Graphic Arts Table
Assembly Instructions
Model
27344
27345
27346
27347
27348
For assistance in assembling product,
or to place an order please contact customer service at 800-328-1061.
You may also place your order online at

01/2018
Form# 179773 www.smithsystem.com 2
Special Notes
1. DO NOT remove the components for the shipping box. Keeping the Top Assembly in the box will ease
assembly later.
2. Check that all components are accounted for and undamaged before assembling.
2. Plan to assemble product in a clean and dry area.
3. Due to size, we recommend that two people should be involved in assembling product.
4. If necessary, clean the product with a mild cleaner and a damp cloth.
Tools
You will need a Phillips head screw driver.
Notes:
If you have damaged or missing components or hardware please contact customer service at 1 (800)
328-1061
Hardware and Components
Pencil Retainer (1)
with (3) Screws
Connector Bolts (8)
Allen Wrench (2)
Legs (1 pair)
Top Sub Assembly
(w/ Curved Easel, Cable, Easel Clip, Front Brace,
Fasteners, and Rear Brace) (1)

01/2018
Form# 179773 www.smithsystem.com 3
Step 1: NOTE: You will assemble the legs while the contents (Top Sub Assembly) are
still in the shipping box.
Remove the filler pieces on each end. This should allow some working room to
attach the legs.
You may break down the short ends of the box to gain more access to the ends.
Attach the legs to the front brace and rear brace. Make sure the pinholes on the
legs are facing the desk.
(4) Connector Bolts, (2) per leg. (See drawing 1A).
Step 2: There are (8) connector bolts enclosed in the box with the legs. Using these
connector bolts, attach the legs as shown below. Use the two enclosed allen
wrenches to tighten the bolts from both sides
Pilot Hole
Facing Inward

01/2018
Form# 179773 www.smithsystem.com 4
Step 3: Attach the cable.
Take the loose end of the cable and set it flush against the pilot hole on the leg.
Using a Phillips head screwdriver, or an electric screwdriver, attach the eyehole
of the cable with the (1) Sheet Metal Screw enclosed with pencil retainer.
Step 4: Optional: Adjust the legs.
Legs are set to a standard height upon arrival. If you require a different height,
use the allen wrench to loosen the dog screws. Set the leg stem to the desired
height, and re-tighten the dog screws.

01/2018
Form# 179773 www.smithsystem.com 5
Step 5: Optional: Install Pencil Retainer
The pencil retainer and required hardware are included in the Top Sub-
Assembly. There are two holes predrilled into the top (in front of the hinge of the
front brace). These are the two holes needed to attach the pencil retainer to the
Graphic Arts Desk top. Using a Phillips head screwdriver and the (2) wood
screws included, attach the pencil retainer to the top.
Step 6: Remove complete assembly from packaging
Once you are finished assembling the product, two people are recommended to remove
the complete assembly from the shipping box and turn right-side-up.
