Series CYV
CAT.ES20-158 A
Simplifies and reduces
the size of equipment
Since the cylinder can be installed inside a vacuum
chamber, it contributes to simplifying
and reducing the size of a transfer system.
Air cylinder for transfer
in vacuum environments (1.3 x 10
- 4Pa)
Rodless Cylinder for Vacuum
Series CYV
ø15, ø32

0.1
Stainless steel
linear guide &
low particulate generation
vacuum grease
Operation cycles
Particulate generation [particles/cycle]
5.0
0.0 1000000 200000 1000000
There is no particulate generation due
to friction, since the construction does
not allow contact between the cylinder
tube's exterior surface and the slide
table's internal surface.
Non-contact construction
No contact
Cylinder tube
Slide table
Note 1) This data indicates deterioration with age of the average number
of particles per operation under the following test conditions.
<Test conditions>
• Cylinder: CYV32-100 •Work piece weight: 5kg
• Average speed: 100mm/s
• Measurement environment: Operation in the atmosphere after
baking at 150°C for 48 hours.
Note 2) This data is considered typical but not guaranteed.
Note 3) A particulate generation test has been conducted in a vacuum
environment of 10-⁵Pa.
A special cylinder tube using extruded
aluminum material is employed.
No deflection or contact occurs even
for long strokes, since the cylinder is
rigidly attached to the base and the
slide table is independently supported
by a linear guide.
Special cylinder tube
Long strokes
(Max. 700mm)
L
o
w
p
a
r
t
i
c
u
l
a
t
e
g
e
n
e
r
a
t
i
o
n
1
L
o
w
p
a
r
t
i
c
u
l
a
t
e
g
e
n
e
r
a
t
i
o
n
2
L
o
w
p
a
r
t
i
c
u
l
a
t
e
g
e
n
e
r
a
t
i
o
n
3
Air cylinder for transfer
Low particulate generation
Speed [mm/s]
Relationship between speed and impact acceleration
Impact acceleration [m/s²]
50 100 150 200 250 300
5
0
Low particulate generation at the stroke ends
Particulate generation
has been reduced at
the stroke ends by
reducing impact using
a sine cushion and by
stopping the stroke
using an internal
stopper.
L
o
w
p
a
r
t
i
c
u
l
a
t
e
g
e
n
e
r
a
t
i
o
n
4
Rodless Cylinder for Vacuum
Series CYV
ø15, ø32
Particulate generation from the linear
guide unit has been reduced with the use
of a stainless steel linear guide and low
particulate generating vacuum grease.
Reduced initial
particulate
generation
Cleaned, assembled,
inspected and first-stage
packaged in a clean
environment.
Average particle generation (particles >0.1 µ)
is 0.1 particles/cycle. (Atmospheric conditions)
Features 1

in vacuum environments (1.3 x 10-⁴Pa)
1.3 x 10
-
⁷Pa⋅m³/sec
Leakage:1.3 x 10
-
⁷Pa⋅m³/sec or less
(at normal temperatures, excluding gas permeation)
O-ring seals separate vacuum and atmosphere.
Static O-ring seals are used for
all the seals between vacuum
and atmosphere.
Laser marking
L
o
w
l
e
a
k
a
g
e
1
Note 1) The chart above shows the leakage test results
based on a test conducted using this cylinder
construction.
Note 2) To allow fine stroke adjustments, O-ring seals
are installed to separate vacuum and atmos-
phere. Consult SMC if the sealing method
needs to be altered.
R
e
d
u
c
e
d
o
u
t
g
a
s
s
i
n
g
1
Reduction of outgassing
due to surface treatment
All the external parts (made of
aluminum alloy) such as the body
and slide table are electroless nickel
plated.
Furthermore, external magnets are
coated with titanium nitride.
Note 1) Consult SMC if other specifications
for surface treatment are required.
2
Resin materials
eliminated
Laser marking is employed for
the model designation.
Note 1) The data indicates the leakage
measured in a vacuum environment
of 10-⁵Pa.
Note 2) The leakage test result shown is
based on a test conducted for 10
minutes after the cylinder was
pressurized with helium at 0.1 MPa.
Note 3) This data is considered typical but
not guaranteed.
O-ring seal
Employs a
magnetically
coupled rodless
cylinder with no
air leakage from
moving parts.
L
o
w
l
e
a
k
a
g
e
2
Fine adjustments
at the end of the stroke
Fine adjustments between –2to 0mm
can be made on one side (–4to 0mm
for both sides).
Reduced outgassing
Leakage [Pa⋅m3/sec]
Time [min]
10-⁷
10-⁸
10-⁹
10-¹⁰
0510
Standard value
Leakage test result
Low leakage
Hexagon wrench
Carefully designed for low particulate generation, low leakage,
and low outgassing.
R
e
d
u
c
e
d
o
u
t
g
a
s
s
i
n
g
Features 2

How to Order
CYV 15
Rodless cylinder
for vacuum
15
32 15mm
32mm
Standard stroke
Bore size
200
Bore size (mm)
15, 32
Standard stroke (mm)
100, 150, 200, 250
300, 350, 400, 450
500, 600, 700
Specifications
Magnet Holding Force
Bore size (mm)
Operating environment pressure
Operating atmosphere
Fluid
Action
Proof pressure
Operating pressure range
Leakage
Maximum baking temperature
Ambient and fluid temperature
Piston speed
Stroke adjustment
Cushion
Port size
Lubrication
Atmosphere to 1.3 x 10-⁴ Pa (ABS)
Air and inert gases
Air and inert gases
Double acting
0.5MPa
0.05 to 0.3MPa
1.3 x 10
-
⁷Pa⋅m³/sec or less
(at normal temperatures, excluding gas permeation)
150°C
- 10 to 60°C
50 to 300mm/s
- 2 to 0mm on each side ( - 4 to 0mm total)
Sine cushion (Air cushion)
Vacuum grease for linear guide unit
and inside the cylinder tube
5/16-24UNF 7/16-20UNF
15 32
Bore size (mm)
15
32
Magnet holding
force (N)
59
268
Theoretical Output
15
32
Bore size
(mm)
176
804
0.1
18
80
0.2
35
161
0.3
53
241
Piston area
(mm²)
Operating pressure
(MPa)
(N)
(kg)
Weights
Model
CYV15
CYV32
Standard stroke (mm)
100
1.2
4.2
150
1.4
4.6
200
1.6
5.0
250
1.7
5.5
300
1.9
5.9
350
2.0
6.3
400
2.2
6.7
450
2.4
7.1
500
2.5
7.5
600
2.8
8.3
700
3.2
9.1
1
Rodless Cylinder for Vacuum
