Assembly Instructions
Silhouette Arc Desk
Models: 01620, 01621, 01622
Fixed Height Tables
If you have damaged or missing components,
Please contact customer service at 1-800-328-1061

Form# 179000
07/2018
Hardware and Components
Special Notes
Check that all components are accounted for and undamaged before assembling.
Please assemble the products in a clean and dry area.
Clean the product with a mild cleaner and a damp cloth.
3/8-16 DOG POINT SET SCREWS
(4) PRE-INSTALLED IN LEGS
T-LEG SET (1)
01620 –ADJUSTABLE HEIGHT
01621 –FIXED HEIGHT W/GLIDES
01622 –FIXED HEIGHT W/CASTERS

Form# 179000
07/2018
Assembly Instructions
1. Using supplied allen wrench, attach legs to cross brace using M8-12mm cap screws.
2. Place the table top on a smooth surface facing down and attach the legs using #10 wood
screws.

Form# 179000
07/2018
Assembly Instructions Continue
3. Identify desired height setting. Using the allen wrench, secure the adjustable legs using
3/8-16 dog-point set screws.
a. NOTE: if your desk came with fixed height leg set, you may skip this step and go
to step 4.
4. Carefully flip the desk to the upright position. The desk is now ready to use.
