SMITH SYSTEM UXL User manual

UXL Table
Assembly Instructions
UXL Table Model Numbers:
XL________PLT__
Examples:
XL2436____PLTTL = 24x36 UXL table with tapered leg & casters.
XL2436____PLTAC= 24X36 UXL table with adjustable leg & casters.
XL2436____PLTAL= 24X36 UXL table with adjustable leg & glides.
XL2436____PLTFC= 24X36 UXL table with fixed leg & casters.
XL2436____PLTFL= 24X36 UXL table with fixed leg & glides.
For assistance in assembling product, missing or damaged parts, or to place
an order please contact customer service at 1-800-328-1061. You may also
place your order online at
www.smithsystem.com

Special Notes:
1. Check that all components are accounted for and undamaged before
assembling.
2. Please assemble product in a clean and dry area.
3. For larger units you may need another person to help assemble the product.
4. Clean the product with a mild cleaner and a damp cloth.
Components:
1. Table Top with frame attached: 2. Leg set **(& Casters)**
Tools/Hardware
2. Nyloc Bolts (2 per leg)
1. 5mm Allen Key 3. 13mm Caster Wrench
4. Vice Grip or Wrench *Not Included*
Notes:
If you have damaged or missing components or hardware or need assistance in assembling product, please
contact Customer Service at 1-800-328-1061.

Step 1: Locate all parts needed for assembly. Place the table
laminate face down on a clean, dry surface.
Step 2: At each corner, attach a leg using the supplied Bolts and 5mm Allen Key.
(B) The legs are bolted on from Inside the Table Frame; place the bolts into the Bolt Holes
as shown in Image (2B).
(A) Start by lining up the bolt holes on the leg and the frame as shown in Image (2A).
(C) Using the 5mm Allen Key; tighten the bolts by hand as tight as you can (see Image (2C)).
(2A) (2B) (2C) (2D)
(D) With the bolts Hand-Tightened; use a Vice Grip or Wrench to compltely tighten
the bolts. (See Image (2D)).
Step 3: If you have a leg set with casters; attach the casters.
(A) Start by hand-tightening the caster to the Leg (See Image 3A).
(B) Once hand-tightened, use the supplied 13mm wrench to tighten the casters.
(See Image 3B).
(3A)
(3B)
Step 4: Verify that all legs are securely fastened. *If casters were used, verify that all casters
are securely fastened to the legs.* If the leg set is adjustable, press the spring loaded
button and adjust the height as desired ( See Images 4A and 4B).
Step 5: With help, flip the desk over to the upright position and your UXL Table is now
ready for use.
(4A) (4B)
(1A)
Notes:
If you have damaged or missing components or hardware or need assistance in assembling product, please
contact Customer Service at 1-800-328-1061.
