage
24 VDC ±10%
US2 (for output) power
voltage
24 VDC ±10%
Current
consumption (US1)
100 mA or less
Outputs
Number of points
16 points (2 points / connector)
Output type
NPN
Connector type
e
-
CON (4 pins)
Maximum load current
0.3 A / point, 2 A / unit
Short circuit protection
Included
2.4 Electrical specifications – EXW1-RDM# Input / Output unit
Item
EXW1
-
RDMP
#
EXW1
-
RDMN
#
US1 (for control / input)
power voltage drop
24 VDC ±10%
US2 (for output) power
voltage)
24 VDC ±10%
Current consumption (US1)
100 mA or less
Inputs
Number of points
8
points (2 points
/
connector)
In
put type
PNP
NPN
Connector type
e
-
CON (4 pins)
Max. supply current for
sensor
0.3 A / connector, 1 A / unit
ON current
0.5 mA
Typ
.
OFF current
2 mA or less
ON voltage
11 V or more
OFF current
5 V or less
Short circuit protection
Included
Outputs
Number of points
8 points (2 points / connector)
Output type
PNP
NPN
Connector type
e
-
CON (4 pins)
Maximum load current
0.3 A / point, 2 A / unit
Short circuit protection
Included
2 Specifications (continued)
2.5 Wireless Communication specifications
Item Specifications
Protocol SMC original protocol
(SMC encryption)
Radio wave type (spread) Frequency Hopping Spread Spectrum
(FHSS)
Frequency
band
2.4 GHz (2403 to 2481 MHz)
Frequency channel select
function (F.C.S.)
Supported
*1
Frequency channel
s
79 ch
max.
(Bandwidth: 1.0 MHz)
Communication speed
1 Mbps /
250 kbps
*
2
Communication distance Up to 100 m line of sight
(depending on the environment)
Radio Law certificates Refer to the operation manual on the
SMC website
*1: The number of selectable frequency channels varies depending on
the product number.
*2: Select a protocol before performing pairing (V.2.0: 1 Mbps, V.1.0: 250
kbps). Different communication speeds are mutually incompatible.
2.6 NFC Communication specifications
Item Specifications
Communication standard ISO / IEC14443B (Type-B)
Frequency 13.56 MHz
Communication speed 20 to 100 kHz (I2C)
Communication distance Up to 1 cm
* NFC component is a 13.56 MHz passive-type RFID tag.
3 Name and Function of parts
•Compact Remote Input unit (EXW1-RDX#)
•Compact Remote Output unit (EXW1-RDY#)
3 Name and Function of parts (continued)
•Compact Remote Input / Output unit (EXW1-RDM#)
No.
Item
Description
1 Mounting holes Mounting holes for compact wireless
base
(2 x M4).
2 PWR (Power connector) Supplies power to the compact
wireless
Remote.
3 RF connector
SMA coaxial connector for external
antenna (external antenna versions
only).
4 Fn (Pairing button) Press the button to select pairing
mode.
5 NFC antenna area Area in close contact with the NFC
reader / writer
(
"
○"
marks
the cent
re)
.
6 LED display Indicates the status of the compact
wireless
Remote.
7 FE terminal and
mounting hole (M4)
To be connected to Ground (for
improved noise immunity).
8 Connector for Inputs Connector for an input device.
(PIN2, PIN4: input)
.
9 Connector for Outputs Connector for an output device.
(PIN2, PIN4: output)
.
•Ground connection
The Ground connection to the FE terminal (M4 mounting hole) should be
as close as possible to the product and the grounding wire should be as
short as possible.
4 Installation
4.1 Installation
Warning
•Do not install the product unless the safety instructions have been read
and understood.
4.2 Mounting
Mount the unit with M4 screws (not supplied) using the 2 mounting holes
in the unit (Recommended torque: 0.8 ±10% N•m).
Item Specification
Enclosure rating IP20
Ambient operating temperature -10 to +50
°
C
Ambient storage temperature -20 to +60
°
C
Ambient humidity 35 to 85% RH (no condensation)
Withstand voltage
500 VAC for 1 minute between
external terminals (including the FE
terminal) and enclosure screws
Insulation resistance
10 MΩor more (500 VDC between
external terminals (including the FE
terminal) and enclosure screws
Vibration resistance
EN61131-2 compliant:
5 ≤f < 8.4 Hz 3.5 mm
8.4 ≤f < 150 Hz 9.8 m/s
2
Impact resistance EN61131-2 compliant:
147
m
/s
2
,
11
ms
Weight 130 g
ORIGINAL INSTRUCTIONS
2 x M4 Mounting holes

EXW1-TF2Z563EN
Page 1 of 2
Instruction Manual
SMC Wireless System - Compact Remote
Series EXW1-RDX# / -RDY# / -RDM#
The intended use of this product is to provide a connection from the SMC
wireless communication system to pneumatic devices.
1 Safety Instructions
These safety instructions are intended to prevent hazardous situations
and/or equipment damage. These instructions indicate the level of
potential hazard with the labels of “Caution,” “Warning” or “Danger.”
They are all important notes for safety and must be followed in addition
to International Standards (ISO/IEC)
*1)
, and other safety regulations.
*1)
ISO 4414: Pneumatic fluid power - General rules relating to systems.
ISO 4413: Hydraulic fluid power - General rules relating to systems.
IEC 60204-1: Safety of machinery - Electrical equipment of machines.
(Part 1: General requirements)
ISO 10218-1: Manipulating industrial robots -Safety. etc.
•Refer to product catalogue, Operation Manual and Handling
Precautions for SMC Products for additional information.
•Keep this manual in a safe place for future reference.
Caution
Caution indicates a hazard with a low level of risk which, if
not avoided, could result in minor or moderate injury.
Warning
Warning indicates a hazard with a medium level of risk
which, if not avoided, could result in death or serious injury.
Danger
Danger indicates a hazard with a high level of risk which, if
not avoided, will result in death or serious injury.
Warning
•Always ensure compliance with relevant safety laws and
standards.
All work must be carried out in a safe manner by a qualified person in
compliance with applicable national regulations.
2 Specifications
2.1 General specifications
2 Specifications (continued)
2.2 Electrical specifications – EXW1-RDX# Input unit
Item
Specifica
tion
US1 (for control / input)
power
supply
voltage
24 VDC ±10%
Current consumption
100 mA or less
Inputs
Number of points
16 points (2 points / connector)
In
put type
NPN
Connector type
e
-
CON (4 pins)
Max. supply current for
sensor
0.3 A / connector, 2 A/unit
ON current
0.5 mA Typ
.
OFF current
2 mA or less
ON voltage
11 V or more
OFF
current
5 V or less
Short circuit protection
Included
2.3 Electrical specifications – EXW1-RDY# Output unit
Item
Specification
US1 (for control / input)
power
supply
voltage
24 VDC ±10%
US2 (for output) power
voltage
24 VDC ±10%
Current
consumption (US1)
100 mA or less
Outputs
Number of points
16 points (2 points / connector)
Output type
NPN
Connector type
e
-
CON (4 pins)
Maximum load current
0.3 A / point, 2 A / unit
Short circuit protection
Included
2.4 Electrical specifications – EXW1-RDM# Input / Output unit
Item
EXW1
-
RDMP
#
EXW1
-
RDMN
#
US1 (for control / input)
power voltage drop
24 VDC ±10%
US2 (for output) power
voltage)
24 VDC ±10%
Current consumption (US1)
100 mA or less
Inputs
Number of points
8
points (2 points
/
connector)
In
put type
PNP
NPN
Connector type
e
-
CON (4 pins)
Max. supply current for
sensor
0.3 A / connector, 1 A / unit
ON current
0.5 mA
Typ
.
OFF current
2 mA or less
ON voltage
11 V or more
OFF current
5 V or less
Short circuit protection
Included
Outputs
Number of points
8 points (2 points / connector)
Output type
PNP
NPN
Connector type
e
-
CON (4 pins)
Maximum load current
0.3 A / point, 2 A / unit
Short circuit protection
Included
2 Specifications (continued)
2.5 Wireless Communication specifications
Item Specifications
Protocol SMC original protocol
(SMC encryption)
Radio wave type (spread) Frequency Hopping Spread Spectrum
(FHSS)
Frequency
band
2.4 GHz (2403 to 2481 MHz)
Frequency channel select
function (F.C.S.)
Supported
*1
Frequency channel
s
79 ch
max.
(Bandwidth: 1.0 MHz)
Communication speed
1 Mbps /
250 kbps
*
2
Communication distance Up to 100 m line of sight
(depending on the environment)
Radio Law certificates Refer to the operation manual on the
SMC website
*1: The number of selectable frequency channels varies depending on
the product number.
*2: Select a protocol before performing pairing (V.2.0: 1 Mbps, V.1.0: 250
kbps). Different communication speeds are mutually incompatible.
2.6 NFC Communication specifications
Item Specifications
Communication standard ISO / IEC14443B (Type-B)
Frequency 13.56 MHz
Communication speed 20 to 100 kHz (I2C)
Communication distance Up to 1 cm
* NFC component is a 13.56 MHz passive-type RFID tag.
3 Name and Function of parts
•Compact Remote Input unit (EXW1-RDX#)
•Compact Remote Output unit (EXW1-RDY#)
3 Name and Function of parts (continued)
•Compact Remote Input / Output unit (EXW1-RDM#)
No.
Item
Description
1 Mounting holes Mounting holes for compact wireless
base
(2 x M4).
2 PWR (Power connector) Supplies power to the compact
wireless
Remote.
3 RF connector
SMA coaxial connector for external
antenna (external antenna versions
only).
4 Fn (Pairing button) Press the button to select pairing
mode.
5 NFC antenna area Area in close contact with the NFC
reader / writer
(
"
○"
marks
the cent
re)
.
6 LED display Indicates the status of the compact
wireless
Remote.
7 FE terminal and
mounting hole (M4)
To be connected to Ground (for
improved noise immunity).
8 Connector for Inputs Connector for an input device.
(PIN2, PIN4: input)
.
9 Connector for Outputs Connector for an output device.
(PIN2, PIN4: output)
.
•Ground connection
The Ground connection to the FE terminal (M4 mounting hole) should be
as close as possible to the product and the grounding wire should be as
short as possible.
4 Installation
4.1 Installation
Warning
•Do not install the product unless the safety instructions have been read
and understood.
4.2 Mounting
Mount the unit with M4 screws (not supplied) using the 2 mounting holes
in the unit (Recommended torque: 0.8 ±10% N•m).
Item Specification
Enclosure rating IP20
Ambient operating temperature -10 to +50
°
C
Ambient storage temperature -20 to +60
°
C
Ambient humidity 35 to 85% RH (no condensation)
Withstand voltage
500 VAC for 1 minute between
external terminals (including the FE
terminal) and enclosure screws
Insulation resistance
10 MΩor more (500 VDC between
external terminals (including the FE
terminal) and enclosure screws
Vibration resistance
EN61131-2 compliant:
5 ≤f < 8.4 Hz 3.5 mm
8.4 ≤f < 150 Hz 9.8 m/s
2
Impact resistance EN61131-2 compliant:
147
m
/s
2
,
11
ms
Weight 130 g
ORIGINAL INSTRUCTIONS
2 x M4 Mounting holes

EXW1-TF2Z563EN
Page 2 of 2
4 Installation (continued)
4.3 Environment
Warning
•Do not use in an environment where corrosive gases, chemicals, salt
water or steam are present.
•Do not use in an explosive atmosphere.
•Do not expose to direct sunlight. Use a suitable protective cover.
•Do not install in a location subject to vibration or impact in excess of
the product’s specifications.
•Do not mount in a location exposed to radiant heat that would result in
temperatures in excess of the product’s specifications.
5 Wiring
5.1 Wiring Connections – EXW1-RDX# Input unit
•Power supply connector
Pin number Description
1 24V (US1)
2 N.C.
3 0V (US1)
4 N.C.
•INPUT connector
Pin number Description
1 24V (US1)
2 n+1
3 0V (US1)
4 n
5.2 Wiring Connections – EXW1-RDY# Output unit
•Power supply connector
Pin number Description
1 24V (US1)
2 24V (US2)
3 0V (US1)
4 0V (US2)
•OUTPUT connector
Pin number Description
1 +COM (US2_24V)
2 n+1
3 +COM (US2_24V)
4 n
* +COM is connected to 24V (US2) inside the product.
5.3 Wiring Connections – EXW1-RDM# Input / Output unit
•Power supply connector
Pin number Description
1 24V (US1)
2 24V (US2)
3 0V (US1)
4 0V (US2)
5 Wiring (continued)
•INPUT connector
Pin number Description
1 24V (US1)
2 n+1
3 0V (US1)
4 n
•OUTPUT connector (PNP outputs)
Pin number Description
1 -COM (US2_0V)
2 n+1
3 -COM (US2_0V)
4 n
•OUTPUT connector (NPN outputs)
Pin number Description
1 +COM (US2_24V)
2 n+1
3 +COM (US2_24V)
4 n
* -COM is connected to 0V (US2) and +COM to 24V (US2) inside the
product.
6 Settings
• Flow chart for using the wireless system.
To use SMC wireless units (Base and Remotes), they need to be set up
using an NFC reader/writer and the I/O Configurator. A setup procedure
using NFC is shown below.
Refer to the operation manual for each manufacturer for how to set the
controller and the PLC.
Step 1 Preparation before use (PC, Application)
(1) Install the NFC reader / writer and drivers.
(2) Install the I/O Configurator
Step 2 Setting / installation of the wireless unit
(1) Parameter setting of the Remote (optional).
(2) Communication, system and frequency channel select
function (F.C.S.) settings of the Base .
(3) Register the Remote to the Base (pairing)
(4) Installation and wiring.
7 LED Display
•The LED indicators on the compact wireless Remote indicate the
power supply, communication and diagnostic status. The same LED
indications are used for all of the EXW1-RD# series.
7 LED Display (continued)
Refer to the Operation manual on the SMC website (URL:
https://www.smcworld.com) for further LED Display details.
8 How to Order
Refer to the Operation manual or catalogue on the SMC website (URL:
https://www.smcworld.com) for How to Order information.
9 Outline Dimensions (mm)
Refer to the Operation manual or catalogue on the SMC website (URL:
https://www.smcworld.com) for Outline dimensions.
10 Maintenance
10.1 General Maintenance
Caution
•Not following proper maintenance procedures could cause the product
to malfunction and lead to equipment damage.
•If handled improperly, compressed air can be dangerous.
•Maintenance of pneumatic systems should be performed only by
qualified personnel.
•Before performing maintenance, turn off the power supply and be sure
to cut off the supply pressure. Confirm that the air is released to
atmosphere.
•After installation and maintenance, apply operating pressure and
power to the equipment and perform appropriate functional and
leakage tests to make sure the equipment is installed correctly.
•If any electrical connections are disturbed during maintenance, ensure
they are reconnected correctly and safety checks are carried out as
required to ensure continued compliance with applicable national
regulations.
•Do not make any modification to the product.
•Do not disassemble the product, unless required by installation or
maintenance instructions.
11 Limitations of Use
11.1 Limited warranty and Disclaimer/Compliance Requirements
Refer to Handling Precautions for SMC Products.
NOTE
This equipment has been tested and found to comply with the limits for a
Class A digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against
harmful interference when the equipment is operated in a commercial
environment.
This equipment generates, uses, and can radiate radio frequency energy
and, if not installed and used in accordance with the instruction manual,
may cause harmful interference to radio communications.
Operation of this equipment in a residential area is likely to cause harmful
interference in which case the user will be required to correct the
interference at his own expense.
•Influence of radio frequency on implantable medical devices:
The radio frequency generated by this product may give an adverse
effect on implantable medical devices, such as implantable cardiac
pacemakers and implantable cardioverter defibrillators.
Please read catalogues or instruction manuals of the equipment and
device which may be affected by radio frequencies for any instructions
for use or contact their manufacturers.
12 Product Disposal
This product shall not be disposed of as municipal waste. Check your
local regulations and guidelines to dispose of this product correctly, in
order to reduce the impact on human health and the environment.
13 Contacts
Refer to www.smcworld.com or www.smc.eu for your local distributor /
importer.
URL
:
https://
www.smcworld.com
(Global)
https://www.smceu.com
(Euro
p
e)
SMC Corporation, 4-14-1, Sotokanda, Chiyoda-ku, Tokyo 101-0021, Japan
Specifications are subject to change without prior notice from the manufacturer.
© 2021 SMC Corporation All Rights Reserved.
Template DKP50047-F-085M
Step 3 Connection to PLC
Note) Refer to the operation manual of the PLC manufacturer for
connection to a PLC and Configurator.
LED LED Colour Operation
PWR
Green LED
ON
US1 (for control) power supply is ON
Red LED
flashing
US2 (for output) power supply voltage level is
abnorma
l
(when the setting is enabled)
OFF US1 (for control) power supply is OFF
MS
Green LED
ON Compact wireless Base is operating normally
Red LED
flashing
Recoverable error is detected.
(LED flashes when more than one diagnostic
information item is detected).
•US1 (for control and input) power supply
voltage level is abnormal (when the setting
is enabled).
•Short-circuit detection of US1 (for control /
input) power supply.
•Short-circuit detection of US2 (for output)
power supply
.
Red LED
ON Unrecoverable error is detected.
OFF US1 (for control) power supply is OFF.
W-SS
Green LED
ON
Received radio wave intensity level 3.
Green LED
flashing
(1 Hz)
Received radio wave intensity level 2.
Green LED
flashing
(2 Hz)
Received radio wave intensity level 1.
Red LED
flash
ing
Protocol V.1.0 wireless communication is not
established
.
Orange LED
flashing
Protocol V.2.0 wireless communication is not
established
.
OFF Wireless Base is not registered.
W-NS
Green LED
ON
Wireless Base connected correctly.
Red LED
flashing
Base not connected.
Orange LED
flashing
Pairing operation is in progress.
Red LED
ON
Base not connected (Unrecoverable error in
wireless communication)
.
Red / Green
LED flashing
Wireless communication connection is being
configured (Pairing).
OFF Base not registered.
US1 (for control / input) power supply is
OFF
.

EXW1-TF2Z563EN
Page 2 of 2
4 Installation (continued)
4.3 Environment
Warning
•Do not use in an environment where corrosive gases, chemicals, salt
water or steam are present.
•Do not use in an explosive atmosphere.
•Do not expose to direct sunlight. Use a suitable protective cover.
•Do not install in a location subject to vibration or impact in excess of
the product’s specifications.
•Do not mount in a location exposed to radiant heat that would result in
temperatures in excess of the product’s specifications.
5 Wiring
5.1 Wiring Connections – EXW1-RDX# Input unit
•Power supply connector
Pin number Description
1 24V (US1)
2 N.C.
3 0V (US1)
4 N.C.
•INPUT connector
Pin number Description
1 24V (US1)
2 n+1
3 0V (US1)
4 n
5.2 Wiring Connections – EXW1-RDY# Output unit
•Power supply connector
Pin number Description
1 24V (US1)
2 24V (US2)
3 0V (US1)
4 0V (US2)
•OUTPUT connector
Pin number Description
1 +COM (US2_24V)
2 n+1
3 +COM (US2_24V)
4 n
* +COM is connected to 24V (US2) inside the product.
5.3 Wiring Connections – EXW1-RDM# Input / Output unit
•Power supply connector
Pin number Description
1 24V (US1)
2 24V (US2)
3 0V (US1)
4 0V (US2)
5 Wiring (continued)
•INPUT connector
Pin number Description
1 24V (US1)
2 n+1
3 0V (US1)
4 n
•OUTPUT connector (PNP outputs)
Pin number Description
1 -COM (US2_0V)
2 n+1
3 -COM (US2_0V)
4 n
•OUTPUT connector (NPN outputs)
Pin number Description
1 +COM (US2_24V)
2 n+1
3 +COM (US2_24V)
4 n
* -COM is connected to 0V (US2) and +COM to 24V (US2) inside the
product.
6 Settings
• Flow chart for using the wireless system.
To use SMC wireless units (Base and Remotes), they need to be set up
using an NFC reader/writer and the I/O Configurator. A setup procedure
using NFC is shown below.
Refer to the operation manual for each manufacturer for how to set the
controller and the PLC.
Step 1 Preparation before use (PC, Application)
(1) Install the NFC reader / writer and drivers.
(2) Install the I/O Configurator
Step 2 Setting / installation of the wireless unit
(1) Parameter setting of the Remote (optional).
(2) Communication, system and frequency channel select
function (F.C.S.) settings of the Base .
(3) Register the Remote to the Base (pairing)
(4) Installation and wiring.
7 LED Display
•The LED indicators on the compact wireless Remote indicate the
power supply, communication and diagnostic status. The same LED
indications are used for all of the EXW1-RD# series.
7 LED Display (continued)
Refer to the Operation manual on the SMC website (URL:
https://www.smcworld.com) for further LED Display details.
8 How to Order
Refer to the Operation manual or catalogue on the SMC website (URL:
https://www.smcworld.com) for How to Order information.
9 Outline Dimensions (mm)
Refer to the Operation manual or catalogue on the SMC website (URL:
https://www.smcworld.com) for Outline dimensions.
10 Maintenance
10.1 General Maintenance
Caution
•Not following proper maintenance procedures could cause the product
to malfunction and lead to equipment damage.
•If handled improperly, compressed air can be dangerous.
•Maintenance of pneumatic systems should be performed only by
qualified personnel.
•Before performing maintenance, turn off the power supply and be sure
to cut off the supply pressure. Confirm that the air is released to
atmosphere.
•After installation and maintenance, apply operating pressure and
power to the equipment and perform appropriate functional and
leakage tests to make sure the equipment is installed correctly.
•If any electrical connections are disturbed during maintenance, ensure
they are reconnected correctly and safety checks are carried out as
required to ensure continued compliance with applicable national
regulations.
•Do not make any modification to the product.
•Do not disassemble the product, unless required by installation or
maintenance instructions.
11 Limitations of Use
11.1 Limited warranty and Disclaimer/Compliance Requirements
Refer to Handling Precautions for SMC Products.
NOTE
This equipment has been tested and found to comply with the limits for a
Class A digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against
harmful interference when the equipment is operated in a commercial
environment.
This equipment generates, uses, and can radiate radio frequency energy
and, if not installed and used in accordance with the instruction manual,
may cause harmful interference to radio communications.
Operation of this equipment in a residential area is likely to cause harmful
interference in which case the user will be required to correct the
interference at his own expense.
•Influence of radio frequency on implantable medical devices:
The radio frequency generated by this product may give an adverse
effect on implantable medical devices, such as implantable cardiac
pacemakers and implantable cardioverter defibrillators.
Please read catalogues or instruction manuals of the equipment and
device which may be affected by radio frequencies for any instructions
for use or contact their manufacturers.
12 Product Disposal
This product shall not be disposed of as municipal waste. Check your
local regulations and guidelines to dispose of this product correctly, in
order to reduce the impact on human health and the environment.
13 Contacts
Refer to www.smcworld.com or www.smc.eu for your local distributor /
importer.
URL
:
https://
www.smcworld.com
(Global)
https://www.smceu.com
(Euro
p
e)
SMC Corporation, 4-14-1, Sotokanda, Chiyoda-ku, Tokyo 101-0021, Japan
Specifications are subject to change without prior notice from the manufacturer.
© 2021 SMC Corporation All Rights Reserved.
Template DKP50047-F-085M
Step 3 Connection to PLC
Note) Refer to the operation manual of the PLC manufacturer for
connection to a PLC and Configurator.
LED LED Colour Operation
PWR
Green LED
ON
US1 (for control) power supply is ON
Red LED
flashing
US2 (for output) power supply voltage level is
abnorma
l
(when the setting is enabled)
OFF US1 (for control) power supply is OFF
MS
Green LED
ON Compact wireless Base is operating normally
Red LED
flashing
Recoverable error is detected.
(LED flashes when more than one diagnostic
information item is detected).
•US1 (for control and input) power supply
voltage level is abnormal (when the setting
is enabled).
•Short-circuit detection of US1 (for control /
input) power supply.
•Short-circuit detection of US2 (for output)
power supply
.
Red LED
ON Unrecoverable error is detected.
OFF US1 (for control) power supply is OFF.
W-SS
Green LED
ON
Received radio wave intensity level 3.
Green LED
flashing
(1 Hz)
Received radio wave intensity level 2.
Green LED
flashing
(2 Hz)
Received radio wave intensity level 1.
Red LED
flash
ing
Protocol V.1.0 wireless communication is not
established
.
Orange LED
flashing
Protocol V.2.0 wireless communication is not
established
.
OFF Wireless Base is not registered.
W-NS
Green LED
ON
Wireless Base connected correctly.
Red LED
flashing
Base not connected.
Orange LED
flashing
Pairing operation is in progress.
Red LED
ON
Base not connected (Unrecoverable error in
wireless communication)
.
Red / Green
LED flashing
Wireless communication connection is being
configured (Pairing).
OFF Base not registered.
US1 (for control / input) power supply is
OFF
.

EXW1-TF2Z563EN
Page 2 of 2
4 Installation (continued)
4.3 Environment
Warning
•Do not use in an environment where corrosive gases, chemicals, salt
water or steam are present.
•Do not use in an explosive atmosphere.
•Do not expose to direct sunlight. Use a suitable protective cover.
•Do not install in a location subject to vibration or impact in excess of
the product’s specifications.
•Do not mount in a location exposed to radiant heat that would result in
temperatures in excess of the product’s specifications.
5 Wiring
5.1 Wiring Connections – EXW1-RDX# Input unit
•Power supply connector
Pin number Description
1 24V (US1)
2 N.C.
3 0V (US1)
4 N.C.
•INPUT connector
Pin number Description
1 24V (US1)
2 n+1
3 0V (US1)
4 n
5.2 Wiring Connections – EXW1-RDY# Output unit
•Power supply connector
Pin number Description
1 24V (US1)
2 24V (US2)
3 0V (US1)
4 0V (US2)
•OUTPUT connector
Pin number Description
1 +COM (US2_24V)
2 n+1
3 +COM (US2_24V)
4 n
* +COM is connected to 24V (US2) inside the product.
5.3 Wiring Connections – EXW1-RDM# Input / Output unit
•Power supply connector
Pin number Description
1 24V (US1)
2 24V (US2)
3 0V (US1)
4 0V (US2)
5 Wiring (continued)
•INPUT connector
Pin number Description
1 24V (US1)
2 n+1
3 0V (US1)
4 n
•OUTPUT connector (PNP outputs)
Pin number Description
1 -COM (US2_0V)
2 n+1
3 -COM (US2_0V)
4 n
•OUTPUT connector (NPN outputs)
Pin number Description
1 +COM (US2_24V)
2 n+1
3 +COM (US2_24V)
4 n
* -COM is connected to 0V (US2) and +COM to 24V (US2) inside the
product.
6 Settings
• Flow chart for using the wireless system.
To use SMC wireless units (Base and Remotes), they need to be set up
using an NFC reader/writer and the I/O Configurator. A setup procedure
using NFC is shown below.
Refer to the operation manual for each manufacturer for how to set the
controller and the PLC.
Step 1 Preparation before use (PC, Application)
(1) Install the NFC reader / writer and drivers.
(2) Install the I/O Configurator
Step 2 Setting / installation of the wireless unit
(1) Parameter setting of the Remote (optional).
(2) Communication, system and frequency channel select
function (F.C.S.) settings of the Base .
(3) Register the Remote to the Base (pairing)
(4) Installation and wiring.
7 LED Display
•The LED indicators on the compact wireless Remote indicate the
power supply, communication and diagnostic status. The same LED
indications are used for all of the EXW1-RD# series.
7 LED Display (continued)
Refer to the Operation manual on the SMC website (URL:
https://www.smcworld.com) for further LED Display details.
8 How to Order
Refer to the Operation manual or catalogue on the SMC website (URL:
https://www.smcworld.com) for How to Order information.
9 Outline Dimensions (mm)
Refer to the Operation manual or catalogue on the SMC website (URL:
https://www.smcworld.com) for Outline dimensions.
10 Maintenance
10.1 General Maintenance
Caution
•Not following proper maintenance procedures could cause the product
to malfunction and lead to equipment damage.
•If handled improperly, compressed air can be dangerous.
•Maintenance of pneumatic systems should be performed only by
qualified personnel.
•Before performing maintenance, turn off the power supply and be sure
to cut off the supply pressure. Confirm that the air is released to
atmosphere.
•After installation and maintenance, apply operating pressure and
power to the equipment and perform appropriate functional and
leakage tests to make sure the equipment is installed correctly.
•If any electrical connections are disturbed during maintenance, ensure
they are reconnected correctly and safety checks are carried out as
required to ensure continued compliance with applicable national
regulations.
•Do not make any modification to the product.
•Do not disassemble the product, unless required by installation or
maintenance instructions.
11 Limitations of Use
11.1 Limited warranty and Disclaimer/Compliance Requirements
Refer to Handling Precautions for SMC Products.
NOTE
This equipment has been tested and found to comply with the limits for a
Class A digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against
harmful interference when the equipment is operated in a commercial
environment.
This equipment generates, uses, and can radiate radio frequency energy
and, if not installed and used in accordance with the instruction manual,
may cause harmful interference to radio communications.
Operation of this equipment in a residential area is likely to cause harmful
interference in which case the user will be required to correct the
interference at his own expense.
•Influence of radio frequency on implantable medical devices:
The radio frequency generated by this product may give an adverse
effect on implantable medical devices, such as implantable cardiac
pacemakers and implantable cardioverter defibrillators.
Please read catalogues or instruction manuals of the equipment and
device which may be affected by radio frequencies for any instructions
for use or contact their manufacturers.
12 Product Disposal
This product shall not be disposed of as municipal waste. Check your
local regulations and guidelines to dispose of this product correctly, in
order to reduce the impact on human health and the environment.
13 Contacts
Refer to www.smcworld.com or www.smc.eu for your local distributor /
importer.
URL
:
https://
www.smcworld.com
(Global)
https://www.smceu.com
(Euro
p
e)
SMC Corporation, 4-14-1, Sotokanda, Chiyoda-ku, Tokyo 101-0021, Japan
Specifications are subject to change without prior notice from the manufacturer.
© 2021 SMC Corporation All Rights Reserved.
Template DKP50047-F-085M
Step 3 Connection to PLC
Note) Refer to the operation manual of the PLC manufacturer for
connection to a PLC and Configurator.
LED LED Colour Operation
PWR
Green LED
ON
US1 (for control) power supply is ON
Red LED
flashing
US2 (for output) power supply voltage level is
abnorma
l
(when the setting is enabled)
OFF US1 (for control) power supply is OFF
MS
Green LED
ON Compact wireless Base is operating normally
Red LED
flashing
Recoverable error is detected.
(LED flashes when more than one diagnostic
information item is detected).
•US1 (for control and input) power supply
voltage level is abnormal (when the setting
is enabled).
•Short-circuit detection of US1 (for control /
input) power supply.
•Short-circuit detection of US2 (for output)
power supply
.
Red LED
ON Unrecoverable error is detected.
OFF US1 (for control) power supply is OFF.
W-SS
Green LED
ON
Received radio wave intensity level 3.
Green LED
flashing
(1 Hz)
Received radio wave intensity level 2.
Green LED
flashing
(2 Hz)
Received radio wave intensity level 1.
Red LED
flash
ing
Protocol V.1.0 wireless communication is not
established
.
Orange LED
flashing
Protocol V.2.0 wireless communication is not
established
.
OFF Wireless Base is not registered.
W-NS
Green LED
ON
Wireless Base connected correctly.
Red LED
flashing
Base not connected.
Orange LED
flashing
Pairing operation is in progress.
Red LED
ON
Base not connected (Unrecoverable error in
wireless communication)
.
Red / Green
LED flashing
Wireless communication connection is being
configured (Pairing).
OFF Base not registered.
US1 (for control / input) power supply is
OFF
.

EXW1-TF2Z563EN
Page 2 of 2
4 Installation (continued)
4.3 Environment
Warning
•Do not use in an environment where corrosive gases, chemicals, salt
water or steam are present.
•Do not use in an explosive atmosphere.
•Do not expose to direct sunlight. Use a suitable protective cover.
•Do not install in a location subject to vibration or impact in excess of
the product’s specifications.
•Do not mount in a location exposed to radiant heat that would result in
temperatures in excess of the product’s specifications.
5 Wiring
5.1 Wiring Connections – EXW1-RDX# Input unit
•Power supply connector
Pin number Description
1 24V (US1)
2 N.C.
3 0V (US1)
4 N.C.
•INPUT connector
Pin number Description
1 24V (US1)
2 n+1
3 0V (US1)
4 n
5.2 Wiring Connections – EXW1-RDY# Output unit
•Power supply connector
Pin number Description
1 24V (US1)
2 24V (US2)
3 0V (US1)
4 0V (US2)
•OUTPUT connector
Pin number Description
1 +COM (US2_24V)
2 n+1
3 +COM (US2_24V)
4 n
* +COM is connected to 24V (US2) inside the product.
5.3 Wiring Connections – EXW1-RDM# Input / Output unit
•Power supply connector
Pin number Description
1 24V (US1)
2 24V (US2)
3 0V (US1)
4 0V (US2)
5 Wiring (continued)
•INPUT connector
Pin number Description
1 24V (US1)
2 n+1
3 0V (US1)
4 n
•OUTPUT connector (PNP outputs)
Pin number Description
1 -COM (US2_0V)
2 n+1
3 -COM (US2_0V)
4 n
•OUTPUT connector (NPN outputs)
Pin number Description
1 +COM (US2_24V)
2 n+1
3 +COM (US2_24V)
4 n
* -COM is connected to 0V (US2) and +COM to 24V (US2) inside the
product.
6 Settings
• Flow chart for using the wireless system.
To use SMC wireless units (Base and Remotes), they need to be set up
using an NFC reader/writer and the I/O Configurator. A setup procedure
using NFC is shown below.
Refer to the operation manual for each manufacturer for how to set the
controller and the PLC.
Step 1 Preparation before use (PC, Application)
(1) Install the NFC reader / writer and drivers.
(2) Install the I/O Configurator
Step 2 Setting / installation of the wireless unit
(1) Parameter setting of the Remote (optional).
(2) Communication, system and frequency channel select
function (F.C.S.) settings of the Base .
(3) Register the Remote to the Base (pairing)
(4) Installation and wiring.
7 LED Display
•The LED indicators on the compact wireless Remote indicate the
power supply, communication and diagnostic status. The same LED
indications are used for all of the EXW1-RD# series.
7 LED Display (continued)
Refer to the Operation manual on the SMC website (URL:
https://www.smcworld.com) for further LED Display details.
8 How to Order
Refer to the Operation manual or catalogue on the SMC website (URL:
https://www.smcworld.com) for How to Order information.
9 Outline Dimensions (mm)
Refer to the Operation manual or catalogue on the SMC website (URL:
https://www.smcworld.com) for Outline dimensions.
10 Maintenance
10.1 General Maintenance
Caution
•Not following proper maintenance procedures could cause the product
to malfunction and lead to equipment damage.
•If handled improperly, compressed air can be dangerous.
•Maintenance of pneumatic systems should be performed only by
qualified personnel.
•Before performing maintenance, turn off the power supply and be sure
to cut off the supply pressure. Confirm that the air is released to
atmosphere.
•After installation and maintenance, apply operating pressure and
power to the equipment and perform appropriate functional and
leakage tests to make sure the equipment is installed correctly.
•If any electrical connections are disturbed during maintenance, ensure
they are reconnected correctly and safety checks are carried out as
required to ensure continued compliance with applicable national
regulations.
•Do not make any modification to the product.
•Do not disassemble the product, unless required by installation or
maintenance instructions.
11 Limitations of Use
11.1 Limited warranty and Disclaimer/Compliance Requirements
Refer to Handling Precautions for SMC Products.
NOTE
This equipment has been tested and found to comply with the limits for a
Class A digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against
harmful interference when the equipment is operated in a commercial
environment.
This equipment generates, uses, and can radiate radio frequency energy
and, if not installed and used in accordance with the instruction manual,
may cause harmful interference to radio communications.
Operation of this equipment in a residential area is likely to cause harmful
interference in which case the user will be required to correct the
interference at his own expense.
•Influence of radio frequency on implantable medical devices:
The radio frequency generated by this product may give an adverse
effect on implantable medical devices, such as implantable cardiac
pacemakers and implantable cardioverter defibrillators.
Please read catalogues or instruction manuals of the equipment and
device which may be affected by radio frequencies for any instructions
for use or contact their manufacturers.
12 Product Disposal
This product shall not be disposed of as municipal waste. Check your
local regulations and guidelines to dispose of this product correctly, in
order to reduce the impact on human health and the environment.
13 Contacts
Refer to www.smcworld.com or www.smc.eu for your local distributor /
importer.
URL
:
https://
www.smcworld.com
(Global)
https://www.smceu.com
(Euro
p
e)
SMC Corporation, 4-14-1, Sotokanda, Chiyoda-ku, Tokyo 101-0021, Japan
Specifications are subject to change without prior notice from the manufacturer.
© 2021 SMC Corporation All Rights Reserved.
Template DKP50047-F-085M
Step 3 Connection to PLC
Note) Refer to the operation manual of the PLC manufacturer for
connection to a PLC and Configurator.
LED
LED Colour Operation
PWR
Green LED
ON
US1 (for control) power supply is ON
Red LED
flashing
US2 (for output) power supply voltage level is
abnorma
l
(when the setting is enabled)
OFF US1 (for control) power supply is OFF
MS
Green LED
ON Compact wireless Base is operating normally
Red LED
flashing
Recoverable error is detected.
(LED flashes when more than one diagnostic
information item is detected).
•US1 (for control and input) power supply
voltage level is abnormal (when the setting
is enabled).
•Short-circuit detection of US1 (for control /
input) power supply.
•Short-circuit detection of US2 (for output)
power supply
.
Red LED
ON Unrecoverable error is detected.
OFF US1 (for control) power supply is OFF.
W-SS
Green LED
ON
Received radio wave intensity level 3.
Green LED
flashing
(1 Hz)
Received radio wave intensity level 2.
Green LED
flashing
(2 Hz)
Received radio wave intensity level 1.
Red LED
flash
ing
Protocol V.1.0 wireless communication is not
established
.
Orange LED
flashing
Protocol V.2.0 wireless communication is not
established
.
OFF Wireless Base is not registered.
W-NS
Green LED
ON
Wireless Base connected correctly.
Red LED
flashing
Base not connected.
Orange LED
flashing
Pairing operation is in progress.
Red LED
ON
Base not connected (Unrecoverable error in
wireless communication)
.
Red / Green
LED flashing
Wireless communication connection is being
configured (Pairing).
OFF Base not registered.
US1 (for control / input) power supply is
OFF
.
