Smithco ZTR093 Quick start guide

Sand Star Zee
Model 45-500-A Turf Application
Model 45-501-A Golf Application
SN: ZTR093
September 2015
Product Support: Hwy SS & Poplar Ave; Cameron WI 54822
1-800-891-9435 [e-mail]
Parts & Service

Introduction Service Diagrams Parts Accessories Reference
CONTENTS
Introduction ................................................................................................................ 1-6
Introduction ................................................................................................................... 1
Safe Practices ........................................................................................................... 2-4
Specifications ............................................................................................................... 5
OperatingInstructions.................................................................................................... 6
Service ...................................................................................................................... 7-14
Maintenance .............................................................................................................. 7-9
DailyChecklISt ........................................................................................................... 10
ServiceChart.............................................................................................................. 11
MaintenanceService Chart ......................................................................................... 12
Adjustments ........................................................................................................... 13-14
Diagrams ................................................................................................................ 15-19
45-500Turf ZTRWiringDiagram................................................................................. 15
45-501Golf ZTRWiring Diagram........................................................................... 16-17
HydraulicDiagram ................................................................................................. 18-19
Parts........................................................................................................................ 20-47
45-500TurfZTRMain Frame ................................................................................. 20-21
45-501Golf ZTRMainFrame................................................................................. 22-23
45-500Turf ZTRFront Fork ........................................................................................ 24
45-501Golf ZTRFront Fork ....................................................................................... 25
SeatPanel ............................................................................................................. 26-27
Brake and Control Linkage .................................................................................... 28-29
ControlPanel andGasTank ................................................................................... 30-31
RollBar andOilTank .............................................................................................. 32-33
45-501 Golf Center Lift Linkage ............................................................................. 34-35
45-500Turf CenterLiftLinkage .............................................................................. 36-37
45-500TurfZTRManual RearLift........................................................................... 38-39
45-501Golf ZTRElec/Hyd RearLiftw/ Speed Boss 40-41
45-501TurfRear Hitch ........................................................................................... 42-43
45-500Golf ZTRRear Hitchw/ SpeedBoss 44-45
EngineDrawing ..................................................................................................... 46-47
Accessories............................................................................................................ 48-63
45-503 84” Rake.................................................................................................... 48-49
45-504 Center Grader Blade.................................................................................. 50-51
45-505SpringTIne Scarifier .................................................................................. 52-53
45-506Sand Cultivator .......................................................................................... 54-55
45-507 Tine Scarifier ............................................................................................. 56-57
45-509 Digger Blade Scarifier ............................................................................... 58-59
45-510 Light Kit ..................................................................................................... 60-61
45-502 Plow .......................................................................................................... 62-63
13-731Single-Bank Valve...................................................................................... 64-65
Decals ........................................................................................................................ 66
QuickReference ......................................................................................................... 67
Warranty .........................................................................................................................

1
Introduction
PARTSMANUALSAVAILABLE ONLINEATsmithco.com
INTRODUCTION
Thank you for purchasing a SmithcoSmithco
SmithcoSmithco
Smithco product.
Read this manual and all other manuals pertaining to the Sand Star Zee carefully as they contain safety, operat-
ing, assembly and maintenance instructions. Failure to do so could result in personal injury or equipment dam-
age.
Keepmanuals in asafeplace after operatorand maintenance personnelhaveread them. Rightand left sidesare
fromtheoperator’s seat, facing forward.
All SmithcoSmithco
SmithcoSmithco
Smithco machineshave aSerial Number and Model Number.Both numbers are needed whenordering
parts. Refer toenginemanual for placement ofengineserial number.
For product and accessory information, help finding a dealer, or to register your procuct please contact us at
www.Smithco.com.
Informationneededwhenorderingreplacementparts:
1. ModelNumberofmachine
2. SerialNumberofmachine
3. NameandPart Number ofpart
4. Quantityof parts
For easy access record your Serial and Model numbers here.
CALIFORNIA
Proposition 65 Warning
Engineexhaustandsomeofitsconstituents
are known to the State of California to
cause cancer, birth defects, and other
reproductive harm.
WARNING
Failure to follow cautious operating practices
can result in serious injury to the operator or
other persons. The owner must understand
these instructions, and must allow only trained
persons who understand these instructions to
operate this vehicle.
WARNING

2
Introduction
PARTSMANUALSAVAILABLE ONLINEATsmithco.com
SAFETY
SAFETY
Read and understand this manual and all safety signs before operating and maintaining. Review
the safety instructions and precautions annually.
TAKE NOTE! THIS SAFETY ALERT SYMBOL FOUND THROUGHOUT THIS MANUAL IS
USED TO CALL YOUR ATTENTION TO INSTRUCTIONS INVOLVING YOUR PERSONAL
SAFETY AND THE SAFETY OF OTHERS. FAILURE TO FOLLOW THESE INSTRUCTIONS
CAN RESULT IN INJURY OR DEATH.
THIS SYMBOL MEANS
-ATTENTION!
-BECOME ALERT!
-YOUR SAFETY IS INVOLVED!
SAFETY SIGNAL WORDS
Note the use of the signal words DANGER, WARNING and CAUTION with the safety
messages. The appropriate signal word for each has been selected using the following
guidelines:
DANGER: Red. Indicates an imminently hazardous situation that, if not avoided, will result
in death or serious injury. This signal word is to be limited to the most extreme situations
typically for machine components which, for functional purposes, cannot be guarded.
WARNING: Orange. Indicates a potentially hazardous situation that, if not avoided, could
result in death or serious injury, and includes hazards that are exposed when guards are
removed. It may also be used to alert against unsafe practices.
CAUTION: Yellow. Indicates a potentially hazardous situation that, if not avoided, may
result in minor or moderate injury. It may also be used to alert against unsafe practices.

3
Introduction
PARTSMANUALSAVAILABLE ONLINEATsmithco.com
SAFETY WARNINGDECALS
REMEMBER: If Safety Signs have been damaged, removed, become illegible or parts
replaced without decals, new decals must be applied. New decals are available from your
authorized distributor or factory.
Warning!Readmanual,
batterypositiveand
negative
Warning!Pinch Points Warning! Hot
Noise emision to the
operatorsearin accor-
dancewithEuropean
Directives

4
Introduction
PARTSMANUALSAVAILABLE ONLINEATsmithco.com
SAFEPRACTICES
1. It is your responsibility to read this manual and all publications associated with this machine (engine,
accessoriesand attachments).
2. Neverallow anyone tooperateor service themachine or itsattachmentswithout proper trainingand
instructions.Never allow minorstooperate any equipment.
3. Learnthe proper useof the machine,the location andpurpose of allthe controls andgauges before you
operatethe equipment. Workingwith unfamiliar equipmentcan lead toaccidents.
4. Wear all Personal Protective Equipment (PPE) on your head, eyes, ears, hands and feet. Operate the
machine only in daylight or in good artificial light.
5. Inspect the area where the equipment will be used. Pick up all debris you can find before operating.
Bewareofoverhead obstructions and undergroundobstacles.Stay alert forhiddenhazards.
6. Neveroperate equipment thatis not inperfect working orderor without decals,guards, shields, orother
protectivedevicesin place.
7. Never disconnect or bypass any switch.
8. Carbonmonoxide in the exhaustfumescan be fatalwheninhaled, never operateamachine without proper
ventilation.
9. Fuel is highly flammable, handle with care.
10. Keepengine clean.Allow theengine to coolbefore storingand always removethe ignition key.
11. After engine hasstarted machinemust not move.If movement is evident, theneutral mechanism isnot
adjustedcorrectly.Shut engine off andreadjust sothe machinedoes not move when in neutral position.
13. Neveruse your hands to searchfor oilleaks. Hydraulic fluidunder pressurecan penetrate theskin and
cause serious injury.
14. Thismachine demands yourattention.To preventloss of controlor tipping ofthe vehicle:
A. Use extra caution in backing up the vehicle. Ensure area is clear.
B. Do not stop or start suddenly on any slope.
C.Do not driveon slopes greaterthan 10°.
D. Reduce speed on slopes and in sharp turns. Use caution when changing directions on slopes.
E. Stay alert for holes in the terrain and other hidden hazards.
15. Before leaving operator’s position foranyreason:
A.Disengageall drives.
B. Lower all attachments to the ground.
C. Set park brake.
D.Shut engine offandremovethe ignition key.
16. Keephands, feet andclothing away frommoving parts.Wait for allmovement to stopbefore you clean,
adjustor service themachine.
17. Keepthe area ofoperation clear ofall bystanders.
18. Nevercarry passengers.
19. Stopenginebefore making repairs/adjustmentsorchecking/addingoil to thecrankcase.
20. Use parts and materials supplied by SmithcoSmithco
SmithcoSmithco
Smithco only. Do not modify any function or part.
These machines are intended for professional maintenance on golf courses, sports turf, and any other
area maintained turf and related trails, paths and lots. No guaranty as to the suitability for any task is
expressed or implied.

5
Introduction
PARTSMANUALSAVAILABLE ONLINEATsmithco.com
SANDSTARSPECIFICATIONS
WEIGHTSANDDIMENSIONS 45-500 45-501
Length 75"(1,91 m) 75" (1,91m)
Width 59"(1,50 m) 59"(1,50 m)
Height 67"(1,71 m) 70" (1,78m)
Wheel Base 48"(1,22m) 48"(1,22m)
GroundClearance 5.5" - 7" (13 -18 cm) - under cultivator depending on attachment
Weight 880 lbs. (399 kg)
SOUNDLEVEL
AtEarLevel 82 dB
ENGINE
Make BriggsandStratton CommercialTurf
Model# 44T677
Type/Spec# 0001G1
Horsepower 22HP(16.4 kW)
Fuel Unleaded87Octane Gasoline Minimum
LubricationSystem Full Pressure
Alternator 16 amp
WHEELS&TIRE
5 psi (.34 bar) Two:22X11 - 10.0RearKnobbyTire Two:25X10 - 12RearKnobbyTire
20 psi (1,38 bar) One: 15 x 6.00 - 6 Front Castor One: 16 x 7.50 - 8 Front Castor
SPEED
ForwardSpeed 0 to 10 m.p.h. (0-16 kph)
ReverseSpeed 0 to 4 m.p.h. (0-6 kph)
BATTERY AutomotiveTypeSP35
BCIGroup Size 35
ColdCrankingAmps 300
GroundTerminal Polarity Negative(-)
MaximumLength 7.5" (19 cm)
Maximum Width 5" (12,7 cm)
MaximumHeight 7.5" (19 cm)
FLUIDCAPACITY
CrankcaseOil SeeEngineManual
Fuel 20 quarts (18,93liters)
Hydraulic Fluid 7 quarts (6,6 liters)
Gradeof Hydraulic Fluid ParkerDura Clean Hydraulic Oilor Equivalent ofAW32minimumhydraulic oil
ISO21299 ROPsCertified
OSHA1928.51 SeatRestraintCertified

6
Introduction
PARTSMANUALSAVAILABLEONLINEATsmithco.com
OPERATION
STEERINGCONTROLLEVERS
Acquaintyourself with thesteering before operating themachine. This machineis equipped withtwo steering
controllevers (A) thatmake the machinesspeed and directioncontinuously variable. Thesteering controls can
bemoved forward orbackwardabout a neutralposition. The neutralpositionis locked whenthe steering control
leversare moved outwardand the machinewillstand still.
Move in a straight line - By moving both controls an equal amount forward or backward, the machine will move
ina straight lineforwardor backward respectively.
To turn right while going forward - Move right control lever towards the neutral position. This will cause the
rotation of the right wheel to reduce which will result in the machine turning to the right.
To turn left while going forward - Move left control lever towards the neutral position. This will cause the rota-
tion of the left wheel to reduce which will result in the machine turning to the left.
Zero Turn - Zero turncanbe achieved bymovingone control leverbackward,behind neutral position,andcare-
fully moving the other control lever forward from its neutral position. The rotation direction is determined by
the control lever that is moved backward behind the neutral position. If left control lever is backward,
machinewill turn left.If right controllever is movedbackward, machine willturn right.
WARNING! The machine can move rapidly if one steering control is moved much further than the
other.
Reverse Neutral Forward RightZeroTurn
WARNING! Do not drive up and down hills with slopes greater than 10°. Do not drive across slopes.
STARTINGENGINE
Beforeoperating this machine,become familiar withall controls andfunctions of
theseunits.Also completeall maintenancerequirementsand read allsafety warn-
ings. By knowing the machine thoroughly, how it operates and by doing the pre-
scribedmaintenance steps, youcanexpect relatively trouble-freeoperationfor years
to come.
1. Set park brake. Start safety switch is on the park brake.
2. The ignition switch is a three position on gas and four position on diesel. Insert
key (A) and turn clockwise until engine starts (C). Release key and it will return
to run position (B). Use choke and hand throttle as necessary.
3. Allowengine to idle and warm up a few minutes before selectinga directionof
travel.
4. To shut off engine on all gas machines turn key to the stop position.

7
Service
PARTSMANUALSAVAILABLEONLINEATsmithco.com
MAINTENANCE
WARNING! Before servicing or making adjustments to machine, stop engine and remove key
from ignition.
Use all procedures and parts prescribed by the manufacturer's. Read the engine manual.
LUBRICATION
Machineshould be greased beforestarting.Use
generalpurpose No. 2 lithiumbase grease. Lubri-
cateevery250 hours.
A. Rear attachment lift yoke.
B. Right attachment lift mount.
C. Left attachment lift mount.
D. Center attachment lift yoke.
E. Centerliftlever.
F. Front fork.
G. BrakeRelay (both ends)
TIREPRESSURE
Cautionmust beused when inflatinga lowtire to recommendedpressure. Over inflating can causetires to
explode.Rear tires shouldbe 5 psi(0.34bar). The frontcastor wheel shouldbe 20psi (1.38bar). Improper infla-
tion will reduce tire life considerably.
ENGINE
Change and add oil according to chart below. Do not overfill. Engine oil capacity is 2 quarts. We recommend
high-quality detergent oils classified for service SF, SG, SH, SJ or higher. Do not use special additives. Outdoor
temperatures determine the proper oil viscosity for the engine. Use the chart to select the best viscosity for the
outdoortemperaturerangeexpected.
SAEVISCOSITYGRADES
Use of multi-viscosity oils (10W-30, etc.) above 80° F (27° C) will result in high oil consumption and possible
enginedamage. Checkoil levelmore frequentlyif using these types of oils.
SAE 30 oil, if used below 40° F (4° C), will result in hard starting and possible engine bore damage due to inad-
equatelubrication.

8
Service
PARTSMANUALSAVAILABLEONLINEATsmithco.com
MAINTENANCE
HYDRAULICOIL
1. Use Parker DuraClean HydraulicOil or equivalentof AW32 minimumhydraulic oil.
2. Forproperwarranty,changeoilevery 250 hoursofuse.
3. The oil level in reservoir should be 1-3"from thebottom ofthe dipstick when fluid is cold. Donot overfill.
4. After changing oil and/or filter, run the machine for a few minutes. Check oil level and check for leaks.
5. Always use caution when filling hydraulic oil tank or checking level to keep system free of contaminants.
Checkand service morefrequently whenoperating in extremelycold, hot ordusty conditions.
6. If natural color of fluid is black or smells burnt, it is possible that an overheating problem exists.
7. If fluid becomes milky, water contamination may be a problem.
8. Ifeither of theabove conditions happen,change oil andfilter immediately afterfluid is cooland find cause.
Take fluid level readings when system is cold.
9. Oil being added to the system must be the same as what is already in the tank. Mark tank fill area as to
which type you put in.
WHEELMOUNTINGPROCEDURE
1. Turn machine offand remove key.
2. Block one of the other wheels.
3. Loosennuts slightly onwheel to beremoved.
4. Jackup machine beingcareful not todamageunderside of machine.
5. Removenuts.Removewheel.
5. Place new wheel on hub lining up bolt holes.
6. Torquenutsto64-74ft/lb(87-100Nm) using across pattern. Re-torque after first8hours and every250
hoursthereafter.
7. Lowermachine to groundandremove blocks andjack.

9
Service
PARTSMANUALSAVAILABLEONLINEATsmithco.com
MAINTENANCE
BATTERY
Batteries normally produce explosive gases which can cause personal injury. Do not allow flames, sparks or any
ignited object to come near the battery. When charging or working near battery, always shield your eyes and
alwaysprovideproperventilation.
Batterycable should bedisconnected before using"Fast Charge".
Charge battery at 15 amps for 10 minutes or 7 amps for 30 minutes. Do not exceed the recommended charging
rate.If electrolyte starts boiling over, decreasecharging.
Alwaysremove grounded (-)battery clampfirst and replaceit last.Avoidhazards by:
1. Fillingbatteriesin well-ventilated areas.
2. Weareyeprotection and rubber gloves.
3. Avoidbreathingfumes when electrolyteisadded.
4. Avoidspilling or dripping electrolyte.
WARNING! Battery Electrolyte is an acidic solution and
should be handled with care. If electrolyte is splashed on
any part of your body, flush all contact areas immediately
with liberal amounts of water. Get medical attention
immediately.
WARNING! Connecting battery cables to the wrong post
could result in personal injury and/or damage to the
electrical system. Make sure battery and cables do not
interfere or rub on any moving part. Connect the red
positive (+) cable (A) to the battery first. When disconnect-
ing remove the black negative (-) cable (B) first.
JUMP STARTING
WARNING! Use of booster battery and jumper cables. Particular care should be used when connecting a
booster battery. Use proper polarity in order to prevent sparks.
To jump start (negative grounded battery):
1. Shield eyes.
2. Connect ends of one cable to positive (+) terminals of bottom
post on solenoid first (A), then positive post of booster battery.
(B).
3. Connect one end of other cable to negative (-) terminal of
booster battery (C).
4. Connect other end of cable (D) to engine block on unit being
started.
To prevent damage to other electrical components on unit being
started, make certain that engine is at idle speed before disconnect-
ing jumper cables.
Solenoid

10
Introduction
PARTSMANUALSAVAILABLEONLINEATsmithco.com
DAILYCHECKLIST
Follow all procedures and ONLY use parts prescribed by the manufacturer. Read the engine
manual before maintenance..
Before servicing or making adjustments to the machine, stop engine, set park break, block
wheels and remove key from ignition.
DAILYCHECKLIST
1. Check park brake adjustment.Adjust as required.
2. Checkengine oil level.Add asneeded.DO NOT OVERFILL.
3. Tire pressure should be 5 psi (0.34 bar) maximum on rear tires and 20 psi (1.38 bar) on the front tire.
4. Inspect electrical system for loose connections or frayed wiring, including battery cables. Replace any
faultyequipment or tightenif loose.
5. Check hardware for loose or missing nuts, bolts, screws, etc., and tighten or replace as needed.
6. Inspect hydraulic lines for damage or leaks. Never use hands to inspect leaks.
7. Check hydraulic oil level on the tank. The level should be 1-3" from the bottom of the dipstick. If level is
low, Parker Dura Clean Hydraulic Oil orEquivalent ofAW32 minimum hydraulic oil.
8. Inspectsteering control levers,throttle and shiftlinkagesfor good hookupsand clear travel.
9. Checkcontrolsfor smooth, properworkingoperation.

11
Service
PARTSMANUALSAVAILABLEONLINEATsmithco.com
SERVICECHART
Thesuggested maintenance checklistis not offeredasa replacement forthe manufacturer’s enginemanualbut
asa supplement.Youmust adhere tothe guidelines establishedbythemanufacturer for warrantycoverage. In
adverseconditions such asdirt,mud or extremetemperatures, maintenance shouldbe more frequent.
Maintenance Service Interval Maintenance Procedure
Torque the wheel lug nuts. (64-74 ft/lb (87-100 Nm))
Change the engine oil filter.
Check the engine oil level.
Clean area around muffler and controls
Check the hydraulic fluid level.
Check tire pressure (5 psi)-Rear. 20 psi - Front.
Check condition of hydraulic hoses and fittings.
Inspect and clean the machine.
Clean air filter1
Check battery terminals and electrolyte level
Change oil when operating under heavy load or high
ambient temperatures.
Change engine oil and filter
Check muffler and spark arrestor
Every100 hours Lubricate machine
Change air filter
Check tire wear
Torque the wheel lug nuts. (64-74 ft/lb (87-100 Nm))
Change hydrauilic oil and filter
Replace Pre Cleaner
Replace spark plugs
Clean air cooling system1
Replace fuel filter
Check engine valve clearance2
1In dusty conditions or when airborne debris is present, clean more often
2Not required unless engine performance problems are noted.
Every500 hours or yearly
Before eachuse daily
Every25 hours
Every50 hours
Every250 hours
After the first 8 operating hours

12
Service
PARTSMANUALSAVAILABLEONLINEATsmithco.com
Mon Tues. Wed. Thurs. Fri. Sat. Sun.
Check the Safety Seat Switch
Check Steering Operation
Check the fuel level
Check the engine oil level.
Clean the air filter
Clean the engine cooling fins.
Check for unusual engine noises
Check the hydraulic oil level
Check hydraulic hoses and fittings for damage
Check for fluid leaks.
Check the tire pressure
Check the Instrumentation
Inspect electrical system for frayed wires
Check park brake adjustment
Change oil filter.
Change oil.
Lubricate Machine
Ensure all warning decals are intact.
Item Date Information
For the week of:
Maintence Check Item
Areas of Concern
Inspection Performed by:
MAINTENANCESERVICECHART
Duplicate this page for routine use. Service
Clean more often under dusty conditions or when airborne debris is present , replace air cleaner parts, if very
dirty.

13
Service
PARTSMANUALSAVAILABLEONLINEATsmithco.com
ADJUSTMENTS
CENTERLIFT
Usingthe foot pedalon the leftfloorboard and thecenterlift lever you
can raise and lower the center lift.To lift, push right foot pedal all the
way down and the center lift lever will lock into place.To lower, place
pressure on the foot pedal, place detent pin in hole for correct depth
youare trying toobtain, push centerlift lever inwardand release pedal.
Detent pin will stop center lift at selected depth.
MANUALREARLIFT(45-500)
Using the foot pedal on the right floorboard. Push all the way down to
lift. The arm will lock on the lever on the right floorboard.To lower, put
somepressure on theright foot pedaland with yourhand pushlift lever
outwardandrelease foot pedalslowly.
MANUALREARLIFTSTOPADJUSTMENT(45-500)
Thethreaded adjustmentknob, located onleft side ofrear liftbar can
be used to limit the downward travel of rear attachment during wet
conditions.
Wet Conditions - When the knob is threaded inward, the lift bar will
holdthe front of theattachmentabove the groundsurface.
Dry Conditions - When working in dry conditions, turn the knob coun-
terclockwise, all the way out.
ELECTRIC/HYDRAULIC REARLIFT(45-501)
To lift and lower the rear attachments on the 45-501, use the rocker switch on the right control lever. Pushing
the switch up will raise the rear attachment. Pushing the rocker switch down will lower the rear attachment.
RearElectric Lift
RockerSwitch

14
Diagrams
PARTSMANUALSAVAILABLEONLINEATsmithco.com
ADJUSTMENTS
PARKBRAKE
The park brake is located on the left side of the machine and operates the brakes on the rear wheels. Push
leverforwardto dis-engage andpullback to engage.
To adjust turn the knob on the end of the handle. For further adjustment you may turn the yokes clockwise to
tighten and counter clockwise to loosen.
ADJUSTMENTOFBELTTENSIONER
The belt tensioner controls the tension on the belt from
theengine tothe left and right hydrounits. The proper
tension of the idler should be in the third notch on the
sideof the tensioner. Overtightening the beltwill shorten
the life of the belt and the machine may not perform to the
best of its ability. To adjust belt tensioner, loosen the bolt
holding the tensioner. Bring idler pulley tight to the belt
and turn tensioner into belt to the third notch. Using a pair
of channel lock pliers, rotate the upper half of the ten-
sioner clockwise until the indicator is at the theird notch.
Tighten bolt ontensioner.

15
Diagrams
PARTSMANUALSAVAILABLEONLINEATsmithco.com
45-500WIRINGDIAGRAM
REF# PART# DESCRIPTION QUANTITY
1 13-488 IgnitionSwitch 1
2 45-529-01 ReplacementSeat Switch 1
3 45-523 RelaySwitch 2
4 8975 30AMPCircuit Breaker 1
8977 CircuitBreaker Boot 1
5 13-750 SolenoidwithConnector 1
6 45-563 Red Battery Boot 1
13-215 StarterCable 1
7 45-520 22HP Briggs & Stratton Engine 1
8 12-031 Black Battery Boot 1
22-065 StarterCable 1
9 50-359 WaringLight 1
10 12-017 HourMeter 1
11 45-521 Main Wire Harness 1
12 45-628 4-Contat Body Connector (engineside) 2
OPTIONAL
13 45-627 Light 1
14 45-614 Light Wire Harness 1
15 15-727 Rocker Switch, no light 1
15-782 SwitchBody, Unlit,On-None-Off 1
Color Code Chart
Bl Blue
Br Brown
Y Yellow
Grn Green
O Orange
R Red
B Black
P Purple
W White

16
Diagrams
PARTSMANUALSAVAILABLEONLINEATsmithco.com
45-501WIRINGDIAGRAM
Color Code Chart
Bl Blue
Br Brown
Y Yellow
Grn Green
O Orange
R Red
B Black
P Purple
W White

17
Diagrams
PARTSMANUALSAVAILABLEONLINEATsmithco.com
45-501WIRINGDIAGRAM
REF# PART# DESCRIPTION QUANTITY
1 13-488 IgnitionSwitch 1
2 14-272 ReplacementSeat Switch 1
3 45-523 RelaySwitch 2
4 8975 30AMPCircuit Breaker 1
8977 CircuitBreaker Boot 1
5 13-750 SolenoidwithConnector 1
6 45-563 Red Battery Boot 1
13-215 StarterCable 1
7 45-520 22HP Briggs & Stratton Engine 1
8 12-031 Black Battery Boot 1
22-065 StarterCable 1
9 50-359 WaringLight 1
10 12-017 HourMeter 1
11 45-631 Electric/HydraulicActuator w/Connector 1
12 45-592 Wire Harness 1
13 30-042-06 Relay 2
14 45-625 Rocker Switch Momentary On-Off-On 1
15* 45-627 Light 1
16* 45-614 LightWire Harness 1
17* 15-727 Rocker Switch, no light 1
15-782 Non-LightedSwitch,On-None-Off 1
18 45-521 Main Wire Harness 1
19 45-628 4-Contact Body Connector (engineside) 2
* OPTIONAL

18
Diagrams
PARTSMANUALSAVAILABLEONLINEATsmithco.com
HYDRAULICDIAGRAM
45-527-01
Filter
