Smithco SweepStar V62 Quick start guide

SweepStar V62
with Electric Clutch
78-200
SN: 78595
January 2012
Product Support: Hwy SS & Poplar Ave; Cameron WI 54822
1-800-891-9435 [e-mail]
Parts & Service

Introduction Service Diagrams Parts Accessories Reference
CONTENTS
Introduction..........................................1-10
Introduction...................................................................................1-3
SafePractices.............................................................................2
Specifications ..............................................................................3
OptionalEquipment .....................................................................3
Service ........................................................................................ 4-11
Maintenance.............................................................................4-6
OverloadingDebrisHopperand VacuumHousingWear ...............7
ServiceChart ............................................................................8-9
Adjustments ..............................................................................10
TailgateAdjustments ................................................................. 11
Storage ...................................................................................... 11
Diagrams ................................................................................... 12-15
WiringDiagram..................................................................... 12-13
Wiring Schematic ......................................................................13
Parts .......................................................................................... 16-37
BodyandFrame................................................................... 16-17
EngineandControls ............................................................. 18-19
Pulley and Pump .................................................................. 20-21
BlowerandVacuumHousing ................................................ 22-23
FingerReel ........................................................................... 24-25
BrushReel ........................................................................... 26-27
ReelandHydraulicPump ..................................................... 28-29
Hopper.................................................................................. 30-33
78-4152-BankHydraulicValve ............................................. 34-35
RearAxle / Electric Brake .................................................... 36-37
Accessories ............................................................................... 38-59
78-201ReplacementBrushReel .......................................... 38-39
78-202ReplacementFingerReel .......................................... 38-39
78-205RemoteVacuum Hose .............................................. 40-41
78-2045th WheelHitch ......................................................... 42-43
78-206ClevisHitch............................................................... 44-45
78-209Ball Hitch .................................................................. 46-47
78-207Hydraulic Lift Kit........................................................ 48-49
78-4163-Bank HydraulicValve ............................................. 50-51
78-208FilterSystem ............................................................ 52-53
78-210& 78-211 ReelandHydraulic Pump ........................... 54-55
78-210Nylon BrushHead ..................................................... 56-57
78-211 RubberFingerHead................................................... 58-59
Reference.................................................................................. 61-62
Decal List .................................................................................. 61
QuickReference Replacement Parts .........................................62
Warranty ...........................................................InsideBackCover

1
Introduction
INTRODUCTION
Thank you for purchasing a SmithcoSmithco
SmithcoSmithco
Smithco product.
Read this manual and all other manuals pertaining to the Sand Star Zee carefully as they contain safety, operat-
ing, assembly and maintenance instructions. Failure to do so could result in personal injury or equipment dam-
age.
Keepmanuals in a safe place after operator and maintenance personnel havereadthem.Rightand left sides are
fromthe operator’s seat, facingforward.
All SmithcoSmithco
SmithcoSmithco
Smithco machineshave a Serial Number and Model Number. Both numbers are needed when ordering
parts.Refer to engine manual forplacementofengine serial number.
For product and accessory information, help finding a dealer, or to register your procuct please contact us at
www.Smithco.com.
Informationneededwhenordering replacementparts:
1. ModelNumber ofmachine
2. SerialNumber ofmachine
3. Nameand Part Number of part
4. Quantityof parts
For easy access record your Serial and Model numbers here.
lb/kg Empty lb/kg Full
CALIFORNIA
Proposition 65 Warning
Engineexhaust and some of its constituents
are known to the State of California to
cause cancer, birth defects, and other
reproductive harm.
WARNING

2
Introduction
SAFEPRACTICES
1. It is your responsibility to read this manual and all publications associated with this machine (engine, accesso-
ries and attachments).
2. Never allow anyone to operate or service the machine or its attachments without proper training and instructions.
Never allow minors to operate any equipment.
3. Learn the proper use of the machine, the location and purpose of all the controls and gauges before you operate
the equipment. Working with unfamiliar equipment can lead to accidents.
4. Wear all the necessary protective clothing and personal safety devises to protect your head, eyes, ears, hands
and feet. Operate the machine only in daylight or in good artificial light.
5. Inspect the area where the equipment will be used. Beware of overhead obstructions and underground ob-
stacles. Stay alert for hidden hazards.
6. Never operate equipment that is not in perfect working order or without decals, guards, shields, or other protec-
tive devices in place.
7. Never disconnect or bypass any switch.
8. Carbon monoxide in the exhaust fumes can be fatal when inhaled, never operate a machine without proper
ventilation.
9. Fuel is highly flammable, handle with care.
10. Keep engine clean. Allow the engine to cool before storing and always remove the ignition key.
11. Never use your hands to search for oil leaks. Hydraulic fluid under pressure can penetrate the skin and cause
serious injury.
12. This machine demands your attention. To prevent loss of control or tipping of the vehicle:
A. Use extra caution in backing up the vehicle. Ensure area is clear.
B. Do not stop or start suddenly on any slope.
C. Reduce speed on slopes and in sharp turns. Use caution when changing directions on slopes.
D. Stay alert for holes in the terrain and other hidden hazards.
E. Run up and down slopes, never across the face.
13. Before leaving operator’s position for any reason:
A Disengage all drives.
B. Lower all attachments to the ground.
C. Shut engine off and remove the ignition key.
14. Keep hands, feet and clothing away from moving parts. Wait for all movement to stop before you clean, adjust or
service the machine.
15. The rubber fingers, sweeper and vacuum pick up and propel debris and small objects in its path during opera-
tion. Keep the area of operation clear of all bystanders.
16. Never carry passengers.
17. Stop engine before making repairs/adjustments or checking/adding oil to the crankcase.
18. Use parts and materials supplied by SMITHCO only. Do not modify any function or part.
19. Do not remove the radiator cap when the engine is hot. When cooled, loosen cap slightly to the stop to relieve
any pressure before removing the cap completely.
20. Avoid sharp turns. Watch the tires of the tractor while turning to make sure they do not contact the tongue of the
Sweep Star V62.
21. Shut down power source before attempting to unclog any part of the machine.
22. If reel deck begins to vibrate abnormally, immediately shut off power and determine the cause.
23. Do not tow on public roads.
These machines are intended for professional maintenance on golf courses, sports turf, and any other
area maintained turf and related trails, paths and lots. No guaranty as to the suitability for any task is
expressed or implied.

3
Introduction
SPECIFICATIONS FORSWEEPSTARV62
WEIGHTSANDDIMENSIONS
Length 151"(384 cm)
Width 68"(172cm)
Height 87"(221cm)
Weight 1500 lb (680 kg)
SOUNDLEVEL
Atear level 98 dBA
At 30 ft (9.14m) 92.5 dBA
ENGINE
Make Briggs&Stratton
Model# 543477
Type/Spec 0175G1
Horsepower 31 Hp (23 kW)
Fuel Unleaded87Octane
GasolineMinimum
CoolingSystem Air Cooled
LubricationSystem Full Pressure
Alternator 20Amp
TIRES&WHEELS Two 24 x 13.00 x 12 NHS (18 psi (1.3 bar))
Castor: 9 x 3.5 x 4 (20 psi (1.4 bar))
BATTERY(optional) Automotive type 45- 12volt
BCIGroup Size 45
ColdCrankingAmps 480minimum
GroundTerminalPolarity Negative(-)
MaximumLength 9" (23 cm)
Maximum Width 5.38" (14 cm)
MaximumHeight 9" (23 cm)
FLUIDCAPACITY
CrankcaseOil See Engine Manual
Fuel 6 gallon(22.7 liters)
HydraulicFluid 3.2 gallon (12.2 liters)
Cooling 2.8 quarts (2.7 liters)
Grade of Hydraulic Fluid SAE 10W-40API Service SJ or higher Motor Oil
OPTIONALEQUIPMENT
78-201 ReplacementBrush Reel 78-207 Hydraulic Lift System
78-202 ReplacementFingerReel 78-208 Filter System
78-204 5th Wheel Hitch 78-210 NylonBrush Head
78-205 RemoteVacuumHose 78-211 RubberFingerHead
78-206 ClevisHitch 22-073 Battery
78-215 Electric Brake 78-209 Ball Hitch

4
Service
MAINTENANCE
Before servicing or making adjustments to machine, stop engine and remove key from ignition.
Use all procedures and parts prescribed by the manufacturer's. Read the engine manual
before operation.
LUBRICATION
UseNo. 2 General Purpose Lithium Base Grease and lubricate every 100 hours.The Sweep Star V62hassev-
enteen grease fittings.All bearings are sealed bearings. When inserting grease, be careful not to ruin the seal, if
this happens, replace the bearing at once.
Be sure to wipe grease fitting clean before injecting grease. Give only one or two pumps of grease at each lubri-
cation.
REF# LOCATION
1 One on all four castor wheels.
2 Oneon right and left hopper door arms.
3 Oneon each mounted bearing for reelshaft.
4 One on right and left deck lift arm.
5 oneonall four castor wheel mount
brackets.
6 One on the jack stand.
7 Twoonmachine control panel
that go to the blower shaft
mountedbearing.
HYDRAULICOIL
1. Use SAE 10W-40API Service SJ or higher motor oil.
2. Forproper warranty, change oil every 500 hoursorannually, which everisfirstand change the filter after
thefirst 50 hours, then every 250 hours thereafter.
3. The oil level should be 2" to 21/2" from top of the tank when fluid is cold. Do not overfill.
4. After changing oil and/or filter, run the machine for a few minutes. Check oil level and for leaks.
5. Always use caution when filling hydraulic oil tank or checking level to keep system free of contaminants.
Checkandservicemorefrequentlywhenoperating in extremely cold, hot or dusty conditions.
6. If natural color of fluid is now black or smells burnt, it is possible that an overheating problem exists.
7. If fluid becomes milky, water contamination may be a problem.
8. Ifeither of the above conditions happen, change oil and filter immediately after fluid is cool and find cause.
Take fluid level readings when system is cold.
9. In extreme temperatures you can use straight weight oil. We recommend SAE 30WAPI Service SJ or
higherwhen hot (above 90°F(33°C))and SAE 10WAPIService SJ or higherwhencold (below 32°F (0°C))
ambient temperature. Use either motor oil or hydraulic oil, but do not mix.
10. Oil being added to the system must be the same as what is already in the tank. Mark tank fill area as to
which type you put in.

5
Service
MAINTENANCE (CONTINUED)
TIREPRESSURE
Cautionmustbe used when inflating a low tire to recommended pressure. Over inflating cancause tires to
explode. Tires on the machine should be 18 psi (1.3 bar), castor wheels should be 20 psi (1.4 bar). Improper
inflationwill reduce tire life considerably.
ENGINEOIL
Change and add oil according to charts below. Do not overfill. Use a high quality detergent oil. For Briggs engine
use oil classified “For Service SJ or higher” SAE 30 oil. Use no special additives with recommended oils. Do not
mix oil with gasoline.
WHEELMOUNTINGPROCEDURE
MACHINEWHEELS
1. Turn machine offand removekey.
2. Be sure unit is on a level surface. Unhitch from tow vehicle if possible.
3. Block the opposite wheel then the one you are working on.
4. Loosennuts slightly on wheel to be removed.
5. Jackup machine being careful not to damage underside of machine.
6. Removenuts, removewheel.
7. Place new wheel on hub lining up bolt holes.
8. Torquenutsto 64-74 ft/lb(87-100 Nm) using a cross pattern.Torque again afterfirst 8 hours and every 200
hoursthereafter.
9. Lowermachine to ground and remove blocks and jack.
FILTERSYSTEM
Filter pack may be cleaned by shaking or spraying off with low pressure water. Filter will disintegrate if high
pressure is used on it.

6
Service
MAINTENANCE (CONTINUED)
BATTERY
Batteries normally produce explosive gases which can cause personal injury. Do not allow flames, sparks or any
ignited object to come near the battery. When charging or working near battery, always shield your eyes and
alwaysprovideproper ventilation.
Batterycable should be disconnected before using “Fast Charge”.
Charge battery at 15 amps for 10 minutes or 7 amps for 30 minutes. Do not exceed the recommended charging
rate.If electrolyte startsboiling over,decrease charging.
Alwaysremovegrounded(-)batteryclampfirstand replace it last.Avoidhazards by:
1. Fillingbatteries in well-ventilated areas.
2. Weareye protection andrubbergloves.
3. Avoidbreathing fumes when electrolyteisadded.
4. Avoidspilling or dripping electrolyte.
Battery Electrolyte is an acidic solution and should be handled with care. If electrolyte is
splashed on any part of your body, flush all contact areas immediately with liberal amounts
of water. Get medical attention immediately.
JUMPSTARTING
Use of booster battery and jumper cables. Particular care should be used when connecting a
booster battery. Use proper polarity in order to prevent sparks.
Tojump start(negativegrounded battery):
1. Shield eyes.
2. Connectends of one cable to positive (+) termi-
nals of each battery, first (A) then (B).
3. Connectone end of other cabletonegative (-)
terminalof "good" battery (C).
4. Connectother end ofcable (D) to engine block on
unitbeing started (NOT to negative(-)terminal of
battery)
Toprevent damage to other electrical componentson
unit being started, make certain that engine is at idle speed before disconnecting jumper cables.

7
Service
OVERLOADINGDEBRISHOPPERANDWEARONVACUUMHOUSING
MAXIMUMLOADCAPACITY
There are decals on each side of the hopper to indicate the maximum depth of aeration cores. The maximum
depth for aeration cores in the hopper is 40" (101 cm). The maximum depth of sand and dirt in hopper is 20"
(50cm). The maximum load capacity of the Sweep Star V-62 is 860 lbs (400 kg).
Overloading will cause damage that is not covered by the warranty.
OVERLOAINGDEBRISHOPPER
SmithcoSweeper-Vacs are designed to carry the following maximum loads:
Model72-000BigVac 1500 lbs. (608 kg)
Model78-200 & 78-500 Sweep Star V62 860 lbs. (400 kg)
PLEASENOTE THEFOLLOWING:
1. Loadsheavier than that will damage the unit.
2. Suchdamage is not covered by warranty.
3. Overloadingis particularly easy when collecting aerifiercores.
4. The hoppers on the Big Vac and V62 are large in order to hold 7 and 4 cubic yards respectively, of thatch,
grassclippings, leaves and trash.
5. They will not hold 7 or 4 cubic yards of aerifier cores.
6. Themaximum depth (in the debris hopper) of aerifier cores is:
Model72-000 BigVac 12 in. (30 cm)
Model 78-200& 78-500Sweep Star V62 40 in. (101 cm)
VACUUMHOUSINGWEAR
SmithcoSweeper-Vacs are fitted with a wear resistantliner in the vacuum housing. This will provide additional
housing life. Be sure the following points are explained to the user:
1. The vacuum housing and impeller must be cleaned each time the unit is used so the housing liner is
inspecteddaily. Only SmithcoSweeper-Vacs provide a cleanout/inspection port for easy inspection and
cleaning.
2. When bare steel is visible at any point in the housing lining, the lining must be replaced. It is expected the
linerwill wear and be replaced. It is a vast improvement over competitive units with no liners.
3. Replacementof the liner or the vacuum housing due ti wear is normal and is not covered by warranty.
4. Collectionof aerifier cores causes extreme wear on the liner (and if unchecked, on the housing).
5. Caution users that, while Smithco Sweeper-Vacs do an excellent job collecting cores, the lining (and the
housing) will wear quickly in such use.
RUBBERIZEDBOOT
Therubberized boot between main unit and sweeper head is subject to wearanddamagefromdebris. Unless
defecetive,replacement of this boot is not covered by warranty.

8
Service
SERVICECHART
Before servicing or making adjustments to the machine, stop engine, set park break, block
wheels and remove key from ignition.
Follow all procedures and ONLY use parts prescribed by the manufacturer. Read the engine
manual before maintenance.
Thesuggested maintenance checklist is not offered as a replacement for the manufacturer’s engine manualbut
asa supplement.Youmust adhere to the guidelines establishedby the manufacturer for warranty coverage. In
adverseconditions such as dirt, mud or extreme temperatures, maintenance should be more frequent.
Duplicate this page for routine use
Mon Tues. Wed. Thurs. Fri. Sat. Sun.
Check the Safety Seat Switch
Check Steering Operation
Check the fuel level
Check the engine oil level.
Check the condition of the air filter
Clean the engine cooling fins.
Check for unusual engine noises
Check the hydraulic oil level
Check hydraulic hoses and fittings for damage
Check for fluid leaks.
Check the tire pressure (18-& 20 psi)
Check the Instrumentation
Inspect electrical system for frayed wires
Check neutral start
Change oil filter.
Change oil.
Lubricate Machine and Booms
Ensure all warning decals are intact.
Item
Maintence Check Item For the week of:
Areas of Concern
Inspection Performed by: Date Information

9
Service
SERVICECHART
Maintenance Service Interval Maintenance Procedure
Torque the wheel lug nuts. (64-74 ft/lb (87-100 Nm))
Change the engine oil filter.
Check the engine oil level.
Clean area around muffler and controls.
Check the hydraulic fluid level.
Check the tire pressure.
Check condition of hydraulic hoses and fittings.
Inspect and clean the machine.
After the first 50 hours Change Hydraulic Oil Filter.
Clean or change air filter.1&2
Clean pre-cleaner.1
Change engine oil and filter.
Replace spark plug .
Lubricate machine.
Clean or change remote air cleaner.
Check the battery fluid level and cable connections..
Service exhaust sytem.
Check belt tension .
Check engine valve clearance and adjust if necessary.
Check idle speed.
Clean battery terminals.
Change hydrauilic oil filter.
Torque the wheel lug nuts. (64-74 ft/lb (87-100 Nm))
Change fuel filter.
Change hydrauilic oil and filter.
Clean oil cooler fins.1
Replace air filter2
Replace fuel filter
Clean air cooling system.1
Check safety filter in remote air cleaner.
Every500 hours or yearly
1
In dusty conditions or when airborne debris is present, clean more often.
2
Every third air filter change, replace the inner safety filter.
After the first 8 operating hours
Before eachuse daily
Every100 hours
Every250 hours

10
Service
ADJUSTMENTS
ADJUSTMENTOFBELTTENSIONER
Therearetwobelttensioners on the Sweep Star V62. One
controls the tension on the belt from the engine to blower
shaft the other controls the belt on the finger or brush reel.
The proper tension of the idler should be 12 to 15 as per the
gauge(A)onthesideof the tightener.Overtighteningthebelt
will shorten the life of the belt and the machine may not per-
form to the best of its ability. To adjust belt tensioner, loosen
bolt holding tensioner. Bring idler pulley tight to belts and turn
tensioner into belts to 15°. Tighten holder bolt.
CASTORWHEELS
Install castor wheels onto the brush/finger head assembly. You may put the machine bush-
ings and spacers (A) on in any combination to get desired height.You should leave one
machine bushing on the very bottom and one on the very top next to the lockpin. Check the
tire pressure on Castor Wheels they should be 20 psi (1.4 bar).
DRAIN
The drain is used to flush out any water or debris that accu-
mulates in the bottom of the blower housing.

11
TAILGATEADJUSTMENT
V62TAILGATELEVELING
If the tailgate is not sitting level against the hopper it can be leveled by loosening the 3/8 inch bolts that hold the
pivot bracket to the upper lift arms then rotate the pivot brackets until tailgate level then tighten. Once it is level it
must be readjusted using steps 1, 2 and 3.
V62TAILGATEADJUSTMENTPROCEDURE
1. Open tailgate approximately 10 inches and shut off engine. Locate the 3/8 inch bolts that connect the
lower lift arm to the tailgate (Connected by springs). Loosen them about 1½ turns.
2. Find at top corners of the tailgate the 1/2inch bolt that connects the upper lift arms to the tailgate. Loosen
both sides then push the tailgate in towards the hopper. The bolts will slide in the slots of the brackets on
the end of the lift arms when pushed tight against the hopper. Tighten the outside nut just tight enough to
hold it from moving in the slot, repeat on other side. (Do not over tighten).
3. Start the machine move the valve handle to the lower position and close the tailgate, as the tailgate comes
in contact with the hopper it will push the top of the tailgate outward in the slots in the top lift arm as the
bolts slide outward in the slots. As the bolts slide outward in the slots the tailgate will also glide down-
ward approximately ½ inch. Check to see that the tailgate fits tight against the hopper. Then tighten the
nuts together on both of the top corners of the tailgate using two ¾ inch wrenches. Then tighten the nuts
on the 3/8inch bolts on the lower sides of the tailgate using two 9/16 inch wrenches.
STORAGE
Whenstoring, remove the key from the key switch to avoid unauthorized persons from operating machine.
1. Beforestoring clean machine thoroughly.
2. Check bolts and nuts, tighten as necessary.
3. Makeall repairs that are needed and remove any debris.
4. Remove the battery, adjust the electrolyte level and recharge it. Store the battery in a dry, dark place.
5. Store in a clean and dry area, but NOT near a stove, furnace or water heater which uses a pilot light or any
device that can create a spark.
6. Enginesstored over 30 days need to be protected or drained of fuel to preventgumfromformingin a fuel
system or on essential carburetor parts. Check the engine manual and follow the instructions for the
storageof the engine.

12
Diagrams
WIRINGDRAWING

13
Diagrams
WIRINGPARTSLIST
REF# PART# DESCRIPTION QUANTITY
1 78-368 Electric Clutch 1
2 15-314 ToggleSwitch 1
15-472 Switch Boot 1
3 12-017 HourMeter 1
4 13-488 IgnitionSwitch 1
5 50-359 Oil Light 1
8874 FemaleBullet Connector 1
8875 MaleBullet Connector 1
8963 HeatShrink 2
6 Plugon Engine 1
7 8975 30Amp Circuit Breaker 1
8977 CircuitBreaker Boot 1
8 22-054 Battery Cable Black 1
9 22-073 Battery (optional) 1
10 78-325 Red Battery Cable with Boot 1
11 17-271 Pigtail Harness for Electric Clutch 1
78-442 Wire Harness (includes all wire colors with *)

14
Diagrams
HYDRAULICDRAWING

15
Diagrams
HYDRAULICPARTSLIST
REF# PART# DESCRIPTION QUANTITY
1 78-247 Hydraulic Hose (brush motor to valve) 2
2 78-413 HydraulicPump 1
3 23-006 Oil Filter 1
23-031 Filter Element (replacement only) 1
4 78-249 Hydraulic Hose (pump to valve) 1
5 78-250 Hydraulic Hose (return to tank ) 1
6 78-415 2-BankHydraulic Valve 1
7 78-246 Hydraulic Hose (rear hyd. cyl. to front valve) 1
8 78-248 Hydraulic Hose (front hyd. cyl. to rear valve) 1
9 13-584 OilTank 1
10 8917-14 Suction Hose 5/8ID x 14 1
18-040 HoseClamp 2
11 78-414 Hydraulic Motor 1
12 15-839 HydraulicCylinder 1
HYDRAULICPRESSURES
PumpDisplacement .4in3/rev
PumpInput Speed(upto) 3600 rpm
Max.Operating Pressure 2500 psi
Max. Inlet Vacuum 10 in. Hg
Max. Case Pressure 80 psi
78-415HydraulicValve(2 bank) 2500 psi

16
Parts
BODYANDFRAMEDRAWING

17
Parts
BODYANDFRAMEPARTSLIST
REF# PART# DESCRIPTION QUANTITY
1 HSTP-14-20-075 Phillips Truss Head Machine Screw 1/4- 20 x 3/48
2 78-253 Right Guard 1
78-274 Cage Nuts 2
3 78-315 Right Guard Mount 1
78-274 Cage Nuts 2
HBFL-516-18-075 Flange Bolt 5/16 - 18 x 3/42
HNFL-516-18 Flange Whiz Lock Nut 5/16 - 18 2
4 HBFL-516-18-075 Flange Bolt 5/16 -18 x 3/48
HNFL-516-18 Flange Whiz Lock Nut 5/16 - 18 8
5 78-260 Right Hopper 1
6 15-839 Hydraulic Cylinder 1
14-531 Seal Kit 1
7 18-169 Adapter3/8 SAE 2
8 78-265 Cross Bar 1
9 78-272 Hopper Cover 1
10 HCP-58-175 Clevis Pin 5/8x 13/42
HHP-18-100 Cotter Pin 1/8x 1 2
11 78-319 Hopper Door Adjustment 2
12 HNFL-12-13 Flange Whiz Lock Nut 1/2- 13 4
HW-12 Washer 1/24
HB-12-13-250 Bolt 1/2 - 13 x 21/22
13 78-266 Hopper Door 1
14 HNFL-38-16 Flange Whiz Lock Nut 3/8- 16 4
15 78-264 Left Door Arm 1
16 19-205 Spring 2
17 HB-38-16-575 Bolt 3/8 - 16 x 53/42
18 78-387 Weatherstripping Bracket 2
8979-61 Door Weatherstripping 2
HSD-8-050 Drill Screw #8 x 1/232
19 78-448 Left Guard Mount 1
78-274 Cage Nuts 3
HBFL-516-18-075 Flange Bolt 5/16 - 18 x 3/43
HNFL-516-18 Flange Whiz Lock Nut 5/16 -18 3
20 78-339 Left Guard 1
78-274 Cage Nuts 4
21 78-447 LH Guard Exension 1
22 78-221 Tire and Wheel 2
78-221-01 Tire 24 x 13 -12 6 Ply 2
78-221-02 Wheel 2
23 HNL-12-20 Lug Nut 1/2- 20 (part of 78-216) 10
24 78-216 RearAxle 1
25 78-444 Left Brush Guard 1
26 HB-12-13-150 Bolt 1/2- 13 x 11/24
HW-12 Washer 1/24
HNTL-12-13 Lock Nut 1/2- 13 4
27 78-240 Jack 1
28 78-449 Main Frame 1
HLC-A-200 Loom Clamp 4
HSDPS-14-075 Stainless Steel Pan Head Drill Screw 1/4x 3/44
29 78-446 Operator Control Panel 1
30 78-269 Right Brush Guard 1
31 78-345 Clear Lexan Window 1
32 78-458 Tank Brace 1

18
Parts
ENGINEANDCONTROLSDRAWING
