SMITH SYSTEM Cascade User manual

For assistance in assembling the product,, missing or damaged parts, or to place an order, please contact
customer service at 1-800-328-1061. You may also place your order online at
Form# 179974 www.smithsystem.com 5/2014
Cascade Presentation Cart
Assembly Instructions

For assistance in assembling the product,, missing or damaged parts, or to place an order, please contact
customer service at 1-800-328-1061. You may also place your order online at
Form# 179974 www.smithsystem.com 5/2014
Components and Hardware
#10X5/8” Wood Screw
P/N –70080
QTY. 32
Countersunk ½”
Wood Screw
QTY. 8
3/8-16X1”
Countersunk Bolt
QTY. 4
3/8-16 Hex Head Bolt
QTY. 4
Acorn Cap Nut
QTY. 4
Steel Washer
QTY. 4
Presentation Steel
Washer Top
QTY. 4
Presentation Steel
Washer Bottom
QTY. 4
Lectern Shelf
Tall Handle
QTY. 2
Lectern Shelf
Short Handle
QTY. 2
Riser Shelf Handles
QTY. 4
Riser Shelf Top
QTY. 1
Lectern Top
QTY. 1
Mega Case Cascade Unit
QTY. 1

For assistance in assembling the product,, missing or damaged parts, or to place an order, please contact
customer service at 1-800-328-1061. You may also place your order online at
Form# 179974 www.smithsystem.com 5/2014
Replacement Hardware
1. Replacement Hardware Pack 69725 ZINC-R includes:
(16) #10X5/8” Wood Screws
(4) 3/8-16X1.25” Hex Head Bolts
(4) Steel Washers
2. Replacement Hardware Pack 17089 PLT includes:
(4) Acorn Nuts
(4) Presentation Steel Washer Bottom
(4) Presentation Steel Washer Top
(8) Countersunk ½” Wood Screws
(4) 3/18-16 X ½” Countersunk Bolts
3. Replacement Hardware Pack 17088 PLT includes:
(4) Riser Shelf Handles
(16) #10X5/8” Wood Screws
(4) 3/8-16X1.5”Hex Head Bolts
(4) Steel Washers
4. Replacement Hardware Pack 17087 PLT includes
(2) Lectern Riser Handles Short
(2) Lectern Riser Handles Tall
(16) #10X5/8” Wood Screws
(4) 3/8-16X1.25” Hex Head Bolt
Special Note
1. Check that all components are accounted for and undamaged before assembling.
2. Please assemble product in a clean and dry area.
3. For larger units, you may need another person to help assemble the product.
4. Clean the product with a mild cleaner and a damp cloth.

For assistance in assembling the product,, missing or damaged parts, or to place an order, please contact
customer service at 1-800-328-1061. You may also place your order online at
Form# 179974 www.smithsystem.com 5/2014
Step 1: Flip the riser shelf top face down onto a clean dry surface, so the pre-drilled holes face
up.
Step 2: Align the Pole Handles with the predrilled holes as shown and screw in to the top using
(16) wood screws provided.
Step 3: Flip the top with pole handles attached into upright position, and align on cascade unit.
Step 4: Using a Ratchet and socket or wrench, bolt in the top to the cascade with the washer
underneath the cascade as shown.
Step 5: Flip the lectern top over onto a clean dry surface, so the predrilled holes face upward

For assistance in assembling the product,, missing or damaged parts, or to place an order, please contact
customer service at 1-800-328-1061. You may also place your order online at
Form# 179974 www.smithsystem.com 5/2014
Step 6: Align and attach the Lectern Poles to the top using the provided wood screws. Ensure
that the poles are all slanted in the same direction and the two taller poles are on the back side
of the top when flipped over, as seen in the picture.
Step 7: Attach the Presentation Steel Washer Top onto the bottoms of the lectern riser poles using the
(4) 3/-16 X 1” countersunk bolts. Ensure the slots on all washers are towards the inside of the unit.

For assistance in assembling the product,, missing or damaged parts, or to place an order, please contact
customer service at 1-800-328-1061. You may also place your order online at
Form# 179974 www.smithsystem.com 5/2014
Step 8: Align the bottom washers to the predrilled holes on the riser shelf and attach to the riser shelf
using the (8) ½” countersunk woodscrews. Ensure the bolts from the bottom washer are all towards the
inside of the unit.
Step 9: Place the lectern top onto the riser top, aligning the washers together. The bolt from
the bottom washer should slide into the slot from the top washer.

For assistance in assembling the product,, missing or damaged parts, or to place an order, please contact
customer service at 1-800-328-1061. You may also place your order online at
Form# 179974 www.smithsystem.com 5/2014
Step 10: Using the provided Acorn Nuts, tighten the lectern top onto the riser top.
