SMITH SYSTEM Second Surface Shelf Kit User manual

Form# 179914
08/2018
7
Assembly Instructions
Planner Studio - Second Surface
If you have damaged or missing components,
Please contact customer service at 1-800-328-1061
Planner Studio Table shown with SECOND SURFACE (shelf) installed.

Form# 179914
08/2018
7
¼-20 SHOULDER BOLT
QTY. 4
¾” THICK SHELF
QTY. 1
RAILS
QTY. 2
¼-20 PAN HEAD SCREW
QTY. 4
#10 X ¾” WOOD SCREW
QTY. 8
SHELF MOUNTING BRACKET
QTY. 8
Hardware and Components
Special Notes:
TOOLS REQUIRED:
•Safety glasses (to protect from sawdust)
•Drill w/#2 Phillips Head Driver Bit.
•#2 Phillips Head Screwdriver.
•3/16”Allen Wrench.
•Ratchet with 7/16”Socket –or –7/16”wrench
You will need another person to help assemble the product.
•Team lifting required.
•Extra person helpful when fitting rails onto table legs.
Check that all components are accounted for and undamaged beforeassembling.
Please assemble the product in a clean and dry area.
Clean the product with a mild cleaner and a damp cloth.

Form# 179914
08/2018
7
Assembly Instructions
BEGIN
1. With a partner, team lift the table and lay it upside down on a surface that will not damage the
laminate table top.
2. Use 7/16” socket (or wrench), 3/16” allen wrench, and #2 screwdriver to loosen leg fasteners in
order to flex slightly during rail installation in upcoming steps. This will help prevent scratching leg
paint with the rails.
3. Using a 3/16”allen wrench, install 1/4-20 Shoulder Bolts as shown on all 4 legs.

Form# 179914
08/2018
7
4. With a partner, install rails by aligning slots on rail ends with shoulder bolts and sliding rails into
position as shown.
5. Secure rails into place by installing the 1/4-20 Pan Head Screws as shown.

Form# 179914
08/2018
7
6. Tighten all the leg fasteners, then use a partner to team lift the table back into its upright position.
7. Slide shelf into position and center on rails as shown. (Some shelves may overhang rails.)
8. Install all 8 shelf mounting brackets using a drill to drive the provided wood screws into place once
the bracket is in position.
a. HELPFUL HINT –Install the outer corners first.
DONE.
